Ricoh WG-60 vs YI M1

The Ricoh WG-60 and the YI M1 are two digital cameras that were revealed to the public, respectively, in October 2018 and September 2016. The WG-60 is a fixed lens compact, while the M1 is a mirrorless interchangeable lens camera. The cameras are based on a 1/2.3-inch (WG-60) and a Four Thirds (M1) sensor. The Ricoh has a resolution of 15.9 megapixels, whereas the YI provides 20.2 MP.

Below is an overview of the main specs of the two cameras as a starting point for the comparison.

Headline Specifications

Ricoh WG-60		YI M1
Fixed lens compact camera		Mirrorless system camera
28-140mm f/3.5-5.5		Micro Four Thirds lenses
15.9 MP – 1/2.3" sensor		20.2 MP – Four Thirds sensor
1080/60p Video		4K/30p Video
ISO 125-6,400		ISO 100-25,600
No viewfinder, LCD framing		No viewfinder, LCD framing
2.7" LCD – 230k dots		3.0" LCD – 1040k dots
Fixed screen (not touch-sensitive)		Fixed touchscreen
8 shutter flaps per second		5 shutter flaps per second
Waterproof body (14m)		not weather sealed
300 shots per battery charge		450 shots per battery charge
123 x 62 x 30 mm, 193 g		114 x 64 x 34 mm, 281 g

Check WG-60 offers at
ebay.com
Check M1 offers at
ebay.com

Going beyond this snapshot of core features and characteristics, what are the differences between the Ricoh WG-60 and the YI M1? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.

Body comparison

The physical size and weight of the Ricoh WG-60 and the YI M1 are illustrated in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive perspectives from the front, the top, and the back are available. All size dimensions are rounded to the nearest millimeter.

The WG-60 can be obtained in two different colors (black, red), while the M1 is also available in two color-versions, but different ones (black, silver).

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the YI M1 is somewhat smaller (4 percent) than the Ricoh WG-60. It is worth mentioning in this context that the WG-60 is splash and dust resistant, while the M1 does not feature any corresponding weather-sealing. More than that, the WG-60 is water-proof up to 14m and can, thus, be used for underwater photography.

The above size and weight comparisons are to some extent incomplete and possibly misleading, as the WG-60 has a lens built in, whereas the M1 is an interchangeable lens camera that requires a separate lens. Attaching the latter will add extra weight and bulk to the setup. You can compare the optics available for the M1 and their specifications in the Micro Four Thirds Lens Catalog.

The power pack in the M1 can be charged via the USB port, which can be very convenient when travelling.

The following table provides a synthesis of the main physical specifications of the two cameras and other similar ones. In case you want to display and compare another camera duo, you can use the CAM-parator app to select your camera combination among a large number of options.

Body Specifications

		Camera Model	Camera Width	Camera Height	Camera Depth	Camera Weight	Battery Life	Weather Sealing	Camera Launch	Launch Price	Street Price
1.		Ricoh WG-60	123 mm	62 mm	30 mm	193 g	300	Y	Oct 2018	US$ 279	ebay.com
2.		YI M1	114 mm	64 mm	34 mm	281 g	450	n	Sep 2016	US$ 349	ebay.com
3.		Canon SX600	104 mm	61 mm	26 mm	188 g	290	n	Jan 2014	US$ 249	ebay.com
4.		Canon SX730	110 mm	64 mm	40 mm	300 g	250	n	Apr 2017	US$ 399	ebay.com
5.		Fujifilm X-A3	117 mm	67 mm	40 mm	339 g	410	n	Aug 2016	US$ 399	ebay.com
6.		Fujifilm XP120	110 mm	71 mm	28 mm	203 g	210	Y	Jan 2017	US$ 229	ebay.com
7.		Fujifilm XP130	110 mm	71 mm	28 mm	207 g	240	Y	Jan 2018	US$ 229	ebay.com
8.		Fujifilm XP140	110 mm	71 mm	28 mm	207 g	240	Y	Feb 2019	US$ 229	ebay.com
9.		Nikon 1 J5	98 mm	60 mm	32 mm	231 g	250	n	Apr 2015	US$ 399	ebay.com
10.		Nikon P1000	146 mm	119 mm	181 mm	1415 g	250	n	Jul 2018	US$ 999	amazon.com
11.		Nikon W300	112 mm	66 mm	29 mm	231 g	280	Y	May 2017	US$ 389	ebay.com
12.		Panasonic GF7	107 mm	65 mm	33 mm	266 g	230	n	Jan 2015	US$ 499	ebay.com
13.		Panasonic GX850	107 mm	65 mm	33 mm	269 g	210	n	Jan 2017	US$ 549	ebay.com
14.		Panasonic TS7	117 mm	76 mm	37 mm	319 g	300	Y	May 2018	US$ 449	ebay.com
15.		Pentax WG-90	123 mm	62 mm	30 mm	194 g	300	Y	Nov 2023	US$ 279	amazon.com
16.		Ricoh WG-6	118 mm	66 mm	33 mm	246 g	340	Y	Feb 2019	US$ 399	amazon.com
17.		Sony WX800	102 mm	58 mm	36 mm	233 g	370	n	Oct 2018	US$ 399	ebay.com
Note: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
Convert to Imperial

