Olympus E-PL5 vs Panasonic GF2
The Olympus PEN E-PL5 and the Panasonic Lumix DMC-GF2 are two digital cameras that were revealed to the public, respectively, in September 2012 and November 2010. Both the E-PL5 and the GF2 are mirrorless interchangeable lens cameras that are equipped with a Four Thirds sensor. The Olympus has a resolution of 15.9 megapixels, whereas the Panasonic provides 12 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
Going beyond this snapshot of core features and characteristics, what are the differences between the Olympus PEN E-PL5 and the Panasonic Lumix DMC-GF2? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
An illustration of the physical size and weight of the Olympus E-PL5 and the Panasonic GF2 is provided in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive perspectives from the front, the top, and the back are available. All size dimensions are rounded to the nearest millimeter.
The E-PL5 can be obtained in three different colors (black, silver, white), while the GF2 is available in four color-versions (black, silver, red, white).
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Panasonic GF2 is notably larger (8 percent) than the Olympus E-PL5. However, the GF2 is markedly lighter (5 percent) than the E-PL5. In this context, it is worth noting that neither the E-PL5 nor the GF2 are weather-sealed.
The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. In this particular case, both cameras feature the same lens mount, so that they can use the same lenses. You can compare the optics available in the Micro Four Thirds Lens Catalog. Mirrorless cameras, such as the two under consideration, have the additional advantage of having a short flange to focal plane distance, which makes it possible to mount many lenses from other systems onto the camera via adapters.
The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you would like to visualize and compare a different camera combination, you can navigate to the CAM-parator app and make your selection from a broad list of cameras there.
|1.||Olympus E-PL5||111 mm||64 mm||38 mm||325 g||360||n||Sep 2012||599|
|2.||Panasonic GF2||113 mm||68 mm||33 mm||310 g||300||n||Nov 2010||549|
|3.||Olympus E-PL9||117 mm||68 mm||39 mm||380 g||350||n||Feb 2018||599|
|4.||Olympus E-PL8||115 mm||67 mm||38 mm||357 g||350||n||Sep 2016||549|
|5.||Olympus E-M10 II||120 mm||83 mm||47 mm||390 g||320||n||Aug 2015||649|
|6.||Olympus E-M10||119 mm||82 mm||46 mm||396 g||320||n||Jan 2014||699|
|7.||Olympus E-PL7||115 mm||67 mm||38 mm||357 g||350||n||Aug 2014||599|
|8.||Olympus E-P5||122 mm||69 mm||37 mm||420 g||330||n||May 2013||999|
|9.||Olympus E-PL6||111 mm||64 mm||38 mm||325 g||360||n||May 2013||599|
|10.||Olympus E-PM2||110 mm||64 mm||34 mm||269 g||360||n||Sep 2012||499|
|11.||Olympus E-PL3||110 mm||64 mm||37 mm||313 g||300||n||Jun 2011||599|
|12.||Panasonic G6||122 mm||85 mm||71 mm||390 g||340||n||Apr 2013||599|
|13.||Panasonic G3||115 mm||84 mm||47 mm||336 g||270||n||May 2011||599|
|14.||Panasonic GF3||108 mm||67 mm||32 mm||264 g||300||n||Jun 2011||549|
|15.||Panasonic G10||124 mm||84 mm||74 mm||388 g||380||n||Mar 2010||499|
|16.||Panasonic G2||124 mm||84 mm||74 mm||428 g||360||n||Mar 2010||599|
|17.||Panasonic GF1||119 mm||71 mm||36 mm||385 g||380||n||Sep 2009||749|
|Notes: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.|
The price is, of course, an important factor in any camera decision. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The GF2 was somewhat cheaper (by 8 percent) than the E-PL5 at launch, but both cameras fall into the same price category. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.
The size of the imaging sensor is a crucial determinant of image quality. All other things equal, a large sensor will have larger individual pixel-units that offer better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixels in a sensor of the same technological generation. Moreover, a large sensor camera will give the photographer more control over depth-of-field in the image and, thus, the ability to better isolate a subject from the background. On the downside, larger sensors tend to be associated with larger, more expensive camera bodies and lenses.
Both cameras under consideration feature a Four Thirds sensor and have a format factor (sometimes also referred to as "crop factor") of 2.0. Within the spectrum of camera sensors, this places the review cameras among the medium-sized sensor cameras that aim to strike a balance between image quality and portability. Both cameras feature a native aspect ratio (sensor width to sensor height) of 4:3.
