How much dynamic range does the Canon M10 offer?
According to measurements carried out by DXO Mark, the sensor in the Canon EOS M10 provides a maximum of 11.4 EV of dynamic range (DR). DR is defined as the ratio between the highest and lowest brightness a camera can capture. A value of 12 EV or above is considered excellent.
High dynamic range of a camera sensor is particularly desirable for scenes with a mix of very bright and very dark parts, such as in some landscape photography settings. It helps to avoid that highlights get washed out or that detail in shadows is lost.
Sensor specs and performance
The table below compares the sensor specs of the Canon M10 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better). In addition to dynamic range (DXO Landscape), the listing also covers color depth (DXO Portrait) and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Canon M10 | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 22.2 | 11.4 | 753 | 65 | |
2. | Canon G7 X | 1-inch | 20.0 | 5472 | 3648 | 1080/60p | 23.0 | 12.7 | 556 | 71 | |
3. | Canon G9 X | 1-inch | 20.0 | 5472 | 3648 | 1080/60p | 21.5 | 12.3 | 495 | 63 | |
4. | Canon M | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 22.1 | 11.2 | 827 | 65 | |
5. | Canon M3 | APS-C | 24.0 | 6000 | 4000 | 1080/30p | 22.8 | 11.8 | 1169 | 72 | |
6. | Canon M100 | APS-C | 24.0 | 6000 | 4000 | 1080/60p | 23.5 | 12.9 | 1272 | 78 | |
7. | Canon SL1 | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 21.8 | 11.3 | 843 | 63 | |
8. | Canon T3i | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 22.1 | 11.5 | 793 | 65 | |
9. | Canon T5 | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 21.9 | 11.3 | 724 | 63 | |
10. | Canon T6 | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 22.0 | 11.7 | 781 | 66 | |
11. | Sony A5000 | APS-C | 19.8 | 5456 | 3632 | 1080/60i | 23.8 | 13.0 | 1089 | 79 |
In the United States, the M10 was initially launched in October 2015 at a price of $499.
Camera to camera comparisons
In case you would like to check on the differences and similarities with other camera models, just make your choice using the following search menu. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
Camera Model | Canon M10 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Canon EF-M mount lenses | |
Launch Date | October 2015 | |
Launch Price | USD 499 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | APS-C Sensor | |
Sensor Size | 22.3 x 14.9 mm | |
Sensor Area | 332 mm2 | |
Sensor Diagonal | 26.8 mm | |
Crop Factor | 1.6x | |
Sensor Resolution | 17.9 Megapixels | |
Image Resolution | 5 184 x 3 456 pixels | |
Pixel Pitch | 4.31 μm | |
Pixel Density | 5.39 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 1080/30p Video | |
ISO Setting | 100 - 12 800 ISO | |
ISO Boost | 100 - 25 600 ISO | |
Image Processor | DIGIC 6 | |
DXO Sensor Quality (score) | 65 | |
DXO Color Depth (bits) | 22.2 | |
DXO Dynamic Range (EV) | 11.4 | |
DXO Low Light (ISO) | 753 | |
Screen Specs | ||
Viewfinder Type | No viewfinder | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1040k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | Front-flip possible | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | On-Sensor Phase-detect | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 4.6 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | no Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | mini HDMI | |
Wifi Support | Wifi built-in | |
Near-Field Communication | NFC built-in | |
Body Specs | ||
Battery Type | Canon LP-E12 power pack | |
Battery Life (CIPA) | 255 shots per charge | |
Body Dimensions |
108 x 67 x 35 mm (4.3 x 2.6 x 1.4 in) |
|
Camera Weight | 301 g (10.6 oz) |
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