Any camera decision will obviously take relative prices into account. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The WG-60 was launched at a lower price than the M1, despite having a lens built in. Normally, street prices remain initially close to the MSRP, but after a couple of months, the first discounts appear. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.

Sensor comparison

The imaging sensor is at the core of digital cameras and its size is one of the main determining factors of image quality. All other things equal, a large sensor will have larger individual pixel-units that offer better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixels in a sensor of the same technological generation. Moreover, a large sensor camera will give the photographer more control over depth-of-field in the image and, thus, the ability to better isolate a subject from the background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.

Of the two cameras under consideration, the Ricoh WG-60 features a 1/2.3-inch sensor and the YI M1 a Four Thirds sensor. The sensor area in the M1 is 704 percent bigger. As a result of these sensor size differences, the cameras have a format factor of, respectively, 5.6 and 2.0. Both cameras feature a native aspect ratio (sensor width to sensor height) of 4:3.

With 20.2MP, the M1 offers a higher resolution than the WG-60 (15.9MP), but the M1 nevertheless has larger individual pixels (pixel pitch of 3.34μm versus 1.33μm for the WG-60) due to its larger sensor. However, the WG-60 is a much more recent model (by 2 years and 1 month) than the M1, and its sensor will have benefitted from technological advances during this time that enhance the light gathering capacity of its pixel-units. Coming back to sensor resolution, it should be mentioned that the WG-60 has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.

The resolution advantage of the YI M1 implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the M1 for good quality output (200 dots per inch) amounts to 25.9 x 19.4 inches or 65.8 x 49.4 cm, for very good quality (250 dpi) 20.7 x 15.6 inches or 52.7 x 39.5 cm, and for excellent quality (300 dpi) 17.3 x 13 inches or 43.9 x 32.9 cm. The corresponding values for the Ricoh WG-60 are 23 x 17.3 inches or 58.5 x 43.9 cm for good quality, 18.4 x 13.8 inches or 46.8 x 35.1 cm for very good quality, and 15.4 x 11.5 inches or 39 x 29.3 cm for excellent quality prints.

The Ricoh WG-60 has a native sensitivity range from ISO 125 to ISO 6400. The corresponding ISO settings for the YI M1 are ISO 100 to ISO 25600 (no boost).

Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors. Both cameras use a Bayer filter for capturing RGB colors on a square grid of photosensors. This arrangement is found in most digital cameras.

Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service determines an overall sensor rating, as well as sub-scores for low-light sensitivity ("DXO Sports"), dynamic range ("DXO Landscape"), and color depth ("DXO Portrait"). The table below summarizes the physical sensor characteristics and sensor quality findings and compares them across a set of similar cameras.

