Olympus E-M1X vs E-M5 II

The Olympus OM-D E-M1X and the Olympus OM-D E-M5 Mark II are two enthusiast cameras that were officially introduced, respectively, in January 2019 and February 2015. Both the E-M1X and the E-M5 II are mirrorless interchangeable lens cameras that are equipped with a Four Thirds sensor. The E-M1X has a resolution of 20.2 megapixels, whereas the E-M5 II provides 15.9 MP.

Below is an overview of the main specs of the two cameras as a starting point for the comparison.

Headline Specifications
Olympus E-M1X
versus
Olympus E-M5 II
Olympus E-M1X   Olympus E-M5 II
Mirrorless system camera Mirrorless system camera
Micro Four Thirds lenses Micro Four Thirds lenses
20.2 MP – Four Thirds sensor 15.9 MP – Four Thirds sensor
4K/30p Video 1080/60p Video
ISO 200-25,600 ISO 200-25,600
Electronic viewfinder (2360k dots) Electronic viewfinder (2360k dots)
3.0" LCD – 1037k dots 3.0" LCD – 1037k dots
Swivel touchscreen Swivel touchscreen
18 shutter flaps per second 10 shutter flaps per second
In-body stabilizationIn-body stabilization
Weathersealed bodyWeathersealed body
870 shots per battery charge310 shots per battery charge
144 x 147 x 75 mm, 997 g 124 x 85 x 45 mm, 469 g
logo
Check E-M1X offers at
ebay.com
logo
Check E-M5 II offers at
ebay.com

Going beyond this snapshot of core features and characteristics, what are the differences between the Olympus OM-D E-M1X and the Olympus OM-D E-M5 Mark II? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.

ad

Body comparison

The side-by-side display below illustrates the physical size and weight of the Olympus E-M1X and the Olympus E-M5 II. The two cameras are presented according to their relative size. Three consecutive perspectives from the front, the top, and the back are available. All width, height and depth measures are rounded to the nearest millimeter.

Both cameras are available in two different colors (black, silver).

Size Olympus E-M1X vs Olympus E-M5 II
Compare E-M1X versus E-M5 II top
Comparison E-M1X or E-M5 II rear

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Olympus E-M5 II is considerably smaller (50 percent) than the Olympus E-M1X. Moreover, the E-M5 II is substantially lighter (53 percent) than the E-M1X. In this context, it is worth noting that both cameras are splash and dust-proof and can, hence, be used in inclement weather conditions or harsh environments.

The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. In this particular case, both cameras feature the same lens mount, so that they can use the same lenses. You can compare the optics available in the Micro Four Thirds Lens Catalog. Mirrorless cameras, such as the two under consideration, have the additional advantage of having a short flange to focal plane distance, which makes it possible to mount many lenses from other systems onto the camera via adapters.

Concerning battery life, the E-M1X gets 870 shots out of its Olympus BLH-1 battery, while the E-M5 II can take 310 images on a single charge of its Olympus BLN-1 power pack. As can be seen in the images above, the E-M1X has a battery grip built in. This facilitates image-taking in portrait orientation and gives it additional battery power. In order to provide similar functionality for the E-M5 II, Olympus provides the HLD-8 vertical grip as an optional accessory (see here on ebay). The power pack in the E-M1X can be charged via the USB port, so that it is not always necessary to take the battery charger along when travelling.

The table below summarizes the key physical specs of the two cameras alongside a broader set of comparators. If you want to switch the focus of the display and review another camera pair, you can move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.

scroll hint
Body Specifications
  empty Camera
Model
Camera
Width
Camera
Height
Camera
Depth
Camera
Weight
Battery
Life
Weather
Sealing
Camera
Launch
Launch
Price
Street
Price
1.

Olympus E-M1X 144 mm 147 mm 75 mm 997 g 870 i Jan 2019 US$ 2 999ebay.com
2.

Olympus E-M5 II 124 mm 85 mm 45 mm 469 g 310 i Feb 2015 US$ 1 099ebay.com
3.

Olympus E-M1 130 mm 94 mm 63 mm 497 g 350 i Sep 2013 US$ 1 399ebay.com
4.

Olympus E-M1 II 134 mm 91 mm 67 mm 574 g 440 i Sep 2016 US$ 1 999ebay.com
5.

Olympus E-M1 III 134 mm 91 mm 69 mm 580 g 420 i Feb 2020 US$ 1 799ebay.com
6.

Olympus E-M5 122 mm 89 mm 43 mm 425 g 360 i Feb 2012 US$ 1 299ebay.com
7.

Olympus E-M5 III 125 mm 85 mm 50 mm 414 g 310 i Oct 2019 US$ 1 199ebay.com
8.

Olympus E-M10 119 mm 82 mm 46 mm 396 g 320 i Jan 2014 US$ 699ebay.com
9.

Olympus E-M10 II 120 mm 83 mm 47 mm 390 g 320 i Aug 2015 US$ 649ebay.com
10.

Olympus E-M10 IV 122 mm 84 mm 49 mm 383 g 360 i Aug 2020 US$ 699 amazon.com
11.

Panasonic G90 130 mm 94 mm 77 mm 536 g 290 i Apr 2019 US$ 999ebay.com
12.

Panasonic G97 130 mm 94 mm 77 mm 536 g 290 i Apr 2019 US$ 749ebay.com
13.

