Canon 5DS R vs Epson R-D1
The Canon EOS 5DS R and the Epson R-D1 are two digital cameras that were officially introduced, respectively, in February 2015 and March 2004. The 5DS R is a DSLR, while the R-D1 is a rangefinder-style mirrorless camera. The cameras are based on a full frame (5DS R) and an APS-C (R-D1) sensor. The Canon has a resolution of 50.3 megapixels, whereas the Epson provides 6 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS 5DS R and the Epson R-D1? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
The physical size and weight of the Canon 5DS R and the Epson R-D1 are illustrated in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive views from the front, the top, and the rear side are shown. All width, height and depth dimensions are rounded to the nearest millimeter.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Epson R-D1 is notably smaller (28 percent) than the Canon 5DS R. Moreover, the R-D1 is markedly lighter (33 percent) than the 5DS R. It is worth mentioning in this context that the 5DS R is splash and dust resistant, while the R-D1 does not feature any corresponding weather-sealing.
The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. A larger imaging sensor will tend to go along with bigger and heavier lenses, although exceptions exist. You can compare the optics available for the two cameras in the Canon EF Lens Catalog (5DS R) and the Leica M Lens Catalog (R-D1).
The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you would like to visualize and compare a different camera combination, just use the right or left arrows in the table to switch to the respective camera. Alternatively, you can also navigate to the CAM-parator app and make your selection from the full list of cameras there.
|Canon 5DS R||6.0 in||4.6 in||3.0 in||32.8 oz||700||Y||Feb 2015||3,699|
|Epson R-D1||5.6 in||3.5 in||1.6 in||21.9 oz||..||n||Mar 2004||2,999|
|Canon 1D X Mark II||6.2 in||6.6 in||3.3 in||54.0 oz||1210||Y||Feb 2016||5,999|
|Canon 5D Mark IV||5.9 in||4.6 in||3.0 in||31.4 oz||900||Y||Aug 2016||3,499|
|Canon 5DS||6.0 in||4.6 in||3.0 in||32.8 oz||700||Y||Feb 2015||3,699|
|Canon 5D Mark III||6.0 in||4.6 in||3.0 in||33.5 oz||950||Y||Mar 2012||3,499|
|Canon 6D||5.7 in||4.4 in||2.8 in||27.2 oz||1090||Y||Sep 2012||2,099|
|Canon 5D Mark II||6.0 in||4.5 in||3.0 in||30.0 oz||850||Y||Sep 2008||3,499|
|Canon 5D||6.0 in||4.4 in||3.0 in||31.6 oz||400||Y||Aug 2005||3,299|
|Canon Rebel||5.6 in||3.9 in||2.8 in||22.9 oz||400||n||Aug 2003||899|
|Leica X Vario||5.2 in||2.9 in||3.7 in||24.0 oz||450||n||Jun 2013||2,850|
|Nikon D850||5.7 in||4.9 in||3.1 in||35.5 oz||1840||Y||Jul 2017||3,299|
|Nikon D810||5.7 in||4.8 in||3.2 in||34.6 oz||1200||Y||Jun 2014||3,299|
|Nikon D50||5.2 in||4.0 in||3.0 in||21.9 oz||400||n||Apr 2005||749|
|Nikon D70s||5.5 in||4.4 in||3.1 in||24.0 oz||500||n||Apr 2005||899|
|Nikon D70||5.5 in||4.4 in||3.1 in||24.0 oz||400||n||Jan 2004||999|
|Sony A99 II||5.6 in||4.1 in||3.0 in||29.9 oz||490||Y||Sep 2016||3,199|
Notes: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
(1) Number of images that can be taken on a full battery charge according to the CIPA-standard; (2) Official announcement.
The price is, of course, an important factor in any camera decision. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The R-D1 was launched at a somewhat lower price (by 19 percent) than the 5DS R, which makes it more attractive for photographers on a tight budget. Normally, street prices remain initially close to the MSRP, but after a couple of months, the first discounts appear. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.
The size of the imaging sensor is a crucial determinant of image quality. All other things equal, a large sensor will have larger individual pixel-units that offer better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixels in a sensor of the same technological generation. Moreover, a large sensor camera will give the photographer more control over depth-of-field in the image and, thus, the ability to better isolate a subject from the background. On the downside, larger sensors tend to be associated with larger, more expensive camera bodies and lenses.
Of the two cameras under consideration, the Canon 5DS R features a full frame sensor and the Epson R-D1 an APS-C sensor. The sensor area in the R-D1 is 57 percent smaller. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.0 and 1.5. Both cameras have a native aspect ratio (sensor width to sensor height) of 3:2.
