Canon 40D vs Fujifilm X-E3
The Canon EOS 40D and the Fujifilm X-E3 are two digital cameras that were revealed to the public, respectively, in August 2007 and September 2017. The 40D is a DSLR, while the X-E3 is a mirrorless interchangeable lens camera. Both cameras are equipped with an APS-C sensor. The Canon has a resolution of 10.1 megapixels, whereas the Fujifilm provides 24 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS 40D and the Fujifilm X-E3? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
The physical size and weight of the Canon 40D and the Fujifilm X-E3 are illustrated in the side-by-side display below. The two cameras are presented according to their relative size. Three successive views from the front, the top, and the rear are shown. All width, height and depth dimensions are rounded to the nearest millimeter.
The X-E3 can be obtained in two different colors (black, silver), while the 40D is only available in black.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Fujifilm X-E3 is considerably smaller (43 percent) than the Canon 40D. Moreover, the X-E3 is substantially lighter (59 percent) than the 40D. In this context, it is worth noting that neither the 40D nor the X-E3 are weather-sealed.
The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. Both cameras have similarly sized sensors, but DSLRs have a larger flange-to-focal plane distance than mirrorless cameras, which imposes contraints on the optical engineering process and generally leads to bigger and heavier lenses. You can compare the optics available for the two cameras in the Canon EF Lens Catalog (40D) and the Fujinon X Lens Catalog (X-E3). Mirrorless cameras, such as the X-E3, have moreover the advantage that they can use many lenses from other systems via adapters, as they have a relatively short flange to focal plane distance.
Concerning battery life, the 40D gets 750 shots out of its BP-511A battery, while the X-E3 can take 350 images on a single charge of its NP-W126S power pack. The power pack in the X-E3 can be charged via the USB port, which can be very convenient when travelling.
The table below summarizes the key physical specs of the two cameras alongside a broader set of comparators. If you want to switch the focus of the display and review another camera pair, you can move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.
|1.||Canon 40D||5.7 in||4.3 in||2.9 in||29.0 oz||750||n||Aug 2007||1,299|
|2.||Fujifilm X-E3||4.8 in||2.9 in||1.7 in||11.9 oz||350||n||Sep 2017||899|
|3.||Canon T3||5.1 in||3.9 in||3.1 in||17.5 oz||700||n||Feb 2011||449|
|4.||Canon 60D||5.7 in||4.2 in||3.1 in||26.6 oz||1100||Y||Aug 2010||1,399|
|5.||Canon 50D||5.7 in||4.3 in||2.9 in||29.0 oz||800||Y||Aug 2008||1,299|
|6.||Canon XS||5.0 in||3.9 in||2.6 in||17.7 oz||500||n||Jun 2008||449|
|7.||Canon XSi||5.1 in||3.9 in||2.4 in||18.5 oz||500||n||Jan 2008||799|
|8.||Canon 30D||5.7 in||4.2 in||2.9 in||27.7 oz||750||n||Feb 2006||1,399|
|9.||Canon XTi||5.0 in||3.3 in||2.6 in||19.6 oz||370||n||Aug 2006||799|
|10.||Canon 20D||5.7 in||4.2 in||2.8 in||27.2 oz||700||n||Aug 2004||1,499|
|11.||Canon 10D||5.9 in||4.2 in||3.0 in||30.0 oz||500||n||Feb 2003||1,999|
|12.||Fujifilm X-E4||4.8 in||2.9 in||1.3 in||12.8 oz||380||n||Jan 2021||849|
|13.||Fujifilm X-T30||4.6 in||3.3 in||1.9 in||13.5 oz||380||n||Feb 2019||899|
|14.||Fujifilm X-T20||4.6 in||3.3 in||1.6 in||13.5 oz||350||n||Jan 2017||899|
|15.||Fujifilm X-A3||4.6 in||2.6 in||1.6 in||12.0 oz||410||n||Aug 2016||399|
|16.||Fujifilm X-E2S||5.1 in||3.0 in||1.5 in||12.3 oz||350||n||Jan 2016||699|
|17.||Nikon D90||5.2 in||4.1 in||3.0 in||24.8 oz||850||n||Aug 2008||1,299|
|Notes: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.|
The price is, of course, an important factor in any camera decision. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The X-E3 was launched at a markedly lower price (by 31 percent) than the 40D, which puts it into a different market segment. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.
