Panasonic GH4 vs GH5s
The Panasonic Lumix DMC-GH4 and the Panasonic Lumix DC-GH5s are two enthusiast cameras that were officially introduced, respectively, in February 2014 and January 2018. Both the GH4 and the GH5s are mirrorless interchangeable lens cameras that are equipped with a Four Thirds sensor. The GH4 has a resolution of 15.9 megapixels, whereas the GH5s provides 9.9 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
Going beyond this snapshot of core features and characteristics, what are the differences between the Panasonic Lumix DMC-GH4 and the Panasonic Lumix DC-GH5s? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
The physical size and weight of the Panasonic GH4 and the Panasonic GH5s are illustrated in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive perspectives from the front, the top, and the back are available. All width, height and depth measures are rounded to the nearest millimeter.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Panasonic GH5s is notably larger (10 percent) than the Panasonic GH4. Moreover, the GH5s is markedly heavier (18 percent) than the GH4. In this context, it is worth noting that both cameras are splash and dust-proof and can, hence, be used in inclement weather conditions or harsh environments.
The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. In this particular case, both cameras feature the same lens mount, so that they can use the same lenses. You can compare the optics available in the Micro Four Thirds Lens Catalog. Mirrorless cameras, such as the two under consideration, have the additional advantage of having a short flange to focal plane distance, which makes it possible to mount many lenses from other systems onto the camera via adapters.
The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you want to switch the focus of the display and review another camera pair, you can move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.
|1.||Panasonic GH4||133 mm||93 mm||84 mm||560 g||500||Y||Feb 2014||1,499|
|2.||Panasonic GH5s||139 mm||98 mm||87 mm||660 g||440||Y||Jan 2018||2,499|
|3.||Olympus E-M5 II||124 mm||85 mm||45 mm||469 g||310||Y||Feb 2015||1,099|
|4.||Olympus E-M1||130 mm||94 mm||63 mm||497 g||350||Y||Sep 2013||1,399|
|5.||Panasonic GH5||139 mm||98 mm||87 mm||725 g||410||Y||Jan 2017||1,999|
|6.||Panasonic G85||128 mm||89 mm||74 mm||505 g||330||Y||Sep 2016||899|
|7.||Panasonic FZ300||132 mm||92 mm||117 mm||691 g||380||Y||Jul 2015||599|
|8.||Panasonic GX8||133 mm||78 mm||63 mm||487 g||330||Y||Jul 2015||1,199|
|9.||Panasonic GM5||99 mm||60 mm||36 mm||211 g||220||n||Sep 2014||749|
|10.||Panasonic G6||122 mm||85 mm||71 mm||390 g||340||n||Apr 2013||599|
|11.||Panasonic GM1||99 mm||55 mm||30 mm||204 g||230||n||Oct 2013||749|
|12.||Panasonic GH3||133 mm||93 mm||82 mm||550 g||540||Y||Sep 2012||1,299|
|13.||Panasonic G2||124 mm||84 mm||74 mm||428 g||360||n||Mar 2010||599|
|14.||Sony A7||127 mm||94 mm||48 mm||474 g||340||Y||Oct 2013||1,699|
|Notes: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.|
Any camera decision will obviously take relative prices into account. The manufacturer’s suggested retail prices give an idea on the placement of the camera in the maker’s lineup and the broader market. The GH4 was launched at a markedly lower price (by 40 percent) than the GH5s, which puts it into a different market segment. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.
The size of the imaging sensor is a crucial determinant of image quality. A large sensor will generally have larger individual pixels that offer better low-light sensitivity, provide wider dynamic range, and have richer color-depth than smaller pixels in a sensor of the same technological generation. Furthermore, a large sensor camera will give the photographer more possibilities to use shallow depth-of-field in order to isolate a subject from the background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.
Both cameras under consideration feature a Four Thirds sensor and have a format factor (sometimes also referred to as "crop factor") of 2.0. Within the spectrum of camera sensors, this places the review cameras among the medium-sized sensor cameras that aim to strike a balance between image quality and portability. Both cameras feature a native aspect ratio (sensor width to sensor height) of 4:3.
While the two cameras under review share the same sensor size, the GH4 offers a higher resolution of 15.9 megapixels, compared with 9.9 MP of the GH5s. This megapixels advantage translates into a 25 percent gain in linear resolution. On the other hand, these sensor specs imply that the GH4 has a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 3.76μm versus 4.77μm for the GH5s). Moreover, it should be noted that the GH5s is much more recent (by 3 years and 11 months) than the GH4, and its sensor will have benefitted from technological advances during this time that further enhance the light gathering capacity of individual pixels. Coming back to sensor resolution, it should be mentioned that the GH5s has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.
