How many Megapixels does the Panasonic GH5s have?
The Panasonic Lumix DC-GH5s is equipped with a a Four Thirds sensor that offers an image resolution of 9.9 megapixels (MP), or 9.9 million pixels. With its native aspect ratio of 4:3, the sensor has 3 680 horizontal pixels and 2 700 vertical pixels.
A high megapixel count makes it possible to crop any captured image substantially or to make very large prints from the image file. On the downside, large megapixel files are slower to transfer and take up more storage space on the computer harddisk. Also, high-resolution imaging requires sharper, more expensive lenses than low-res picture taking.
How large can I print with 9.9 MP?
The maximum print size of the Panasonic GH5s for good quality output (200 dots per inch) amounts to 18.4 x 13.5 inches or 46.7 x 34.3 cm, for very good quality (250 dpi) 14.7 x 10.8 inches or 37.4 x 27.4 cm, and for excellent quality (300 dpi) 12.3 x 9 inches or 31.2 x 22.9 cm. Few people actually print their images that large on a regular basis, but it is nice to have the option to make very large prints of exceptional shots. Also, as mentioned earlier, a key advantage of high-MP cameras is that it is possible to crop an image ex-post and thereby, for example, change the composition of the capture or zoom in on some detail.
Sensor specs and performance
The table below compares the sensor specs of the Panasonic GH5s to those of several similar cameras. In addition to sensor class and megapixel count, DXO values are reported as indicators of the sensor's imaging quality (higher is better). Three aspects are covered: color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Panasonic GH5s | Four Thirds | 9.9 | 3680 | 2700 | 4K/60p | 23.1 | 12.8 | 1154 | 74 | |
2. | Canon R | Full Frame | 30.1 | 6720 | 4480 | 4K/30p | 24.5 | 13.5 | 2742 | 89 | |
3. | Panasonic FZ300 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 19.3 | 11.0 | 97 | 38 | |
4. | Panasonic G2 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.3 | 493 | 53 | |
5. | Panasonic G9 | Four Thirds | 20.2 | 5184 | 3888 | 4K/60p | 23.1 | 12.8 | 1138 | 74 | |
6. | Panasonic G10 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.1 | 411 | 52 | |
7. | Panasonic GF3 | Four Thirds | 12.0 | 4000 | 3000 | 1080/60i | 20.6 | 10.1 | 459 | 50 | |
8. | Panasonic GF5 | Four Thirds | 12.0 | 4000 | 3000 | 1080/60i | 20.5 | 10.0 | 573 | 50 | |
9. | Panasonic GH3 | Four Thirds | 15.9 | 4608 | 3456 | 1080/60p | 22.7 | 12.4 | 812 | 71 | |
10. | Panasonic GH4 | Four Thirds | 15.9 | 4608 | 3456 | 4K/30p | 23.2 | 12.8 | 791 | 74 | |
11. | Panasonic GH5 | Four Thirds | 20.2 | 5184 | 3888 | 4K/60p | 23.9 | 13.0 | 807 | 77 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
In the United States, the GH5s was initially launched in January 2018 at a price of $2,499.
Camera to camera comparisons
In case you are interested in seeing how this camera compares to another one, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 80D vs Nikon Z6
- Canon 90D vs Panasonic GH5s
- Canon M6 Mark II vs Nikon Z6
- Canon T8i vs Panasonic GH5s
- Canon XSi vs Nikon Z6
- Fujifilm X-H1 vs Nikon Z6
- Fujifilm XP130 vs Panasonic GH5s
- Nikon D2Xs vs Panasonic GH5s
- Nikon Z6 vs Olympus XZ-2
- Nikon Z6 vs Panasonic GH5
- Panasonic GH5s vs Panasonic GX800
- Panasonic GH5s vs Sony ZV-1F
Camera Model | Panasonic GH5s | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | January 2018 | |
Launch Price | USD 2 499 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 9.9 Megapixels | |
Image Resolution | 3 680 x 2 700 pixels | |
Pixel Pitch | 4.77 μm | |
Pixel Density | 4.42 MP/cm2 | |
Moiré control | no AA filter | |
Movie Capability | 4K/60p Video | |
ISO Setting | 160 - 51 200 ISO | |
ISO Boost | 80 - 204 800 ISO | |
Image Processor | Venus 10 | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.76x | |
Viewfinder Resolution | 3680k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.2 inch | |
LCD Resolution | 1620k dots | |
LCD Attachment | Swivel screen | |
V-logging Friendliness | Front-flip possible | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/8000s | |
Continuous Shooting | 12 shutter flaps/s | |
Shutter Life Expectancy | 200 000 actuations | |
Silent Shooting | Electronic Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Fill Flash | no On-Board Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Dual card slots | |
UHS card support | Dual UHS-II | |
Connectivity Specs | ||
External Flash | Hotshoe | |
Studio Flash | PC Sync socket | |
USB Connector | USB 3.1 | |
HDMI Port | full HDMI | |
Microphone Port | External MIC port | |
Headphone Socket | Headphone port | |
Wifi Support | Wifi built-in | |
Bluetooth Support | Bluetooth built-in | |
Body Specs | ||
Environmental Sealing | Weathersealed body | |
Battery Type | Panasonic DMW-BLF19 power pack | |
Battery Life (CIPA) | 440 shots per charge | |
Body Dimensions |
139 x 98 x 87 mm (5.5 x 3.9 x 3.4 in) |
|
Camera Weight | 660 g (23.3 oz) |
