Olympus E-M1 vs PEN-F
The Olympus OM-D E-M1 and the Olympus PEN-F are two enthusiast cameras that were officially introduced, respectively, in September 2013 and January 2016. Both the E-M1 and the PEN-F are mirrorless interchangeable lens cameras that are equipped with a Four Thirds sensor. The E-M1 has a resolution of 15.9 megapixels, whereas the PEN-F provides 20.2 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
Going beyond this snapshot of core features and characteristics, what are the differences between the Olympus OM-D E-M1 and the Olympus PEN-F? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
An illustration of the physical size and weight of the Olympus E-M1 and the Olympus PEN-F is provided in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive perspectives from the front, the top, and the back are available. All size dimensions are rounded to the nearest millimeter.
Both cameras are available in two different colors (black, silver).
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Olympus PEN-F is notably smaller (26 percent) than the Olympus E-M1. Moreover, the PEN-F is markedly lighter (14 percent) than the E-M1. It is worth mentioning in this context that the E-M1 is splash and dust resistant, while the PEN-F does not feature any corresponding weather-sealing.
The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. In this particular case, both cameras feature the same lens mount, so that they can use the same lenses. You can compare the optics available in the Micro Four Thirds Lens Catalog. Mirrorless cameras, such as the two under consideration, have the additional advantage of having a short flange to focal plane distance, which makes it possible to mount many lenses from other systems onto the camera via adapters.
The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you would like to visualize and compare a different camera combination, you can navigate to the CAM-parator app and make your selection from a broad list of cameras there.
|1.||Olympus E-M1||130 mm||94 mm||63 mm||497 g||350||Y||Sep 2013||1,399||ebay.com|
|2.||Olympus PEN-F||125 mm||72 mm||37 mm||427 g||330||n||Jan 2016||1,199||ebay.com|
|3.||Olympus E-M1 II||134 mm||91 mm||67 mm||574 g||440||Y||Sep 2016||1,999||ebay.com|
|4.||Olympus E-M5 II||124 mm||85 mm||45 mm||469 g||310||Y||Feb 2015||1,099||ebay.com|
|5.||Olympus E-M10 II||120 mm||83 mm||47 mm||390 g||320||n||Aug 2015||649||ebay.com|
|6.||Olympus E-M10||119 mm||82 mm||46 mm||396 g||320||n||Jan 2014||699||ebay.com|
|7.||Olympus E-P5||122 mm||69 mm||37 mm||420 g||330||n||May 2013||999||ebay.com|
|8.||Olympus E-M5||122 mm||89 mm||43 mm||425 g||360||Y||Feb 2012||1,299||ebay.com|
|9.||Panasonic G80||128 mm||89 mm||74 mm||505 g||330||Y||Sep 2016||899||ebay.com|
|10.||Panasonic GX8||133 mm||78 mm||63 mm||487 g||330||Y||Jul 2015||1,199||ebay.com|
|11.||Panasonic GH4||133 mm||93 mm||84 mm||560 g||500||Y||Feb 2014||1,499||ebay.com|
|12.||Panasonic GH3||133 mm||93 mm||82 mm||550 g||540||Y||Sep 2012||1,299||ebay.com|
|Note: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.|
Any camera decision will obviously take relative prices into account. The listed launch prices provide an indication of the market segment that the manufacturer of the cameras have been targeting. The PEN-F was launched at a somewhat lower price (by 14 percent) than the E-M1, which makes it more attractive for photographers on a tight budget. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.
The size of the sensor inside a digital camera is one of the key determinants of image quality. A large sensor will generally have larger individual pixels that offer better low-light sensitivity, provide wider dynamic range, and have richer color-depth than smaller pixels in a sensor of the same technological generation. Further, a large sensor camera will give the photographer additional creative options when using shallow depth-of-field to isolate a subject from its background. On the downside, larger sensors tend to be associated with larger, more expensive camera bodies and lenses.
Both cameras under consideration feature a Four Thirds sensor and have a format factor (sometimes also referred to as "crop factor") of 2.0. Within the spectrum of camera sensors, this places the review cameras among the medium-sized sensor cameras that aim to strike a balance between image quality and portability. Both cameras feature a native aspect ratio (sensor width to sensor height) of 4:3.
