What is the sensor size of the Olympus E-P5?
The Olympus PEN E-P5 is a digital camera that has a Four Thirds sensor at its core. This imager measures 17.3mm in width and 13.0mm in height, so that the total imaging area of the sensor amounts to 225 mm2.
The E-P5 provides an image resolution of 15.9 megapixels, based on 4 608 horizontal pixels and 3 456 vertical pixels.
Sensor size comparison with a film slide
The sensor diagonal measures 21.6mm, which gives rise to a format factor (or crop factor) of 2.0. Hence, the Olympus E-P5 is a crop-sensor camera, as its sensor is smaller than a traditional 35mm film slide or negative.
Sensor specs and performance
The table below compares the sensor specs of the Olympus E-P5 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Olympus E-P5 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.8 | 12.4 | 895 | 72 | |
2. | Olympus E-M1 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 23.0 | 12.7 | 757 | 73 | |
3. | Olympus E-M5 | Four Thirds | 15.9 | 4608 | 3456 | 1080/60i | 22.8 | 12.3 | 826 | 71 | |
4. | Olympus E-M10 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.8 | 12.3 | 884 | 72 | |
5. | Olympus E-M10 II | Four Thirds | 15.9 | 4608 | 3456 | 1080/60p | 23.1 | 12.5 | 842 | 73 | |
6. | Olympus E-P3 | Four Thirds | 12.2 | 4032 | 3024 | 1080/60i | 20.8 | 10.1 | 536 | 51 | |
7. | Olympus E-PL5 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.8 | 12.3 | 889 | 72 | |
8. | Olympus E-PL7 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.7 | 12.4 | 873 | 72 | |
9. | Olympus E-PM2 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.7 | 12.2 | 932 | 72 | |
10. | Olympus PEN-F | Four Thirds | 20.2 | 5184 | 3888 | 1080/60p | 23.1 | 12.4 | 894 | 74 | |
11. | Panasonic GX7 | Four Thirds | 15.8 | 4592 | 3448 | 1080/60p | 22.6 | 12.2 | 718 | 70 |
In the United States, the E-P5 was initially launched in May 2013 at a price of $999.
Camera to camera comparisons
In case you would like to check on the differences and similarities with other camera models, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 1D vs Olympus E-P5
- Canon G15 vs Nikon Z6
- Contax N Digital vs Olympus E-P5
- Fujifilm X-T1 vs Nikon Z6
- Leica V-LUX Typ 114 vs Nikon Z6
- Nikon D200 vs Nikon Z6
- Nikon D3400 vs Olympus E-P5
- Nikon Z5 vs Nikon Z6
- Nikon Z6 vs Sony A7R IV
- Olympus E-M10 vs Olympus E-P5
- Olympus E-P5 vs Panasonic TZ200
- Olympus E-P5 vs Sony A7R
Camera Model | Olympus E-P5 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | May 2013 | |
Launch Price | USD 999 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 15.9 Megapixels | |
Image Resolution | 4 608 x 3 456 pixels | |
Pixel Pitch | 3.76 μm | |
Pixel Density | 7.08 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 1080/30p Video | |
ISO Setting | 200 - 25 600 ISO | |
ISO Boost | 100 - 25 600 ISO | |
Image Processor | TruePic VI | |
DXO Sensor Quality (score) | 72 | |
DXO Color Depth (bits) | 22.8 | |
DXO Dynamic Range (EV) | 12.4 | |
DXO Low Light (ISO) | 895 | |
Screen Specs | ||
Viewfinder Type | Viewfinder optional | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1037k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | No front-flip | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/8000s | |
Continuous Shooting | 9 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Body Specs | ||
Battery Type | Olympus BLN-1 power pack | |
Battery Life (CIPA) | 330 shots per charge | |
Body Dimensions |
122 x 69 x 37 mm (4.8 x 2.7 x 1.5 in) |
|
Camera Weight | 420 g (14.8 oz) |