While the two cameras under review share the same sensor size, the E-PL5 offers a higher resolution of 15.9 megapixels, compared with 12 MP of the GF2. This megapixels advantage translates into a 15 percent gain in linear resolution. On the other hand, these sensor specs imply that the E-PL5 has a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 3.76μm versus 4.33μm for the GF2). In this context, it should be noted, however, that the E-PL5 is a somewhat more recent model (by 1 year and 10 months) than the GF2, and its sensor might have benefitted from technological advances during this time that at least partly compensate for the smaller pixel size.
The resolution advantage of the Olympus E-PL5 implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the E-PL5 for good quality output (200 dots per inch) amounts to 23 x 17.3 inches or 58.5 x 43.9 cm, for very good quality (250 dpi) 18.4 x 13.8 inches or 46.8 x 35.1 cm, and for excellent quality (300 dpi) 15.4 x 11.5 inches or 39 x 29.3 cm. The corresponding values for the Panasonic GF2 are 20 x 15 inches or 50.8 x 38.1 cm for good quality, 16 x 12 inches or 40.6 x 30.5 cm for very good quality, and 13.3 x 10 inches or 33.9 x 25.4 cm for excellent quality prints.
The Olympus PEN E-PL5 has a native sensitivity range from ISO 200 to ISO 25600. The corresponding ISO settings for the Panasonic Lumix DMC-GF2 are ISO 100 to ISO 6400 (no boost).
Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). Of the two cameras under review, the E-PL5 provides substantially higher image quality than the GF2, with an overall score that is 18 points higher. This advantage is based on 1.6 bits higher color depth, 2 EV in additional dynamic range, and 0.8 stops in additional low light sensitivity. The following table provides an overview of the physical sensor characteristics, as well as the sensor quality measurements for a selection of comparators.
| DXO |
|1.||Olympus E-PL5||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.3||889||72|
|2.||Panasonic GF2||Four Thirds||12.0||4000||3000||1080/60i||21.2||10.3||506||54|
|3.||Olympus E-PL9||Four Thirds||15.9||4608||3456||4K/30p||..||..||..||..|
|4.||Olympus E-PL8||Four Thirds||15.9||4608||3456||1080/30p||..||..||..||..|
|5.||Olympus E-M10 II||Four Thirds||15.9||4608||3456||1080/60p||23.1||12.5||842||73|
|6.||Olympus E-M10||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.3||884||72|
|7.||Olympus E-PL7||Four Thirds||15.9||4608||3456||1080/30p||22.7||12.4||873||72|
|8.||Olympus E-P5||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.4||895||72|
|9.||Olympus E-PL6||Four Thirds||15.9||4608||3456||1080/30p||..||..||..||..|
|10.||Olympus E-PM2||Four Thirds||15.9||4608||3456||1080/30p||22.7||12.2||932||72|
|11.||Olympus E-PL3||Four Thirds||12.2||4032||3024||1080/60i||20.9||10.3||499||52|
|12.||Panasonic G6||Four Thirds||15.9||4608||3456||1080/60p||21.3||11.5||639||61|
|13.||Panasonic G3||Four Thirds||15.8||4592||3448||1080/60i||21.0||10.6||667||56|
|14.||Panasonic GF3||Four Thirds||12.0||4000||3000||1080/60i||20.6||10.0||458||49|
|15.||Panasonic G10||Four Thirds||12.0||4000||3000||720/30p||21.2||10.1||411||52|
|16.||Panasonic G2||Four Thirds||12.0||4000||3000||720/30p||21.2||10.3||493||53|
|17.||Panasonic GF1||Four Thirds||12.0||4000||3000||720/30p||21.2||10.3||513||54|
Many modern cameras cannot only take still pictures, but also record videos. Both cameras under consideration have a sensor with sufficiently fast read-out times for moving pictures, but the GF2 provides a faster frame rate than the E-PL5. It can shoot movie footage at 1080/60i, while the Olympus is limited to 1080/30p.