While the two cameras under review share the same sensor size, the PEN-F offers a higher resolution of 20.2 megapixels, compared with 15.9 MP of the E-M1. This megapixels advantage translates into a 13 percent gain in linear resolution. On the other hand, these sensor specs imply that the PEN-F has a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 3.34μm versus 3.76μm for the E-M1). However, it should be noted that the PEN-F is much more recent (by 2 years and 4 months) than the E-M1, and its sensor will have benefitted from technological advances during this time that compensate for the smaller pixel size. Coming back to sensor resolution, it should be mentioned that neither of the two cameras has an anti-alias filter installed, so they are able to capture all the detail the sensor resolves.
The resolution advantage of the Olympus PEN-F implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the PEN-F for good quality output (200 dots per inch) amounts to 25.9 x 19.4 inches or 65.8 x 49.4 cm, for very good quality (250 dpi) 20.7 x 15.6 inches or 52.7 x 39.5 cm, and for excellent quality (300 dpi) 17.3 x 13 inches or 43.9 x 32.9 cm. The corresponding values for the Olympus E-M1 are 23 x 17.3 inches or 58.5 x 43.9 cm for good quality, 18.4 x 13.8 inches or 46.8 x 35.1 cm for very good quality, and 15.4 x 11.5 inches or 39 x 29.3 cm for excellent quality prints.
The E-M1 has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.
Unlike the E-M1, the PEN-F has the capacity to capture high quality composite images (40MP) by combining multiple shots after shifting its sensor by miniscule distances. This multi-shot, pixel-shift mode is most suitable for photography of stationary objects (landscapes, studio scenes).
The Olympus OM-D E-M1 has a native sensitivity range from ISO 200 to ISO 25600, which can be extended to ISO 100-25600. The corresponding ISO settings for the Olympus PEN-F are ISO 80 to ISO 25600 (no boost).
Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors. Both cameras use a Bayer filter for capturing RGB colors on a square grid of photosensors. This arrangement is found in most digital cameras.
Since 2007, DXO Mark has published sensor performance measurements that have been derived using a consistent methodology. This service assesses and scores the color depth ("DXO Portrait"), dynamic range ("DXO Landscape"), and low-light sensitivity ("DXO Sports") of camera sensors, and also publishes an overall camera score. The Overall DXO ratings for the two cameras under consideration are close, suggesting that they provide similar imaging performance. The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.
|1.||Olympus E-M1||Four Thirds||15.9||4608||3456||1080/30p||23.0||12.7||757||73|
|2.||Olympus PEN-F||Four Thirds||20.2||5184||3888||1080/60p||23.1||12.4||894||74|
|3.||Olympus E-M1 II||Four Thirds||20.2||5184||3888||4K/30p||23.7||12.8||1312||80|
|4.||Olympus E-M5 II||Four Thirds||15.9||4608||3456||1080/60p||23.0||12.5||842||73|
|5.||Olympus E-M10 II||Four Thirds||15.9||4608||3456||1080/60p||23.1||12.5||842||73|
|6.||Olympus E-M10||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.3||884||72|
|7.||Olympus E-P5||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.4||895||72|
|8.||Olympus E-M5||Four Thirds||15.9||4608||3456||1080/60i||22.8||12.3||826||71|
|9.||Panasonic G80||Four Thirds||15.8||4592||3448||4K/30p||22.8||12.5||656||71|
|10.||Panasonic GX8||Four Thirds||20.2||5184||3888||4K/30p||23.5||12.6||806||75|
|11.||Panasonic GH4||Four Thirds||15.9||4608||3456||4K/30p||23.2||12.8||791||74|
|12.||Panasonic GH3||Four Thirds||15.9||4608||3456||1080/60p||22.7||12.4||812||71|
Many modern cameras cannot only take still pictures, but also record videos. Both cameras under consideration have a sensor with sufficiently fast read-out times for moving pictures, but the PEN-F provides a faster frame rate than the E-M1. It can shoot movie footage at 1080/60p, while the E-M1 is limited to 1080/30p.
