Canon M5 vs Nikon D5100
The Canon EOS M5 and the Nikon D5100 are two digital cameras that were revealed to the public, respectively, in September 2016 and April 2011. The M5 is a mirrorless interchangeable lens camera, while the D5100 is a DSLR. Both cameras are equipped with an APS-C sensor. The Canon has a resolution of 24 megapixels, whereas the Nikon provides 16.1 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
|Canon M5||Nikon D5100|
|Mirrorless system camera||Digital single lens reflex|
|Canon EF-M mount lenses||Nikon F mount lenses|
|24 MP, APS-C Sensor||16.1 MP, APS-C Sensor|
|1080/60p Video||1080/30p Video|
|ISO 100-25600||ISO 100-6400 (100-25600)|
|Electronic viewfinder (2360k dots)||Optical viewfinder|
|3.2" LCD, 1620k dots||3.0" LCD, 921k dots|
|Tilting touchscreen||Swivel screen (not touch-sensitive)|
|9 shutter flaps per second||4 shutter flaps per second|
|295 shots per battery charge||660 shots per battery charge|
|116 x 89 x 61 mm, 427 g||128 x 97 x 79 mm, 560 g|
Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS M5 and the Nikon D5100? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
The physical size and weight of the Canon M5 and the Nikon D5100 are illustrated in the side-by-side display below. The two cameras are presented according to their relative size. Three successive views from the front, the top, and the rear are shown. All width, height and depth measures are rounded to the nearest millimeter.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Nikon D5100 is notably larger (20 percent) than the Canon M5. Moreover, the D5100 is markedly heavier (31 percent) than the M5. In this context, it is worth noting that neither the M5 nor the D5100 are weather-sealed.
The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. Hence, you might want to study and compare the specifications of available lenses in order to get the full picture of the size and weight of the two camera systems.
The following table provides a synthesis of the main physical specifications of the two cameras and other similar ones. If you want to switch the focus of the display and review another camera pair, just select a new right or left comparator from among the camera models in the table. Alternatively, you can also move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.
|Canon M5»||116 mm||89 mm||61 mm||427 g||295||n||Sep 2016||979||Canon M5|
|Nikon D5100«||128 mm||97 mm||79 mm||560 g||660||n||Apr 2011||749||Nikon D5100|
|Canon 77D« »||131 mm||100 mm||76 mm||540 g||600||n||Feb 2017||899||Canon 77D|
|Canon 200D« »||122 mm||93 mm||70 mm||453 g||650||n||Jun 2017||549||Canon 200D|
|Canon G9 X Mark II« »||98 mm||58 mm||31 mm||206 g||235||n||Jan 2017||529||Canon G9 X Mark II|
|Canon M6« »||112 mm||68 mm||45 mm||390 g||295||n||Feb 2017||779||Canon M6|
|Canon M100« »||108 mm||67 mm||35 mm||302 g||295||n||Aug 2017||499||Canon M100|
|Canon 760D« »||132 mm||101 mm||78 mm||565 g||440||n||Feb 2015||649||Canon 760D|
|Canon M3« »||111 mm||68 mm||44 mm||366 g||250||n||Feb 2015||679||Canon M3|
|Fujifilm X-T20« »||118 mm||83 mm||41 mm||383 g||350||n||Jan 2017||899||Fujifilm X-T20|
|Nikon D5600« »||124 mm||97 mm||70 mm||465 g||970||n||Nov 2016||699||Nikon D5600|
|Nikon D5500« »||124 mm||97 mm||70 mm||420 g||820||n||Jan 2015||899||Nikon D5500|
|Nikon D5300« »||125 mm||98 mm||76 mm||480 g||600||n||Oct 2013||799||Nikon D5300|
|Nikon D5200« »||129 mm||98 mm||78 mm||555 g||500||n||Nov 2012||749||Nikon D5200|
|Nikon D3100« »||124 mm||96 mm||75 mm||505 g||550||n||Aug 2010||599||Nikon D3100|
|Nikon D5000« »||127 mm||104 mm||80 mm||590 g||510||n||Apr 2009||749||Nikon D5000|
|Note: Measurements and pricing do not include easily detachable parts, such as interchangeable lenses or optional viewfinders.|
Any camera decision will naturally be influenced heavily by the price. The manufacturer’s suggested retail prices give an idea on the placement of the camera in the maker’s lineup and the broader market. The D5100 was launched at a somewhat lower price (by 23 percent) than the M5, which makes it more attractive for photographers on a tight budget. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.