With 50.3MP, the 5DS R offers a higher resolution than the R-D1 (6MP), but the 5DS R has smaller individual pixels (pixel pitch of 4.14μm versus 7.85μm for the R-D1). However, the 5DS R is a much more recent model (by 10 years and 10 months) than the R-D1, and its sensor will have benefitted from technological advances during this time that enhance the light gathering capacity of its pixels. Coming back to sensor resolution, it should be mentioned that the 5DS R has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.
The resolution advantage of the Canon 5DS R implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the 5DS R for good quality output (200 dots per inch) amounts to 43.4 x 29 inches or 110.3 x 73.6 cm, for very good quality (250 dpi) 34.8 x 23.2 inches or 88.3 x 58.8 cm, and for excellent quality (300 dpi) 29 x 19.3 inches or 73.6 x 49 cm. The corresponding values for the Epson R-D1 are 15 x 10 inches or 38.2 x 25.4 cm for good quality, 12 x 8 inches or 30.6 x 20.3 cm for very good quality, and 10 x 6.7 inches or 25.5 x 16.9 cm for excellent quality prints.
The Canon EOS 5DS R has a native sensitivity range from ISO 100 to ISO 6400, which can be extended to ISO 50-12800. The corresponding ISO settings for the Epson R-D1 are ISO 200 to ISO 1600 (no boost).
For many cameras, data on sensor performance has been reported by DXO Mark. This service determines an overall sensor rating, as well as sub-scores for low-light sensitivity ("DXO Sports"), dynamic range ("DXO Landscape"), and color depth ("DXO Portrait"). The table below summarizes the physical sensor characteristics and sensor quality findings and compares them across a set of similar cameras.
|Canon 5DS R||Full Frame||50.3||8688||5792||1080/30p||24.6||12.4||2308||86|
|Canon 1D X Mark II||Full Frame||20.0||5472||3648||4K/60p||24.1||13.5||3207||88|
|Canon 5D Mark IV||Full Frame||30.1||6720||4480||4K/30p||24.8||13.6||2995||91|
|Canon 5DS||Full Frame||50.3||8688||5792||1080/30p||24.7||12.4||2381||87|
|Canon 5D Mark III||Full Frame||22.1||5760||3840||1080/30p||24.0||11.7||2293||81|
|Canon 6D||Full Frame||20.0||5472||3648||1080/30p||23.8||12.1||2340||82|
|Canon 5D Mark II||Full Frame||21.0||5616||3744||1080/30p||23.7||11.9||1815||79|
|Canon 5D||Full Frame||12.7||4368||2912||none||22.9||11.1||1368||71|
|Leica X Vario||APS-C||16.1||4928||3272||1080/30p||23.4||12.7||1320||78|
|Nikon D850||Full Frame||45.4||8256||5504||4K/30p||26.4||14.8||2660||100|
|Nikon D810||Full Frame||36.2||7360||4912||1080/60p||25.7||14.8||2853||97|
|Sony A99 II||Full Frame||42.2||7952||5304||4K/30p||25.4||13.4||2317||92|
Many modern cameras are not only capable of taking still images, but also of capturing video footage. The 5DS R indeed provides movie recording capabilities, while the R-D1 does not. The highest resolution format that the 5DS R can use is 1080/30p.
Apart from body and sensor, cameras can and do differ across a range of features. The 5DS R and the R-D1 are similar in the sense that both have an optical viewfinder. The latter is useful for getting a clear image for framing even in brightly lit environments. The adjacent table lists some of the other core features of the Canon 5DS R and Epson R-D1 along with similar information for a selection of comparators.
|Canon 5DS R||optical||Y||3.2||1040||fixed||n||1/8000s||5.0||n||n|
|Canon 1D X Mark II||optical||Y||3.2||1620||fixed||Y||1/8000s||16.0||n||n|
|Canon 5D Mark IV||optical||Y||3.2||1620||fixed||Y||1/8000s||7.0||n||n|
|Canon 5D Mark III||optical||Y||3.2||1040||fixed||n||1/8000s||6.0||n||n|
|Canon 5D Mark II||optical||Y||3.0||920||fixed||n||1/8000s||3.9||n||n|
|Leica X Vario||optional||n||3.0||920||fixed||n||1/2000s||5.0||Y||n|
|Sony A99 II||2400||Y||3.0||1229||full-flex||n||1/8000s||12.0||n||Y|
One feature that is present on the 5DS R, but is missing on the R-D1 is a top-level LCD. While being, of course, smaller than the rear screen, the control panel conveys some of the essential shooting information and can be convenient for quick and easy settings verification.