Panasonic G95 130 mm 94 mm 77 mm 536 g 290 i Apr 2019 US$ 999ebay.com
14.

Panasonic GH5 139 mm 98 mm 87 mm 725 g 410 i Jan 2017 US$ 1 999ebay.com
15.

Panasonic S1 149 mm 110 mm 97 mm 1017 g 400 i Feb 2019 US$ 2 499ebay.com
Note: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
  empty Camera
Model
Camera
Width
Camera
Height
Camera
Depth
Camera
Weight
Battery
Life
Weather
Sealing
Camera
Launch
Launch
Price
Street
Price
  empty Camera
Model

The price is, of course, an important factor in any camera decision. The listed launch prices provide an indication of the market segment that the manufacturer of the cameras have been targeting. The E-M5 II was launched at a markedly lower price (by 63 percent) than the E-M1X, which puts it into a different market segment. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.

Sensor comparison

The size of the imaging sensor is a crucial determinant of image quality. A large sensor will tend to have larger individual pixels that provide better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixel-units in a sensor of the same technological generation. Further, a large sensor camera will give the photographer additional creative options when using shallow depth-of-field to isolate a subject from its background. On the downside, larger sensors tend to be associated with larger, more expensive camera bodies and lenses.

Both cameras under consideration feature a Four Thirds sensor and have a format factor (sometimes also referred to as "crop factor") of 2.0. Within the spectrum of camera sensors, this places the review cameras among the medium-sized sensor cameras that aim to strike a balance between image quality and portability. Both cameras feature a native aspect ratio (sensor width to sensor height) of 4:3.

In terms of chip-set technology, the E-M1X uses a more advanced image processing engine (Dual TruePic VIII) than the E-M5 II (TruePic VII), with benefits for noise reduction, color accuracy, and processing speed.

Olympus E-M1X and Olympus E-M5 II sensor measures

While the two cameras under review share the same sensor size, the E-M1X offers a higher resolution of 20.2 megapixels, compared with 15.9 MP of the E-M5 II. This megapixels advantage translates into a 13 percent gain in linear resolution. On the other hand, these sensor specs imply that the E-M1X has a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 3.34μm versus 3.76μm for the E-M5 II). In this context, it should be noted, however, that the E-M1X is much more recent (by 3 years and 11 months) than the E-M5 II, and its sensor will have benefitted from technological advances during this time that compensate for the smaller pixel size. Coming back to sensor resolution, it should be mentioned that the E-M1X has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.

The resolution advantage of the Olympus E-M1X implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the E-M1X for good quality output (200 dots per inch) amounts to 25.9 x 19.4 inches or 65.8 x 49.4 cm, for very good quality (250 dpi) 20.7 x 15.6 inches or 52.7 x 39.5 cm, and for excellent quality (300 dpi) 17.3 x 13 inches or 43.9 x 32.9 cm. The corresponding values for the Olympus E-M5 II are 23 x 17.3 inches or 58.5 x 43.9 cm for good quality, 18.4 x 13.8 inches or 46.8 x 35.1 cm for very good quality, and 15.4 x 11.5 inches or 39 x 29.3 cm for excellent quality prints.

The E-M1X has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.

Both cameras have the capacity to capture high quality composite images by combining multiple shots after shifting the sensor by miniscule distances. This multi-shot, pixel-shift mode is most suitable for photography of stationary objects (landscapes, studio scenes).

The Olympus OM-D E-M1X has a native sensitivity range from ISO 200 to ISO 25600, which can be extended to ISO 64-25600. The corresponding ISO settings for the Olympus OM-D E-M5 Mark II are ISO 200 to ISO 25600, with the possibility to increase the ISO range to 100-25600.

Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors. Both cameras use a Bayer filter for capturing RGB colors on a square grid of photosensors. This arrangement is found in most digital cameras.

E-M1X versus E-M5 II MP

For many cameras, data on sensor performance has been reported by DXO Mark. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.

scroll hint
Sensor Characteristics
  empty Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Olympus E-M1X Four Thirds 20.2 5184 38884K/30p23.213.0125475
2.

Olympus E-M5 II Four Thirds 15.9 4608 34561080/60p23.012.584273
3.

Olympus E-M1 Four Thirds 15.9 4608 34561080/30p23.012.775773
4.

Olympus E-M1 II Four Thirds 20.2 5184 38884K/30p23.712.8131280
5.

Olympus E-M1 III Four Thirds 20.2 5184 38884K/30p23.313.1135676
6.

Olympus E-M5 Four Thirds 15.9 4608 34561080/60i22.812.382671
7.

Olympus E-M5 III Four Thirds 20.2 5184 38884K/30p23.313.1132476
8.

Olympus E-M10 Four Thirds 15.9 4608 34561080/30p22.812.388472
9.

Olympus E-M10 II Four Thirds 15.9 4608 34561080/60p23.112.584273
10.

Olympus E-M10 IV Four Thirds 20.2 5184 38884K/30p23.313.2140276
11.

Panasonic G90 Four Thirds 20.2 5184 38884K/30p23.213.0127375
12.

Panasonic G97 Four Thirds 20.2 5184 38884K/30p23.213.0127375
13.

Panasonic G95 Four Thirds 20.2 5184 38884K/30p23.213.0127375
14.