The size of the sensor inside a digital camera is one of the key determinants of image quality. A large sensor will generally have larger individual pixels that offer better low-light sensitivity, provide wider dynamic range, and have richer color-depth than smaller pixels in a sensor of the same technological generation. Further, a large sensor camera will give the photographer additional creative options when using shallow depth-of-field to isolate a subject from its background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.
Both cameras under consideration feature an APS-C sensor, but their sensors differ slightly in size. The sensor area in the D5100 is 12 percent bigger. As a result of these sensor size differences, the cameras have format factors, respectively, of 1.6 (M5) and 1.5. Both cameras have a native aspect ratio (sensor width to sensor height) of 3:2.
Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors.
Despite having a smaller sensor, the Canon M5 offers a higher resolution of 24 megapixels, compared with 16.1 MP of the Nikon D5100. This megapixels advantage comes at the cost of a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 3.72μm versus 4.80μm for the D5100). However, it should be noted that the M5 is much more recent (by 5 years and 5 months) than the D5100, and its sensor will have benefitted from technological advances during this time that make it possible to gather light more efficiently.
The resolution advantage of the Canon M5 implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the M5 for good quality output (200 dots per inch) amounts to 30 x 20 inch or 76.2 x 50.8 cm, for very good quality (250 dpi) 24 x 16 inch or 61 x 40.6 cm, and for excellent quality (300 dpi) 20 x 13.3 inch or 50.8 x 33.9 cm. The corresponding values for the Nikon D5100 are 24.6 x 16.3 inch or 62.6 x 41.5 cm for good quality, 19.7 x 13.1 inch or 50.1 x 33.2 cm for very good quality, and 16.4 x 10.9 inch or 41.7 x 27.6 cm for excellent quality prints.
The M5 has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.
The Canon EOS M5 has a native sensitivity range from ISO 100 to ISO 25600. The corresponding ISO settings for the Nikon D5100 are ISO 100 to ISO 6400, with the possibility to increase the ISO range to 100-25600.
Since 2007, DXO Mark has published sensor performance measurements that have been derived using a consistent methodology. This service assesses and scores the color depth ("DXO Portrait"), dynamic range ("DXO Landscape"), and low-light sensitivity ("DXO Sports") of camera sensors, and also publishes an overall camera score. The Overall DXO ratings for the two cameras under consideration are close, suggesting that they provide similar imaging performance. The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.
|Canon M5||APS-C||24.0||6000||4000||1080/60p||23.4||12.4||1262||77||Canon M5|
|Nikon D5100||APS-C||16.1||4928||3264||1080/30p||23.5||13.6||1183||80||Nikon D5100|
|Canon 77D||APS-C||24.0||6000||4000||1080/60p||23.6||13.3||971||78||Canon 77D|
|Canon 200D||APS-C||24.0||6000||4000||1080/60p||23.6||13.4||1041||79||Canon 200D|
|Canon G9 X Mark II||1-inch||20.0||5472||3648||1080/60p||21.9||12.5||522||65||Canon G9 X Mark II|
|Canon M6||APS-C||24.0||6000||4000||1080/60p||..||..||..||..||Canon M6|
|Canon M100||APS-C||24.0||6000||4000||1080/60p||23.5||12.9||1272||78||Canon M100|
|Canon 760D||APS-C||24.0||6000||4000||1080/30p||22.6||12.0||915||70||Canon 760D|
|Canon M3||APS-C||24.0||6000||4000||1080/30p||22.8||11.8||1169||72||Canon M3|
|Fujifilm X-T20||APS-C||24.0||6000||4000||4K/30p||..||..||..||..||Fujifilm X-T20|
|Nikon D5600||APS-C||24.0||6000||4000||1080/60p||24.1||14.0||1306||84||Nikon D5600|
|Nikon D5500||APS-C||24.0||6000||4000||1080/60p||24.1||14.0||1438||84||Nikon D5500|
|Nikon D5300||APS-C||24.0||6000||4000||1080/60p||24.0||13.9||1338||83||Nikon D5300|
|Nikon D5200||APS-C||24.0||6000||4000||1080/60i||24.2||13.9||1284||84||Nikon D5200|
|Nikon D3100||APS-C||14.2||4608||3072||1080/24p||22.5||11.3||919||67||Nikon D3100|
|Nikon D5000||APS-C||12.2||4288||2848||720/24p||22.7||12.5||868||72||Nikon D5000|
Many modern cameras are not only capable of taking still images, but also of capturing video footage. The two cameras under consideration both have sensors whose read-out speed is fast enough to capture moving pictures, but the M5 provides a higher frame rate than the D5100. It can shoot video footage at 1080/60p, while the Nikon is limited to 1080/30p.