Apart from body and sensor, cameras can and do differ across a range of features. The E-PL5 and the GF2 are similar in the sense that neither of the two has a viewfinder. The images are, thus, framed using live view on the rear LCD. However, optional viewfinders – the VF-3 for the E-PL5 and the DMW-LVF1 for the GF2 – are available as accessories. The adjacent table lists some of the other core features of the Olympus E-PL5 and Panasonic GF2 along with similar information for a selection of comparators.
|5.||Olympus E-M10 II||2360||n||3.0||1040||tilting||Y||1/4000s||8.0||Y||Y|
One feature that differentiates the E-PL5 and the GF2 is in-body image stabilization (IBIS). The E-PL5 reduces the risk of handshake-induced blur with all attached lenses, while the GF2 offers no blur reduction with lenses that themselves do not provide optical image stabilization.The E-PL5 has an articulated LCD that can be turned to be front-facing. This characteristic will be appreciated by vloggers and photographers who are interested in snapping selfies. In contrast, the GF2 does not have a selfie-screen.
Concerning the storage of imaging data, both the E-PL5 and the GF2 write their files to SDXC cards. The E-PL5 supports UHS-I cards (Ultra High Speed data transfer of up to 104 MB/s), while the GF2 cannot take advantage of Ultra High Speed SD cards.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Olympus PEN E-PL5 and Panasonic Lumix DMC-GF2 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
| WiFi |
| NFC |
|5.||Olympus E-M10 II||Y||stereo||mono||-||-||micro||2.0||Y||-||-|
Both the E-PL5 and the GF2 have been discontinued, but can regularly be found used on eBay. The GF2 was replaced by the Panasonic GF3, while the E-PL5 was followed by the Olympus E-PL6. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Olympus and Panasonic websites.
So what is the bottom line? Which of the two cameras – the Olympus E-PL5 or the Panasonic GF2 – has the upper hand? Is one clearly better than the other? Below is a summary of the relative strengths of each of the two contestants.
Arguments in favor of the Olympus PEN E-PL5:
- More detail: Offers more megapixels (15.9 vs 12MP) with a 15% higher linear resolution.
- Better image quality: Scores substantially higher (18 points) in the DXO overall assessment.
- Richer colors: Generates images with noticeably better colors (1.6 bits more color depth).
- More dynamic range: Captures a larger spectrum of light and dark details (2 EV of extra DR).
- Better low-light sensitivity: Requires less light for good images (0.8 stops ISO advantage).
- More flexible LCD: Has a tilting screen for odd-angle shots in landscape orientation.
- More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
- Faster burst: Shoots at higher frequency (8 vs 2.6 flaps/sec) to capture the decisive moment.
- Longer lasting: Can take more shots (360 versus 300) on a single battery charge.
- Sharper images: Has hand-shake reducing image stabilization built-in.
- Faster buffer clearing: Has an SD card interface that supports the UHS-I standard.
- More modern: Is somewhat more recent (announced 1 year and 10 months after the GF2).
Advantages of the Panasonic Lumix DMC-GF2:
- Better video: Provides higher movie framerates (1080/60i versus 1080/30p).
- Easier fill-in: Has a small integrated flash to brighten shadows of backlit subjects.
- More heavily discounted: Has been on the market for longer (launched in November 2010).
If the number of relative strengths (bullet points above) is taken as a guide, the E-PL5 is the clear winner of the match-up (12 : 3 points). However, the pertinence of the various camera strengths will differ across photographers, so that you might want to weigh individual camera traits according to their importance for your own imaging needs before making a camera decision. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Olympus E-PL5 and the Panasonic GF2 place the cameras among the top in their class? Find out in the latest Best Mirrorless Interchangeable Lens Camera listing whether the two cameras rank among the cream of the crop.
In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it says little about, for example, the shooting experience and imaging performance of the E-PL5 and the GF2 in practical situations. User reviews that are available, for instance, at amazon can sometimes shed light on these issues, but such feedback is all too often partial, inconsistent, and inaccurate.
