What is the pixel pitch of the OM System TG-7?
The OM System Tough TG-7 provides 12 megapixels from a 1/2.3-inch sensor. This pixel density gives rise to a size of the individual pixel of 1.53µm.
The pixel size or pixel pitch can be calculated by dividing the sensor area by the pixel count and then taking the square root. In particular, the sensor in the OM System TG-7 measures 6.17mm in width and 4.55mm in height, so that the total imaging area of the sensor amounts to 28 mm2. Moreover, the TG-7 has 4 000 horizontal pixels and 3 000 vertical pixels, for a total of 12 megapixels. Then, the size (height or width) of each individual pixel can be calculated as the square root of the ratio of the sensor area (28 mm2) to the MP count (12 000 000).
Larger pixels provide advantages with respect to gathering light, particularly in low-light situations. Large pixels notably have a better signal to noise ratio, meaning that they can better differentiate between incoming photons and the noisy signals that the internal processes of the camera create. As a result, big pixels are particularly helpful to the photographer when shooting with high ISO settings.
Sensor specs and performance
The table below compares the sensor specs of the OM System TG-7 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | OM System TG-7 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 20.9 | 12.7 | 1553 | 54 | |
2. | Fujifilm XP130 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/60p | 20.6 | 12.1 | 1000 | 51 | |
3. | Fujifilm XP140 | 1/2.3 | 15.9 | 4608 | 3456 | 4K/15p | 20.7 | 12.2 | 1102 | 52 | |
4. | Nikon W300 | 1/2.3 | 15.9 | 4608 | 3456 | 4K/30p | 20.5 | 12.0 | 938 | 50 | |
5. | Olympus E-PM1 | Four Thirds | 12.2 | 4032 | 3024 | 1080/60i | 21.0 | 10.3 | 499 | 52 | |
6. | Olympus TG-4 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/30p | 20.2 | 11.6 | 737 | 47 | |
7. | Olympus TG-5 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 20.5 | 11.9 | 934 | 50 | |
8. | Olympus TG-6 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 20.7 | 12.2 | 1127 | 52 | |
9. | Olympus XZ-1 | 1/1.7 | 10.1 | 3664 | 2752 | 720/30p | 18.8 | 10.4 | 117 | 34 | |
10. | Olympus XZ-2 | 1/1.7 | 11.8 | 3968 | 2976 | 1080/30p | 20.4 | 11.3 | 216 | 49 | |
11. | Panasonic FZ300 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 19.3 | 11.0 | 97 | 38 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
Further information on the sensor in the OM System TG-7 and the camera's operation can be found in the camera manual.
In the United States, the TG-7 was initially launched in September 2023 at a price of $549.
Camera to camera comparisons
In case you would like to check on the differences and similarities with other camera models, just make your choice using the following search menu. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 10D vs Nikon Z6
- Fujifilm X-T200 vs Nikon Z6
- Fujifilm X-T200 vs OM System TG-7
- Nikon Z fc vs OM System TG-7
- Nikon Z6 II vs OM System TG-7
- Nikon Z6 vs Panasonic GF2
- Nikon Z6 vs Panasonic GX8
- Nikon Z6 vs Sony A850
- Nikon Z6 vs Sony ZV-E10
- OM System TG-7 vs Sigma fp
- OM System TG-7 vs Sony A7R IV
- OM System TG-7 vs Sony RX100 III
Camera Model | OM System TG-7 | |
---|---|---|
Camera Type | Fixed lens compact camera | |
Camera Lens | 25-100mm f/2.0-4.9 | |
Launch Date | September 2023 | |
Launch Price | USD 549 | |
Sensor Specs | ||
Sensor Technology | BSI-CMOS | |
Sensor Format | 1/2.3" Sensor | |
Sensor Size | 6.17 x 4.55 mm | |
Sensor Area | 28 mm2 | |
Sensor Diagonal | 7.7 mm | |
Crop Factor | 5.6x | |
Sensor Resolution | 12 Megapixels | |
Image Resolution | 4 000 x 3 000 pixels | |
Pixel Pitch | 1.53 μm | |
Pixel Density | 42.74 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 4K/30p Video | |
ISO Setting | 100 - 12 800 ISO | |
Image Processor | TruePic VIII | |
Screen Specs | ||
Viewfinder Type | No viewfinder | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1040k dots | |
LCD Attachment | Fixed screen | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/2000s | |
Continuous Shooting | 20 shutter flaps/s | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | no Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Geotagging | GPS built-in | |
Body Specs | ||
Environmental Sealing | Waterproof body (15m) | |
Battery Type | OM System LI-92B power pack | |
Battery Life (CIPA) | 330 shots per charge | |
In-Camera Charging | USB charging | |
Body Dimensions |
114 x 66 x 33 mm (4.5 x 2.6 x 1.3 in) |
|
Camera Weight | 249 g (8.8 oz) |