Beyond body and sensor, cameras can and do differ across a range of features. For example, the M5 has an electronic viewfinder (2360k dots), while the D5100 has an optical one. Both systems have their advantages, with the electronic viewfinder making it possible to project supplementary shooting information into the framing view, whereas the optical viewfinder offers lag-free viewing and a very clear framing image. The table below summarizes some of the other core capabilities of the Canon M5 and Nikon D5100 in connection with corresponding information for a sample of similar cameras.
|Canon M5||2360||n||3.2||1620||tilting||Y||1/4000s||9.0||Y||n||Canon M5|
|Nikon D5100||optical||n||3.0||921||swivel||n||1/4000s||4.0||Y||n||Nikon D5100|
|Canon 77D||optical||Y||3.0||1040||swivel||Y||1/4000s||6.0||Y||n||Canon 77D|
|Canon 200D||optical||n||3.0||1040||swivel||Y||1/4000s||5.0||Y||n||Canon 200D|
|Canon G9 X Mark II||none||n||3.0||1040||fixed||Y||1/2000s||8.2||Y||Y||Canon G9 X Mark II|
|Canon M6||optional||n||3.0||1040||tilting||Y||1/4000s||9.0||Y||n||Canon M6|
|Canon M100||none||n||3.0||1040||tilting||Y||1/4000s||6.1||Y||n||Canon M100|
|Canon 760D||optical||Y||3.0||1040||swivel||Y||1/4000s||5.0||Y||n||Canon 760D|
|Canon M3||optional||n||3.0||1040||tilting||Y||1/4000s||4.2||Y||n||Canon M3|
|Fujifilm X-T20||2360||n||3.0||1040||tilting||Y||1/4000s||8.0||Y||n||Fujifilm X-T20|
|Nikon D5600||optical||n||3.2||1037||swivel||Y||1/4000s||5.0||Y||n||Nikon D5600|
|Nikon D5500||optical||n||3.2||1037||swivel||Y||1/4000s||5.0||Y||n||Nikon D5500|
|Nikon D5300||optical||n||3.2||1037||swivel||n||1/4000s||5.0||Y||n||Nikon D5300|
|Nikon D5200||optical||n||3.0||921||swivel||n||1/4000s||5.0||Y||n||Nikon D5200|
|Nikon D3100||optical||n||3.0||230||fixed||n||1/4000s||3.0||Y||n||Nikon D3100|
|Nikon D5000||optical||n||2.7||230||full-flex||n||1/4000s||4.0||Y||n||Nikon D5000|
One differentiating feature between the two cameras concerns the touch sensitivity of the rear screen. The M5 has a touchscreen, while the D5100 has a conventional panel. Touch control can be particularly helpful, for example, for setting the focus point.Both cameras have an articulated rear screen that can be turned to be front-facing. This feature will be particularly appreciated by vloggers and photographers who are interested in taking selfies.