Panasonic GH5 Four Thirds 20.2 5184 38884K/60p23.913.080777
15.

Panasonic S1 Full Frame 24.0 6000 40004K/60p25.214.5333395
Note: DXO values in italics represent estimates based on sensor size and age.
  empty Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
  empty Camera
Model

Many modern cameras are not only capable of taking still images, but also of capturing video footage. Both cameras under consideration are equipped with sensors that have a sufficiently high read-out speed for moving images, but the E-M1X provides a higher video resolution than the E-M5 II. It can shoot video footage at 4K/30p, while the E-M5 II is limited to 1080/60p.

Feature comparison

Apart from body and sensor, cameras can and do differ across a range of features. The E-M1X and the E-M5 II are similar in the sense that both feature an electronic viewfinder, which is helpful when framing images in bright sunlight. Moreover, their viewfinders offer an identical resolution of 2360k dots. The following table reports on some other key feature differences and similarities of the Olympus E-M1X, the Olympus E-M5 II, and comparable cameras.

scroll hint
Core Features
  empty Camera
Model
Viewfinder
(Type or
000 dots)
Control
Panel
(yes/no)
LCD
Specifications
(inch/000 dots)
LCD
Attach-
ment
Touch
Screen
(yes/no)
Max
Shutter
Speed *
Max
Shutter
Flaps *
Built-in
Flash
(yes/no)
Built-in
Stab
1.

Olympus E-M1X2360 i3.0 / 1037 swivel i 1/8000s 18.0/s i i
2.

Olympus E-M5 II2360 i3.0 / 1037 swivel i 1/8000s 10.0/s i i
3.

Olympus E-M12360 i3.0 / 1037 tilting i 1/8000s 10.0/s i i
4.

Olympus E-M1 II2360 i3.0 / 1037 swivel i 1/8000s 18.0/s i i
5.

Olympus E-M1 III2360 i3.0 / 1037 swivel i 1/8000s 18.0/s i i
6.

Olympus E-M51440 i3.0 / 610 tilting i 1/4000s 9.0/s i i
7.

Olympus E-M5 III2360 i3.0 / 1040 swivel i 1/8000s 10.0/s i i
8.

Olympus E-M101440 i3.0 / 1037 tilting i 1/4000s 8.0/s i i
9.

Olympus E-M10 II2360 i3.0 / 1040 tilting i 1/4000s 8.0/s i i
10.

Olympus E-M10 IV2360 i3.0 / 1040 tilting i 1/4000s 15.0/s i i
11.

Panasonic G902360 i3.0 / 1240 swivel i 1/4000s 9.0/s i i
12.

Panasonic G972360 i3.0 / 1840 swivel i 1/4000s 9.0/s i i
13.

Panasonic G952360 i3.0 / 1240 swivel i 1/4000s 9.0/s i i
14.

Panasonic GH53680 i3.2 / 1620 swivel i 1/8000s 12.0/s i i
15.

Panasonic S15760 i3.2 / 2100 full-flex i 1/8000s 9.0/s i i
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one.
  empty Camera
Model
Viewfinder
(Type or
000 dots)
Control
Panel
(yes/no)
LCD
Specifications
(inch/000 dots)
LCD
Attach-
ment
Touch
Screen
(yes/no)
Max
Shutter
Speed *
Max
Shutter
Flaps *
Built-in
Flash
(yes/no)
Built-in
Stab
  empty Camera
Model
Both cameras have an articulated rear screen that can be turned to be front-facing. This feature will be particularly appreciated by vloggers and photographers who are interested in taking selfies.

The reported shutter speed information refers to the use of the mechanical shutter. Yet, some cameras only have an electronic shutter, while others have an electronic shutter in addition to a mechanical one. In fact, both cameras under consideration feature an electronic shutter, which makes completely silent shooting possible. However, this mode is less suitable for photographing moving objects (risk of rolling shutter) or shooting under artificial light sources (risk of flickering).

The Olympus E-M1X and the Olympus E-M5 II both have an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.

Concerning the storage of imaging data, both the E-M1X and the E-M5 II write their files to SDXC cards. The E-M1X features dual card slots, which can be very useful in case a memory card fails. In contrast, the E-M5 II only has one slot. Both cameras support UHS-II cards, which provide for Ultra High Speed data transfer of up to 312 MB/s.

Connectivity comparison

For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Olympus OM-D E-M1X and Olympus OM-D E-M5 Mark II and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.

scroll hint
Input-Output Connections
  empty Camera
Model
Hotshoe
Port
Internal
Mic / Speaker
Microphone
Port
Headphone
Port
HDMI
Port
USB
Port
WiFi
Support
NFC
Support
Bluetooth
Support
1.

Olympus E-M1Xistereo / monoiimicro3.0iii
2.

Olympus E-M5 IIistereo / monoiimicro2.0iii
3.

Olympus E-M1istereo / monoiimicro2.0iii
4.

Olympus E-M1 IIistereo / monoiimicro3.0iii
5.

Olympus E-M1 IIIistereo / monoiimicro3.1iii
6.

Olympus E-M5istereo / monoiimini2.0iii
7.

Olympus E-M5 IIIistereo / monoiimicro2.0iii
8.

Olympus E-M10istereo / monoiimicro2.0iii
9.

