What is the sensor size of the Sony RX10 IV?
The Sony Cyber-shot DSC-RX10 IV is a digital camera that has an one-inch sensor at its core. This imager measures 13.2mm in width and 8.8mm in height, so that the total imaging area of the sensor amounts to 116 mm2.
The RX10 IV provides an image resolution of 20 megapixels, based on 5 472 horizontal pixels and 3 648 vertical pixels.
Sensor size comparison with a film slide
The sensor diagonal measures 15.9mm, which gives rise to a format factor (or crop factor) of 2.7. Hence, the Sony RX10 IV is a crop-sensor camera, as its sensor is smaller than a traditional 35mm film slide or negative.
Sensor specs and performance
The table below compares the sensor specs of the Sony RX10 IV to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
# | Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
|
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Sony RX10 IV | 1-inch | 20.0 | 5472 | 3648 | 4K/30p | 22.0 | 12.2 | 408 | 63 | |
2. | Canon G1 X Mark III | APS-C | 24.0 | 6000 | 4000 | 1080/60p | 23.8 | 13.2 | 1649 | 81 | |
3. | Fujifilm X-Pro2 | APS-C | 24.0 | 6000 | 4000 | 1080/60p | 23.7 | 13.0 | 1608 | 80 | |
4. | Panasonic FZ2500 | 1-inch | 20.0 | 5472 | 3648 | 4K/30p | 23.0 | 12.6 | 538 | 70 | |
5. | Sony RX100 VI | 1-inch | 20.0 | 5472 | 3648 | 4K/30p | 22.1 | 12.3 | 478 | 64 | |
6. | Sony RX0 | 1-inch | 15.4 | 4800 | 3200 | 1080/60p | 22.4 | 12.4 | 548 | 68 | |
7. | Sony A6300 | APS-C | 24.0 | 6000 | 4000 | 4K/30p | 24.4 | 13.7 | 1437 | 85 | |
8. | Sony RX10 III | 1-inch | 20.0 | 5472 | 3648 | 4K/30p | 23.1 | 12.6 | 472 | 70 | |
9. | Sony RX100 V | 1-inch | 20.0 | 5472 | 3648 | 4K/30p | 22.8 | 12.4 | 586 | 70 | |
10. | Sony RX10 II | 1-inch | 20.0 | 5472 | 3648 | 4K/30p | 23.0 | 12.6 | 531 | 70 | |
11. | Sony RX10 | 1-inch | 20.0 | 5472 | 3648 | 1080/60p | 22.9 | 12.6 | 474 | 69 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
In the United States, the RX10 IV was initially launched in September 2017 at a price of $1,699.
Camera to camera comparisons
In case you are interested in seeing how this camera compares to another one, just use the search menu below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 5D Mark II vs Sony RX10 IV
- Canon 6D vs Nikon Z6
- Canon G7 X vs Nikon Z6
- Canon T6s vs Sony RX10 IV
- Canon XC10 vs Sony RX10 IV
- Fujifilm X-Pro2 vs Sony RX10 IV
- Leica M10-P vs Nikon Z6
- Nikon B500 vs Sony RX10 IV
- Nikon D5100 vs Nikon Z6
- Nikon Z6 vs Panasonic GX800
- Nikon Z6 vs Sony NEX-3N
- Panasonic FZ330 vs Sony RX10 IV
Camera Model | Sony RX10 IV | |
---|---|---|
Camera Type | Fixed lens compact camera | |
Camera Lens | 24-600mm f/2.4-4.0 | |
Launch Date | September 2017 | |
Launch Price | USD 1 699 | |
Sensor Specs | ||
Sensor Technology | BSI-CMOS | |
Sensor Format | 1" Sensor | |
Sensor Size | 13.2 x 8.8 mm | |
Sensor Area | 116 mm2 | |
Sensor Diagonal | 15.9 mm | |
Crop Factor | 2.7x | |
Sensor Resolution | 20 Megapixels | |
Image Resolution | 5 472 x 3 648 pixels | |
Pixel Pitch | 2.41 μm | |
Pixel Density | 17.18 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 4K/30p Video | |
ISO Setting | 100 - 12 800 ISO | |
ISO Boost | 64 - 25 600 ISO | |
Image Processor | BIONZ X | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 2359k dots | |
Top-Level Screen | Control Panel | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1440k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | No front-flip | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | On-Sensor Phase-detect | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/2000s | |
Continuous Shooting | 24 shutter flaps/s | |
Silent Shooting | Electronic Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | MS or SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Microphone Port | External MIC port | |
Headphone Socket | Headphone port | |
Wifi Support | Wifi built-in | |
Near-Field Communication | NFC built-in | |
Body Specs | ||
Environmental Sealing | Weathersealed body | |
Battery Type | Sony NP-FW50 power pack | |
Battery Life (CIPA) | 400 shots per charge | |
In-Camera Charging | USB charging | |
Body Dimensions |
133 x 94 x 145 mm (5.2 x 3.7 x 5.7 in) |
|
Camera Weight | 1 095 g (38.6 oz) |
