Canon 200D vs Olympus E-400

The Canon EOS 200D (called Canon SL2 in some regions) and the Olympus E-400 are two digital cameras that were announced, respectively, in June 2017 and September 2006. Both are DSLR (Digital Single Lens Reflex) cameras that are based on an APS-C (200D) and a Four Thirds (E-400) sensor. The Canon has a resolution of 24 megapixels, whereas the Olympus provides 10 MP.

Below is an overview of the main specs of the two cameras as a starting point for the comparison.

Headline Specifications

Canon 200D		Olympus E-400
Digital single lens reflex		Digital single lens reflex
Canon EF mount lenses		Four Thirds lenses
24 MP – APS-C sensor		10 MP – Four Thirds sensor
1080/60p Video		no Video
ISO 100-25,600 (100 - 51,200)		ISO 100-1,600
Optical viewfinder		Optical viewfinder
3.0" LCD – 1040k dots		2.5" LCD – 215k dots
Swivel touchscreen		Fixed screen (not touch-sensitive)
5 shutter flaps per second		3 shutter flaps per second
650 shots per battery charge		500 shots per battery charge
122 x 93 x 70 mm, 453 g		130 x 91 x 53 mm, 435 g

Check 200D offers at
ebay.com
Check E-400 offers at
ebay.com

Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS 200D and the Olympus E-400? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.

Body comparison

The side-by-side display below illustrates the physical size and weight of the Canon 200D and the Olympus E-400. The two cameras are presented according to their relative size. Three consecutive views from the front, the top, and the rear side are shown. All width, height and depth dimensions are rounded to the nearest millimeter.

The 200D can be obtained in two different colors (black, white), while the E-400 is only available in black.

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Olympus E-400 is somewhat larger (4 percent) than the Canon 200D. However, the E-400 is slightly lighter (4 percent) than the 200D. In this context, it is worth noting that neither the 200D nor the E-400 are weather-sealed.

The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. A larger imaging sensor will tend to go along with bigger and heavier lenses, although exceptions exist. You can compare the optics available for the two cameras in the Canon EF Lens Catalog (200D) and the Four Thirds Lens Catalog (E-400).

Concerning battery life, the 200D gets 650 shots out of its LP-E17 battery, while the E-400 can take 500 images on a single charge of its BLS-1 power pack.

The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you would like to visualize and compare a different camera combination, you can navigate to the CAM-parator app and make your selection from a broad list of cameras there.

Body Specifications

		Camera Model	Camera Width	Camera Height	Camera Depth	Camera Weight	Battery Life	Weather Sealing	Camera Launch	Launch Price (USD)	Street Price
1.		Canon 200D	122 mm	93 mm	70 mm	453 g	650	n	Jun 2017	549	ebay.com
2.		Olympus E-400	130 mm	91 mm	53 mm	435 g	500	n	Sep 2006	699	ebay.com
3.		Canon 250D	122 mm	93 mm	70 mm	449 g	1070	n	Apr 2019	599	amazon.com
4.		Canon 2000D	129 mm	101 mm	78 mm	475 g	500	n	Feb 2018	449	amazon.com
5.		Canon 77D	131 mm	100 mm	76 mm	540 g	600	n	Feb 2017	899	ebay.com
6.		Canon 800D	131 mm	100 mm	76 mm	532 g	600	n	Feb 2017	749	ebay.com
7.		Canon G9 X Mark II	98 mm	58 mm	31 mm	206 g	235	n	Jan 2017	529	amazon.com
8.		Canon M100	108 mm	67 mm	35 mm	302 g	295	n	Aug 2017	499	ebay.com
9.		Canon M5	116 mm	89 mm	61 mm	427 g	295	n	Sep 2016	979	ebay.com
10.		Canon 760D	132 mm	101 mm	78 mm	565 g	440	n	Feb 2015	649	ebay.com
11.		Canon 100D	117 mm	91 mm	69 mm	407 g	380	n	Mar 2013	549	ebay.com
12.		Nikon D3400	124 mm	98 mm	76 mm	445 g	1200	n	Aug 2016	499	ebay.com
13.		Olympus E-420	130 mm	91 mm	53 mm	440 g	500	n	Mar 2008	599	ebay.com
14.		Olympus E-410	130 mm	91 mm	53 mm	435 g	500	n	Mar 2007	699	ebay.com
15.		Olympus E-510	136 mm	92 mm	68 mm	538 g	750	n	Mar 2007	799	ebay.com
16.		Olympus E-500	130 mm	95 mm	66 mm	479 g	750	n	Sep 2005	599	ebay.com
17.		Panasonic L10	135 mm	96 mm	78 mm	556 g	450	n	Aug 2007	599	ebay.com
Note: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
Convert to Imperial