Olympus E-M10 IIistereo / monoiimicro2.0iii
10.

Olympus E-M10 IVistereo / monoiimicro2.0iii
11.

Panasonic G90istereo / monoiimicro2.0iii
12.

Panasonic G97istereo / monoiimicro2.0iii
13.

Panasonic G95istereo / monoiimicro2.0iii
14.

Panasonic GH5istereo / monoiifull3.1iii
15.

Panasonic S1istereo / monoiifull3.1iii
  empty Camera
Model
Hotshoe
Port
Internal
Mic / Speaker
Microphone
Port
Headphone
Port
HDMI
Port
USB
Port
WiFi
Support
NFC
Support
Bluetooth
Support
  empty Camera
Model

It is notable that the E-M1X has a headphone jack, which is not present on the E-M5 II This port makes it possible to attach external headphones and monitor the quality of sound during the recording process.

Both cameras feature a PC Sync terminal to control professional strobe lights, which will be appreciated by studio photographers.

Travel and landscape photographers will find it useful that the E-M1X has an internal geolocalization sensor and can record GPS coordinates in its EXIF data.

Both the E-M1X and the E-M5 II have been discontinued, but can regularly be found used on ebay. The E-M5 II was replaced by the Olympus E-M5 III, while the E-M1X does not have a direct successor. Further information on the features and operation of the E-M1X and E-M5 II can be found, respectively, in the Olympus E-M1X Manual (free pdf) or the online Olympus E-M5 II Manual.

Review summary

So how do things add up? Which of the two cameras – the Olympus E-M1X or the Olympus E-M5 II – has the upper hand? Is one clearly better than the other? A synthesis of the relative strong points of each of the models is listed below.


Reasons to prefer the Olympus OM-D E-M1X:

  • More detail: Offers more megapixels (20.2 vs 15.9MP) with a 13% higher linear resolution.
  • Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
  • Better jpgs: Has a more modern image processing engine (Dual TruePic VIII vs TruePic VII).
  • Better video: Provides higher definition movie capture (4K/30p vs 1080/60p).
  • Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
  • Better sound control: Has a headphone port that enables audio monitoring while recording.
  • Larger viewfinder image: Features a viewfinder with a higher magnification (0.83x vs 0.74x).
  • Faster burst: Shoots at higher frequency (18 vs 10 flaps/sec) to capture the decisive moment.
  • More portrait friendly: Features an integrated vertical grip for easier portrait shooting.
  • Longer lasting: Can take more shots (870 versus 310) on a single battery charge.
  • Easier travel charging: Can be conveniently charged via its USB port.
  • Easier geotagging: Features an internal GPS sensor to log localization data.
  • Faster data transfer: Supports a more advanced USB protocol (3.0 vs 2.0).
  • Easier wireless transfer: Supports Bluetooth for image sharing without cables.
  • Greater peace of mind: Features a second card slot as a backup in case of memory card failure.
  • More modern: Reflects 3 years and 11 months of technical progress since the E-M5 II launch.


Arguments in favor of the Olympus OM-D E-M5 Mark II:

  • Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
  • More compact: Is smaller (124x85mm vs 144x147mm) and will fit more readily into a bag.
  • Less heavy: Has a lower weight (by 528g or 53 percent) and is thus easier to take along.
  • More affordable: Was introduced into a lower priced category (63 percent cheaper at launch).
  • More heavily discounted: Has been around for much longer (launched in February 2015).

If the number of relative strengths (bullet points above) is taken as a guide, the E-M1X is the clear winner of the match-up (16 : 5 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional sports photographer will view the differences between cameras in a way that diverges from the perspective of a street photog, and a person interested in family portraits has distinct needs from a landscape shooter. Hence, the decision which camera is best and worth buying is often a very personal one.

E-M1X 16:05 E-M5 II

How about other alternatives? Do the specifications of the Olympus E-M1X and the Olympus E-M5 II place the cameras among the top in their class? Find out in the latest Best Mirrorless Interchangeable Lens Camera listing whether the two cameras rank among the cream of the crop.

In any case, while the comparison of the spec-sheets of cameras can offer a general idea of their imaging potential, it remains incomplete and does no justice, for example, to the way the E-M1X or the E-M5 II perform in practice. User reviews, such as those found at amazon, can sometimes inform about these issues, but such feedback is often incomplete, inconsistent, and biased.

Expert reviews

This is where reviews by experts come in. The table below provides a synthesis of the camera assessments of some of the best known photo-gear review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.

scroll hint
Expert Camera Reviews
  empty  Camera
 Model
 AP
 score
 CL
 score
 DCW
 score
 DPR
 score
 EPZ
 score
 PB
 score
Camera
Launch
Launch
Price
Street
Price
1.

Olympus E-M1X4.5/5o5/585/1004.5/5.. Jan 2019 US$ 2 999ebay.com
2.

Olympus E-M5 II5/5+ +4.5/581/1005/55/5 Feb 2015 US$ 1 099ebay.com
3.

Olympus E-M15/5+ +..84/1004.5/54.5/5 Sep 2013 US$ 1 399ebay.com
4.

Olympus E-M1 II5/5+ +5/585/1004.5/54.5/5 Sep 2016 US$ 1 999ebay.com
5.

Olympus E-M1 III5/5..5/583/1004.5/54/5 Feb 2020 US$ 1 799ebay.com
6.