The Nikon D5100 has an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
Concerning the storage of imaging data, both the M5 and the D5100 write their files to SDXC cards. Both cameras can use UHS-I cards, which provide for Ultra High Speed data transfer of up to 104 MB/s.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS M5 and Nikon D5100 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
|Canon M5||Y||stereo||mono||Y||-||mini||2.0||Y||Y||Y||Canon M5|
|Nikon D5100||Y||mono||mono||Y||-||mini||2.0||-||-||-||Nikon D5100|
|Canon 77D||Y||stereo||mono||Y||-||mini||2.0||Y||Y||Y||Canon 77D|
|Canon 200D||Y||stereo||mono||Y||-||mini||2.0||Y||Y||Y||Canon 200D|
|Canon G9 X Mark II||-||stereo||mono||-||-||micro||2.0||Y||Y||Y||Canon G9 X Mark II|
|Canon M6||Y||stereo||mono||Y||-||mini||2.0||Y||Y||Y||Canon M6|
|Canon M100||-||stereo||mono||-||-||mini||2.0||Y||Y||Y||Canon M100|
|Canon 760D||Y||stereo||mono||Y||-||mini||2.0||Y||Y||-||Canon 760D|
|Canon M3||Y||stereo||mono||Y||-||mini||2.0||Y||Y||-||Canon M3|
|Fujifilm X-T20||Y||stereo||mono||Y||-||micro||2.0||Y||-||-||Fujifilm X-T20|
|Nikon D5600||Y||stereo||mono||Y||-||mini||2.0||Y||Y||Y||Nikon D5600|
|Nikon D5500||Y||stereo||mono||Y||-||mini||2.0||Y||-||-||Nikon D5500|
|Nikon D5300||Y||stereo||mono||Y||-||mini||2.0||Y||-||-||Nikon D5300|
|Nikon D5200||Y||stereo||mono||Y||-||mini||2.0||-||-||-||Nikon D5200|
|Nikon D3100||Y||mono||mono||-||-||mini||2.0||-||-||-||Nikon D3100|
|Nikon D5000||Y||mono||mono||-||-||mini||2.0||-||-||-||Nikon D5000|
It is notable that the M5 offers wifi support, while the D5100 does not. Wifi can be a very convenient means to transfer image data to an off-camera location.
The M5 is a recent model that features in the current product line-up of Canon. In contrast, the D5100 has been discontinued (but it can be found pre-owned on eBay). As a replacement in the same line of cameras, the D5100 was succeeded by the Nikon D5200. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Canon and Nikon websites.
So how do things add up? Is there a clear favorite between the Canon M5 and the Nikon D5100? Which camera is better? A synthesis of the relative strong points of each of the models is listed below.
Advantages of the Canon EOS M5:
- More detail: Offers more megapixels (24 vs 16.1MP) with a 22% higher linear resolution.
- Better video: Provides higher movie framerates (1080/60p versus 1080/30p).
- Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
- More framing info: Has an electronic viewfinder that displays shooting data.
- Larger screen: Has a bigger rear LCD (3.2" vs 3.0") for image review and settings control.
- More detailed LCD: Has a higher resolution rear screen (1620k vs 921k dots).
- Fewer buttons to press: Is equipped with a touch-sensitive rear screen to facilitate handling.
- Faster burst: Shoots at higher frequency (9 vs 4 flaps/sec) to capture the decisive moment.
- More compact: Is smaller (116x89mm vs 128x97mm) and thus needs less room in the bag.
- Less heavy: Is lighter (by 133g or 24 percent) and hence easier to carry around.
- More legacy lens friendly: Can take a broad range of non-native lenses via adapters.
- Easier file upload: Has wifi built in for automatic backup or image transfer to the web.
- Easier device pairing: Supports NFC for fast wireless image transfer over short distances.
- Easier wireless transfer: Supports Bluetooth for image sharing without cables.
- More modern: Reflects 5 years and 5 months of technical progress since the D5100 launch.
Reasons to prefer the Nikon D5100:
- More dynamic range: Captures a broader range of light and dark details (1.2 EV of extra DR).
- Brighter framing: Features an optical viewfinder for clear, lag-free composition.
- More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
- Easier time-lapse photography: Has an intervalometer built-in for low frequency shooting.
- Longer lasting: Gets more shots (660 versus 295) out of a single battery charge.
- More affordable: Was released into a lower priced segment (23 percent cheaper at launch).
- More heavily discounted: Has been around for much longer (launched in April 2011).
If the count of relative strengths (bullet points above) is taken as a measure, the M5 is the clear winner of the match-up (15 : 7 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Canon M5 and the Nikon D5100 place the cameras among the top in their class? Find out in the latest Best Mirrorless Interchangeable Lens Camera and Best DSLR Camera listings whether the two cameras rank among the cream of the crop.
In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it says little about, for example, the shooting experience and imaging performance of the M5 and the D5100 in practical situations. User reviews, such as those found at amazon, can sometimes inform about these issues, but such feedback is often incomplete, inconsistent, and biased.
This is where reviews by experts come in. The following table reports the overall ratings of the cameras as published by some of the major camera review sites (cameralabs, dpreview, ephotozine, imaging-resource, and photographyblog). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
The above review scores should be interpreted with care, though. The assessments were made in relation to similar cameras of the same technological generation. Thus, a score needs to be put into the context of the launch date and the launch price of the camera, and comparisons of ratings among very different cameras or across long time periods have little meaning. Also, kindly note that some of the listed sites have over time developped their review approaches and their reporting style.