The Canon 5DS R has an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
The 5DS R writes its imaging data to Compact Flash or SDXC cards, while the R-D1 uses SDHC cards. The 5DS R features dual card slots, which can be very useful in case a memory card fails. In contrast, the R-D1 only has one slot. The 5DS R supports UHS-I cards (Ultra High Speed data transfer of up to 104 MB/s), while the R-D1 cannot take advantage of Ultra High Speed SD cards.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS 5DS R and Epson R-D1 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
| WiFi |
|Canon 5DS R||Y||mono||mono||Y||-||mini||3.0||-||-||-|
|Canon 1D X Mark II||Y||mono||mono||Y||Y||mini||3.0||-||-||-|
|Canon 5D Mark IV||Y||mono||mono||Y||Y||mini||3.0||Y||Y||-|
|Canon 5D Mark III||Y||mono||mono||Y||Y||mini||2.0||-||-||-|
|Canon 5D Mark II||Y||mono||mono||Y||-||mini||2.0||-||-||-|
|Leica X Vario||Y||stereo||mono||-||-||mini||2.0||-||-||-|
|Sony A99 II||Y||stereo||mono||Y||Y||micro||2.0||Y||Y||Y|
Both cameras feature a PC Sync terminal to control professional strobe lights, which will be appreciated by studio photographers.
The 5DS R is a recent model that features in the current product line-up of Canon. In contrast, the R-D1 has been discontinued (but can be found pre-owned on eBay). There has not been a direct replacement model for the R-D1 from Epson. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Canon and Epson websites.
So how do things add up? Is there a clear favorite between the Canon 5DS R and the Epson R-D1? Which camera is better? A synthesis of the relative strong points of each of the models is listed below.
Advantages of the Canon EOS 5DS R:
- More detail: Offers more megapixels (50.3 vs 6MP) with a 189% higher linear resolution.
- Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
- Better image quality: Features a larger and more technologically advanced imaging sensor.
- Richer colors: The sensor size advantage translates into images with better, more accurate colors.
- More dynamic range: Larger sensor captures a wider spectrum of light and dark details.
- Better low-light sensitivity: Larger sensor produces good images even in poorly lit environments.
- Broader imaging potential: Can record not only still images but also 1080/30p movies.
- Easier setting verification: Features an LCD display on top to control shooting parameters.
- Larger screen: Has a bigger rear LCD (3.2" vs 2.0") for image review and settings control.
- More detailed LCD: Has a higher resolution rear screen (1040k vs 235k dots).
- Faster shutter: Has higher mechanical shutter speed (1/8000s vs 1/2000s) to freeze action.
- Faster burst: Shoots at higher frequency (5 vs 1 flaps/sec) to capture the decisive moment.
- Easier time-lapse photography: Has an intervalometer built-in for low frequency shooting.
- Better sealing: Is weather sealed to enable shooting in dusty or wet environments.
- Greater peace of mind: Features a second card slot as a backup in case of memory card failure.
- Faster buffer clearing: Has an SD card interface that supports the UHS-I standard.
- More modern: Reflects 10 years and 10 months of technical progress since the R-D1 launch.
Arguments in favor of the Epson R-D1:
- Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
- More compact: Is smaller (142x89mm vs 152x116mm) and will fit more readily into a bag.
- Less heavy: Has a lower weight (by 310g or 33 percent) and is thus easier to take along.
- More affordable: Was released into a lower priced segment (19 percent cheaper at launch).
- More heavily discounted: Has been around for much longer (launched in March 2004).
If the count of relative strengths (bullet points above) is taken as a measure, the 5DS R is the clear winner of the match-up (17 : 5 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it says little about, for example, the shooting experience and imaging performance of the 5DS R and the R-D1 in practical situations. User reviews that are available, for instance, at amazon can sometimes shed light on these issues, but such feedback is all too often partial, inconsistent, and inaccurate.
This is where reviews by experts come in. The following table reports the overall ratings of the cameras as published by some of the major camera review sites (cameralabs, dpreview, ephotozine, imaging-resource, and photographyblog). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|Canon 5DS R||+||83/100||5/5||5/5||4.5/5||Feb 2015||3,699|
|Epson R-D1||..||..||..||..||..||Mar 2004||2,999|
|Canon 1D X Mark II||..||89/100||4.5/5||5/5||4.5/5||Feb 2016||5,999|
|Canon 5D Mark IV||+ +||87/100||4.5/5||5/5||4.5/5||Aug 2016||3,499|
|Canon 5DS||+||83/100||4.5/5||5/5||4.5/5||Feb 2015||3,699|
|Canon 5D Mark III||+ +||82/100||4.5/5||5/5||4.5/5||Mar 2012||3,499|
|Canon 6D||+ +||83/100||4.5/5||4.5/5||4.5/5||Sep 2012||2,099|
|Canon 5D Mark II||91/100||79/100||4/5||5/5||..||Sep 2008||3,499|
|Canon 5D||88/100||+ +||o||o||..||Aug 2005||3,299|
|Canon Rebel||..||+ +||..||o||..||Aug 2003||899|
|Leica X Vario||..||..||4/5||4/5||4/5||Jun 2013||2,850|
|Nikon D850||+ +||89/100||4.5/5||5/5||5/5||Jul 2017||3,299|
|Nikon D810||..||86/100||5/5||4.5/5||4.5/5||Jun 2014||3,299|
|Nikon D50||78/100||+ +||4/5||o||4.5/5||Apr 2005||749|
|Nikon D70s||..||..||..||o||5/5||Apr 2005||899|
|Nikon D70||..||+ +||..||o||..||Jan 2004||999|
|Sony A99 II||..||85/100||4.5/5||4.5/5||4.5/5||Sep 2016||3,199|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
The review scores listed above should be treated with care, though. The ratings were established in reference to similarly priced cameras that were available in the market at the time of the review. A score, therefore, has to be seen in close connection to the price and market introduction time of the camera, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, please note that some of the review sites have changed their methodology and reporting over time.