Beyond body and sensor, cameras can and do differ across a range of features. The E-M1 and the PEN-F are similar in the sense that both feature an electronic viewfinder, which is helpful when framing images in bright sunlight. Moreover, their viewfinders offer an identical resolution of 2360k dots. The table below summarizes some of the other core capabilities of the Olympus E-M1 and Olympus PEN-F in connection with corresponding information for a sample of similar cameras.
|1.||Olympus E-M1||2360||n||3.0 / 1037||tilting||Y||1/8000s||10.0/s||n||Y|
|2.||Olympus PEN-F||2360||n||3.0 / 1037||swivel||Y||1/8000s||10.0/s||n||Y|
|3.||Olympus E-M1 II||2360||n||3.0 / 1037||swivel||Y||1/8000s||18.0/s||n||Y|
|4.||Olympus E-M5 II||2360||n||3.0 / 1037||swivel||Y||1/8000s||10.0/s||n||Y|
|5.||Olympus E-M10 II||2360||n||3.0 / 1040||tilting||Y||1/4000s||8.0/s||Y||Y|
|6.||Olympus E-M10||1440||n||3.0 / 1037||tilting||Y||1/4000s||8.0/s||Y||Y|
|7.||Olympus E-P5||optional||n||3.0 / 1037||tilting||Y||1/8000s||9.0/s||Y||Y|
|8.||Olympus E-M5||1440||n||3.0 / 610||tilting||Y||1/4000s||9.0/s||n||Y|
|9.||Panasonic G80||2360||n||3.0 / 1040||swivel||Y||1/4000s||9.0/s||Y||Y|
|10.||Panasonic GX8||2360||n||3.0 / 1040||swivel||Y||1/8000s||10.0/s||n||Y|
|11.||Panasonic GH4||2359||n||3.0 / 1036||swivel||Y||1/8000s||12.0/s||Y||n|
|12.||Panasonic GH3||1746||n||3.0 / 614||swivel||Y||1/4000s||6.0/s||Y||n|
|Notes: *) Information refers to the mechanical shutter, unless the camera only has an electronic one.|
The reported shutter speed information refers to the use of the mechanical shutter. Yet, some cameras only have an electronic shutter, while others have an electronic shutter in addition to a mechanical one. In fact, both cameras under consideration feature an electronic shutter, which makes completely silent shooting possible. However, this mode is less suitable for photographing moving objects (risk of rolling shutter) or shooting under artificial light sources (risk of flickering).
The Olympus E-M1 and the Olympus PEN-F both have an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
Concerning the storage of imaging data, both the E-M1 and the PEN-F write their files to SDXC cards. The PEN-F supports UHS-II cards (Ultra High Speed data transfer of up to 312 MB/s), while the E-M1 can use UHS-I cards (up to 104 MB/s).
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Olympus OM-D E-M1 and Olympus PEN-F and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
Mic / Speaker
|1.||Olympus E-M1||Y||stereo / mono||Y||-||micro||2.0||Y||-||-|
|2.||Olympus PEN-F||Y||stereo / mono||-||-||micro||2.0||Y||-||-|
|3.||Olympus E-M1 II||Y||stereo / mono||Y||Y||micro||3.0||Y||-||-|
|4.||Olympus E-M5 II||Y||stereo / mono||Y||-||micro||2.0||Y||-||-|
|5.||Olympus E-M10 II||Y||stereo / mono||-||-||micro||2.0||Y||-||-|
|6.||Olympus E-M10||Y||stereo / mono||-||-||micro||2.0||Y||-||-|
|7.||Olympus E-P5||Y||stereo / mono||-||-||micro||2.0||Y||-||-|
|8.||Olympus E-M5||Y||stereo / mono||-||-||mini||2.0||-||-||-|
|9.||Panasonic G80||Y||stereo / mono||Y||-||micro||2.0||Y||-||-|
|10.||Panasonic GX8||Y||stereo / mono||Y||-||micro||2.0||Y||Y||-|
|11.||Panasonic GH4||Y||stereo / mono||Y||Y||micro||2.0||Y||Y||-|
|12.||Panasonic GH3||Y||stereo / mono||Y||Y||mini||2.0||Y||-||-|
It is notable that the E-M1 has a microphone port, which is missing on the PEN-F. Such an external microphone input can help to substantially improve the quality of audio recordings when a good external microphone is used.
Studio photographers will appreciate that the Olympus E-M1 (unlike the PEN-F) features a PC Sync socket, so that professional strobe lights can be controlled by the camera.
Both the E-M1 and the PEN-F have been discontinued, but can regularly be found used on ebay. The E-M1 was replaced by the Olympus E-M1 II, while the PEN-F does not have a direct successor. Further information on the features and operation of the E-M1 and PEN-F can be found, respectively, in the Olympus E-M1 Manual (free pdf) or the online Olympus PEN-F Manual.
