Canon 70D vs Leica D-LUX Typ 109
The Canon EOS 70D and the Leica D-LUX (Typ 109) are two enthusiast cameras that were announced, respectively, in July 2013 and September 2014. The 70D is a DSLR, while the D-LUX Typ 109 is a fixed lens compact. The cameras are based on an APS-C (70D) and a Four Thirds (D-LUX Typ 109) sensor. The Canon has a resolution of 20 megapixels, whereas the Leica provides 12.7 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
|Canon 70D||Leica D-LUX Typ 109|
|Digital single lens reflex||Fixed lens compact camera|
|Canon EF mount lenses||24-75mm f/1.7-2.8|
|20 MP, APS-C Sensor||12.7 MP, Four Thirds Sensor|
|1080/30p Video||4K/30p Video|
|ISO 100-12,800 (100 - 25,600)||ISO 200-12,500 (100 - 25,600)|
|Optical viewfinder||Electronic viewfinder (2764k dots)|
|3.0 LCD, 1040k dots||3.0 LCD, 921k dots|
|Swivel touchscreen||Fixed screen (not touch-sensitive)|
|7 shutter flaps per second||11 shutter flaps per second|
|Weathersealed body||not weather sealed|
|920 shots per battery charge||300 shots per battery charge|
|139 x 104 x 79 mm, 755 g||118 x 66 x 55 mm, 405 g|
Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS 70D and the Leica D-LUX (Typ 109)? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
The physical size and weight of the Canon 70D and the Leica D-LUX Typ 109 are illustrated in the side-by-side display below. The two cameras are presented according to their relative size. Three successive views from the front, the top, and the rear are shown. All size dimensions are rounded to the nearest millimeter.
The D-LUX Typ 109 can be obtained in two different colors (black, grey), while the 70D is only available in black.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Leica D-LUX Typ 109 is considerably smaller (46 percent) than the Canon 70D. It is worth mentioning in this context that the 70D is splash and dust resistant, while the D-LUX Typ 109 does not feature any corresponding weather-sealing.
The above size and weight comparisons are to some extent incomplete and possibly misleading, as the D-LUX Typ 109 has a lens built in, whereas the 70D is an interchangeable lens camera that requires a separate lens. Attaching the latter will add extra weight and bulk to the setup. You can compare the optics available for the 70D and their specifications in the Canon EF Lens Catalog.
The following table provides a synthesis of the main physical specifications of the two cameras and other similar ones. In case you want to display and compare another camera duo, just click on the right or left arrow next to the camera that you would like to inspect. Alternatively, you can also use the CAM-parator to select your camera combination among a larger number of options.
|Canon 70D||5.5 in||4.1 in||3.1 in||26.6 oz||920||Y||Jul 2013||1,199|
|Leica D-LUX Typ 109||4.6 in||2.6 in||2.2 in||14.3 oz||300||n||Sep 2014||1,195|
|Canon 80D||5.5 in||4.1 in||3.1 in||25.8 oz||960||Y||Feb 2016||1,199|
|Canon G3 X||4.8 in||3.0 in||4.1 in||25.9 oz||300||Y||Jun 2015||999|
|Canon 7D II||5.9 in||4.4 in||3.1 in||32.1 oz||670||Y||Sep 2014||1,799|
|Canon T5||5.1 in||3.9 in||3.1 in||16.9 oz||500||n||Feb 2014||449|
|Canon G16||4.3 in||3.0 in||1.6 in||12.6 oz||360||n||Aug 2013||549|
|Canon 6D||5.7 in||4.4 in||2.8 in||27.2 oz||1090||Y||Sep 2012||2,099|
|Canon 60D||5.7 in||4.2 in||3.1 in||26.6 oz||1100||Y||Aug 2010||1,399|
|Canon 7D||5.8 in||4.4 in||2.9 in||30.3 oz||800||Y||Sep 2009||1,699|
|Canon 50D||5.7 in||4.3 in||2.9 in||29.0 oz||800||Y||Aug 2008||1,299|
|Fujifilm X100T||5.0 in||2.9 in||2.0 in||15.5 oz||330||n||Sep 2014||1,299|
|Fujifilm X100S||5.0 in||2.9 in||2.1 in||15.7 oz||330||n||Jan 2013||1,299|
|Leica D-LUX 7||4.5 in||2.6 in||2.6 in||13.8 oz||300||n||Nov 2018||1,195|
|Leica X Typ 113||5.2 in||2.9 in||3.1 in||17.1 oz||350||n||Sep 2014||2,295|
|Nikon D7100||5.4 in||4.2 in||3.0 in||27.0 oz||950||Y||Feb 2013||1,199|
|Sony RX10||5.1 in||3.5 in||4.0 in||28.7 oz||420||Y||Oct 2013||1,299|
Notes: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
(1) Number of images that can be taken on a full battery charge according to the CIPA-standard; (2) Official announcement.
