Sony A7 PDF User Manual

Did you lose or misplace the instruction manual that came with your Sony Alpha A7? It happens all too easily, but fortunately Sony makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the A7 offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.

That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.

Also, you might want to check out the video tutorial on the Sony Alpha A7 below.

camera

In any case, the A7 is an advanced imaging tool, whose many features merit serious attention. This mirrorless interchangeable lens camera was announced on October 16th, 2013, which means that, as of today, the camera is 3266 days old (young?). The camera has meanwhile been discontinued and was succeeded by the Sony A7 II as a replacement in the same line of cameras.

Sony's instruction manual for the A7

The camera's instruction manual is 96 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the A7 is included towards the bottom of this webpage.

Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!

Click on the button below to download the pdf version of the Sony Alpha A7 manual to your computer. The file will open in a new browser window.

Download the Manual

If you prefer to read the user guide in another language, please check the respective availability on Sony's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.

Printed, hardcopy versions of the Sony A7 manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.

amazon.com ebay.com

Video tutorial for the Sony Alpha A7

Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your A7 by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.

Once again, the Sony A7 is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.

Find A7 guide book at
amazon.com

Sony A7 FAQ

Below are some additional questions and answers concerning some particular features of the A7.

What is the technology behind the imaging sensor in the A7?

The camera features a CMOS (Complementary Metal–Oxide–Semiconductor) sensor.

Which image processing chip is used to convert the raw signal into an image file and perform noise reduction and image sharpening?

Sony equipped the A7 with the BIONZ X image processor.

What is the ISO sensitivity range of the A7?

The camera has a native sensitivity range from ISO 100 to ISO 25600, which can be extended to ISO 50-51200.

What is the life expectancy of the shutter in the Sony Alpha A7?

Sony does not publish a shutter rating for the A7. Yet, shutters in comparable cameras from other manufacturers are said to be good for at least 200 000 actuations. It should be noted, though, that this number represents a Mean Time before Failure. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust an expected shutter life of 200 000 shots over, say, three years, one would have to take about 200 pictures each and every day.

How do I find the shutter count on my A7?

Sony embeds the number of shutter actuations in image metadata. You can check the number of shots that your A7 has taken up to now by uploading a recent image to the free online shutter count finder app.

Is it difficult to use manual focus lenses with the Sony A7?

The A7 offers focus peaking as a manual focus aid. This feature works by placing a colored highlight on in-focus zones within the image.

Does the Sony A7 feature an autofocus assist light?

Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.

What is the fastest shutter speed that can be used with flash?

The A7's flash sync speed is 1/250 sec.

Does the Sony A7 support the Ultra High Speed (UHS) bus interface for SD cards?

Yes, the camera can indeed use UHS-I cards (data transfer speed of up to 104 MB/s).

Which battery does the A7 use?

The camera gets its power from the NP-FW50 (here at amazon), which is a rechargeable Lithium-Ion power pack.

Is there a vertical grip available for the A7?

Yes, Sony offers the VG-C1EM as an optional accessory to facilitate shooting in portrait orientation and to provide additional battery power.

Further reading

How does the A7 stack up against available alternatives? In case you are interested in seeing how this camera compares to another one, just make a corresponding selection in the search boxes below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.

~
    loader

    Core camera specifications

    Here is a list of the main features and technical characteristics of the Sony Alpha A7.

    Specifications Summary
    Camera Model Sony A7
    Camera Type Mirrorless system camera
    Camera Lens Sony E mount lenses
    Launch Date October 2013
    Launch Price USD 1 699
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format Full Frame Sensor
    Sensor Size 35.8 x 23.9 mm
    Sensor Area 856 mm2
    Sensor Diagonal 43 mm
    Crop Factor 1.0x
    Sensor Resolution 24 Megapixels
    Image Resolution 6 000 x 4 000 pixels
    Pixel Pitch 5.97 μm
    Pixel Density 2.80 MP/cm2
    Moiré control Anti-Alias filter
    Movie Capability 1080/60p Video
    ISO Setting 100 - 25 600 ISO
    ISO Boost 50 - 51 200 ISO
    Image Processor BIONZ X
    DXO Sensor Quality (score) 90
    DXO Color Depth (bits) 24.8
    DXO Dynamic Range (EV) 14.2
    DXO Low Light (ISO) 2248
    Screen Specs
    Viewfinder Type Electronic viewfinder
    Viewfinder Field of View 100%
    Viewfinder Magnification 0.71x
    Viewfinder Resolution 2400k dots
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 1230k dots
    LCD Attachment Tilting screen
    V-logging Friendliness No front-flip
    Touch Input No touchscreen
    Shooting Specs
    Focus System On-Sensor Phase-detect
    Manual Focusing AidFocus Peaking
    Maximum Shutter Speed 1/8000s
    Continuous Shooting 5 shutter flaps/s
    Shutter Life Expectancy200 000 actuations
    Silent Shootingno E-Shutter
    Time Lapse Photographyno Intervalometer
    Fill Flash no On-Board Flash
    Storage Medium MS or SDXC cards
    Single or Dual Card Slots Single card slot
    UHS card support UHS-I
    Connectivity Specs
    External Flash Hotshoe
    USB Connector USB 2.0
    HDMI Port micro HDMI
    Microphone Port External MIC port
    Headphone Socket Headphone port
    Wifi Support Wifi built-in
    Near-Field Communication NFC built-in
    Body Specs
    Environmental SealingWeathersealed body
    Battery Type NP-FW50 power pack
    Battery Life (CIPA)340 shots per charge
    In-Camera Charging USB charging
    Body Dimensions 127 x 94 x 48 mm
    (5.0 x 3.7 x 1.9 in)
    Camera Weight 474 g (16.7 oz)