Other camera comparisons
Did this review help to inform your camera decision process? In case you would like to check on the differences and similarities of other camera models, just make your choice using the following search menu. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 5D Mark IV vs Epson R-D1
- Canon 5DS R vs Canon G3 X
- Canon 5DS R vs Fujifilm X30
- Canon 5DS R vs Leica S2
- Canon 5DS R vs Nikon D5000
- Canon 5DS R vs Olympus E-PM1
- Canon 5DS vs Canon 5DS R
- Canon XS vs Epson R-D1
- Epson R-D1 vs Leica X Vario
- Epson R-D1 vs Olympus E-5
- Epson R-D1 vs Panasonic G5
- Epson R-D1 vs Sony RX10 II
Specifications: Canon 5DS R vs Epson R-D1
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Canon 5DS R||Epson R-D1|
|Camera Type||Digital single lens reflex||Rangefinder camera|
|Camera Lens||Canon EF mount lenses||Leica M mount lenses|
|Launch Date||February 2015||March 2004|
|Launch Price||USD 3,699||USD 2,999|
|Sensor Specs||Canon 5DS R||Epson R-D1|
|Sensor Format||Full Frame Sensor||APS-C Sensor|
|Sensor Size||36.0 x 24.0 mm||23.7 x 15.6 mm|
|Sensor Area||864 mm2||369.72 mm2|
|Sensor Diagonal||43.3 mm||28.4 mm|
|Sensor Resolution||50.3 Megapixels||6 Megapixels|
|Image Resolution||8688 x 5792 pixels||3008 x 2000 pixels|
|Pixel Pitch||4.14 μm||7.85 μm|
|Pixel Density||5.82 MP/cm2||1.63 MP/cm2|
|Moiré control||no AA filter||Anti-Alias filter|
|Movie Capability||1080/30p Video||no Video|
|ISO Setting||100 - 6,400 ISO||200 - 1,600 ISO|
|ISO Boost||50 - 12,800 ISO||no Enhancement|
|DXO Sensor Quality (score)||86||..|
|DXO Color Depth (bits)||24.6||..|
|DXO Dynamic Range (EV)||12.4||..|
|DXO Low Light (ISO)||2308||..|
|Screen Specs||Canon 5DS R||Epson R-D1|
|Viewfinder Type||Optical viewfinder||Optical viewfinder|
|Viewfinder Field of View||100%||100%|
|Top-Level Screen||Control Panel||no Top Display|
|LCD Framing||Live View|
|Rear LCD Size||3.2inch||2.0inch|
|LCD Resolution||1040k dots||235k dots|
|LCD Attachment||Fixed screen||Fixed screen|
|Shooting Specs||Canon 5DS R||Epson R-D1|
|Focus System||Phase-detect AF||Manual Focus|
|Continuous Shooting||5 shutter flaps/s||1 shutter flaps/s|
|Time-Lapse Photography||Intervalometer built-in||no Intervalometer|
|Fill Flash||no On-Board Flash||no On-Board Flash|
|Storage Medium||CF or SDXC cards||SDHC cards|
|Second Storage Option||Dual card slots||Single card slot|
|UHS card support||UHS-I||no|
|Connectivity Specs||Canon 5DS R||Epson R-D1|
|Studio Flash||PC Sync socket||PC Sync socket|
|USB Connector||USB 3.0||no USB|
|HDMI Port||mini HDMI||no HDMI|
|Microphone Port||External MIC port||no MIC socket|
|Wifi Support||no Wifi||no Wifi|
|Body Specs||Canon 5DS R||Epson R-D1|
|Environmental Sealing||Weathersealed body||not weather sealed|
152 x 116 x 76 mm
(6.0 x 4.6 x 3.0 in)
142 x 89 x 40 mm
(5.6 x 3.5 x 1.6 in)
|Camera Weight||930 g (32.8 oz)||620 g (21.9 oz)|