Olympus E-M54/5+ +..80/1004.5/55/5 Feb 2012 US$ 1 299ebay.com
7.

Olympus E-M5 III5/5+5/582/1004.5/54.5/5 Oct 2019 US$ 1 199ebay.com
8.

Olympus E-M104/5....80/1005/55/5 Jan 2014 US$ 699ebay.com
9.

Olympus E-M10 II4.5/5+ +..80/1005/55/5 Aug 2015 US$ 649ebay.com
10.

Olympus E-M10 IV4.5/5..5/581/1004.5/54.5/5 Aug 2020 US$ 699 amazon.com
11.

Panasonic G904.5/5+4.5/583/1004.5/54.5/5 Apr 2019 US$ 999ebay.com
12.

Panasonic G97............ Apr 2019 US$ 749ebay.com
13.

Panasonic G954.5/5+4.5/583/1004.5/54.5/5 Apr 2019 US$ 999ebay.com
14.

Panasonic GH54.5/5+ +..85/1004.5/55/5 Jan 2017 US$ 1 999ebay.com
15.

Panasonic S14.5/5+ +4.5/588/1004.5/54/5 Feb 2019 US$ 2 499ebay.com
Note: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.
  empty  Camera
 Model
 AP
 score
 CL
 score
 DCW
 score
 DPR
 score
 EPZ
 score
 PB
 score
Camera
Launch
Launch
Price
Street
Price
  empty  Camera
 Model

The above review scores should be interpreted with care, though. The ratings were established in reference to similarly priced cameras that were available in the market at the time of the review. Hence, a score should always be seen in the context of the camera's market launch date and its price, and comparisons of ratings among very different cameras or across long time periods have little meaning. Also, please note that some of the review sites have changed their methodology and reporting over time.

logo
Check E-M1X offers at
ebay.com
logo
Check E-M5 II offers at
ebay.com

Other camera comparisons

Did this review help to inform your camera decision process? In case you are interested in seeing how other cameras pair up, just make a corresponding selection in the search boxes below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.