The size of the sensor inside a digital camera is one of the key determinants of image quality. All other things equal, a large sensor will have larger individual pixel-units that offer better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixels in a sensor of the same technological generation. Furthermore, a large sensor camera will give the photographer more possibilities to use shallow depth-of-field in order to isolate a subject from the background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.
Both cameras under consideration feature an APS-C sensor, but their sensors differ slightly in size. The sensor area in the X-E3 is 11 percent bigger. As a result of these sensor size differences, the cameras have format factors, respectively, of 1.6 (40D) and 1.5. Both cameras have a native aspect ratio (sensor width to sensor height) of 3:2.
Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors.
With 24MP, the X-E3 offers a higher resolution than the 40D (10.1MP), but the X-E3 has smaller individual pixels (pixel pitch of 3.92μm versus 5.73μm for the 40D). Yet, the X-E3 is a much more recent model (by 10 years) than the 40D, and its sensor will have benefitted from technological advances during this time that enhance the light gathering capacity of its pixel-units. Coming back to sensor resolution, it should be mentioned that the X-E3 has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.
The resolution advantage of the Fujifilm X-E3 implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the X-E3 for good quality output (200 dots per inch) amounts to 30 x 20 inches or 76.2 x 50.8 cm, for very good quality (250 dpi) 24 x 16 inches or 61 x 40.6 cm, and for excellent quality (300 dpi) 20 x 13.3 inches or 50.8 x 33.9 cm. The corresponding values for the Canon 40D are 19.4 x 13 inches or 49.4 x 32.9 cm for good quality, 15.6 x 10.4 inches or 39.5 x 26.3 cm for very good quality, and 13 x 8.6 inches or 32.9 x 21.9 cm for excellent quality prints.
The X-E3 has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.
The Canon EOS 40D has a native sensitivity range from ISO 100 to ISO 1600, which can be extended to ISO 100-3200. The corresponding ISO settings for the Fujifilm X-E3 are ISO 200 to ISO 12800, with the possibility to increase the ISO range to 100-51200.
For many cameras, data on sensor performance has been reported by DXO Mark. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.
| DXO |
Many modern cameras are not only capable of taking still images, but also of capturing video footage. The X-E3 indeed provides for movie recording, while the 40D does not. The highest resolution format that the X-E3 can use is 4K/30p.
Apart from body and sensor, cameras can and do differ across a variety of features. For example, the X-E3 has an electronic viewfinder (2360k dots), while the 40D has an optical one. Both systems have their advantages, with the electronic viewfinder making it possible to project supplementary shooting information into the framing view, whereas the optical viewfinder offers lag-free viewing and a very clear framing image. The viewfinder in the X-E3 offers a wider field of view (100%) than the one in the 40D (95%), so that a larger proportion of the captured image is visible in the finder. On the other hand, the viewfinder of the 40D has a higher magnification (0.59x vs 0.41x), so that the size of the image transmitted appears closer to the size seen with the naked human eye. The following table reports on some other key feature differences and similarities of the Canon 40D, the Fujifilm X-E3, and comparable cameras.
One difference between the cameras concerns the presence of an on-board flash. The 40D has one, while the X-E3 does not. While the built-in flash of the 40D is not very powerful, it can at times be useful as a fill-in light.
The reported shutter speed information refers to the use of the mechanical shutter. Yet, some cameras only have an electronic shutter, while others have an electronic shutter in addition to a mechanical one. In fact, the X-E3 is one of those camera that have an additional electronic shutter, which makes completely silent shooting possible. However, this mode is less suitable for photographing moving objects (risk of rolling shutter) or shooting under artificial light sources (risk of flickering).
The Fujifilm X-E3 has an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
The 40D writes its imaging data to Compact Flash cards, while the X-E3 uses SDXC cards.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS 40D and Fujifilm X-E3 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
| WiFi |
| NFC |
It is notable that the X-E3 offers wifi support, which can be a very convenient means to transfer image data to an off-camera location. In contrast, the 40D does not provide wifi capability.
Studio photographers will appreciate that the Canon 40D (unlike the X-E3) features a PC Sync socket, so that professional strobe lights can be controlled by the camera.
The X-E3 is a recent model that features in the current product line-up of Fujifilm. In contrast, the 40D has been discontinued (but can be found pre-owned on eBay). As a replacement in the same line of cameras, the 40D was succeeded by the Canon 50D. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Canon and Fujifilm websites.
So how do things add up? Is the Canon 40D better than the Fujifilm X-E3 or vice versa? A synthesis of the relative strong points of each of the models is listed below.
Reasons to prefer the Canon EOS 40D:
- Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
- Brighter framing: Features an optical viewfinder for clear, lag-free composition.
