What is the pixel pitch of the Panasonic GH1?
The Panasonic Lumix DMC-GH1 provides 12 megapixels from a Four Thirds sensor. This pixel density gives rise to a size of the individual pixel of 4.33µm.
The pixel size or pixel pitch can be calculated by dividing the sensor area by the pixel count and then taking the square root. In particular, the sensor in the Panasonic GH1 measures 17.3mm in width and 13.0mm in height, so that the total imaging area of the sensor amounts to 225 mm2. Moreover, the GH1 has 4 000 horizontal pixels and 3 000 vertical pixels, for a total of 12 megapixels. Then, the size (height or width) of each individual pixel can be calculated as the square root of the ratio of the sensor area (225 mm2) to the MP count (12 000 000).
Larger pixels provide advantages with respect to gathering light, particularly in low-light situations. Large pixels notably have a better signal to noise ratio, meaning that they can better differentiate between incoming photons and the noisy signals that the internal processes of the camera create. As a result, big pixels are particularly helpful to the photographer when shooting with high ISO settings.
Sensor specs and performance
The table below compares the sensor specs of the Panasonic GH1 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
# | Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
|
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Panasonic GH1 | Four Thirds | 12.0 | 4000 | 3000 | 1080/24p | 21.6 | 11.6 | 772 | 64 | |
2. | Olympus E-P1 | Four Thirds | 12.2 | 4032 | 3024 | 720/30p | 21.4 | 10.4 | 536 | 55 | |
3. | Olympus E-P2 | Four Thirds | 12.2 | 4032 | 3024 | 720/30p | 21.5 | 10.4 | 505 | 56 | |
4. | Panasonic LX100 | Four Thirds | 12.7 | 4112 | 3088 | 4K/30p | 22.3 | 12.5 | 553 | 67 | |
5. | Panasonic GX1 | Four Thirds | 15.8 | 4592 | 3448 | 1080/60p | 20.8 | 10.6 | 703 | 55 | |
6. | Panasonic G10 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.1 | 411 | 52 | |
7. | Panasonic G2 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.3 | 493 | 53 | |
8. | Panasonic GF2 | Four Thirds | 12.0 | 4000 | 3000 | 1080/60i | 21.2 | 10.3 | 506 | 54 | |
9. | Panasonic GH2 | Four Thirds | 15.9 | 4608 | 3456 | 1080/60i | 21.2 | 11.3 | 655 | 60 | |
10. | Panasonic GF1 | Four Thirds | 12.0 | 4000 | 3000 | 720/30p | 21.2 | 10.3 | 513 | 54 | |
11. | Panasonic G1 | Four Thirds | 12.0 | 4000 | 3000 | none | 21.1 | 10.3 | 463 | 53 |
Further information on the sensor in the Panasonic GH1 and the camera's operation can be found in the camera manual.
In the United States, the GH1 was initially launched in March 2009 at a price of $899.
Camera to camera comparisons
If you would like to see a side-by-side review with another camera, just make your choice using the following search menu. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 1D X vs Nikon Z6
- Canon 50D vs Panasonic GH1
- Canon G16 vs Nikon Z6
- Canon M3 vs Panasonic GH1
- Hasselblad X1D II vs Panasonic GH1
- Leica S Typ 006 vs Nikon Z6
- Nikon B700 vs Nikon Z6
- Nikon D500 vs Panasonic GH1
- Nikon Z6 vs Sony H200
- Nikon Z6 vs Sony ZV-E10
- Panasonic GH1 vs Panasonic GM1
- Panasonic GH1 vs Ricoh WG-60
Camera Model | Panasonic GH1 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | March 2009 | |
Launch Price | USD 899 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 12 Megapixels | |
Image Resolution | 4 000 x 3 000 pixels | |
Pixel Pitch | 4.33 μm | |
Pixel Density | 5.34 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 1080/24p Video | |
ISO Setting | 100 - 1 600 ISO | |
ISO Boost | 100 - 3 200 ISO | |
Image Processor | Venus HD | |
DXO Sensor Quality (score) | 64 | |
DXO Color Depth (bits) | 21.6 | |
DXO Dynamic Range (EV) | 11.6 | |
DXO Low Light (ISO) | 772 | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 1440k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 460k dots | |
LCD Attachment | Swivel screen | |
V-logging Friendliness | Front-flip possible | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 3 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | SDHC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | no | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | mini HDMI | |
Microphone Port | External MIC port | |
Wifi Support | no Wifi | |
Body Specs | ||
Battery Type | Panasonic DMW-BLB13 power pack | |
Battery Life (CIPA) | 300 shots per charge | |
Body Dimensions |
124 x 90 x 45 mm (4.9 x 3.5 x 1.8 in) |
|
Camera Weight | 385 g (13.6 oz) |
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
