Canon 80D vs Sony HX80
The Canon EOS 80D and the Sony Cyber-shot DSC-HX80 are two digital cameras that were officially introduced, respectively, in February 2016 and March 2016. The 80D is a DSLR, while the HX80 is a fixed lens compact. The cameras are based on an APS-C (80D) and a 1/2.3-inch (HX80) sensor. The Canon has a resolution of 24 megapixels, whereas the Sony provides 18 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS 80D and the Sony Cyber-shot DSC-HX80? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
An illustration of the physical size and weight of the Canon 80D and the Sony HX80 is provided in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive views from the front, the top, and the rear side are shown. All width, height and depth measures are rounded to the nearest millimeter.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Sony HX80 is considerably smaller (59 percent) than the Canon 80D. It is worth mentioning in this context that the 80D is splash and dust resistant, while the HX80 does not feature any corresponding weather-sealing.
The above size and weight comparisons are to some extent incomplete and possibly misleading, as the HX80 has a lens built in, whereas the 80D is an interchangeable lens camera that requires a separate lens. Attaching the latter will add extra weight and bulk to the setup. You can compare the optics available for the 80D and their specifications in the Canon EF Lens Catalog.
Concerning battery life, the 80D gets 960 shots out of its LP-E6N battery, while the HX80 can take 390 images on a single charge of its NP-BX1 power pack. The power pack in the HX80 can be charged via the USB port, which can be very convenient when travelling.
The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you want to switch the focus of the display and review another camera pair, you can move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.
|1.||Canon 80D||139 mm||105 mm||79 mm||730 g||960||Y||Feb 2016||1,199|
|2.||Sony HX80||102 mm||58 mm||36 mm||245 g||390||n||Mar 2016||349|
|3.||Canon 90D||141 mm||105 mm||77 mm||701 g||1300||Y||Aug 2019||1,199|
|4.||Canon 6D Mark II||144 mm||111 mm||75 mm||765 g||1200||Y||Jun 2017||1,999|
|5.||Canon 77D||131 mm||100 mm||76 mm||540 g||600||n||Feb 2017||899|
|6.||Canon 5D Mark IV||151 mm||116 mm||76 mm||890 g||900||Y||Aug 2016||3,499|
|7.||Canon SX720||110 mm||64 mm||36 mm||270 g||250||n||Feb 2016||379|
|8.||Canon G3 X||123 mm||77 mm||105 mm||733 g||300||Y||Jun 2015||999|
|9.||Canon SX710||113 mm||66 mm||35 mm||269 g||230||n||Jan 2015||349|
|10.||Canon 70D||139 mm||104 mm||79 mm||755 g||920||Y||Jul 2013||1,199|
|11.||Canon 60D||145 mm||106 mm||79 mm||755 g||1100||Y||Aug 2010||1,399|
|12.||Nikon D7500||136 mm||104 mm||73 mm||720 g||950||Y||Apr 2017||1,299|
|13.||Nikon D7200||136 mm||107 mm||76 mm||765 g||1110||Y||Mar 2015||1,199|
|14.||Sony WX800||102 mm||58 mm||36 mm||233 g||370||n||Oct 2018||399|
|15.||Sony RX100 V||102 mm||58 mm||41 mm||299 g||220||n||Oct 2016||999|
|16.||Sony RX10 II||129 mm||88 mm||102 mm||813 g||400||Y||Jun 2015||1,299|
|17.||Sony RX100 IV||102 mm||58 mm||41 mm||298 g||280||n||Jun 2015||999|
|Notes: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.|
Any camera decision will obviously take relative prices into account. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The HX80 was launched at a lower price than the 80D, despite having a lens built in. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.
The size of the imaging sensor is a crucial determinant of image quality. A large sensor will generally have larger individual pixels that offer better low-light sensitivity, provide wider dynamic range, and have richer color-depth than smaller pixels in a sensor of the same technological generation. Furthermore, a large sensor camera will give the photographer more possibilities to use shallow depth-of-field in order to isolate a subject from the background. On the downside, larger sensors tend to be more expensive and lead to bigger and heavier cameras and lenses.
Of the two cameras under consideration, the Canon 80D features an APS-C sensor and the Sony HX80 a 1/2.3-inch sensor. The sensor area in the HX80 is 92 percent smaller. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.6 and 5.6. The sensor in the 80D has a native 3:2 aspect ratio, while the one in the HX80 offers a 4:3 aspect.
With 24MP, the 80D offers a higher resolution than the HX80 (18MP), but the 80D nevertheless has larger individual pixels (pixel pitch of 3.75μm versus 1.25μm for the HX80) due to its larger sensor. It is noteworthy in this context that the two cameras were released in close succession, so that their sensors are from the same technological generation. Coming back to sensor resolution, it should be mentioned that the HX80 has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.
