Canon 1D Mark III versus Olympus E-M5 II

The Canon EOS-1D Mark III and the Olympus OM-D E-M5 Mark II are two digital cameras that were revealed to the public, respectively, in February 2007 and February 2015. The 1D Mark III is a DSLR, while the E-M5 II is a mirrorless interchangeable lens camera. The cameras are based on an APS-H (1D Mark III) and a Four Thirds (E-M5 II) sensor. The Canon has a resolution of 10.1 megapixel, whereas the Olympus provides 15.9 MP. Read on to find out how these two cameras compare with respect to their size, their sensors, their features, and their reception by expert reviewers.

Body comparison: Canon 1D Mark III vs Olympus E-M5 II

An illustration of the physical size and weight of the Canon 1D Mark III and the Olympus E-M5 II is provided in the side-by-side display below. Three consecutive perspectives from the front, the top, and the back are presented. All size dimensions are rounded to the nearest millimeter. You can also use the toggle button to switch to a percentage comparison if you prefer that the measures are being expressed in relative terms (in this case, the camera on the left – the 1D Mark III – represents the basis or 100 percent across all the size and weight measures).

Compare Canon 1D Mark III vs Olympus E-M5 II
1D Mark III versus E-M5 II top view
1D Mark III and E-M5 II rear side
Body view (1D Mark III on the left)

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Olympus E-M5 II is considerably smaller (57 percent) than the Canon 1D Mark III. Moreover, the E-M5 II is substantially lighter (59 percent) than the 1D Mark III. In this context, it is worth noting that both cameras are splash and dust-proof and can, hence, be used in inclement weather conditions or harsh environments.

The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. A larger imaging sensor will tend to go along with bigger and heavier lenses, although exceptions exist. You can find an overview of optics for the two cameras in the Canon EF Lens Catalog (1D Mark III) and the Micro Four Thirds Lens Catalog (E-M5 II). Mirrorless cameras, such as the E-M5 II, have moreover the advantage that they can use many lenses from other systems via adapters, as they have a relatively short flange to focal plane distance.

Concerning battery life, the 1D Mark III gets 2200 shots out of its LP-E4 battery, while the E-M5 II can take 310 images on a single charge of its BLN-1 power pack.

The table below summarizes the key physical specs of the two cameras alongside a broader set of comparators. If you want to switch the focus of the display and review another camera pair, just select a new right or left comparator from among the camera models in the table. Alternatively, you can also move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.

Camera Body Specifications
Camera Camera
Width
Camera
Height
Camera
Depth
Camera
Weight
Battery
Life
(CIPA)
Weather
Sealing
(y/n)
Camera
Launch
(year)
Launch
Price
(USD)
Street
Price
(amazon)
Used
Price
(ebay)
Canon 1D Mark III (⇒ rgt) 156 mm 156.6 mm 80 mm 1155 g 2200 YES 2007 4,499discont. check
Olympus E-M5 II (⇒ lft) 124 mm 85 mm 45 mm 469 g 310 YES 2015 1,099 latest check
Canon 5DS R (⇒ lft | rgt) 152 mm 116 mm 76 mm 930 g 700 YES 2015 3,699 latest check
Canon 5D Mark III (⇒ lft | rgt) 152 mm 116 mm 76 mm 950 g 950 YES 2012 3,499discont. check
Canon 1D Mark IV (⇒ lft | rgt) 156 mm 157 mm 80 mm 1230 g 1500 YES 2009 4,999discont. check
Canon 5D Mark II (⇒ lft | rgt) 152 mm 114 mm 75 mm 850 g 850 YES 2008 3,499discont. check
Canon 1Ds Mark III (⇒ lft | rgt) 150 mm 160 mm 80 mm 1385 g 1800 YES 2007 7,999discont. check
Canon 1D Mark II (⇒ lft | rgt) 156 mm 158 mm 80 mm 1535 g 1200 YES 2004 4,499discont. check
Canon 1Ds (⇒ lft | rgt) 156 mm 157.6 mm 80 mm 1265 g 600 YES 2002 8,999discont. check
Nikon D3S (⇒ lft | rgt) 160 mm 157 mm 88 mm 1240 g 4200 YES 2009 5,199discont. check
Nikon D3 (⇒ lft | rgt) 160 mm 157 mm 88 mm 1300 g 4300 YES 2007 4,999discont. check
Nikon D2Xs (⇒ lft | rgt) 157.5 mm 149.5 mm 86 mm 1252 g 3800 YES 2006 4,699discont. check
Olympus E-M1 II (⇒ lft | rgt) 134 mm 91 mm 67 mm 574 g 440 YES 2016 1,999 latest check
Olympus E-M10 II (⇒ lft | rgt) 120 mm 83 mm 47 mm 390 g 320 no 2015 799discont. check
Olympus E-M10 (⇒ lft | rgt) 119 mm 82 mm 46 mm 396 g 320 no 2014 699discont. check
Olympus E-M1 (⇒ lft | rgt) 130 mm 94 mm 63 mm 497 g 350 YES 2013 1,399discont. check
Olympus E-M5 (⇒ lft | rgt) 122 mm 89 mm 43 mm 425 g 360 YES 2012 1,299discont. check