Any camera decision will obviously take relative prices into account. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The D-LUX Typ 109 was launched at a lower price than the 70D, despite having a lens built in. Normally, street prices remain initially close to the MSRP, but after a couple of months, the first discounts appear. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.
The size of the sensor inside a digital camera is one of the key determinants of image quality. A large sensor will generally have larger individual pixels that offer better low-light sensitivity, provide wider dynamic range, and have richer color-depth than smaller pixels in a sensor of the same technological generation. Furthermore, a large sensor camera will give the photographer more possibilities to use shallow depth-of-field in order to isolate a subject from the background. On the downside, larger sensors tend to be more expensive and lead to bigger and heavier cameras and lenses.
Of the two cameras under consideration, the Canon 70D features an APS-C sensor and the Leica D-LUX Typ 109 a Four Thirds sensor. The sensor area in the D-LUX Typ 109 is 33 percent smaller. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.6 and 2.0. The sensor in the 70D has a native 3:2 aspect ratio, while the one in the D-LUX Typ 109 offers a 4:3 aspect. The D-LUX Typ 109 has the particularity of featuring a switch that allows to toggle between multiple aspect ratios, while maintaining the same field of view and full image resolution.
In terms of underlying technology, both cameras are build around CMOS sensors.
With 20MP, the 70D offers a higher resolution than the D-LUX Typ 109 (12.7MP), but the 70D has marginally smaller individual pixels (pixel pitch of 4.11μm versus 4.21μm for the D-LUX Typ 109). Moreover, the D-LUX Typ 109 is a somewhat more recent model (by 1 year and 2 months) than the 70D, and its sensor might have benefitted from technological advances during this time that further enhance the light gathering capacity of its pixels.
The resolution advantage of the Canon 70D implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the 70D for good quality output (200 dots per inch) amounts to 27.4 x 18.2 inches or 69.5 x 46.3 cm, for very good quality (250 dpi) 21.9 x 14.6 inches or 55.6 x 37.1 cm, and for excellent quality (300 dpi) 18.2 x 12.2 inches or 46.3 x 30.9 cm. The corresponding values for the Leica D-LUX Typ 109 are 20.6 x 15.4 inches or 52.2 x 39.2 cm for good quality, 16.4 x 12.4 inches or 41.8 x 31.4 cm for very good quality, and 13.7 x 10.3 inches or 34.8 x 26.1 cm for excellent quality prints.
The 70D has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.
The Canon EOS 70D has a native sensitivity range from ISO 100 to ISO 12800, which can be extended to ISO 100-25600. The corresponding ISO settings for the Leica D-LUX (Typ 109) are ISO 200 to ISO 12500, with the possibility to increase the ISO range to 100-25600.
For many cameras, data on sensor performance has been reported by DXO Mark. This service assesses and scores the color depth ("DXO Portrait"), dynamic range ("DXO Landscape"), and low-light sensitivity ("DXO Sports") of camera sensors, and also publishes an overall camera score. The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.
|Leica D-LUX Typ 109||Four Thirds||12.7||4112||3088||4K/30p||..||..||..||..|
|Canon G3 X||1-inch||20.0||5472||3648||1080/60p||21.4||12.3||521||63|
|Canon 7D II||APS-C||20.0||5472||3648||1080/60p||22.4||11.8||1082||70|
|Canon 6D||Full Frame||20.0||5472||3648||1080/30p||23.8||12.1||2340||82|
|Leica D-LUX 7||Four Thirds||16.8||4736||3552||4K/30p||..||..||..||..|
|Leica X Typ 113||APS-C||16.1||4928||3264||1080/30p||..||..||..||..|
Many modern cameras cannot only take still pictures, but also record videos. Both cameras under consideration have a sensor with sufficiently fast read-out times for moving pictures, but the D-LUX Typ 109 provides a better video resolution than the 70D. It can shoot movie footage at 4K/30p, while the Canon is limited to 1080/30p.