The resolution advantage of the Canon 80D implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the 80D for good quality output (200 dots per inch) amounts to 30 x 20 inches or 76.2 x 50.8 cm, for very good quality (250 dpi) 24 x 16 inches or 61 x 40.6 cm, and for excellent quality (300 dpi) 20 x 13.3 inches or 50.8 x 33.9 cm. The corresponding values for the Sony HX80 are 24.5 x 18.4 inches or 62.2 x 46.6 cm for good quality, 19.6 x 14.7 inches or 49.7 x 37.3 cm for very good quality, and 16.3 x 12.2 inches or 41.5 x 31.1 cm for excellent quality prints.
The 80D has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.
The Canon EOS 80D has a native sensitivity range from ISO 100 to ISO 16000, which can be extended to ISO 100-25600. The corresponding ISO settings for the Sony Cyber-shot DSC-HX80 are ISO 80 to ISO 3200, with the possibility to increase the ISO range to 80-12800.
Since 2007, DXO Mark has published sensor performance measurements that have been derived using a consistent methodology. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). The table below summarizes the physical sensor characteristics and sensor quality findings and compares them across a set of similar cameras.
| DXO |
|4.||Canon 6D Mark II||Full Frame||26.0||6240||4160||1080/60p||24.4||11.9||2862||85|
|6.||Canon 5D Mark IV||Full Frame||30.1||6720||4480||4K/30p||24.8||13.6||2995||91|
|8.||Canon G3 X||1-inch||20.0||5472||3648||1080/60p||21.4||12.3||521||63|
|15.||Sony RX100 V||1-inch||20.0||5472||3648||4K/30p||22.8||12.4||586||70|
|16.||Sony RX10 II||1-inch||20.0||5472||3648||4K/30p||23.0||12.6||531||70|
|17.||Sony RX100 IV||1-inch||20.0||5472||3648||4K/30p||22.8||12.6||591||70|
Many modern cameras are not only capable of taking still images, but can also record movies. Both cameras under consideration have a sensor with sufficiently fast read-out times for moving pictures, and both provide the same movie specifications (1080/60p).
Beyond body and sensor, cameras can and do differ across a range of features. For example, the HX80 has an electronic viewfinder (638k dots), while the 80D has an optical one. Both systems have their advantages, with the electronic viewfinder making it possible to project supplementary shooting information into the framing view, whereas the optical viewfinder offers lag-free viewing and a very clear framing image. The following table reports on some other key feature differences and similarities of the Canon 80D, the Sony HX80, and comparable cameras.
|4.||Canon 6D Mark II||optical||Y||3.0||1040||swivel||Y||1/4000s||6.5||n||n|
|6.||Canon 5D Mark IV||optical||Y||3.2||1620||fixed||Y||1/8000s||7.0||n||n|
|8.||Canon G3 X||optional||n||3.2||1620||tilting||Y||1/2000s||5.9||Y||Y|
|15.||Sony RX100 V||2359||n||3.0||1229||tilting||n||1/2000s||24.0||Y||Y|
|16.||Sony RX10 II||2359||Y||3.0||1229||tilting||n||1/3200s||14.0||Y||Y|
|17.||Sony RX100 IV||2359||n||3.0||1228||tilting||n||1/2000s||16.0||Y||Y|
One feature that is present on the 80D, but is missing on the HX80 is a top-level LCD. While being, of course, smaller than the rear screen, the control panel conveys some of the essential shooting information and can be convenient for quick and easy settings verification.Both cameras have an articulated rear screen that can be turned to be front-facing. This feature will be particularly appreciated by vloggers and photographers who are interested in taking selfies.
The Canon 80D has an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
The 80D writes its imaging data to SDXC cards, while the HX80 uses SDXC or Memory Stick PRO Duo cards. Both cameras can use UHS-I cards, which provide for Ultra High Speed data transfer of up to 104 MB/s.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS 80D and Sony Cyber-shot DSC-HX80 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
| WiFi |
| NFC |
|4.||Canon 6D Mark II||Y||stereo||mono||Y||-||mini||2.0||Y||Y||Y|
|6.||Canon 5D Mark IV||Y||mono||mono||Y||Y||mini||3.0||Y||Y||-|
|8.||Canon G3 X||Y||stereo||mono||Y||Y||mini||2.0||Y||Y||-|
|15.||Sony RX100 V||-||stereo||mono||-||-||micro||2.0||Y||Y||-|
|16.||Sony RX10 II||Y||stereo||mono||Y||Y||micro||2.0||Y||Y||-|
|17.||Sony RX100 IV||-||stereo||mono||-||-||micro||2.0||Y||Y||-|
It is notable that the 80D has a hotshoe, while the HX80 does not. This socket makes it possible to easily attach optional accessories, such as an external flash gun.