So what conclusions can be drawn? Which of the two cameras – the Olympus E-M1 or the Olympus PEN-F – has the upper hand? Is one clearly better than the other? The listing below highlights the relative strengths of the two models.
Reasons to prefer the Olympus OM-D E-M1:
- Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
- Better sound: Can connect to an external microphone for higher quality sound recording.
- Larger viewfinder image: Features a viewfinder with a higher magnification (0.74x vs 0.62x).
- Better sealing: Is weather sealed to enable shooting in dusty or wet environments.
- Better studio light control: Has a PC Sync socket to connect to professional strobe lights.
- More heavily discounted: Has been available for much longer (launched in September 2013).
Advantages of the Olympus PEN-F:
- More detail: Has more megapixels (20.2 vs 15.9MP), which boosts linear resolution by 13%.
- High quality composites: Can combine several shots after pixel-shifting its sensor.
- Better video: Provides higher movie framerates (1080/60p versus 1080/30p).
- More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
- More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
- More compact: Is smaller (125x72mm vs 130x94mm) and will fit more readily into a bag.
- Less heavy: Has a lower weight (by 70g or 14 percent) and is thus easier to take along.
- Faster buffer clearing: Supports a more advanced SD data transfer standard (UHS-II vs UHS-I).
- More affordable: Was released into a lower priced segment (14 percent cheaper at launch).
- More modern: Reflects 2 years and 4 months of technical progress since the E-M1 launch.
If the count of individual advantages (bullet points above) is taken as a guide, the PEN-F is the clear winner of the contest (10 : 6 points). However, the pertinence of the various camera strengths will differ across photographers, so that you might want to weigh individual camera traits according to their importance for your own imaging needs before making a camera decision. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Olympus E-M1 and the Olympus PEN-F place the cameras among the top in their class? Find out in the latest Best Mirrorless Interchangeable Lens Camera listing whether the two cameras rank among the cream of the crop.
In any case, while the specs-based evaluation of cameras can be instructive in revealing their potential as photographic tools, it remains incomplete and does no justice, for example, to the way the E-M1 or the PEN-F perform in practice. At times, user reviews, such as those published at amazon, address these issues in a useful manner, but such feedback is on many occasions incomplete, inconsistent, and unreliable.
This is why expert reviews are important. The adjacent summary-table relays the overall verdicts of several of the most popular camera review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|1.||Olympus E-M1||5/5||+ +||..||84/100||4.5/5||4.5/5||Sep 2013||1,399||ebay.com|
|2.||Olympus PEN-F||..||..||4/5||82/100||4.5/5||5/5||Jan 2016||1,199||ebay.com|
|3.||Olympus E-M1 II||5/5||+ +||5/5||85/100||4.5/5||4.5/5||Sep 2016||1,999||ebay.com|
|4.||Olympus E-M5 II||5/5||+ +||4.5/5||81/100||5/5||5/5||Feb 2015||1,099||ebay.com|
|5.||Olympus E-M10 II||4.5/5||+ +||..||80/100||5/5||5/5||Aug 2015||649||ebay.com|
|6.||Olympus E-M10||4/5||..||..||80/100||5/5||5/5||Jan 2014||699||ebay.com|
|7.||Olympus E-P5||5/5||+ +||..||78/100||4.5/5||5/5||May 2013||999||ebay.com|
|8.||Olympus E-M5||4/5||+ +||..||80/100||4.5/5||5/5||Feb 2012||1,299||ebay.com|
|9.||Panasonic G80||..||+ +||..||84/100||5/5||4.5/5||Sep 2016||899||ebay.com|
|10.||Panasonic GX8||5/5||+||..||82/100||4.5/5||4.5/5||Jul 2015||1,199||ebay.com|
|11.||Panasonic GH4||5/5||+ +||..||85/100||5/5||5/5||Feb 2014||1,499||ebay.com|
|12.||Panasonic GH3||5/5||+ +||..||79/100||4.5/5||4.5/5||Sep 2012||1,299||ebay.com|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
The review scores listed above should be treated with care, though. The ratings were established in reference to similarly priced cameras that were available in the market at the time of the review. A score, therefore, has to be seen in close connection to the price and market introduction time of the camera, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. It should also be noted that some of the review sites have over time altered the way they render their verdicts.