~
  • Credit Card
  • Canon 1D
  • Canon 1D Mark II
  • Canon 1D Mark II N
  • Canon 1D Mark III
  • Canon 1D Mark IV
  • Canon 1Ds
  • Canon 1Ds Mark II
  • Canon 1Ds Mark III
  • Canon 1D C
  • Canon 1D X
  • Canon 1D X Mark II
  • Canon 1D X Mark III
  • Canon 5D
  • Canon 5D Mark II
  • Canon 5D Mark III
  • Canon 5D Mark IV
  • Canon 5DS
  • Canon 5DS R
  • Canon 6D
  • Canon 6D Mark II
  • Canon 7D
  • Canon 7D II
  • Canon 10D
  • Canon 20D
  • Canon 30D
  • Canon 40D
  • Canon 50D
  • Canon 60D
  • Canon 70D
  • Canon 77D
  • Canon 80D
  • Canon 90D
  • Canon D30
  • Canon D60
  • Canon G1 X
  • Canon G1 X Mark II
  • Canon G1 X Mark III
  • Canon G3 X
  • Canon G5 X
  • Canon G5 X Mark II
  • Canon G7 X
  • Canon G7 X Mark II
  • Canon G7 X Mark III
  • Canon G9 X
  • Canon G9 X Mark II
  • Canon G12
  • Canon G15
  • Canon G16
  • Canon M
  • Canon M3
  • Canon M5
  • Canon M6
  • Canon M6 Mark II
  • Canon M10
  • Canon M50
  • Canon M50 Mark II
  • Canon M100
  • Canon M200
  • Canon R
  • Canon R1
  • Canon R3
  • Canon R5
  • Canon R5 Mark II
  • Canon R5 C
  • Canon R6
  • Canon R6 Mark II
  • Canon R7
  • Canon R8
  • Canon R10
  • Canon R50
  • Canon R50 V
  • Canon R100
  • Canon RP
  • Canon S120
  • Canon SL1
  • Canon SL2
  • Canon SL3
  • Canon SX1
  • Canon SX10
  • Canon SX20
  • Canon SX30
  • Canon SX40
  • Canon SX50
  • Canon SX60
  • Canon SX70
  • Canon SX400
  • Canon SX410
  • Canon SX420
  • Canon SX430
  • Canon SX500
  • Canon SX510
  • Canon SX520
  • Canon SX530
  • Canon SX540
  • Canon SX600
  • Canon SX610
  • Canon SX620
  • Canon SX700
  • Canon SX710
  • Canon SX720
  • Canon SX730
  • Canon SX740
  • Canon Rebel
  • Canon T1i
  • Canon T2i
  • Canon T3
  • Canon T3i
  • Canon T4i
  • Canon T5
  • Canon T5i
  • Canon T6
  • Canon T6i
  • Canon T6s
  • Canon T7
  • Canon T7i
  • Canon T8i
  • Canon T100
  • Canon V1
  • Canon XC10
  • Canon XS
  • Canon XSi
  • Canon XT
  • Canon XTi
  • Contax N Digital
  • Epson R-D1
  • Fujifilm GFX 50R
  • Fujifilm GFX 50S
  • Fujifilm GFX 50S II
  • Fujifilm GFX 100
  • Fujifilm GFX 100 II
  • Fujifilm GFX 100RF
  • Fujifilm GFX 100S
  • Fujifilm GFX 100S II
  • Fujifilm X-A1
  • Fujifilm X-A2
  • Fujifilm X-A3
  • Fujifilm X-A5
  • Fujifilm X-A7
  • Fujifilm X-A10
  • Fujifilm X-E1
  • Fujifilm X-E2
  • Fujifilm X-E2S
  • Fujifilm X-E3
  • Fujifilm X-E4
  • Fujifilm X-E5
  • Fujifilm X-H1
  • Fujifilm X-H2
  • Fujifilm X-H2S
  • Fujifilm X-M1
  • Fujifilm X-M5
  • Fujifilm X-Pro1
  • Fujifilm X-Pro2
  • Fujifilm X-Pro3
  • Fujifilm X-S10
  • Fujifilm X-S20
  • Fujifilm X-T1
  • Fujifilm X-T2
  • Fujifilm X-T3
  • Fujifilm X-T4
  • Fujifilm X-T5
  • Fujifilm X-T10
  • Fujifilm X-T20
  • Fujifilm X-T30
  • Fujifilm X-T30 II
  • Fujifilm X-T50
  • Fujifilm X-T100
  • Fujifilm X-T200
  • Fujifilm X10
  • Fujifilm X20
  • Fujifilm X30
  • Fujifilm X70
  • Fujifilm X100
  • Fujifilm X100S
  • Fujifilm X100T
  • Fujifilm X100F
  • Fujifilm X100V
  • Fujifilm X100VI
  • Fujifilm XF10
  • Fujifilm XQ1
  • Fujifilm XQ2
  • Fujifilm XP120
  • Fujifilm XP130
  • Fujifilm XP140
  • Hasselblad X1D
  • Hasselblad X1D II
  • Hasselblad X2D 100C
  • Kodak AZ901
  • Kodak S-1
  • Leica C-LUX
  • Leica CL
  • Leica D-LUX Typ 109
  • Leica D-LUX 5
  • Leica D-LUX 6
  • Leica D-LUX 7
  • Leica D-LUX 8
  • Leica Digilux 3
  • Leica M Typ 240
  • Leica M-E Typ 240
  • Leica M Typ 262
  • Leica M8
  • Leica M9
  • Leica M10
  • Leica M10-P
  • Leica M10-R
  • Leica M11
  • Leica Q Typ 116
  • Leica Q2
  • Leica Q3
  • Leica S1
  • Leica S2
  • Leica S3
  • Leica S Typ 006
  • Leica S-E Typ 006
  • Leica S Typ 007
  • Leica SL
  • Leica SL2
  • Leica SL2-S
  • Leica SL3
  • Leica SL3-S
  • Leica T
  • Leica TL
  • Leica TL2
  • Leica V-LUX 1
  • Leica V-LUX 2
  • Leica V-LUX 3
  • Leica V-LUX 4
  • Leica V-LUX Typ 114
  • Leica V-LUX 5
  • Leica X1
  • Leica X2
  • Leica X Vario
  • Leica X Typ 113
  • Leica X-U Typ 113
  • Leitz Ur-Leica
  • Nikon 1 J4
  • Nikon 1 J5
  • Nikon 1 V1
  • Nikon 1 V2
  • Nikon 1 V3
  • Nikon Coolpix A
  • Nikon A1000
  • Nikon B500
  • Nikon B600
  • Nikon B700
  • Nikon D1
  • Nikon D1H
  • Nikon D1X
  • Nikon D2H
  • Nikon D2X
  • Nikon D2Xs
  • Nikon D3
  • Nikon D3S
  • Nikon D3X
  • Nikon D4
  • Nikon D4S
  • Nikon D5
  • Nikon D6
  • Nikon D40
  • Nikon D40X
  • Nikon D50
  • Nikon D60
  • Nikon D70
  • Nikon D70s
  • Nikon D80
  • Nikon D90
  • Nikon D100
  • Nikon D200
  • Nikon D300
  • Nikon D300S
  • Nikon D500
  • Nikon D600
  • Nikon D610
  • Nikon D700
  • Nikon D750
  • Nikon D780
  • Nikon D800
  • Nikon D800E
  • Nikon D810
  • Nikon D850
  • Nikon D3000
