Olympus E-510 PDF User Manual
Did you lose or misplace the instruction manual that came with your Olympus E-510? It happens all too easily, but fortunately Olympus makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the E-510 offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.
That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.
Also, you might want to check out the video tutorial on the Olympus E-510 below.
In any case, the E-510 is an advanced imaging tool, whose many features merit serious attention. This DSLR (Digital Single Lens Reflex) camera was announced on March 5th, 2007, which means that, as of today, the camera is 5691 days old (young?). The camera has meanwhile been discontinued and was succeeded by the Olympus E-520 as a replacement in the same line of cameras.
Olympus's instruction manual for the E-510
The camera's instruction manual is 140 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the E-510 is included towards the bottom of this webpage.
Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!
Click on the button below to download the pdf version of the Olympus E-510 manual to your computer. The file will open in a new browser window.
If you prefer to read the user guide in another language, please check the respective availability on Olympus's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.
Printed, hardcopy versions of the Olympus E-510 manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.
Video tutorial for the Olympus E-510
Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your E-510 by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.
Once again, the Olympus E-510 is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.
Olympus E-510 FAQ
Below are some additional questions and answers concerning some particular features of the E-510.
What technology is the imaging sensor in the E-510 based on?
The camera has a CMOS (Complementary Metal–Oxide–Semiconductor) sensor at its core.
Which image processing chip is used to convert the raw signal into an image file and perform noise reduction and image sharpening?
Olympus equipped the E-510 with the TruePic III image processor.
What is the ISO sensitivity range of the E-510?
The camera has a native sensitivity range from ISO 100 to ISO 1600.
What is the life expectancy of the shutter in the Olympus E-510?
Olympus does not publish a shutter rating for the E-510. Yet, shutters in comparable cameras from other manufacturers are said to be good for at least 100 000 actuations. It should be noted, though, that this number represents a Mean Time before Failure. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust an expected shutter life of 100 000 shots over, say, three years, one would have to take about 100 pictures each and every day.
How do I find the shutter count on my E-510?
Olympus embeds the number of shutter actuations in hidden menus. You can check the number of shots that your E-510 has taken up to now by carefully following the steps described on the Olympus E-510 shutter count page.
Does the Olympus E-510 feature an autofocus assist light?
Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.
What is the fastest shutter speed that can be used with flash?
The E-510's flash sync speed is 1/180 sec.
Which battery does the E-510 use?
How does the E-510 stack up against available alternatives? In case you are interested in seeing how this camera compares to another one, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 1D vs Olympus E-510
- Canon R6 vs Sony A9 II
- Fujifilm X-Pro1 vs Sony A9 II
- Leica C-LUX vs Olympus E-510
- Nikon D7100 vs Olympus E-510
- Nikon W300 vs Olympus E-510
- Nikon Z7 II vs Sony A9 II
- Olympus E-510 vs Olympus E-M5
- Olympus E-510 vs Pentax K-1
- Ricoh GR IIIx vs Sony A9 II
- Sony A6000 vs Sony A9 II
- Sony A9 vs Sony A9 II
Core camera specifications
Here is a list of the main features and technical characteristics of the Olympus E-510.
|Camera Model||Olympus E-510|
|Camera Type||Digital single lens reflex|
|Camera Lens||Four Thirds lenses|
|Launch Date||March 2007|
|Launch Price||USD 799|
|Sensor Format||Four Thirds Sensor|
|Sensor Size||17.3 x 13.0 mm|
|Sensor Area||225 mm2|
|Sensor Diagonal||21.6 mm|
|Sensor Resolution||10 Megapixels|
|Image Resolution||3 648 x 2 736 pixels|
|Pixel Pitch||4.74 μm|
|Pixel Density||4.44 MP/cm2|
|Moiré control||Anti-Alias filter|
|Movie Capability||no Video|
|ISO Setting||100 - 1 600 ISO|
|Image Processor||TruePic III|
|DXO Sensor Quality (score)||52|
|DXO Color Depth (bits)||21.2|
|DXO Dynamic Range (EV)||10.0|
|DXO Low Light (ISO)||442|
|Viewfinder Type||Optical viewfinder|
|Viewfinder Field of View||95%|
|Top-Level Screen||no Top Display|
|LCD Framing||Live View|
|LCD Size||2.5 inch|
|LCD Resolution||215k dots|
|LCD Attachment||Fixed screen|
|Touch Input||No touchscreen|
|Focus System||Phase-detect AF|
|Manual Focusing Aid||no Peaking Feature|
|Maximum Shutter Speed||1/4000s|
|Continuous Shooting||3 shutter flaps/s|
|Shutter Life Expectancy||100 000 actuations|
|Silent Shooting||no E-Shutter|
|Time Lapse Photography||no Intervalometer|
|Image Stabilization||In-body stabilization|
|Fill Flash||Built-in Flash|
|Storage Medium||CF or XD cards|
|Single or Dual Card Slots||Dual card slots|
|USB Connector||USB 2.0|
|HDMI Port||no HDMI|
|Wifi Support||no Wifi|
|Battery Type||BLM-1 power pack|
|Battery Life (CIPA)||750 shots per charge|
136 x 92 x 68 mm
(5.4 x 3.6 x 2.7 in)
|Camera Weight||538 g (19.0 oz)|
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