The HX80 is a recent model that features in the current product line-up of Sony. In contrast, the 80D has been discontinued (but can be found pre-owned on eBay). As a replacement in the same line of cameras, the 80D was succeeded by the Canon 90D. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Canon and Sony websites.
So what is the bottom line? Is the Canon 80D better than the Sony HX80 or vice versa? Below is a summary of the relative strengths of each of the two contestants.
Reasons to prefer the Canon EOS 80D:
- More detail: Offers more megapixels (24 vs 18MP) with a 18% higher linear resolution.
- Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
- Better image quality: Features bigger pixels on a larger sensor for higher quality imaging.
- Richer colors: The pixel size advantage translates into images with better, more accurate colors.
- More dynamic range: Larger pixels capture a wider spectrum of light and dark details.
- Better low-light sensitivity: Larger pixels means good image quality even under poor lighting.
- Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
- Better sound: Can connect to an external microphone for higher quality sound recording.
- Better sound control: Has a headphone port that enables audio monitoring while recording.
- Brighter framing: Features an optical viewfinder for clear, lag-free composition.
- Easier setting verification: Features an LCD display on top to control shooting parameters.
- More detailed LCD: Has a higher resolution rear screen (1040k vs 922k dots).
- More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
- Fewer buttons to press: Is equipped with a touch-sensitive rear screen to facilitate handling.
- Faster shutter: Has higher mechanical shutter speed (1/8000s vs 1/2000s) to freeze action.
- Easier time-lapse photography: Has an intervalometer built-in for low frequency shooting.
- More flexible: Can take a variety of interchangeable lenses, including specialty optics.
- Longer lasting: Can take more shots (960 versus 390) on a single battery charge.
- Better sealing: Is weather sealed to enable shooting in dusty or wet environments.
- Better lighting: Features a hotshoe and can thus hold and trigger an external flash gun.
Arguments in favor of the Sony Cyber-shot DSC-HX80:
- Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
- More framing info: Has an electronic viewfinder that displays shooting data.
- Faster burst: Shoots at higher frequency (10 vs 7 flaps/sec) to capture the decisive moment.
- Ready to shoot: Comes with an integrated lens, while the 80D requires a separate lens.
- More compact: Is smaller (102x58mm vs 139x105mm) and will fit more readily into a bag.
- Less heavy: Has a lower weight even though it has a lens built in (unlike the 80D).
- Easier travel charging: Can be conveniently charged via its USB port.
- Sharper images: Has stabilization technology built-in to reduce the impact of hand-shake.
- More affordable: Was introduced at a lower price, despite coming with a built-in lens.
If the count of relative strengths (bullet points above) is taken as a measure, the 80D is the clear winner of the match-up (20 : 9 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional wedding photographer will view the differences between cameras in a way that diverges from the perspective of a travel photog, and a person interested in cityscapes has distinct needs from a macro shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Canon 80D and the Sony HX80 place the cameras among the top in their class? Find out in the latest Best DSLR Camera and Best Superzoom Camera listings whether the two cameras rank among the cream of the crop.
In any case, while the comparison of the spec-sheets of cameras can offer a general idea of their imaging potential, it says little about, for example, the shooting experience and imaging performance of the 80D and the HX80 in practical situations. User reviews that are available, for instance, at amazon can sometimes shed light on these issues, but such feedback is all too often partial, inconsistent, and inaccurate.
This is why expert reviews are important. The adjacent summary-table relays the overall verdicts of several of the most popular camera review sites (amateurphotographer [AP], cameralabs [CL], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|1.||Canon 80D||4/5||+ +||84/100||4.5/5||4.5/5||Feb 2016||1,199|
|2.||Sony HX80||..||..||..||..||..||Mar 2016||349|
|3.||Canon 90D||4/5||+||85/100||4.5/5||4.5/5||Aug 2019||1,199|
|4.||Canon 6D Mark II||4/5||+||80/100||4.5/5||4/5||Jun 2017||1,999|
|5.||Canon 77D||4.5/5||..||82/100||4.5/5||4/5||Feb 2017||899|
|6.||Canon 5D Mark IV||4.5/5||+ +||87/100||4.5/5||4.5/5||Aug 2016||3,499|
|7.||Canon SX720||..||+||..||4/5||4.5/5||Feb 2016||379|
|8.||Canon G3 X||3.5/5||+||..||4.5/5||4/5||Jun 2015||999|
|9.||Canon SX710||..||+||..||4/5||3.5/5||Jan 2015||349|
|10.||Canon 70D||5/5||+ +||83/100||4.5/5||5/5||Jul 2013||1,199|
|11.||Canon 60D||5/5||+||79/100||4/5||4.5/5||Aug 2010||1,399|
|12.||Nikon D7500||4.5/5||+ +||86/100||5/5||4.5/5||Apr 2017||1,299|
|13.||Nikon D7200||4/5||+ +||84/100||4.5/5||4.5/5||Mar 2015||1,199|
|14.||Sony WX800||..||..||..||..||..||Oct 2018||399|
|15.||Sony RX100 V||4.5/5||+ +||83/100||4/5||4.5/5||Oct 2016||999|
|16.||Sony RX10 II||5/5||+ +||82/100||4.5/5||4/5||Jun 2015||1,299|
|17.||Sony RX100 IV||4.5/5||+ +||85/100||4/5||4.5/5||Jun 2015||999|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
The above review scores should be interpreted with care, though. The ratings are only valid when referring to cameras in the same category and of the same age. A score, therefore, has to be seen in close connection to the price and market introduction time of the camera, and comparisons of ratings among very different cameras or across long time periods have little meaning. It should also be noted that some of the review sites have over time altered the way they render their verdicts.