The resolution advantage of the Panasonic GH4 implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the GH4 for good quality output (200 dots per inch) amounts to 23 x 17.3 inches or 58.5 x 43.9 cm, for very good quality (250 dpi) 18.4 x 13.8 inches or 46.8 x 35.1 cm, and for excellent quality (300 dpi) 15.4 x 11.5 inches or 39 x 29.3 cm. The corresponding values for the Panasonic GH5s are 18.4 x 13.5 inches or 46.7 x 34.3 cm for good quality, 14.7 x 10.8 inches or 37.4 x 27.4 cm for very good quality, and 12.3 x 9 inches or 31.2 x 22.9 cm for excellent quality prints.
The Panasonic Lumix DMC-GH4 has a native sensitivity range from ISO 200 to ISO 25600, which can be extended to ISO 100-25600. The corresponding ISO settings for the Panasonic Lumix DC-GH5s are ISO 160 to ISO 51200, with the possibility to increase the ISO range to 80-204800.
Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service determines an overall sensor rating, as well as sub-scores for low-light sensitivity ("DXO Sports"), dynamic range ("DXO Landscape"), and color depth ("DXO Portrait"). The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.
|1.||Panasonic GH4||Four Thirds||15.9||4608||3456||4K/30p||23.2||12.8||791||74|
|2.||Panasonic GH5s||Four Thirds||9.9||3680||2700||4K/60p||..||..||..||..|
|3.||Olympus E-M5 II||Four Thirds||15.9||4608||3456||1080/60p||23.0||12.5||842||73|
|4.||Olympus E-M1||Four Thirds||15.9||4608||3456||1080/30p||23.0||12.7||757||73|
|5.||Panasonic GH5||Four Thirds||20.2||5184||3888||4K/60p||23.9||13.0||807||77|
|6.||Panasonic G85||Four Thirds||15.8||4592||3448||4K/30p||22.8||12.5||656||71|
|8.||Panasonic GX8||Four Thirds||20.2||5184||3888||4K/30p||23.5||12.6||806||75|
|9.||Panasonic GM5||Four Thirds||15.8||4592||3448||1080/60p||22.1||11.7||721||66|
|10.||Panasonic G6||Four Thirds||15.9||4608||3456||1080/60p||21.3||11.5||639||61|
|11.||Panasonic GM1||Four Thirds||15.8||4592||3448||1080/60i||22.3||11.7||660||66|
|12.||Panasonic GH3||Four Thirds||15.9||4608||3456||1080/60p||22.7||12.4||812||71|
|13.||Panasonic G2||Four Thirds||12.0||4000||3000||720/30p||21.2||10.3||493||53|
|14.||Sony A7||Full Frame||24.0||6000||4000||1080/60p||24.8||14.2||2248||90|
Many modern cameras cannot only take still pictures, but also record videos. The two cameras under consideration both have sensors whose read-out speed is fast enough to capture moving pictures, but the GH5s provides a faster frame rate than the GH4. It can shoot movie footage at 4K/60p, while the GH4 is limited to 4K/30p.
Beyond body and sensor, cameras can and do differ across a range of features. The two cameras under review are similar with respect to both having an electronic viewfinder. However, the one in the GH5s offers a substantially higher resolution than the one in the GH4 (3680k vs 2359k dots). The following table reports on some other key feature differences and similarities of the Panasonic GH4, the Panasonic GH5s, and comparable cameras.