Sensor Characteristics

		Camera Model	Sensor Class	Resolution (MP)	Horiz. Pixels	Vert. Pixels	Video Format	DXO Portrait	DXO Landscape	DXO Sports	DXO Overall
1.		Ricoh WG-60	1/2.3	15.9	4608	3456	1080/60p	20.6	12.2	1072	51
2.		YI M1	Four Thirds	20.2	5184	3888	4K/30p	23.0	12.6	1030	73
3.		Canon SX600	1/2.3	15.9	4608	3456	1080/30p	20.0	11.4	620	45
4.		Canon SX730	1/2.3	20.2	5184	3888	1080/60p	20.5	11.9	924	50
5.		Fujifilm X-A3	APS-C	24.0	6000	4000	1080/60p	23.8	13.1	1664	81
6.		Fujifilm XP120	1/2.3	15.9	4608	3456	1080/60p	20.5	11.9	900	49
7.		Fujifilm XP130	1/2.3	15.9	4608	3456	1080/60p	20.6	12.1	1000	51
8.		Fujifilm XP140	1/2.3	15.9	4608	3456	4K/15p	20.7	12.2	1102	52
9.		Nikon 1 J5	1-inch	20.7	5568	3712	4K/15p	21.1	12.0	479	65
10.		Nikon P1000	1/2.3	15.9	4608	3456	4K/30p	20.6	12.1	1044	51
11.		Nikon W300	1/2.3	15.9	4608	3456	4K/30p	20.5	12.0	938	50
12.		Panasonic GF7	Four Thirds	15.8	4592	3448	1080/60p	22.7	12.3	874	70
13.		Panasonic GX850	Four Thirds	15.8	4592	3448	4K/30p	23.2	13.3	586	73
14.		Panasonic TS7	1/2.3	20.2	5184	3888	4K/30p	20.6	12.1	1028	51
15.		Pentax WG-90	1/2.3	15.9	4608	3456	1080/60p	20.9	12.8	1570	54
16.		Ricoh WG-6	1/2.3	20.2	5184	3888	4K/30p	20.7	12.2	1104	52
17.		Sony WX800	1/2.3	18.0	4896	3672	4K/30p	20.6	12.2	1070	51
Note: DXO values in italics represent estimates based on sensor size and age.

Many modern cameras cannot only take still pictures, but also record videos. Both cameras under consideration have a sensor with sufficiently fast read-out times for moving pictures, but the M1 provides a better video resolution than the WG-60. It can shoot movie footage at 4K/30p, while the Ricoh is limited to 1080/60p.

Feature comparison

Beyond body and sensor, cameras can and do differ across a range of features. The WG-60 and the M1 are similar in the sense that neither of the two has a viewfinder. The images are, thus, framed using live view on the rear LCD. The table below summarizes some of the other core capabilities of the Ricoh WG-60 and YI M1 in connection with corresponding information for a sample of similar cameras.

Core Features

		Camera Model	Viewfinder (Type or 000 dots)	Control Panel (yes/no)	LCD Specifications (inch/000 dots)	LCD Attach- ment	Touch Screen (yes/no)	Max Shutter Speed *	Max Shutter Flaps *	Built-in Flash (yes/no)	Built-in Image Stab
1.		Ricoh WG-60	none	n	2.7 / 230	fixed	n	1/4000s	8.0/s	Y	n
2.		YI M1	none	n	3.0 / 1040	fixed	Y	1/4000s	5.0/s	n	n
3.		Canon SX600	none	n	3.0 / 461	fixed	n	1/2000s	3.9/s	Y	Y
4.		Canon SX730	none	n	3.0 / 922	tilting	n	1/3200s	5.9/s	Y	Y
5.		Fujifilm X-A3	none	n	3.0 / 1040	tilting	Y	1/4000s	6.0/s	Y	n
6.		Fujifilm XP120	none	n	3.0 / 920	fixed	n	1/2000s	10.0/s	Y	Y
7.		Fujifilm XP130	none	n	3.0 / 920	fixed	n	1/2000s	10.0/s	Y	Y
8.		Fujifilm XP140	none	n	3.0 / 920	fixed	n	1/2000s	10.0/s	Y	Y
9.		Nikon 1 J5	none	n	3.0 / 1037	tilting	Y	1/4000s	60.0/s	Y	n
10.		Nikon P1000	2359	n	3.2 / 921	swivel	n	1/4000s	7.0/s	Y	Y
11.		Nikon W300	none	n	3.0 / 921	fixed	n	1/4000s	7.0/s	Y	Y
12.		Panasonic GF7	none	n	3.0 / 1040	tilting	Y	1/500s	5.8/s	Y	n
13.		Panasonic GX850	none	n	3.0 / 1040	tilting	Y	1/500s	10.0/s	Y	n
14.		Panasonic TS7	1170	n	3.0 / 1040	fixed	n	1/1300s	10.0/s	Y	Y
15.		Pentax WG-90	none	n	2.7 / 230	fixed	n	1/4000s	8.0/s	Y	n
16.		Ricoh WG-6	none	n	3.0 / 1040	fixed	n	1/4000s	1.0/s	Y	n
17.		Sony WX800	none	n	3.0 / 922	tilting	Y	1/2000s	10.0/s	Y	Y
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one.