Other camera comparisons
Did this review help to inform your camera decision process? If you would like to see a different side-by-side camera review, just use the search menu below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
Specifications: Canon 80D vs Sony HX80
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Canon 80D||Sony HX80|
|Camera Type||Digital single lens reflex||Fixed lens compact camera|
|Camera Lens||Canon EF mount lenses||24-720mm f/3.5-6.4|
|Launch Date||February 2016||March 2016|
|Launch Price||USD 1,199||USD 349|
|Sensor Specs||Canon 80D||Sony HX80|
|Sensor Format||APS-C Sensor||1/2.3" Sensor|
|Sensor Size||22.5 x 15.0 mm||6.17 x 4.55 mm|
|Sensor Area||337.5 mm2||28.0735 mm2|
|Sensor Diagonal||27 mm||7.7 mm|
|Sensor Resolution||24 Megapixels||18 Megapixels|
|Image Resolution||6000 x 4000 pixels||4896 x 3672 pixels|
|Pixel Pitch||3.75 μm||1.25 μm|
|Pixel Density||7.11 MP/cm2||64.04 MP/cm2|
|Moiré control||Anti-Alias filter||no AA filter|
|Movie Capability||1080/60p Video||1080/60p Video|
|ISO Setting||100 - 16,000 ISO||80 - 3,200 ISO|
|ISO Boost||100 - 25,600 ISO||80 - 12,800 ISO|
|Image Processor||DIGIC 6||BIONZ X|
|DXO Sensor Quality (score)||79||..|
|DXO Color Depth (bits)||23.6||..|
|DXO Dynamic Range (EV)||13.2||..|
|DXO Low Light (ISO)||1135||..|
|Screen Specs||Canon 80D||Sony HX80|
|Viewfinder Type||Optical viewfinder||Electronic viewfinder|
|Viewfinder Field of View||100%||100%|
|Viewfinder Resolution||638k dots|
|Top-Level Screen||Control Panel||no Top Display|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0inch||3.0inch|
|LCD Resolution||1040k dots||922k dots|
|LCD Attachment||Swivel screen||Tilting screen|
|Touch Input||Touchscreen||no Touchscreen|
|Shooting Specs||Canon 80D||Sony HX80|
|Focus System||Phase-detect AF||Contrast-detect AF|
|Continuous Shooting||7 shutter flaps/s||10 shutter flaps/s|
|Time-Lapse Photography||Intervalometer built-in||no Intervalometer|
|Fill Flash||Build-in Flash||Build-in Flash|
|Storage Medium||SDXC cards||MS or SDXC cards|
|Second Storage Option||Single card slot||Single card slot|
|UHS card support||UHS-I||UHS-I|
|Connectivity Specs||Canon 80D||Sony HX80|
|External Flash||Hotshoe||no Hotshoe|
|USB Connector||USB 2.0||USB 2.0|
|HDMI Port||mini HDMI||micro HDMI|
|Microphone Port||External MIC port||no MIC socket|
|Headphone Socket||Headphone port||no Headphone port|
|Wifi Support||Wifi built-in||Wifi built-in|
|Near-Field Communication||NFC built-in||NFC built-in|
|Body Specs||Canon 80D||Sony HX80|
|Environmental Sealing||Weathersealed body||not weather sealed|
|Battery Life (CIPA)||960 shots per charge||390 shots per charge|
|In-Camera Charging||no USB charging||USB charging|
139 x 105 x 79 mm
(5.5 x 4.1 x 3.1 in)
102 x 58 x 36 mm
(4.0 x 2.3 x 1.4 in)
|Camera Weight||730 g (25.8 oz)||245 g (8.6 oz)|