|1.||Panasonic GH4||2359||n||3.0 / 1036||swivel||Y||1/8000s||12.0||Y||n|
|2.||Panasonic GH5s||3680||n||3.2 / 1620||swivel||Y||1/8000s||12.0||n||n|
|3.||Olympus E-M5 II||2360||n||3.0 / 1037||swivel||Y||1/8000s||10.0||n||Y|
|4.||Olympus E-M1||2360||n||3.0 / 1037||tilting||Y||1/8000s||10.0||n||Y|
|5.||Panasonic GH5||3680||n||3.2 / 1620||swivel||Y||1/8000s||12.0||n||Y|
|6.||Panasonic G85||2360||n||3.0 / 1040||swivel||Y||1/4000s||9.0||Y||Y|
|7.||Panasonic FZ300||1440||n||3.0 / 1040||swivel||Y||1/4000s||12.0||Y||Y|
|8.||Panasonic GX8||2360||n||3.0 / 1040||swivel||Y||1/8000s||10.0||n||Y|
|9.||Panasonic GM5||1166||n||3.0 / 921||fixed||Y||1/500s||5.8||n||n|
|10.||Panasonic G6||1440||n||3.0 / 1036||swivel||Y||1/4000s||7.0||Y||n|
|11.||Panasonic GM1||none||n||3.0 / 1036||fixed||Y||1/500s||5.0||Y||n|
|12.||Panasonic GH3||1746||n||3.0 / 614||swivel||Y||1/4000s||6.0||Y||n|
|13.||Panasonic G2||1440||n||3.0 / 460||swivel||Y||1/4000s||2.6||Y||n|
|14.||Sony A7||2400||n||3.0 / 1230||tilting||n||1/8000s||5.0||n||n|
One difference between the cameras concerns the presence of an on-board flash. The GH4 has one, while the GH5s does not. While the built-in flash of the GH4 is not very powerful, it can at times be useful as a fill-in light.Both cameras have an articulated rear screen that can be turned to be front-facing. This feature will be particularly appreciated by vloggers and photographers who are interested in taking selfies.
The reported shutter speed information refers to the use of the mechanical shutter. Yet, some cameras only have an electronic shutter, while others have an electronic shutter in addition to a mechanical one. In fact, both cameras under consideration feature an electronic shutter, which makes completely silent shooting possible. However, this mode is less suitable for photographing moving objects (risk of rolling shutter) or shooting under artificial light sources (risk of flickering).
The Panasonic GH4 and the Panasonic GH5s both have an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
Concerning the storage of imaging data, both the GH4 and the GH5s write their files to SDXC cards. The GH5s features dual card slots, which can be very useful in case a memory card fails. In contrast, the GH4 only has one slot. The GH5s supports UHS-II cards (on both slots), while the GH4 can use UHS-I cards.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Panasonic Lumix DMC-GH4 and Panasonic Lumix DC-GH5s and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
Mic / Speaker
|1.||Panasonic GH4||Y||stereo / mono||Y||Y||micro||2.0||Y||Y||-|
|2.||Panasonic GH5s||Y||stereo / mono||Y||Y||full||3.1||Y||-||Y|
|3.||Olympus E-M5 II||Y||stereo / mono||Y||-||micro||2.0||Y||-||-|
|4.||Olympus E-M1||Y||stereo / mono||Y||-||micro||2.0||Y||-||-|
|5.||Panasonic GH5||Y||stereo / mono||Y||Y||full||3.1||Y||-||Y|
|6.||Panasonic G85||Y||stereo / mono||Y||-||micro||2.0||Y||-||-|
|7.||Panasonic FZ300||Y||stereo / mono||Y||-||mini||2.0||Y||-||-|
|8.||Panasonic GX8||Y||stereo / mono||Y||-||micro||2.0||Y||Y||-|
|9.||Panasonic GM5||Y||stereo / mono||-||-||micro||2.0||Y||-||-|
|10.||Panasonic G6||Y||stereo / mono||Y||-||mini||2.0||Y||Y||-|
|11.||Panasonic GM1||-||stereo / mono||-||-||micro||2.0||Y||-||-|
|12.||Panasonic GH3||Y||stereo / mono||Y||Y||mini||2.0||Y||-||-|
|13.||Panasonic G2||Y||stereo / mono||-||-||mini||2.0||-||-||-|
|14.||Sony A7||Y||stereo / mono||Y||Y||micro||2.0||Y||Y||-|
Both cameras feature a PC Sync terminal to control professional strobe lights, which will be appreciated by studio photographers.
The GH5s is a recent model that features in the current product line-up of Panasonic. In contrast, the GH4 has been discontinued (but can be found pre-owned on eBay). As a replacement in the same line of cameras, the GH4 was succeeded by the Panasonic GH5. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Panasonic website.
So how do things add up? Is the Panasonic GH4 better than the Panasonic GH5s or vice versa? The listing below highlights the relative strengths of the two models.
Arguments in favor of the Panasonic Lumix DMC-GH4:
- More detail: Offers more megapixels (15.9 vs 9.9MP) with a 26% higher linear resolution.
- Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
- Less heavy: Is lighter (by 100g or 15 percent) and hence easier to carry around.
- Longer lasting: Can take more shots (500 versus 440) on a single battery charge.