The price is, of course, an important factor in any camera decision. The listed launch prices provide an indication of the market segment that the manufacturer of the cameras have been targeting. The E-M5 II was launched at a markedly lower price (by 76 percent) than the 1D Mark III, which puts it into a different market segment. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.


Sensor comparison: Canon 1D Mark III vs Olympus E-M5 II

The size of the imaging sensor is a crucial determinant of image quality. All other things equal, a large sensor will have larger individual pixel-units that offer better low-light sensitivity, wider dynamic range, and richer color depth than smaller pixels in a sensor of the same technological generation. Furthermore, a large sensor camera will give the photographer more possibilities to use shallow depth-of-field in order to isolate a subject from the background. On the downside, larger sensors tend to be more expensive and lead to bigger and heavier cameras and lenses.

Of the two cameras under consideration, the Canon 1D Mark III features an APS-H sensor and the Olympus E-M5 II a Four Thirds sensor. The sensor area in the E-M5 II is 57 percent smaller. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.3 and 2.0. The sensor in the 1D Mark III has a native 3:2 aspect ratio, while the one in the E-M5 II offers a 4:3 aspect.

Canon 1D Mark III and Olympus E-M5 II sensor measures
Sensor size

Despite having a smaller sensor, the E-M5 II offers a higher resolution of 15.9 megapixel, compared with 10.1 MP of the 1D Mark III. This megapixel advantage comes at the cost of a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 3.76μm versus 7.21μm for the 1D Mark III). However, it should be noted that the E-M5 II is much more recent (by 7 years and 11 months) than the 1D Mark III, and its sensor will have benefitted from technological advances during this time that make it possible to gather light more efficiently.

Unlike the 1D Mark III, the E-M5 II has the capacity to capture high quality composite images (40MP) by combining multiple shots after shifting its sensor by miniscule distances. This multi-shot, pixel-shift mode is most suitable for photography of stationary objects (landscapes, studio scenes).

1D Mark III versus E-M5 II MP
Sensor resolution

Consistent information on actual sensor performance is available from DXO Mark for most cameras. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). The Overall DXO ratings for the two cameras under consideration are close, suggesting that they provide similar image quality. The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.

Sensor Characteristics
Camera Sensor
Class
Resolution
(Megapixel)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
Canon 1D Mark III (⇒ rgt) APS-H 10.1 3888 2592 no 22.7 11.7 1078 71
Olympus E-M5 II (⇒ lft) Four Thirds 15.9 4608 3456 1080/60p 23.0 12.5 842 73
Canon 5DS R (⇒ lft | rgt) Full Frame 50.3 8688 5792 1080/60p 24.6 12.4 2308 86
Canon 5D Mark III (⇒ lft | rgt) Full Frame 22.1 5760 3840 1080/30p 24 11.7 2293 81
Canon 1D Mark IV (⇒ lft | rgt) APS-H 16.0 4896 3264 1080/30p 22.8 12.0 1320 74
Canon 5D Mark II (⇒ lft | rgt) Full Frame 21.0 5616 3744 1080/30p 23.7 11.9 1815 79
Canon 1Ds Mark III (⇒ lft | rgt) Full Frame 21.0 5616 3744 no 24.0 12.0 1663 80
Canon 1D Mark II (⇒ lft | rgt) APS-H 8.2 3504 2336 no 22.3 11.1 1003 66
Canon 1Ds (⇒ lft | rgt) Full Frame 11.0 4064 2704 no 21.8 11.0 954 63
Nikon D3S (⇒ lft | rgt) Full Frame 12.1 4256 2832 720/24p 23.5 12.0 3253 82
Nikon D3 (⇒ lft | rgt) Full Frame 12.1 4256 2832 no 23.5 12.2 2290 81
Nikon D2Xs (⇒ lft | rgt) APS-C 12.2 4288 2848 no 22.2 10.9 489 59
Olympus E-M1 II (⇒ lft | rgt) Four Thirds 20.2 5184 3888 4K/30p 23.7 12.8 1312 80
Olympus E-M10 II (⇒ lft | rgt) Four Thirds 15.9 4608 3456 1080/60p 23.1 12.5 842 73
Olympus E-M10 (⇒ lft | rgt) Four Thirds 15.9 4608 3456 1080/30p 22.8 12.3 884 72
Olympus E-M1 (⇒ lft | rgt) Four Thirds 15.9 4608 3456 1080/30p 23.0 12.7 757 73
Olympus E-M5 (⇒ lft | rgt) Four Thirds 15.9 4608 3456 1080/60i 22.8 12.3 826 71

Many modern cameras cannot only take still pictures, but also record videos. The E-M5 II indeed provides for movie recording, while the 1D Mark III does not. The highest resolution format that the E-M5 II can use is 1080/60p.