The price is, of course, an important factor in any camera decision. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The 200D was launched at a somewhat lower price (by 21 percent) than the E-400, which makes it more attractive for photographers on a tight budget. Normally, street prices remain initially close to the MSRP, but after a couple of months, the first discounts appear. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.

Sensor comparison

The size of the imaging sensor is a crucial determinant of image quality. All other things equal, a large sensor will have larger individual pixel-units that offer better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixels in a sensor of the same technological generation. Further, a large sensor camera will give the photographer additional creative options when using shallow depth-of-field to isolate a subject from its background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.

Of the two cameras under consideration, the Canon 200D features an APS-C sensor and the Olympus E-400 a Four Thirds sensor. The sensor area in the E-400 is 32 percent smaller. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.6 and 2.0. The sensor in the 200D has a native 3:2 aspect ratio, while the one in the E-400 offers a 4:3 aspect.

With 24MP, the 200D offers a higher resolution than the E-400 (10MP), but the 200D has smaller individual pixels (pixel pitch of 3.72μm versus 4.74μm for the E-400). However, the 200D is a much more recent model (by 10 years and 9 months) than the E-400, and its sensor will have benefitted from technological advances during this time that enhance the light gathering capacity of its pixels.

The resolution advantage of the Canon 200D implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the 200D for good quality output (200 dots per inch) amounts to 30 x 20 inches or 76.2 x 50.8 cm, for very good quality (250 dpi) 24 x 16 inches or 61 x 40.6 cm, and for excellent quality (300 dpi) 20 x 13.3 inches or 50.8 x 33.9 cm. The corresponding values for the Olympus E-400 are 18.2 x 13.7 inches or 46.3 x 34.7 cm for good quality, 14.6 x 10.9 inches or 37.1 x 27.8 cm for very good quality, and 12.2 x 9.1 inches or 30.9 x 23.2 cm for excellent quality prints.

The 200D has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.

The Canon EOS 200D has a native sensitivity range from ISO 100 to ISO 25600, which can be extended to ISO 100-51200. The corresponding ISO settings for the Olympus E-400 are ISO 100 to ISO 1600 (no boost).

Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors. Both cameras use a Bayer filter for capturing RGB colors on a square grid of photosensors. This arrangement is found in most digital cameras.

Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). The following table provides an overview of the physical sensor characteristics, as well as the sensor quality measurements for a selection of comparators.

Sensor Characteristics

		Camera Model	Sensor Class	Resolution (MP)	Horiz. Pixels	Vert. Pixels	Video Format	DXO Portrait	DXO Landscape	DXO Sports	DXO Overall
1.		Canon 200D	APS-C	24.0	6000	4000	1080/60p	23.6	13.4	1041	79
2.		Olympus E-400	Four Thirds	10.0	3648	2736	none	21.0	10.6	127	53
3.		Canon 250D	APS-C	24.0	6000	4000	4K/25p	23.9	13.4	1791	82
4.		Canon 2000D	APS-C	24.0	6000	4000	1080/30p	22.6	11.9	1009	71
5.		Canon 77D	APS-C	24.0	6000	4000	1080/60p	23.6	13.3	971	78
6.		Canon 800D	APS-C	24.0	6000	4000	1080/60p	23.7	13.1	1586	80
7.		Canon G9 X Mark II	1-inch	20.0	5472	3648	1080/60p	21.9	12.5	522	65
8.		Canon M100	APS-C	24.0	6000	4000	1080/60p	23.5	12.9	1272	78
9.		Canon M5	APS-C	24.0	6000	4000	1080/60p	23.4	12.4	1262	77
10.		Canon 760D	APS-C	24.0	6000	4000	1080/30p	22.6	12.0	915	70
11.		Canon 100D	APS-C	17.9	5184	3456	1080/30p	21.8	11.3	843	63
12.		Nikon D3400	APS-C	24.0	6000	4000	1080/60p	24.8	13.9	1192	86
13.		Olympus E-420	Four Thirds	10.0	3648	2736	none	21.5	10.4	527	56
14.		Olympus E-410	Four Thirds	10.0	3648	2736	none	21.1	10.0	494	51
15.		Olympus E-510	Four Thirds	10.0	3648	2736	none	21.2	10.0	442	52
16.		Olympus E-500	Four Thirds	8.0	3264	2448	none	20.7	10.3	45	51
17.		Panasonic L10	Four Thirds	10.0	3648	2736	none	21.3	10.8	429	55
Note: DXO values in italics represent estimates based on sensor size and age.