Apart from body and sensor, cameras can and do differ across a variety of features. For example, the D-LUX Typ 109 has an electronic viewfinder (2764k dots), while the 70D has an optical one. Both systems have their advantages, with the electronic viewfinder making it possible to project supplementary shooting information into the framing view, whereas the optical viewfinder offers lag-free viewing and a very clear framing image. The viewfinder in the D-LUX Typ 109 offers a wider field of view (100%) than the one in the 70D (98%), so that a larger proportion of the captured image is visible in the finder. In addition, the viewfinder of the D-LUX Typ 109 has a higher magnification (0.70x vs 0.59x), so that the size of the image transmitted appears closer to the size seen with the naked human eye. The adjacent table lists some of the other core features of the Canon 70D and Leica D-LUX Typ 109 along with similar information for a selection of comparators.
|Leica D-LUX Typ 109||2764||n||3.0||921||fixed||n||1/4000s||11.0||n||Y|
|Canon G3 X||optional||n||3.2||1620||tilting||Y||1/2000s||5.9||Y||Y|
|Canon 7D II||optical||Y||3.0||1040||fixed||n||1/8000s||10.0||Y||n|
|Leica D-LUX 7||2764||n||3.0||1240||fixed||Y||1/4000s||11.0||n||Y|
|Leica X Typ 113||optional||n||3.0||920||fixed||n||1/2000s||5.0||Y||n|
One difference between the cameras concerns the presence of an on-board flash. The 70D has one, while the D-LUX Typ 109 does not. While the built-in flash of the 70D is not very powerful, it can at times be useful as a fill-in light.The 70D has an articulated LCD that can be turned to be front-facing. This characteristic will be appreciated by vloggers and photographers who are interested in snapping selfies. In contrast, the D-LUX Typ 109 does not have a selfie-screen.
The reported shutter speed information refers to the use of the mechanical shutter. Yet, some cameras only have an electronic shutter, while others have an electronic shutter in addition to a mechanical one. In fact, the D-LUX Typ 109 is one of those camera that have an additional electronic shutter, which makes completely silent shooting possible. However, this mode is less suitable for photographing moving objects (risk of rolling shutter) or shooting under artificial light sources (risk of flickering).
The Leica D-LUX Typ 109 has an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
Concerning the storage of imaging data, both the 70D and the D-LUX Typ 109 write their files to SDXC cards. Both cameras can use UHS-I cards, which provide for Ultra High Speed data transfer of up to 104 MB/s.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS 70D and Leica D-LUX (Typ 109) and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
| WiFi |
|Leica D-LUX Typ 109||Y||stereo||mono||-||-||micro||2.0||Y||Y||-|
|Canon G3 X||Y||stereo||mono||Y||Y||mini||2.0||Y||Y||-|
|Canon 7D II||Y||stereo||mono||Y||Y||mini||3.0||-||-||-|
|Leica D-LUX 7||Y||stereo||mono||-||-||micro||2.0||Y||-||Y|
|Leica X Typ 113||Y||stereo||mono||-||-||mini||2.0||-||-||-|
It is notable that the 70D has a microphone port, which is missing on the D-LUX Typ 109. Such an external microphone input can help to substantially improve the quality of audio recordings when a good external microphone is used.
Both the 70D and the D-LUX Typ 109 have been discontinued, but can regularly be found used on eBay. The 70D was replaced by the Canon 80D, while the D-LUX Typ 109 was followed by the Leica D-LUX 7. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Canon and Leica websites.
So what conclusions can be drawn? Is there a clear favorite between the Canon 70D and the Leica D-LUX Typ 109? Which camera is better? Below is a summary of the relative strengths of each of the two contestants.
Arguments in favor of the Canon EOS 70D:
- More detail: Offers more megapixels (20 vs 12.7MP) with a 28% higher linear resolution.
- Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
- Better sound: Can connect to an external microphone for higher quality sound recording.
- Brighter framing: Features an optical viewfinder for clear, lag-free composition.
- Easier setting verification: Features an LCD display on top to control shooting parameters.
- More detailed LCD: Has a higher resolution rear screen (1040k vs 921k dots).
- More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
- Fewer buttons to press: Is equipped with a touch-sensitive rear screen to facilitate handling.
- More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
- Faster shutter: Has higher mechanical shutter speed (1/8000s vs 1/4000s) to freeze action.
- More flexible: Can take a variety of interchangeable lenses, including specialty optics.
- Longer lasting: Can take more shots (920 versus 300) on a single battery charge.
- Better sealing: Is weather sealed to enable shooting in dusty or wet environments.
- Easier fill-in: Is equipped with a small onboard flash to brighten deep shadow areas.
- More heavily discounted: Has been on the market for longer (launched in July 2013).