This is where reviews by experts come in. The following table reports the overall ratings of the cameras as published by some of the major camera review sites (amateurphotographer [AP], cameralabs [CL], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|1.||Olympus E-PL5||3/5||+ +||..||4.5/5||4.5/5||Sep 2012||599|
|2.||Panasonic GF2||3/5||82/100||70/100||4.5/5||4.5/5||Nov 2010||549|
|3.||Olympus E-PL9||..||+||..||4.5/5||4/5||Feb 2018||599|
|4.||Olympus E-PL8||..||..||..||4.5/5||4/5||Sep 2016||549|
|5.||Olympus E-M10 II||4.5/5||+ +||80/100||5/5||5/5||Aug 2015||649|
|6.||Olympus E-M10||4/5||..||80/100||5/5||5/5||Jan 2014||699|
|7.||Olympus E-PL7||4/5||+||..||5/5||4/5||Aug 2014||599|
|8.||Olympus E-P5||5/5||+ +||78/100||4.5/5||5/5||May 2013||999|
|9.||Olympus E-PL6||..||..||..||..||..||May 2013||599|
|10.||Olympus E-PM2||3/5||..||77/100||5/5||4.5/5||Sep 2012||499|
|11.||Olympus E-PL3||3/5||+ +||72/100||4.5/5||4/5||Jun 2011||599|
|12.||Panasonic G6||4/5||+ +||..||5/5||4.5/5||Apr 2013||599|
|13.||Panasonic G3||3/5||+ +||75/100||4.5/5||5/5||May 2011||599|
|14.||Panasonic GF3||3/5||82/100||71/100||4.5/5||4/5||Jun 2011||549|
|15.||Panasonic G10||3/5||..||70/100||4/5||4/5||Mar 2010||499|
|16.||Panasonic G2||..||..||72/100||4/5||4.5/5||Mar 2010||599|
|17.||Panasonic GF1||..||85/100||69/100||4.5/5||4.5/5||Sep 2009||749|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
The above review scores should be interpreted with care, though. The assessments were made in relation to similar cameras of the same technological generation. Thus, a score needs to be put into the context of the launch date and the launch price of the camera, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, please note that some of the review sites have changed their methodology and reporting over time.
Other camera comparisons
Did this review help to inform your camera decision process? In case you would like to check on the differences and similarities of other camera models, just make your choice using the following search menu. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
Specifications: Olympus E-PL5 vs Panasonic GF2
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Olympus E-PL5||Panasonic GF2|
|Camera Type||Mirrorless system camera||Mirrorless system camera|
|Camera Lens||Micro Four Thirds lenses||Micro Four Thirds lenses|
|Launch Date||September 2012||November 2010|
|Launch Price||USD 599||USD 549|
|Sensor Specs||Olympus E-PL5||Panasonic GF2|
|Sensor Format||Four Thirds Sensor||Four Thirds Sensor|
|Sensor Size||17.3 x 13.0 mm||17.3 x 13.0 mm|
|Sensor Area||224.9 mm2||224.9 mm2|
|Sensor Diagonal||21.6 mm||21.6 mm|
|Sensor Resolution||15.9 Megapixels||12 Megapixels|
|Image Resolution||4608 x 3456 pixels||4000 x 3000 pixels|
|Pixel Pitch||3.76 μm||4.33 μm|
|Pixel Density||7.08 MP/cm2||5.34 MP/cm2|
|Moiré control||Anti-Alias filter||Anti-Alias filter|
|Movie Capability||1080/30p Video||1080/60i Video|
|ISO Setting||200 - 25,600 ISO||100 - 6,400 ISO|
|Image Processor||TruePic VI||Venus FHD|
|DXO Sensor Quality (score)||72||54|
|DXO Color Depth (bits)||22.8||21.2|
|DXO Dynamic Range (EV)||12.3||10.3|
|DXO Low Light (ISO)||889||506|
|Screen Specs||Olympus E-PL5||Panasonic GF2|
|Viewfinder Type||Viewfinder optional||Viewfinder optional|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0inch||3.0inch|
|LCD Resolution||460k dots||460k dots|
|LCD Attachment||Tilting screen||Fixed screen|
|Shooting Specs||Olympus E-PL5||Panasonic GF2|
|Focus System||Contrast-detect AF||Contrast-detect AF|
|Continuous Shooting||8 shutter flaps/s||2.6 shutter flaps/s|
|Image Stabilization||In-body stabilization||Lens stabilization only|
|Fill Flash||no On-Board Flash||Build-in Flash|
|Storage Medium||SDXC cards||SDXC cards|
|Second Storage Option||Single card slot||Single card slot|
|UHS card support||UHS-I||no|
|Connectivity Specs||Olympus E-PL5||Panasonic GF2|
|USB Connector||USB 2.0||USB 2.0|
|HDMI Port||mini HDMI||mini HDMI|
|Wifi Support||no Wifi||no Wifi|
|Body Specs||Olympus E-PL5||Panasonic GF2|
|Battery Life (CIPA)||360 shots per charge||300 shots per charge|
111 x 64 x 38 mm
(4.4 x 2.5 x 1.5 in)
113 x 68 x 33 mm
(4.4 x 2.7 x 1.3 in)
|Camera Weight||325 g (11.5 oz)||310 g (10.9 oz)|
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