Other camera comparisons
Did this review help to inform your camera decision process? In case you would like to check on the differences and similarities of other camera models, just make your choice using the following search menu. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 1000D vs Nikon D5100
- Canon 2000D vs Nikon D5100
- Canon 30D vs Canon M5
- Canon G9 X Mark II vs Canon M5
- Canon G9 X Mark II vs Nikon D5100
- Canon M5 vs Canon SX610
- Canon M5 vs Ricoh GR
- Canon M5 vs Sony HX90V
- Fujifilm X100T vs Nikon D5100
- Leica SL vs Nikon D5100
- Nikon D5100 vs Pentax MX-1
- Nikon D5100 vs Sony A7S
Specifications: Canon M5 vs Nikon D5100
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Canon M5||Nikon D5100|
|Camera Type||Mirrorless system camera||Digital single lens reflex|
|Camera Lens||Canon EF-M mount lenses||Nikon F mount lenses|
|Launch Date||September 2016||April 2011|
|Launch Price||USD 979||USD 749|
|Sensor Specs||Canon M5||Nikon D5100|
|Sensor Format||APS-C Sensor||APS-C Sensor|
|Sensor Size||22.3 x 14.9 mm||23.6 x 15.7 mm|
|Sensor Area||332.27 mm2||370.52 mm2|
|Sensor Diagonal||26.8 mm||28.3 mm|
|Sensor Resolution||24 Megapixels||16.1 Megapixels|
|Image Resolution||6000 x 4000 pixels||4928 x 3264 pixels|
|Pixel Pitch||3.72 μm||4.80 μm|
|Pixel Density||7.22 MP/cm2||4.34 MP/cm2|
|Moiré control||Anti-Alias filter||Anti-Alias filter|
|Movie Capability||1080/60p Video||1080/30p Video|
|ISO Setting||100-25600 ISO||100-6400 ISO|
|ISO Boost||no Enhancement||100-25600 ISO|
|Image Processor||DIGIC 7||EXPEED 2|
|DXO Sensor Quality (score)||77||80|
|DXO Color Depth (bits)||23.4||23.5|
|DXO Dynamic Range (EV)||12.4||13.6|
|DXO Low Light (ISO)||1262||1183|
|Screen Specs||Canon M5||Nikon D5100|
|Viewfinder Type||Electronic viewfinder||Optical viewfinder|
|Viewfinder Field of View||100%||95%|
|Viewfinder Magnification||.. x||0.51x|
|Viewfinder Resolution||2360k dots|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.2 inch||3.0 inch|
|LCD Resolution||1620k dots||921k dots|
|LCD Attachment||Tilting screen||Swivel screen|
|Touch Input||Touchscreen||no Touchscreen|
|Shooting Specs||Canon M5||Nikon D5100|
|Focus System||On-Sensor Phase-detect||Phase-detect AF|
|Manual Focusing Aid||Focus Peaking||No Peaking Feature|
|Continuous Shooting||9 shutter flaps/s||4 shutter flaps/s|
|Shutter Life Expectancy||100 000 actuations||100 000 actuations|
|Time-Lapse Photography||no Intervalometer||Intervalometer built-in|
|Fill Flash||Build-in Flash||Build-in Flash|
|Storage Medium||SDXC cards||SDXC cards|
|Second Storage Option||Single card slot||Single card slot|
|UHS card support||UHS-I||UHS-I|
|Connectivity Specs||Canon M5||Nikon D5100|
|USB Connector||USB 2.0||USB 2.0|
|HDMI Port||mini HDMI||mini HDMI|
|Microphone Port||External MIC port||External MIC port|
|Wifi Support||Wifi built-in||no Wifi|
|Near-Field Communication||NFC built-in||no NFC|
|Bluetooth Support||Bluetooth built-in||no Bluetooth|
|Body Specs||Canon M5||Nikon D5100|
|Battery Life (CIPA)||295 shots per charge||660 shots per charge|
116 x 89 x 61 mm
(4.6 x 3.5 x 2.4 in)
128 x 97 x 79 mm
(5.0 x 3.8 x 3.1 in)
|Camera Weight||427 g (15.1 oz)||560 g (19.8 oz)|
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