  • Nikon D3100
  • Nikon D3200
  • Nikon D3300
  • Nikon D3400
  • Nikon D3500
  • Nikon D5000
  • Nikon D5100
  • Nikon D5200
  • Nikon D5300
  • Nikon D5500
  • Nikon D5600
  • Nikon D7000
  • Nikon D7100
  • Nikon D7200
  • Nikon D7500
  • Nikon Df
  • Nikon L840
  • Nikon P900
  • Nikon P950
  • Nikon P1000
  • Nikon P1100
  • Nikon P7800
  • Nikon W150
  • Nikon W300
  • Nikon Z5
  • Nikon Z5 II
  • Nikon Z6
  • Nikon Z6 II
  • Nikon Z6 III
  • Nikon Z7
  • Nikon Z7 II
  • Nikon Z8
  • Nikon Z9
  • Nikon Z30
  • Nikon Z50
  • Nikon Z50 II
  • Nikon Zf
  • Nikon Z fc
  • Olympus E-1
  • Olympus E-3
  • Olympus E-5
  • Olympus E-30
  • Olympus E-300
  • Olympus E-330
  • Olympus E-400
  • Olympus E-410
  • Olympus E-420
  • Olympus E-450
  • Olympus E-500
  • Olympus E-510
  • Olympus E-520
  • Olympus E-600
  • Olympus E-620
  • Olympus E-M1
  • Olympus E-M1 II
  • Olympus E-M1 III
  • Olympus E-M1X
  • Olympus E-M5
  • Olympus E-M5 II
  • Olympus E-M5 III
  • Olympus E-M10
  • Olympus E-M10 II
  • Olympus E-M10 III
  • Olympus E-M10 IV
  • Olympus E-P1
  • Olympus E-P2
  • Olympus E-P3
  • Olympus E-P5
  • Olympus E-P7
  • Olympus E-PL1
  • Olympus E-PL2
  • Olympus E-PL3
  • Olympus E-PL5
  • Olympus E-PL6
  • Olympus E-PL7
  • Olympus E-PL8
  • Olympus E-PL9
  • Olympus E-PL10
  • Olympus E-PM1
  • Olympus E-PM2
  • Olympus PEN-F
  • Olympus Stylus 1
  • Olympus Stylus 1s
  • Olympus TG-4
  • Olympus TG-5
  • Olympus TG-6
  • Olympus XZ-1
  • Olympus XZ-2
  • OM System OM-1
  • OM System OM-1 II
  • OM System OM-3
  • OM System OM-5
  • OM System OM-5 II
  • OM System TG-7
  • Panasonic FZ80
  • Panasonic FZ80D
  • Panasonic FZ100
  • Panasonic FZ150
  • Panasonic FZ200
  • Panasonic FZ300
  • Panasonic FZ1000
  • Panasonic FZ1000 II
  • Panasonic FZ2500
  • Panasonic G1
  • Panasonic G2
  • Panasonic G3
  • Panasonic G5
  • Panasonic G6
  • Panasonic G7
  • Panasonic G9
  • Panasonic G9 II
  • Panasonic G10
  • Panasonic G85
  • Panasonic G97
  • Panasonic G95
  • Panasonic G100
  • Panasonic GF1
  • Panasonic GF2
  • Panasonic GF3
  • Panasonic GF5
  • Panasonic GF6
  • Panasonic GF7
  • Panasonic GH1
  • Panasonic GH2
  • Panasonic GH3
  • Panasonic GH4
  • Panasonic GH5
  • Panasonic GH5 II
  • Panasonic GH5s
  • Panasonic GH6
  • Panasonic GH7
  • Panasonic GM1
  • Panasonic GM5
  • Panasonic GX1
  • Panasonic GX7
  • Panasonic GX8
  • Panasonic GX9
  • Panasonic GX85
  • Panasonic GX850
  • Panasonic L1
  • Panasonic L10
  • Panasonic LF1
  • Panasonic LX5
  • Panasonic LX7
  • Panasonic LX10
  • Panasonic LX100
  • Panasonic LX100 II
  • Panasonic S1
  • Panasonic S1 II
  • Panasonic S1H
  • Panasonic S1R
  • Panasonic S1R II
  • Panasonic S5
  • Panasonic S5 II
  • Panasonic S9
  • Panasonic TS7
  • Panasonic ZS70
  • Panasonic ZS80
  • Panasonic ZS100
  • Panasonic ZS200
  • Pentax 645D
  • Pentax 645Z
  • Pentax K-1
  • Pentax K-1 II
  • Pentax K-3
  • Pentax K-3 II
  • Pentax K-3 III
  • Pentax K-5
  • Pentax K-5 II
  • Pentax K-30
  • Pentax K-50
  • Pentax K-70
  • Pentax K-500
  • Pentax KP
  • Pentax K-S1
  • Pentax K-S2
  • Pentax MX-1
  • Pentax Q
  • Pentax WG-8
  • Pentax WG-90
  • Pentax WG-1000
  • Ricoh GR
  • Ricoh GR II
  • Ricoh GR III
  • Ricoh GR IIIx
  • Ricoh WG-6
  • Ricoh WG-60
  • Samsung NX1
  • Samsung NX30
  • Samsung NX500
  • Sigma fp
  • Sigma fp L
  • Sony A1
  • Sony A1 II
  • Sony A7
  • Sony A7 II
  • Sony A7 III
  • Sony A7 IV
  • Sony A7C
  • Sony A7C II
  • Sony A7C R
  • Sony A7R
  • Sony A7R II
  • Sony A7R III
  • Sony A7R IIIA
  • Sony A7R IV
  • Sony A7R IVA
  • Sony A7R V
  • Sony A7S
  • Sony A7S II
  • Sony A7S III
  • Sony A9
  • Sony A9 II
  • Sony A9 III
  • Sony A58
  • Sony A68
  • Sony A77
  • Sony A77 II
  • Sony A99
  • Sony A99 II
  • Sony A850
  • Sony A900
  • Sony A3000
  • Sony A5000
  • Sony A5100
  • Sony A6000
  • Sony A6100
  • Sony A6300
  • Sony A6400
  • Sony A6500
  • Sony A6600
  • Sony A6700
  • Sony H200
  • Sony H300
  • Sony H400
  • Sony HX80
  • Sony HX90V
  • Sony HX95
  • Sony HX99
  • Sony HX350
  • Sony HX400V
  • Sony NEX-3
  • Sony NEX-3N
  • Sony NEX-5
  • Sony NEX-5N
  • Sony NEX-5R
  • Sony NEX-5T
  • Sony NEX-6
  • Sony NEX-7
  • Sony NEX-C3
  • Sony NEX-F3
  • Sony RX0
  • Sony RX0 II
  • Sony RX1
  • Sony RX1R
  • Sony RX1R II
  • Sony RX1R III
  • Sony RX10
  • Sony RX10 II
  • Sony RX10 III
  • Sony RX10 IV
  • Sony RX100
  • Sony RX100 II
  • Sony RX100 III
  • Sony RX100 IV
  • Sony RX100 V
  • Sony RX100 VI
  • Sony RX100 VII
  • Sony WX800
  • Sony ZV-1
  • Sony ZV-1 II
  • Sony ZV-1F
  • Sony ZV-E1
  • Sony ZV-E10
  • Sony ZV-E10 II
  • YI M1
  • Zeiss ZX1
loader
ad

