What is the sensor size of the Panasonic GH2?
The Panasonic Lumix DMC-GH2 is a digital camera that has a Four Thirds sensor at its core. This imager measures 17.3mm in width and 13.0mm in height, so that the total imaging area of the sensor amounts to 225 mm2.
The GH2 provides an image resolution of 15.9 megapixels, based on 4 608 horizontal pixels and 3 456 vertical pixels.
Sensor size comparison with a film slide
The sensor diagonal measures 21.6mm, which gives rise to a format factor (or crop factor) of 2.0. Hence, the Panasonic GH2 is a crop-sensor camera, as its sensor is smaller than a traditional 35mm film slide or negative.
Sensor specs and performance
The table below compares the sensor specs of the Panasonic GH2 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Panasonic GH2 | Four Thirds | 15.9 | 4608 | 3456 | 1080/60i | 21.2 | 11.3 | 655 | 60 | |
2. | Panasonic G2 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.3 | 493 | 53 | |
3. | Panasonic G3 | Four Thirds | 15.8 | 4592 | 3448 | 1080/60i | 21.0 | 10.6 | 667 | 56 | |
4. | Panasonic G10 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.1 | 411 | 52 | |
5. | Panasonic GF1 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.3 | 513 | 54 | |
6. | Panasonic GH1 | Four Thirds | 12.0 | 4000 | 3000 | 1080/24p | 21.6 | 11.6 | 772 | 64 | |
7. | Panasonic GH3 | Four Thirds | 15.9 | 4608 | 3456 | 1080/60p | 22.7 | 12.4 | 812 | 71 | |
8. | Panasonic GM1 | Four Thirds | 15.8 | 4592 | 3448 | 1080/60i | 22.3 | 11.7 | 660 | 66 | |
9. | Panasonic GM5 | Four Thirds | 15.8 | 4592 | 3448 | 1080/60p | 22.1 | 11.7 | 721 | 66 | |
10. | Panasonic GX7 | Four Thirds | 15.8 | 4592 | 3448 | 1080/60p | 22.6 | 12.2 | 718 | 70 | |
11. | Panasonic GX85 | Four Thirds | 15.8 | 4592 | 3448 | 4K/30p | 22.9 | 12.6 | 662 | 71 |
In the United States, the GH2 was initially launched in September 2010 at a price of $899.
Camera to camera comparisons
If you would like to see a side-by-side review with another camera, just make a corresponding selection in the search boxes below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 400D vs Panasonic GH2
- Canon T3 vs Panasonic GH2
- Contax N Digital vs Nikon Z6
- Fujifilm XP130 vs Nikon Z6
- Nikon D1 vs Panasonic GH2
- Nikon Z6 vs Nikon Z8
- Nikon Z6 vs Nikon Z9
- Nikon Z6 vs Panasonic L10
- Nikon Z6 vs Pentax K-500
- Panasonic G2 vs Panasonic GH2
- Panasonic GH2 vs Panasonic ZS100
- Panasonic GH2 vs Sony RX10 II
Camera Model | Panasonic GH2 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | September 2010 | |
Launch Price | USD 899 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 15.9 Megapixels | |
Image Resolution | 4 608 x 3 456 pixels | |
Pixel Pitch | 3.76 μm | |
Pixel Density | 7.08 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 1080/60i Video | |
ISO Setting | 160 - 12 800 ISO | |
Image Processor | Venus FHD | |
DXO Sensor Quality (score) | 60 | |
DXO Color Depth (bits) | 21.2 | |
DXO Dynamic Range (EV) | 11.3 | |
DXO Low Light (ISO) | 655 | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.71x | |
Viewfinder Resolution | 1534k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 460k dots | |
LCD Attachment | Swivel screen | |
V-logging Friendliness | Front-flip possible | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 3 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | no | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | mini HDMI | |
Microphone Port | External MIC port | |
Wifi Support | no Wifi | |
Body Specs | ||
Battery Type | Panasonic DMW-BLC12 power pack | |
Battery Life (CIPA) | 330 shots per charge | |
Body Dimensions |
124 x 90 x 76 mm (4.9 x 3.5 x 3.0 in) |
|
Camera Weight | 442 g (15.6 oz) |