One difference between the cameras concerns the presence of an on-board flash. The WG-60 has one, while the M1 does not. While the built-in flash of the WG-60 is not very powerful, it can at times be useful as a fill-in light.

The Ricoh WG-60 and the YI M1 both have an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.

Concerning the storage of imaging data, both the WG-60 and the M1 write their files to SDXC cards.

Connectivity comparison

For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Ricoh WG-60 and YI M1 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.

Input-Output Connections

		Camera Model	Hotshoe Port	Internal Mic / Speaker	Microphone Port	Headphone Port	HDMI Port	USB Port	WiFi Support	NFC Support	Bluetooth Support
1.		Ricoh WG-60	-	mono / mono	-	-	micro	2.0	-	-	-
2.		YI M1	Y	stereo / mono	-	-	micro	2.0	Y	-	Y
3.		Canon SX600	-	mono / mono	-	-	micro	2.0	Y	Y	-
4.		Canon SX730	-	stereo / mono	-	-	micro	2.0	Y	Y	Y
5.		Fujifilm X-A3	Y	stereo / mono	-	-	micro	2.0	Y	-	-
6.		Fujifilm XP120	-	mono / mono	-	-	micro	2.0	Y	-	-
7.		Fujifilm XP130	-	mono / mono	-	-	micro	2.0	Y	-	Y
8.		Fujifilm XP140	-	mono / mono	-	-	micro	2.0	Y	-	Y
9.		Nikon 1 J5	-	stereo / mono	-	-	micro	2.0	Y	Y	-
10.		Nikon P1000	Y	stereo / mono	Y	-	micro	2.0	Y	-	Y
11.		Nikon W300	-	stereo / mono	-	-	micro	2.0	Y	-	Y
12.		Panasonic GF7	-	stereo / mono	-	-	micro	2.0	Y	Y	-
13.		Panasonic GX850	-	stereo / mono	-	-	micro	2.0	Y	-	-
14.		Panasonic TS7	-	stereo / mono	-	-	micro	2.0	Y	-	-
15.		Pentax WG-90	-	mono / mono	-	-	micro	2.0	-	-	-
16.		Ricoh WG-6	-	mono / mono	-	-	micro	3.0	-	-	-
17.		Sony WX800	-	stereo / mono	-	-	micro	2.0	Y	Y	-

It is notable that the M1 offers wifi support, which can be a very convenient means to transfer image data to an off-camera location. In contrast, the WG-60 does not provide wifi capability.

Both the WG-60 and the M1 have been discontinued, but can regularly be found used on ebay. Neither of the two has a direct successor, so they represent the end of the respective camera lines from Ricoh and YI. Further information on the features and operation of the WG-60 and M1 can be found, respectively, in the Ricoh WG-60 Manual (free pdf) or the online YI M1 Manual.

Review summary

So how do things add up? Is the Ricoh WG-60 better than the YI M1 or vice versa? Below is a summary of the relative strengths of each of the two contestants.

Reasons to prefer the Ricoh WG-60:

• Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
• Faster burst: Shoots at higher frequency (8 vs 5 flaps/sec) to capture the decisive moment.
• Ready to shoot: Has a lens built-in, whereas the M1 requires a separate lens.
• Less heavy: Is lighter even though it comes with a built-in lens (unlike the M1).
• Better sealing: Is weather sealed to enable shooting in dusty or wet environments.
• Water-proof: Is rugged and sealed and can thus be used for underwater photography (up to 14m).
• Easier fill-in: Is equipped with a small onboard flash to brighten deep shadow areas.
• More affordable: Was introduced at a lower price, despite coming with a built-in lens.
• More modern: Reflects 2 years and 1 month of technical progress since the M1 launch.