Feature comparison: Canon 1D Mark III vs Olympus E-M5 II

Apart from body and sensor, cameras can and do differ across a range of features. For example, the E-M5 II has an electronic viewfinder (2360k dots), while the 1D Mark III has an optical one. Both systems have their advantages, with the electronic viewfinder making it possible to project supplementary shooting information into the framing view, whereas the optical viewfinder offers lag-free viewing and a very clear framing image. The adjacent table lists some of the other core features of the Canon 1D Mark III and Olympus E-M5 II along with similar information for a selection of comparators. If you need more detail on the specs, you can find comprehensive listings, for example, in the dpreview camera hub.

Core Features
Camera Viewfinder
(Type or
'000 dots)
Control
Panel
(Y/n)
LCD
Size
(inch)
LCD
Resolution
('000 dots)
LCD
Attach-
ment
Touch
Screen
(Y/n)
Shutter
speed
(1/sec)
Shutter
flaps
(1/sec))
Build-in
Flash
(GN)
Build-in
Stab
Canon 1D Mark III (⇒ rgt) optical YES 3.0 230 fixed no 8000 10.0 no no
Olympus E-M5 II (⇒ lft) 2360 no 3.0 1037 swivel YES 8000 10.0 no YES
Canon 5DS R (⇒ lft | rgt) optical YES 3.2 1040 fixed no 8000 5.0 no no
Canon 5D Mark III (⇒ lft | rgt) optical YES 3.2 1040 fixed no 8000 6.0 no no
Canon 1D Mark IV (⇒ lft | rgt) optical YES 3.0 920 fixed no 8000 10.0 no no
Canon 5D Mark II (⇒ lft | rgt) optical YES 3.0 920 fixed no 8000 3.9 no no
Canon 1Ds Mark III (⇒ lft | rgt) optical YES 3.0 230 fixed no 8000 5.0 no no
Canon 1D Mark II (⇒ lft | rgt) optical YES 2.0 230 fixed no 8000 8.3 no no
Canon 1Ds (⇒ lft | rgt) optical YES 2.0 120 fixed no 8000 3.0 no no
Nikon D3S (⇒ lft | rgt) optical YES 3.0 921 fixed no 8000 11.0 no no
Nikon D3 (⇒ lft | rgt) optical YES 3.0 922 fixed no 8000 11.0 no no
Nikon D2Xs (⇒ lft | rgt) optical YES 2.5 230 fixed no 8000 5.0 no no
Olympus E-M1 II (⇒ lft | rgt) 2360 no 3.0 1037 swivel YES 8000 18.0 no YES
Olympus E-M10 II (⇒ lft | rgt) 2360 no 3.0 1040 tilting YES 4000 8.0 5.8 YES
Olympus E-M10 (⇒ lft | rgt) 1440 no 3.0 1037 tilting YES 4000 8.0 5.8 YES
Olympus E-M1 (⇒ lft | rgt) 2360 no 3.0 1037 tilting YES 8000 10.0 no YES
Olympus E-M5 (⇒ lft | rgt) 1440 no 3.0 610 tilting YES 4000 9.0 no YES

The E-M5 II is a current model that online retailers, such as amazon, will have in stock. In contrast, the 1D Mark III has been discontinued (but it can be found pre-owned on eBay). As a replacement in the same line of cameras, the 1D Mark III was succeeded by the Canon 1D Mark IV.

Review summary: Canon 1D Mark III vs Olympus E-M5 II

So how do things add up? Which of the two cameras – the Canon 1D Mark III or the Olympus E-M5 II – has the upper hand? Below is a summary of the relative strengths of each of the two contestants.


logo checkmark

Arguments in favor of the Canon EOS-1D Mark III:

  • Better low-light sensitivity: Requires less light for good images (0.4 stops ISO advantage).
  • Brighter framing: Features an optical viewfinder for clear, lag-free composition.
  • Easier setting verification: Has an LCD display on top to control shooting parameters.
  • Longer lasting: Can take more shots (2200 versus 310) on a single battery charge.
  • More heavily discounted: Has been available for much longer (launched in February 2007).

logo checkmark

Advantages of the Olympus OM-D E-M5 Mark II:

  • More detail: Has more megapixels (15.9 vs 10.1MP), which boosts linear resolution by 23%.
  • High quality composites: Can combine several shots after pixel-shifting its sensor.
  • More dynamic range: Captures a broader range of light and dark details (0.8 EV of extra DR).
  • Broader imaging potential: Can capture not only stills but also 1080/60p video.
  • More framing info: Has an electronic viewfinder that displays shooting data.
  • More detailed LCD: Has a higher resolution rear screen (1037k vs 230k dots).
  • More flexible LCD: Has swivel screen for odd-angle shots in portrait or landscape orientation.
  • Fewer buttons to press: Has a touchscreen to facilitate handling and shooting adjustments.
  • More compact: Is smaller (124x85mm vs 156x156.6mm) and will fit more readily into a bag.
  • Less heavy: Has a lower weight (by 686g or 59 percent) and is thus easier to take along.
  • More legacy lens friendly: Can use many non-native lenses via adapters.
  • Sharper images: Has stabilization technology build-in to reduce the impact of hand-shake.
  • More affordable: Was introduced into a lower priced category (76 percent cheaper at launch).
  • More modern: Reflects 7 years and 11 months of technical progress since the 1D Mark III launch.

If the number of relative strengths (bullet points above) is taken as a guide, the E-M5 II is the clear winner of the contest (14 : 5 points). However, the relative importance of the various individual camera aspects will vary according to personal preferences and needs, so that you might like to apply corresponding weights to the particular features before making a decision on a new camera.

1D Mark III 05:14 E-M5 II

In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it says nothing about, for example, the handling, responsiveness, and overall imaging quality of the 1D Mark III and the E-M5 II in practical situations. At times, user reviews, such as those published at amazon, address these issues in a useful manner, but such feedback is on many occasions incomplete, inconsistent, and unreliable. This is where reviews by experts come in. The table below summarizes the assessments of some of the best known camera review sites. You can find the full text of the reviews, respectively, at cameralabs.com, dpreview.com, ephotozine.com, imaging-resource.com, and photographyblog.com.

Review scores
Camera camera
labs
.com
dp
review
.com
ephoto
zine
.com
imaging
resource
.com
photography
blog
.com
Camera
Launch
(year)
Launch
Price
(USD)
Street
Price
(amazon)
Used
Price
(ebay)
Canon 1D Mark III (⇒ rgt) - - - reviewed - 2007 4,499discont. check
Olympus E-M5 II (⇒ lft) HiRec 81/100 Silver 5/5 4.5/5 5/5 2015 1,099 latest check
Canon 5DS R (⇒ lft | rgt) Rec 83/100 Silver 5/5 5/5 4.5/5 2015 3,699 latest check
Canon 5D Mark III (⇒ lft | rgt) HiRec 82/100 Gold 4.5/5 5/5 4.5/5 2012 3,499discont. check
Canon 1D Mark IV (⇒ lft | rgt) - 89/100 Gold - 5/5 - 2009 4,999discont. check
Canon 5D Mark II (⇒ lft | rgt) 91/100 79/100 HiRec 4/5 5/5 - 2008 3,499discont. check
Canon 1Ds Mark III (⇒ lft | rgt) - HiRec 4.5/5 - - 2007 7,999discont. check
Canon 1D Mark II (⇒ lft | rgt) - HiRec - reviewed - 2004 4,499discont. check
Canon 1Ds (⇒ lft | rgt) - HiRec - - - 2002 8,999discont. check
Nikon D3S (⇒ lft | rgt) - 89/100 Gold 4.5/5 5/5 5/5 2009 5,199discont. check
Nikon D3 (⇒ lft | rgt) - HiRec 5/5 reviewed 4.5/5 2007 4,999discont. check
Nikon D2Xs (⇒ lft | rgt) - - - reviewed - 2006 4,699discont. check
Olympus E-M1 II (⇒ lft | rgt) HiRec 85/100 Gold 4.5/5 5/5 4.5/5 2016 1,999 latest check
Olympus E-M10 II (⇒ lft | rgt) HiRec 80/100 Silver 5/5 5/5 5/5 2015 799discont. check
Olympus E-M10 (⇒ lft | rgt) - 80/100 Gold 5/5 4.5/5 5/5 2014 699discont. check
Olympus E-M1 (⇒ lft | rgt) HiRec 84/100 Gold 4.5/5 4.5/5 4.5/5 2013 1,399discont. check
Olympus E-M5 (⇒ lft | rgt) HiRec 80/100 Gold 4.5/5 5/5 5/5 2012 1,299discont. check

The above review scores should be interpreted with care, though. The assessments were made in relation to similar cameras of the same technological generation. A score, therefore, has to be seen in close connection to the price and market introduction time of the camera, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, please note that some of the review sites have changed their methodology and reporting over time.