Other camera comparisons
Did this review help to inform your camera decision process? In case you would like to check on the differences and similarities of other camera models, just make your choice using the following search menu. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 1Ds Mark II vs Olympus PEN-F
- Canon G5 X vs Olympus PEN-F
- Canon T5 vs Olympus E-M1
- Fujifilm GFX 100S vs Olympus E-M1
- Fujifilm X-T10 vs Olympus E-M1
- Fujifilm X-T3 vs Olympus PEN-F
- Fujifilm X100S vs Olympus PEN-F
- Fujifilm X20 vs Olympus E-M1
- Nikon A1000 vs Olympus E-M1
- Nikon D3300 vs Olympus E-M1
- Olympus E-300 vs Olympus PEN-F
- Olympus PEN-F vs Sony A9
Specifications: Olympus E-M1 vs Olympus PEN-F
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Olympus E-M1||Olympus PEN-F|
|Camera Type||Mirrorless system camera||Mirrorless system camera|
|Camera Lens||Micro Four Thirds lenses||Micro Four Thirds lenses|
|Launch Date||September 2013||January 2016|
|Launch Price||USD 1,399||USD 1,199|
|Sensor Specs||Olympus E-M1||Olympus PEN-F|
|Sensor Format||Four Thirds Sensor||Four Thirds Sensor|
|Sensor Size||17.3 x 13.0 mm||17.3 x 13.0 mm|
|Sensor Area||224.9 mm2||224.9 mm2|
|Sensor Diagonal||21.6 mm||21.6 mm|
|Sensor Resolution||15.9 Megapixels||20.2 Megapixels|
|Image Resolution||4608 x 3456 pixels||5184 x 3888 pixels|
|Pixel Pitch||3.76 μm||3.34 μm|
|Pixel Density||7.08 MP/cm2||8.96 MP/cm2|
|Moiré control||no AA filter||no AA filter|
|Movie Capability||1080/30p Video||1080/60p Video|
|ISO Setting||200 - 25,600 ISO||80 - 25,600 ISO|
|ISO Boost||100 - 25,600 ISO||no Enhancement|
|Image Processor||TruePIC VII||TruePic VII|
|DXO Sensor Quality (score)||73||74|
|DXO Color Depth (bits)||23.0||23.1|
|DXO Dynamic Range (EV)||12.7||12.4|
|DXO Low Light (ISO)||757||894|
|Screen Specs||Olympus E-M1||Olympus PEN-F|
|Viewfinder Type||Electronic viewfinder||Electronic viewfinder|
|Viewfinder Field of View||100%||100%|
|Viewfinder Resolution||2360k dots||2360k dots|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0inch||3.0inch|
|LCD Resolution||1037k dots||1037k dots|
|LCD Attachment||Tilting screen||Swivel screen|
|Shooting Specs||Olympus E-M1||Olympus PEN-F|
|Focus System||On-Sensor Phase-detect||Contrast-detect AF|
|Manual Focusing Aid||Focus Peaking||Focus Peaking|
|Max Shutter Speed (mechanical)||1/8000s||1/8000s|
|Continuous Shooting||10 shutter flaps/s||10 shutter flaps/s|
|Electronic Shutter||YES||up to 1/16000s|
|Time-Lapse Photography||Intervalometer built-in||Intervalometer built-in|
|Image Stabilization||In-body stabilization||In-body stabilization|
|Fill Flash||no On-Board Flash||no On-Board Flash|
|Storage Medium||SDXC cards||SDXC cards|
|Single or Dual Card Slots||Single card slot||Single card slot|
|UHS card support||UHS-I||UHS-II|
|Connectivity Specs||Olympus E-M1||Olympus PEN-F|
|Studio Flash||PC Sync socket||no PC Sync|
|USB Connector||USB 2.0||USB 2.0|
|HDMI Port||micro HDMI||micro HDMI|
|Microphone Port||External MIC port||no MIC socket|
|Wifi Support||Wifi built-in||Wifi built-in|
|Body Specs||Olympus E-M1||Olympus PEN-F|
|Environmental Sealing||Weathersealed body||not weather sealed|
|Battery Life (CIPA)||350 shots per charge||330 shots per charge|
130 x 94 x 63 mm
(5.1 x 3.7 x 2.5 in)
125 x 72 x 37 mm
(4.9 x 2.8 x 1.5 in)
|Camera Weight||497 g (17.5 oz)||427 g (15.1 oz)|