Many modern cameras cannot only take still pictures, but also record videos. The 200D indeed provides movie recording capabilities, while the E-400 does not. The highest resolution format that the 200D can use is 1080/60p.

Feature comparison

Apart from body and sensor, cameras can and do differ across a variety of features. The 200D and the E-400 are similar in the sense that both have an optical viewfinder. The latter is useful for getting a clear image for framing even in brightly lit environments. The viewfinders of both cameras offer the same field of view (95%), but the viewfinder of the 200D has a higher magnification than the one of the E-400 (0.54x vs 0.46x), so that the size of the image transmitted appears closer to the size seen with the naked human eye. The following table reports on some other key feature differences and similarities of the Canon 200D, the Olympus E-400, and comparable cameras.

Core Features

		Camera Model	Viewfinder (Type or 000 dots)	Control Panel (yes/no)	LCD Specifications (inch/000 dots)	LCD Attach- ment	Touch Screen (yes/no)	Max Shutter Speed *	Max Shutter Flaps *	Built-in Flash (yes/no)	Built-in Image Stab
1.		Canon 200D	optical	n	3.0 / 1040	swivel	Y	1/4000s	5.0/s	Y	n
2.		Olympus E-400	optical	n	2.5 / 215	fixed	n	1/4000s	3.0/s	Y	n
3.		Canon 250D	optical	n	3.0 / 1040	swivel	Y	1/4000s	5.0/s	Y	n
4.		Canon 2000D	optical	n	3.0 / 920	fixed	n	1/4000s	3.0/s	Y	n
5.		Canon 77D	optical	Y	3.0 / 1040	swivel	Y	1/4000s	6.0/s	Y	n
6.		Canon 800D	optical	n	3.0 / 1040	swivel	Y	1/4000s	6.0/s	Y	n
7.		Canon G9 X Mark II	none	n	3.0 / 1040	fixed	Y	1/2000s	8.2/s	Y	Y
8.		Canon M100	none	n	3.0 / 1040	tilting	Y	1/4000s	6.1/s	Y	n
9.		Canon M5	2360	n	3.2 / 1620	tilting	Y	1/4000s	9.0/s	Y	n
10.		Canon 760D	optical	Y	3.0 / 1040	swivel	Y	1/4000s	5.0/s	Y	n
11.		Canon 100D	optical	n	3.0 / 1040	fixed	Y	1/4000s	4.9/s	Y	n
12.		Nikon D3400	optical	n	3.0 / 921	fixed	n	1/4000s	5.0/s	Y	n
13.		Olympus E-420	optical	n	2.7 / 215	fixed	n	1/4000s	3.5/s	Y	n
14.		Olympus E-410	optical	n	2.5 / 215	fixed	n	1/4000s	3.0/s	Y	n
15.		Olympus E-510	optical	n	2.5 / 215	fixed	n	1/4000s	3.0/s	Y	Y
16.		Olympus E-500	optical	n	2.5 / 215	fixed	n	1/4000s	2.5/s	Y	n
17.		Panasonic L10	optical	n	2.5 / 207	swivel	n	1/4000s	3.0/s	Y	n
Notes: *) Information refers to the mechanical shutter, unless the camera only has an electronic one.