- Larger viewfinder image: Features a viewfinder with a higher magnification (0.59x vs 0.41x).
- Easier setting verification: Features an LCD display on top to control shooting parameters.
- Faster shutter: Has higher mechanical shutter speed (1/8000s vs 1/4000s) to freeze action.
- Longer lasting: Can take more shots (750 versus 350) on a single battery charge.
- Easier fill-in: Is equipped with a small onboard flash to brighten deep shadow areas.
- Better studio light control: Has a PC Sync socket to connect to professional strobe lights.
- More heavily discounted: Has been available for much longer (launched in August 2007).
Arguments in favor of the Fujifilm X-E3:
- More detail: Has more megapixels (24 vs 10.1MP), which boosts linear resolution by 54%.
- Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
- Broader imaging potential: Can capture not only stills but also 4K/30p video.
- Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
- More framing info: Has an electronic viewfinder that displays shooting data.
- More complete view: Has a viewfinder with a larger field of view (100% vs 95%).
- More detailed LCD: Has a higher resolution rear screen (1040k vs 230k dots).
- Fewer buttons to press: Has a touchscreen to facilitate handling and shooting adjustments.
- Faster burst: Shoots at higher frequency (8 vs 6.5 flaps/sec) to capture the decisive moment.
- Less disturbing: Has an electronic shutter option for completely silent shooting.
- Easier time-lapse photography: Has an intervalometer built-in for low frequency shooting.
- More compact: Is smaller (121x74mm vs 146x108mm) and will fit more readily into a bag.
- Less heavy: Has a lower weight (by 485g or 59 percent) and is thus easier to take along.
- Easier travel charging: Can be conveniently charged via its USB port.
- More legacy lens friendly: Can use many non-native lenses via adapters.
- Easier file upload: Has wifi built in for automatic backup or image transfer to the web.
- Easier wireless transfer: Supports Bluetooth for image sharing without cables.
- More affordable: Was introduced into a lower priced category (31 percent cheaper at launch).
- More modern: Reflects 10 years of technical progress since the 40D launch.
If the number of relative strengths (bullet points above) is taken as a guide, the X-E3 is the clear winner of the contest (19 : 9 points). However, the relative importance of the various individual camera aspects will vary according to personal preferences and needs, so that you might like to apply corresponding weights to the particular features before making a decision on a new camera. A professional wedding photographer will view the differences between cameras in a way that diverges from the perspective of a travel photog, and a person interested in cityscapes has distinct needs from a macro shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Canon 40D and the Fujifilm X-E3 place the cameras among the top in their class? Find out in the latest Best DSLR Camera and Best Mirrorless Interchangeable Lens Camera listings whether the two cameras rank among the cream of the crop.
In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it remains partial and cannot reveal, for example, the shooting experience and imaging performance when actually working with the 40D or the X-E3. User reviews, such as those found at amazon, can sometimes inform about these issues, but such feedback is often incomplete, inconsistent, and biased.
This is why expert reviews are important. The following table reports the overall ratings of the cameras as published by some of the major camera review sites (amateurphotographer [AP], cameralabs [CL], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|1.||Canon 40D||..||+ +||+ +||4.5/5||4.5/5||Aug 2007||1,299|
|2.||Fujifilm X-E3||4.5/5||+||84/100||4.5/5||4.5/5||Sep 2017||899|
|3.||Canon T3||..||80/100||69/100||4/5||4.5/5||Feb 2011||449|
|4.||Canon 60D||5/5||+||79/100||4/5||4.5/5||Aug 2010||1,399|
|5.||Canon 50D||..||+ +||+ +||4.5/5||4.5/5||Aug 2008||1,299|
|6.||Canon XS||..||82/100||+ +||3.5/5||4.5/5||Jun 2008||449|
|7.||Canon XSi||..||+ +||+ +||4/5||4.5/5||Jan 2008||799|
|8.||Canon 30D||..||+ +||+ +||o||..||Feb 2006||1,399|
|9.||Canon XTi||..||+ +||+ +||o||4/5||Aug 2006||799|
|10.||Canon 20D||..||..||+ +||..||..||Aug 2004||1,499|
|11.||Canon 10D||..||..||+ +||..||..||Feb 2003||1,999|
|12.||Fujifilm X-E4||..||..||..||..||..||Jan 2021||849|
|13.||Fujifilm X-T30||5/5||+ +||84/100||4.5/5||4.5/5||Feb 2019||899|
|14.||Fujifilm X-T20||5/5||+ +||82/100||5/5||4.5/5||Jan 2017||899|
|15.||Fujifilm X-A3||..||..||74/100||4.5/5||4/5||Aug 2016||399|
|16.||Fujifilm X-E2S||4.5/5||..||77/100||4.5/5||4.5/5||Jan 2016||699|
|17.||Nikon D90||..||+ +||+ +||4/5||4.5/5||Aug 2008||1,299|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
The review scores listed above should be treated with care, though. The ratings are only valid when referring to cameras in the same category and of the same age. Thus, a score needs to be put into the context of the launch date and the launch price of the camera, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. It should also be noted that some of the review sites have over time altered the way they render their verdicts.