Advantages of the YI M1:

• More detail: Has more megapixels (20.2 vs 15.9MP), which boosts linear resolution by 13%.
• Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
• Better image quality: Features bigger pixels on a larger sensor for higher quality imaging.
• Richer colors: The pixel size advantage translates into images with better, more accurate colors.
• More dynamic range: Larger pixels capture a wider spectrum of light and dark details.
• Better low-light sensitivity: Larger pixels means good image quality even under poor lighting.
• Better video: Provides higher definition movie capture (4K/30p vs 1080/60p).
• Larger screen: Has a bigger rear LCD (3.0" vs 2.7") for image review and settings control.
• More detailed LCD: Has a higher resolution rear screen (1040k vs 230k dots).
• Fewer buttons to press: Has a touchscreen to facilitate handling and shooting adjustments.
• More flexible: Takes interchangeable lenses and can thus be used with specialty optics.
• Longer lasting: Gets more shots (450 versus 300) out of a single battery charge.
• Easier travel charging: Can be conveniently charged via its USB port.
• Better lighting: Features a hotshoe and can thus hold and trigger an external flash gun.
• Easier file upload: Has wifi built in for automatic backup or image transfer to the web.
• Easier wireless transfer: Supports Bluetooth for image sharing without cables.
• More heavily discounted: Has been around for much longer (launched in September 2016).

If the count of individual advantages (bullet points above) is taken as a guide, the M1 is the clear winner of the contest (17 : 9 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional sports photographer will view the differences between cameras in a way that diverges from the perspective of a street photog, and a person interested in family portraits has distinct needs from a landscape shooter. Hence, the decision which camera is best and worth buying is often a very personal one.

How about other alternatives? Do the specifications of the Ricoh WG-60 and the YI M1 place the cameras among the top in their class? Find out in the latest Best Travel-Zoom Camera and Best Mirrorless Interchangeable Lens Camera listings whether the two cameras rank among the cream of the crop.

In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it remains incomplete and does no justice, for example, to the way the WG-60 or the M1 perform in practice. User reviews, such as those found at amazon, can sometimes inform about these issues, but such feedback is often incomplete, inconsistent, and biased.

Expert reviews

This is why expert reviews are important. The table below provides a synthesis of the camera assessments of some of the best known photo-gear review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.

Expert Camera Reviews

		Camera   Model	AP   score	CL   score	DCW   score	DPR   score	EPZ   score	PB   score	Camera Launch	Launch Price	Street Price
1.		Ricoh WG-60	..	..	..	..	..	..	Oct 2018	US$ 279	ebay.com
2.		YI M1	..	..	..	69/100	..	..	Sep 2016	US$ 349	ebay.com
3.		Canon SX600	..	+	..	..	4/5	4/5	Jan 2014	US$ 249	ebay.com
4.		Canon SX730	..	+	..	..	4/5	4/5	Apr 2017	US$ 399	ebay.com
5.		Fujifilm X-A3	..	..	..	74/100	4.5/5	4/5	Aug 2016	US$ 399	ebay.com
6.		Fujifilm XP120	..	o	..	..	3.5/5	4/5	Jan 2017	US$ 229	ebay.com
7.		Fujifilm XP130	..	o	..	..	3.5/5	4/5	Jan 2018	US$ 229	ebay.com
8.		Fujifilm XP140	..	+	..	..	3.5/5	4/5	Feb 2019	US$ 229	ebay.com
9.		Nikon 1 J5	..	..	..	..	4.5/5	4.5/5	Apr 2015	US$ 399	ebay.com
10.		Nikon P1000	..	+	3.5/5	73/100	3.5/5	3.5/5	Jul 2018	US$ 999	amazon.com
11.		Nikon W300	..	+	..	..	4/5	4/5	May 2017	US$ 389	ebay.com
12.		Panasonic GF7	4/5	+	..	..	4.5/5	4.5/5	Jan 2015	US$ 499	ebay.com
13.		Panasonic GX850	..	+	..	76/100	4.5/5	4.5/5	Jan 2017	US$ 549	ebay.com
14.		Panasonic TS7	..	+	..	..	..	3.5/5	May 2018	US$ 449	ebay.com
15.		Pentax WG-90	..	..	..	..	..	..	Nov 2023	US$ 279	amazon.com
16.		Ricoh WG-6	..	..	..	..	3.5/5	3.5/5	Feb 2019	US$ 399	amazon.com
17.		Sony WX800	..	..	..	..	..	..	Oct 2018	US$ 399	ebay.com
Note: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.

The above review scores should be interpreted with care, though. The ratings are only valid when referring to cameras in the same category and of the same age. Hence, a score should always be seen in the context of the camera's market launch date and its price, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, please note that some of the review sites have changed their methodology and reporting over time.
