What is the pixel pitch of the Nikon D300S?

The Nikon D300S provides 12.2 megapixels from an APS-C sensor. This pixel density gives rise to a size of the individual pixel of 5.53µm.

The pixel size or pixel pitch can be calculated by dividing the sensor area by the pixel count and then taking the square root. In particular, the sensor in the Nikon D300S measures 23.6mm in width and 15.8mm in height, so that the total imaging area of the sensor amounts to 373 mm2. Moreover, the D300S has 4 288 horizontal pixels and 2 848 vertical pixels, for a total of 12.2 megapixels. Then, the size (height or width) of each individual pixel can be calculated as the square root of the ratio of the sensor area (373 mm2) to the MP count (12 212 224).

camera

Larger pixels provide advantages with respect to gathering light, particularly in low-light situations. Large pixels notably have a better signal to noise ratio, meaning that they can better differentiate between incoming photons and the noisy signals that the internal processes of the camera create. As a result, big pixels are particularly helpful to the photographer when shooting with high ISO settings.

Sensor specs and performance

The table below compares the sensor specs of the Nikon D300S to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.

scroll hint
Sensor Characteristics
    Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Nikon D300S APS-C 12.2 4288 2848720/24p22.512.278770
2.

Canon 7D APS-C 17.9 5184 34561080/30p22.011.785466
3.

Nikon D500 APS-C 20.7 5568 37124K/30p24.014.0132483
4.

Nikon D7000 APS-C 16.1 4928 32641080/24p23.513.9116780
5.

Nikon D3100 APS-C 14.2 4608 30721080/24p22.511.391967
6.

Nikon D3S Full Frame 12.1 4256 2832720/24p23.512.0325382
7.

Nikon D3000 APS-C 10.0 3872 2592none22.311.156362
8.

Nikon D90 APS-C 12.2 4288 2848720/24p22.712.597773
9.

Nikon D700 Full Frame 12.1 4256 2832none23.512.2230380
10.

Nikon D300 APS-C 12.2 4288 2848none22.112.067967
11.

Nikon D200 APS-C 10.0 3872 2592none22.311.558364
Further information on the sensor in the Nikon D300S and the camera's operation can be found in the camera manual.

In the United States, the D300S was initially launched in July 2009 at a price of $1,799.

logo
Check D300S offers at
ebay.com

Camera to camera comparisons

In case you are interested in seeing how this camera compares to another one, just make your choice using the following search menu. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.

~
    loader

    Specifications Summary
    Camera Model Nikon D300S
    Camera Type Digital single lens reflex
    Camera Lens Nikon F mount lenses
    Launch Date July 2009
    Launch Price USD 1 799
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format APS-C Sensor
    Sensor Size 23.6 x 15.8 mm
    Sensor Area 373 mm2
    Sensor Diagonal 28.4 mm
    Crop Factor 1.5x
    Sensor Resolution 12.2 Megapixels
    Image Resolution 4 288 x 2 848 pixels
    Pixel Pitch 5.53 μm
    Pixel Density 3.28 MP/cm2
    Moiré control Anti-Alias filter
    Movie Capability 720/24p Video
    ISO Setting 200 - 3 200 ISO
    ISO Boost 100 - 6 400 ISO
    Image Processor EXPEED
    DXO Sensor Quality (score) 70
    DXO Color Depth (bits) 22.5
    DXO Dynamic Range (EV) 12.2
    DXO Low Light (ISO) 787
    Screen Specs
    Viewfinder Type Optical viewfinder
    Viewfinder Field of View 100%
    Viewfinder Magnification 0.63x
    Top-Level Screen Control Panel
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 920k dots
    LCD Attachment Fixed screen
    Touch Input No touchscreen
    Shooting Specs
    Focus System Phase-detect AF
    Manual Focusing Aidno Peaking Feature
    Maximum Shutter Speed 1/8000s
    Continuous Shooting 7 shutter flaps/s
    Shutter Life Expectancy150 000 actuations
    Silent Shootingno E-Shutter
    Time Lapse PhotographyIntervalometer Built-in
    Fill Flash Built-in Flash
    Storage Medium CF or SDXC cards
    Single or Dual Card Slots Dual card slots
    UHS card support no
    Connectivity Specs
    External Flash Hotshoe
    Studio Flash PC Sync socket
    USB Connector USB 2.0
    HDMI Port mini HDMI
    Microphone Port External MIC port
    Wifi Support no Wifi
    Body Specs
    Environmental SealingWeathersealed body
    Battery Type EN-EL3e power pack
    Battery Life (CIPA)950 shots per charge
    Body Dimensions 147 x 115 x 81 mm
    (5.8 x 4.5 x 3.2 in)
    Camera Weight 938 g (33.1 oz)

    Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