One differentiating feature between the two cameras concerns the touch sensitivity of the rear screen. The 200D has a touchscreen, while the E-400 has a conventional panel. Touch control can be particularly helpful, for example, for setting the focus point.

The 200D writes its imaging data to SDXC cards, while the E-400 uses Compact Flash or xD Picture cards. The E-400 features dual card slots, which can be very useful in case a memory card fails. In contrast, the 200D only has one slot.

Connectivity comparison

For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS 200D and Olympus E-400 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.

Input-Output Connections

		Camera Model	Hotshoe Port	Internal Mic / Speaker	Microphone Port	Headphone Port	HDMI Port	USB Port	WiFi Support	NFC Support	Bluetooth Support
1.		Canon 200D	Y	stereo / mono	Y	-	mini	2.0	Y	Y	Y
2.		Olympus E-400	Y	- / -	-	-	-	2.0	-	-	-
3.		Canon 250D	Y	stereo / mono	Y	-	mini	2.0	Y	-	Y
4.		Canon 2000D	Y	mono / mono	-	-	mini	2.0	Y	Y	-
5.		Canon 77D	Y	stereo / mono	Y	-	mini	2.0	Y	Y	Y
6.		Canon 800D	Y	stereo / mono	Y	-	mini	2.0	Y	Y	Y
7.		Canon G9 X Mark II	-	stereo / mono	-	-	micro	2.0	Y	Y	Y
8.		Canon M100	-	stereo / mono	-	-	micro	2.0	Y	Y	Y
9.		Canon M5	Y	stereo / mono	Y	-	mini	2.0	Y	Y	Y
10.		Canon 760D	Y	stereo / mono	Y	-	mini	2.0	Y	Y	-
11.		Canon 100D	Y	mono / mono	Y	-	mini	2.0	-	-	-
12.		Nikon D3400	Y	mono / mono	-	-	mini	2.0	-	-	Y
13.		Olympus E-420	Y	- / -	-	-	-	2.0	-	-	-
14.		Olympus E-410	Y	- / -	-	-	-	2.0	-	-	-
15.		Olympus E-510	Y	- / -	-	-	-	2.0	-	-	-
16.		Olympus E-500	Y	- / -	-	-	-	2.0	-	-	-
17.		Panasonic L10	Y	- / -	-	-	-	2.0	-	-	-

It is notable that the 200D offers wifi support, while the E-400 does not. Wifi can be a very convenient means to transfer image data to an off-camera location.

Both the 200D and the E-400 have been discontinued, but can regularly be found used on ebay. The E-400 was replaced by the Olympus E-410, while the 200D was followed by the Canon 250D. Further information on the features and operation of the 200D and E-400 can be found, respectively, in the Canon 200D Manual (free pdf) or the online Olympus E-400 Manual.

Review summary

So what is the bottom line? Is the Canon 200D better than the Olympus E-400 or vice versa? Below is a summary of the relative strengths of each of the two contestants.

Arguments in favor of the Canon EOS 200D:

• More detail: Offers more megapixels (24 vs 10MP) with a 58% higher linear resolution.
• Better image quality: Features a larger and more technologically advanced imaging sensor.
• Richer colors: The sensor size advantage translates into images with better, more accurate colors.
• More dynamic range: Larger sensor captures a wider spectrum of light and dark details.
• Better low-light sensitivity: Larger sensor produces good images even in poorly lit environments.
• Broader imaging potential: Can record not only still images but also 1080/60p movies.
• Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
• Larger viewfinder image: Features a viewfinder with a higher magnification (0.54x vs 0.46x).
• Larger screen: Has a bigger rear LCD (3.0" vs 2.5") for image review and settings control.
• More detailed LCD: Has a higher resolution rear screen (1040k vs 215k dots).
• More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
• Fewer buttons to press: Is equipped with a touch-sensitive rear screen to facilitate handling.
• More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
• Faster burst: Shoots at higher frequency (5 vs 3 flaps/sec) to capture the decisive moment.
• Longer lasting: Can take more shots (650 versus 500) on a single battery charge.
• Easier file upload: Has wifi built in for automatic backup or image transfer to the web.
• Easier device pairing: Supports NFC for fast wireless image transfer over short distances.
• Easier wireless transfer: Supports Bluetooth for image sharing without cables.
• More affordable: Was introduced into a lower priced segment (21 percent cheaper at launch).
• More modern: Reflects 10 years and 9 months of technical progress since the E-400 launch.