Advantages of the Leica D-LUX (Typ 109):
- Flexible image proportions: Has a multi-aspect sensor that allows for alternative image shapes.
- Better video: Provides higher definition movie capture (4K/30p vs 1080/30p).
- More framing info: Has an electronic viewfinder that displays shooting data.
- More complete view: Has a viewfinder with a larger field of view (100% vs 98%).
- Larger viewfinder image: Features a viewfinder with a higher magnification (0.70x vs 0.59x).
- Faster burst: Shoots at higher frequency (11 vs 7 flaps/sec) to capture the decisive moment.
- Less disturbing: Has an electronic shutter option for completely silent shooting.
- Easier time-lapse photography: Has an intervalometer built-in for low frequency shooting.
- Ready to shoot: Comes with an integrated lens, while the 70D requires a separate lens.
- More compact: Is smaller (118x66mm vs 139x104mm) and will fit more readily into a bag.
- Less heavy: Has a lower weight even though it has a lens built in (unlike the 70D).
- Sharper images: Has stabilization technology built-in to reduce the impact of hand-shake.
- Easier device pairing: Supports NFC for fast wireless image transfer over short distances.
- More prestigious: Has the Leica luxury appeal, which ensures a high resale value.
- More affordable: Was introduced at a lower price, despite coming with a built-in lens.
- More modern: Was introduced somewhat (1 year and 2 months) more recently.
If the number of relative strengths (bullet points above) is taken as a guide, the D-LUX Typ 109 comes out slightly ahead of the 70D (16 : 15 points). However, the pertinence of the various camera strengths will differ across photographers, so that you might want to weigh individual camera traits according to their importance for your own imaging needs before making a camera decision. A professional sports photographer will view the differences between cameras in a way that diverges from the perspective of a street photog, and a person interested in family portraits has distinct needs from a landscape shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Canon 70D and the Leica D-LUX Typ 109 place the cameras among the top in their class? Find out in the latest Best DSLR Camera and Best Travel-Zoom Camera listings whether the two cameras rank among the cream of the crop.
In any case, while the comparison of the spec-sheets of cameras can offer a general idea of their imaging potential, it says little about, for example, the shooting experience and imaging performance of the 70D and the D-LUX Typ 109 in practical situations. User reviews, such as those found at amazon, can sometimes inform about these issues, but such feedback is often incomplete, inconsistent, and biased.
This is where reviews by experts come in. The following table reports the overall ratings of the cameras as published by some of the major camera review sites (cameralabs, dpreview, ephotozine, imaging-resource, and photographyblog). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|Canon 70D||+ +||83/100||4.5/5||4.5/5||5/5||Jul 2013||1,199|
|Leica D-LUX Typ 109||..||..||4.5/5||..||4.5/5||Sep 2014||1,195|
|Canon 80D||+ +||84/100||4.5/5||4.5/5||4.5/5||Feb 2016||1,199|
|Canon G3 X||+||..||4.5/5||3.5/5||4/5||Jun 2015||999|
|Canon 7D II||+||84/100||4/5||5/5||4.5/5||Sep 2014||1,799|
|Canon T5||+||..||4/5||4/5||4.5/5||Feb 2014||449|
|Canon G16||+||..||4.5/5||4.5/5||4.5/5||Aug 2013||549|
|Canon 6D||+ +||83/100||4.5/5||4.5/5||4.5/5||Sep 2012||2,099|
|Canon 60D||+||79/100||4/5||5/5||4.5/5||Aug 2010||1,399|
|Canon 7D||+ +||84/100||4.5/5||5/5||4.5/5||Sep 2009||1,699|
|Canon 50D||+ +||+ +||4.5/5||5/5||4.5/5||Aug 2008||1,299|
|Fujifilm X100T||+||81/100||4.5/5||4.5/5||5/5||Sep 2014||1,299|
|Fujifilm X100S||+ +||81/100||4.5/5||4/5||5/5||Jan 2013||1,299|
|Leica D-LUX 7||..||..||..||..||4.5/5||Nov 2018||1,195|
|Leica X Typ 113||..||..||3.5/5||..||4/5||Sep 2014||2,295|
|Nikon D7100||+ +||85/100||4.5/5||5/5||4.5/5||Feb 2013||1,199|
|Sony RX10||+||80/100||4.5/5||4.5/5||4.5/5||Oct 2013||1,299|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
Care should be taken when interpreting the review scores above, though. The ratings are only valid when referring to cameras in the same category and of the same age. A score, therefore, has to be seen in close connection to the price and market introduction time of the camera, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, kindly note that some of the listed sites have over time developped their review approaches and their reporting style.