- Easier fill-in: Is equipped with a small onboard flash to brighten deep shadow areas.
- Easier device pairing: Supports NFC for fast wireless image transfer over short distances.
- More affordable: Was introduced into a lower priced category (40 percent cheaper at launch).
- More heavily discounted: Has been available for much longer (launched in February 2014).
Reasons to prefer the Panasonic Lumix DC-GH5s:
- Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
- Better video: Provides higher movie framerates (4K/60p versus 4K/30p).
- More detailed viewfinder: Has higher resolution electronic viewfinder (3680k vs 2359k dots).
- Larger viewfinder image: Features a viewfinder with a higher magnification (0.76x vs 0.67x).
- Larger screen: Has a bigger rear LCD (3.2" vs 3.0") for image review and settings control.
- More detailed LCD: Has a higher resolution rear screen (1620k vs 1036k dots).
- Faster data transfer: Supports a more advanced USB protocol (3.1 vs 2.0).
- More solid recording: Has a full-sized HDMI port for a sturdy connection to an external recorder.
- Easier wireless transfer: Supports Bluetooth for image sharing without cables.
- Greater peace of mind: Features a second card slot as a backup in case of memory card failure.
- Faster buffer clearing: Supports a more advanced SD data transfer standard (UHS-II vs UHS-I).
- More modern: Reflects 3 years and 11 months of technical progress since the GH4 launch.
If the count of individual advantages (bullet points above) is taken as a guide, the GH5s is the clear winner of the contest (12 : 8 points). However, the relative importance of the various individual camera aspects will vary according to personal preferences and needs, so that you might like to apply corresponding weights to the particular features before making a decision on a new camera. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Panasonic GH4 and the Panasonic GH5s place the cameras among the top in their class? Find out in the latest Best Mirrorless Interchangeable Lens Camera listing whether the two cameras rank among the cream of the crop.
In any case, while the comparison of the spec-sheets of cameras can offer a general idea of their imaging potential, it says little about, for example, the shooting experience and imaging performance of the GH4 and the GH5s in practical situations. User reviews that are available, for instance, at amazon can sometimes shed light on these issues, but such feedback is all too often partial, inconsistent, and inaccurate.
This is why hands-on reviews by experts are important. The following table reports the overall ratings of the cameras as published by some of the major camera review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|1.||Panasonic GH4||5/5||+ +||..||85/100||5/5||5/5||Feb 2014||1,499|
|2.||Panasonic GH5s||..||..||4.5/5||84/100||4.5/5||4.5/5||Jan 2018||2,499|
|3.||Olympus E-M5 II||5/5||+ +||4.5/5||81/100||5/5||5/5||Feb 2015||1,099|
|4.||Olympus E-M1||5/5||+ +||..||84/100||4.5/5||4.5/5||Sep 2013||1,399|
|5.||Panasonic GH5||4.5/5||+ +||..||85/100||4.5/5||5/5||Jan 2017||1,999|
|6.||Panasonic G85||..||+ +||..||84/100||5/5||4.5/5||Sep 2016||899|
|7.||Panasonic FZ300||..||+ +||..||..||4.5/5||4.5/5||Jul 2015||599|
|8.||Panasonic GX8||5/5||+||..||82/100||4.5/5||4.5/5||Jul 2015||1,199|
|9.||Panasonic GM5||3.5/5||+||..||77/100||5/5||4.5/5||Sep 2014||749|
|10.||Panasonic G6||4/5||+ +||..||..||5/5||4.5/5||Apr 2013||599|
|11.||Panasonic GM1||3/5||+||..||78/100||5/5||4.5/5||Oct 2013||749|
|12.||Panasonic GH3||5/5||+ +||..||79/100||4.5/5||4.5/5||Sep 2012||1,299|
|13.||Panasonic G2||..||..||..||72/100||4/5||4.5/5||Mar 2010||599|
|14.||Sony A7||5/5||+ +||..||80/100||5/5||5/5||Oct 2013||1,699|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
The above review scores should be interpreted with care, though. The ratings were established in reference to similarly priced cameras that were available in the market at the time of the review. Thus, a score needs to be put into the context of the launch date and the launch price of the camera, and rating-comparisons among cameras that span long time periods or concern very differently equipped models make little sense. Also, kindly note that some of the listed sites have over time developped their review approaches and their reporting style.
Other camera comparisons
Did this review help to inform your camera decision process? In case you are interested in seeing how other cameras pair up, just make your choice using the following search menu. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.