Reasons to prefer the Olympus E-400:

• Greater peace of mind: Features a second card slot as a backup in case of memory card failure.
• More heavily discounted: Has been around for much longer (launched in September 2006).

If the number of relative strengths (bullet points above) is taken as a guide, the 200D is the clear winner of the match-up (20 : 2 points). However, the pertinence of the various camera strengths will differ across photographers, so that you might want to weigh individual camera traits according to their importance for your own imaging needs before making a camera decision. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.

How about other alternatives? Do the specifications of the Canon 200D and the Olympus E-400 place the cameras among the top in their class? Find out in the latest Best DSLR Camera listing whether the two cameras rank among the cream of the crop.

In any case, while the specs-based evaluation of cameras can be instructive in revealing their potential as photographic tools, it remains incomplete and does no justice, for example, to the way the 200D or the E-400 perform in practice. At times, user reviews, such as those published at amazon, address these issues in a useful manner, but such feedback is on many occasions incomplete, inconsistent, and unreliable.

Expert reviews

This is why expert reviews are important. The adjacent summary-table relays the overall verdicts of several of the most popular camera review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.

Expert Camera Reviews

		Camera   Model	AP   score	CL   score	DCW   score	DPR   score	EPZ   score	PB   score	Camera Launch	Launch Price (USD)	Street Price
1.		Canon 200D	4/5	+ +	4/5	78/100	4.5/5	4.5/5	Jun 2017	549	ebay.com
2.		Olympus E-400	..	85/100	..	..	4/5	4/5	Sep 2006	699	ebay.com
3.		Canon 250D	4/5	o	4.5/5	79/100	4/5	4/5	Apr 2019	599	amazon.com
4.		Canon 2000D	3/5	o	3.5/5	..	3.5/5	3.5/5	Feb 2018	449	amazon.com
5.		Canon 77D	4.5/5	..	4/5	82/100	4.5/5	4/5	Feb 2017	899	ebay.com
6.		Canon 800D	4.5/5	..	3.5/5	80/100	4.5/5	4/5	Feb 2017	749	ebay.com
7.		Canon G9 X Mark II	4/5	..	4/5	75/100	4.5/5	4.5/5	Jan 2017	529	amazon.com
8.		Canon M100	3/5	+	..	..	4/5	3.5/5	Aug 2017	499	ebay.com
9.		Canon M5	4/5	+	4/5	82/100	4/5	4/5	Sep 2016	979	ebay.com
10.		Canon 760D	5/5	+	..	77/100	4.5/5	4.5/5	Feb 2015	649	ebay.com
11.		Canon 100D	4/5	+	..	78/100	4/5	4/5	Mar 2013	549	ebay.com
12.		Nikon D3400	4/5	+	4/5	76/100	4/5	4.5/5	Aug 2016	499	ebay.com
13.		Olympus E-420	..	85/100	..	+ +	4/5	4.5/5	Mar 2008	599	ebay.com
14.		Olympus E-410	..	86/100	..	+ +	4/5	4.5/5	Mar 2007	699	ebay.com
15.		Olympus E-510	..	89/100	..	+ +	3.5/5	4.5/5	Mar 2007	799	ebay.com
16.		Olympus E-500	..	76/100	..	+ +	..	..	Sep 2005	599	ebay.com
17.		Panasonic L10	..	85/100	..	+	3.5/5	4/5	Aug 2007	599	ebay.com
Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.

Care should be taken when interpreting the review scores above, though. The ratings are only valid when referring to cameras in the same category and of the same age. Hence, a score should always be seen in the context of the camera's market launch date and its price, and rating-comparisons among cameras that span long time periods or concern very differently equipped models make little sense. It should also be noted that some of the review sites have over time altered the way they render their verdicts.