Other camera comparisons
Did this review help to inform your camera decision process? If you would like to see a different side-by-side camera review, just make a corresponding selection in the search boxes below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.
- Canon 1000D vs Canon 70D
- Canon 1D Mark IV vs Canon 70D
- Canon 70D vs Leica M-E Typ 240
- Canon 70D vs Nikon D3200
- Canon 70D vs Nikon L840
- Canon 70D vs Olympus E-P1
- Canon 70D vs Panasonic GH2
- Fujifilm X-A7 vs Leica D-LUX Typ 109
- Kodak AZ901 vs Leica D-LUX Typ 109
- Leica D-LUX 7 vs Leica D-LUX Typ 109
- Leica D-LUX Typ 109 vs Nikon Df
- Leica D-LUX Typ 109 vs Olympus E-M5
Specifications: Canon 70D vs Leica D-LUX Typ 109
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Canon 70D||Leica D-LUX Typ 109|
|Camera Type||Digital single lens reflex||Fixed lens compact camera|
|Camera Lens||Canon EF mount lenses||24-75mm f/1.7-2.8|
|Launch Date||July 2013||September 2014|
|Launch Price||USD 1,199||USD 1,195|
|Sensor Specs||Canon 70D||Leica D-LUX Typ 109|
|Sensor Format||APS-C Sensor||Four Thirds Sensor|
|Sensor Size||22.5 x 15.0 mm||17.3 x 13.0 mm|
|Sensor Area||337.5 mm2||224.9 mm2|
|Sensor Diagonal||27 mm||21.6 mm|
|Sensor Resolution||20 Megapixels||12.7 Megapixels|
|Image Resolution||5472 x 3648 pixels||4112 x 3088 pixels|
|Pixel Pitch||4.11 μm||4.21 μm|
|Pixel Density||5.91 MP/cm2||5.65 MP/cm2|
|Moiré control||Anti-Alias filter||Anti-Alias filter|
|Movie Capability||1080/30p Video||4K/30p Video|
|ISO Setting||100 - 12,800 ISO||200 - 12,500 ISO|
|ISO Boost||100 - 25,600 ISO||100 - 25,600 ISO|
|DXO Sensor Quality (score)||68||..|
|DXO Color Depth (bits)||22.5||..|
|DXO Dynamic Range (EV)||11.6||..|
|DXO Low Light (ISO)||926||..|
|Screen Specs||Canon 70D||Leica D-LUX Typ 109|
|Viewfinder Type||Optical viewfinder||Electronic viewfinder|
|Viewfinder Field of View||98%||100%|
|Viewfinder Resolution||2764k dots|
|Top-Level Screen||Control Panel||no Top Display|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0inch||3.0inch|
|LCD Resolution||1040k dots||921k dots|
|LCD Attachment||Swivel screen||Fixed screen|
|Touch Input||Touchscreen||no Touchscreen|
|Shooting Specs||Canon 70D||Leica D-LUX Typ 109|
|Focus System||Phase-detect AF||Contrast-detect AF|
|Manual Focusing Aid||no Peaking Feature||Focus Peaking|
|Max Shutter Speed (mechanical)||1/8000s||1/4000s|
|Continuous Shooting||7 shutter flaps/s||11 shutter flaps/s|
|Electronic Shutter||no E-Shutter||up to 1/16000s|
|Time-Lapse Photography||no Intervalometer||Intervalometer built-in|
|Fill Flash||Build-in Flash||no On-Board Flash|
|Storage Medium||SDXC cards||SDXC cards|
|Second Storage Option||Single card slot||Single card slot|
|UHS card support||UHS-I||UHS-I|
|Connectivity Specs||Canon 70D||Leica D-LUX Typ 109|
|USB Connector||USB 2.0||USB 2.0|
|HDMI Port||mini HDMI||micro HDMI|
|Microphone Port||External MIC port||no MIC socket|
|Wifi Support||Wifi built-in||Wifi built-in|
|Near-Field Communication||no NFC||NFC built-in|
|Body Specs||Canon 70D||Leica D-LUX Typ 109|
|Environmental Sealing||Weathersealed body||not weather sealed|
|Battery Life (CIPA)||920 shots per charge||300 shots per charge|
139 x 104 x 79 mm
(5.5 x 4.1 x 3.1 in)
118 x 66 x 55 mm
(4.6 x 2.6 x 2.2 in)
|Camera Weight||755 g (26.6 oz)||405 g (14.3 oz)|
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