- Canon 650D vs Panasonic GH5s
- Canon 90D vs Panasonic GH4
- Canon T5 vs Panasonic GH4
- Canon T7i vs Panasonic GH4
- Leica M8 vs Panasonic GH4
- Leica V-LUX 2 vs Panasonic GH5s
- Nikon D4S vs Panasonic GH5s
- Nikon D5 vs Panasonic GH5s
- Panasonic GF1 vs Panasonic GH4
- Panasonic GH1 vs Panasonic GH5s
- Panasonic GH4 vs Panasonic S5
- Panasonic GH5s vs Sony NEX-6
Specifications: Panasonic GH4 vs Panasonic GH5s
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Panasonic GH4||Panasonic GH5s|
|Camera Type||Mirrorless system camera||Mirrorless system camera|
|Camera Lens||Micro Four Thirds lenses||Micro Four Thirds lenses|
|Launch Date||February 2014||January 2018|
|Launch Price||USD 1,499||USD 2,499|
|Sensor Specs||Panasonic GH4||Panasonic GH5s|
|Sensor Format||Four Thirds Sensor||Four Thirds Sensor|
|Sensor Size||17.3 x 13.0 mm||17.3 x 13.0 mm|
|Sensor Area||224.9 mm2||224.9 mm2|
|Sensor Diagonal||21.6 mm||21.6 mm|
|Sensor Resolution||15.9 Megapixels||9.9 Megapixels|
|Image Resolution||4608 x 3456 pixels||3680 x 2700 pixels|
|Pixel Pitch||3.76 μm||4.77 μm|
|Pixel Density||7.08 MP/cm2||4.42 MP/cm2|
|Moiré control||Anti-Alias filter||no AA filter|
|Movie Capability||4K/30p Video||4K/60p Video|
|ISO Setting||200 - 25,600 ISO||160 - 51,200 ISO|
|ISO Boost||100 - 25,600 ISO||80 - 204,800 ISO|
|Image Processor||Venus IX||Venus 10|
|DXO Sensor Quality (score)||74||..|
|DXO Color Depth (bits)||23.2||..|
|DXO Dynamic Range (EV)||12.8||..|
|DXO Low Light (ISO)||791||..|
|Screen Specs||Panasonic GH4||Panasonic GH5s|
|Viewfinder Type||Electronic viewfinder||Electronic viewfinder|
|Viewfinder Field of View||100%||100%|
|Viewfinder Resolution||2359k dots||3680k dots|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0inch||3.2inch|
|LCD Resolution||1036k dots||1620k dots|
|LCD Attachment||Swivel screen||Swivel screen|
|Shooting Specs||Panasonic GH4||Panasonic GH5s|
|Focus System||Contrast-detect AF||Contrast-detect AF|
|Manual Focusing Aid||Focus Peaking||Focus Peaking|
|Max Shutter Speed (mechanical)||1/8000s||1/8000s|
|Continuous Shooting||12 shutter flaps/s||12 shutter flaps/s|
|Shutter Life Expectancy||200 000 actuations||200 000 actuations|
|Electronic Shutter||up to 1/8000s||up to 1/16000s|
|Time-Lapse Photography||Intervalometer built-in||Intervalometer built-in|
|Fill Flash||Built-in Flash||no On-Board Flash|
|Storage Medium||SDXC cards||SDXC cards|
|Second Storage Option||Single card slot||Dual card slots|
|UHS card support||UHS-I||Dual UHS-II|
|Connectivity Specs||Panasonic GH4||Panasonic GH5s|
|Studio Flash||PC Sync socket||PC Sync socket|
|USB Connector||USB 2.0||USB 3.1|
|HDMI Port||micro HDMI||full HDMI|
|Microphone Port||External MIC port||External MIC port|
|Headphone Socket||Headphone port||Headphone port|
|Wifi Support||Wifi built-in||Wifi built-in|
|Near-Field Communication||NFC built-in||no NFC|
|Bluetooth Support||no Bluetooth||Bluetooth built-in|
|Body Specs||Panasonic GH4||Panasonic GH5s|
|Environmental Sealing||Weathersealed body||Weathersealed body|
|Battery Life (CIPA)||500 shots per charge||440 shots per charge|
133 x 93 x 84 mm
(5.2 x 3.7 x 3.3 in)
139 x 98 x 87 mm
(5.5 x 3.9 x 3.4 in)
|Camera Weight||560 g (19.8 oz)||660 g (23.3 oz)|
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