Other camera comparisons
Did this review help to inform your camera decision process? In case you would like to check on the differences and similarities of other camera models, just use the search menu below. As an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
Specifications: Canon 40D vs Fujifilm X-E3
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Canon 40D||Fujifilm X-E3|
|Camera Type||Digital single lens reflex||Mirrorless system camera|
|Camera Lens||Canon EF mount lenses||Fujifilm X mount lenses|
|Launch Date||August 2007||September 2017|
|Launch Price||USD 1,299||USD 899|
|Sensor Specs||Canon 40D||Fujifilm X-E3|
|Sensor Format||APS-C Sensor||APS-C Sensor|
|Sensor Size||22.3 x 14.9 mm||23.6 x 15.6 mm|
|Sensor Area||332.27 mm2||368.16 mm2|
|Sensor Diagonal||26.8 mm||28.3 mm|
|Sensor Resolution||10.1 Megapixels||24 Megapixels|
|Image Resolution||3888 x 2592 pixels||6000 x 4000 pixels|
|Pixel Pitch||5.73 μm||3.92 μm|
|Pixel Density||3.03 MP/cm2||6.52 MP/cm2|
|Moiré control||Anti-Alias filter||no AA filter|
|Movie Capability||no Video||4K/30p Video|
|ISO Setting||100 - 1,600 ISO||200 - 12,800 ISO|
|ISO Boost||100 - 3,200 ISO||100 - 51,200 ISO|
|Image Processor||DIGIC 3||X-Processor Pro|
|DXO Sensor Quality (score)||64||..|
|DXO Color Depth (bits)||22.1||..|
|DXO Dynamic Range (EV)||11.3||..|
|DXO Low Light (ISO)||703||..|
|Screen Specs||Canon 40D||Fujifilm X-E3|
|Viewfinder Type||Optical viewfinder||Electronic viewfinder|
|Viewfinder Field of View||95%||100%|
|Viewfinder Resolution||2360k dots|
|Top-Level Screen||Control Panel||no Top Display|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0inch||3.0inch|
|LCD Resolution||230k dots||1040k dots|
|LCD Attachment||Fixed screen||Fixed screen|
|Touch Input||no Touchscreen||Touchscreen|
|Shooting Specs||Canon 40D||Fujifilm X-E3|
|Focus System||Phase-detect AF||On-Sensor Phase-detect|
|Manual Focusing Aid||no Peaking Feature||Focus Peaking|
|Max Shutter Speed (mechanical)||1/8000s||1/4000s|
|Continuous Shooting||6.5 shutter flaps/s||8 shutter flaps/s|
|Electronic Shutter||no E-Shutter||up to 1/32000s|
|Time-Lapse Photography||no Intervalometer||Intervalometer built-in|
|Fill Flash||Build-in Flash||no On-Board Flash|
|Storage Medium||CF cards||SDXC cards|
|Second Storage Option||Single card slot||Single card slot|
|Connectivity Specs||Canon 40D||Fujifilm X-E3|
|Studio Flash||PC Sync socket||no PC Sync|
|USB Connector||USB 2.0||USB 2.0|
|HDMI Port||no HDMI||micro HDMI|
|Microphone Port||no MIC socket||External MIC port|
|Wifi Support||no Wifi||Wifi built-in|
|Bluetooth Support||no Bluetooth||Bluetooth built-in|
|Body Specs||Canon 40D||Fujifilm X-E3|
|Battery Life (CIPA)||750 shots per charge||350 shots per charge|
|In-Camera Charging||no USB charging||USB charging|
146 x 108 x 74 mm
(5.7 x 4.3 x 2.9 in)
121 x 74 x 43 mm
(4.8 x 2.9 x 1.7 in)
|Camera Weight||822 g (29.0 oz)||337 g (11.9 oz)|