Specifications: Olympus E-M1X vs Olympus E-M5 II

Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.

Camera Specifications
Camera Model Olympus E-M1X Olympus E-M5 II
Camera Type Mirrorless system camera Mirrorless system camera
Camera Lens Micro Four Thirds lenses Micro Four Thirds lenses
Launch Date January 2019 February 2015
Launch Price USD 2,999 USD 1,099
Sensor Specs Olympus E-M1X Olympus E-M5 II
Sensor Technology CMOS CMOS
Sensor Format Four Thirds Sensor Four Thirds Sensor
Sensor Size 17.3 x 13.0 mm 17.3 x 13.0 mm
Sensor Area 224.9 mm2 224.9 mm2
Sensor Diagonal 21.6 mm 21.6 mm
Crop Factor 2.0x 2.0x
Sensor Resolution 20.2 Megapixels 15.9 Megapixels
Image Resolution 5184 x 3888 pixels 4608 x 3456 pixels
Pixel Pitch 3.34 μm 3.76 μm
Pixel Density 8.96 MP/cm2 7.08 MP/cm2
Moiré control no AA filter Anti-Alias filter
Movie Capability 4K/30p Video 1080/60p Video
ISO Setting 200 - 25,600 ISO 200 - 25,600 ISO
ISO Boost 64 - 25,600 ISO 100 - 25,600 ISO
Image Processor Dual TruePic VIII TruePic VII
DXO Sensor Quality (score) .. 73
DXO Color Depth (bits) .. 23.0
DXO Dynamic Range (EV) .. 12.5
DXO Low Light (ISO) .. 842
Screen Specs Olympus E-M1X Olympus E-M5 II
Viewfinder Type Electronic viewfinder Electronic viewfinder
Viewfinder Field of View 100% 100%
Viewfinder Magnification 0.83x 0.74x
Viewfinder Resolution 2360k dots 2360k dots
LCD Framing Live View Live View
Rear LCD Size 3.0inch 3.0inch
LCD Resolution 1037k dots 1037k dots
LCD Attachment Swivel screen Swivel screen
Touch Input Touchscreen Touchscreen
Shooting Specs Olympus E-M1X Olympus E-M5 II
Focus System On-Sensor Phase-detect Contrast-detect AF
Manual Focusing AidFocus PeakingFocus Peaking
Max Shutter Speed (mechanical) 1/8000s 1/8000s
Continuous Shooting 18 shutter flaps/s 10 shutter flaps/s
Electronic Shutterup to 1/32000sup to 1/16000s
Time-Lapse PhotographyIntervalometer built-inIntervalometer built-in
Image StabilizationIn-body stabilizationIn-body stabilization
Fill Flash no On-Board Flash no On-Board Flash
Storage Medium SDXC cards SDXC cards
Single or Dual Card Slots Dual card slots Single card slot
UHS card support Dual UHS-II UHS-II
Connectivity Specs Olympus E-M1X Olympus E-M5 II
External Flash Hotshoe Hotshoe
Studio Flash PC Sync socket PC Sync socket
USB Connector USB 3.0 USB 2.0
HDMI Port micro HDMI micro HDMI
Microphone Port External MIC port External MIC port
Headphone Socket Headphone port no Headphone port
Wifi Support Wifi built-in Wifi built-in
Bluetooth Support Bluetooth built-in no Bluetooth
Geotagging GPS built-in no internal GPS
Body Specs Olympus E-M1X Olympus E-M5 II
Environmental SealingWeathersealed bodyWeathersealed body
Battery Type Olympus BLH-1 Olympus BLN-1
Battery Life (CIPA)870 shots per charge310 shots per charge
In-Camera Charging USB charging no USB charging
Body Dimensions 144 x 147 x 75 mm
(5.7 x 5.8 x 3.0 in)
124 x 85 x 45 mm
(4.9 x 3.3 x 1.8 in)
Camera Weight 997 g (35.2 oz) 469 g (16.5 oz)
logo
Check E-M1X offers at
ebay.com
logo
Check E-M5 II offers at
ebay.com

Did you notice an error on this page? If so, please get in touch, so that we can correct the information.

You are here Home  »  CAM-parator  »  Olympus E-M1X vs Olympus E-M5 II
