What is the sensor size of the Olympus TG-6?
The Olympus Tough TG-6 is a digital camera that has a 1/2.3-inch sensor at its core. This imager measures 6.17mm in width and 4.55mm in height, so that the total imaging area of the sensor amounts to 28 mm2.
The TG-6 provides an image resolution of 12 megapixels, based on 4 000 horizontal pixels and 3 000 vertical pixels.
Sensor size comparison with a film slide
The sensor diagonal measures 7.7mm, which gives rise to a format factor (or crop factor) of 5.6. Hence, the Olympus TG-6 is a crop-sensor camera, as its sensor is smaller than a traditional 35mm film slide or negative.
Sensor specs and performance
The table below compares the sensor specs of the Olympus TG-6 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Olympus TG-6 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 20.7 | 12.2 | 1127 | 52 | |
2. | Canon SX740 | 1/2.3 | 20.2 | 5184 | 3888 | 4K/30p | 20.6 | 12.1 | 1050 | 51 | |
3. | Nikon W300 | 1/2.3 | 15.9 | 4608 | 3456 | 4K/30p | 20.5 | 12.0 | 938 | 50 | |
4. | Olympus E-PM1 | Four Thirds | 12.2 | 4032 | 3024 | 1080/60i | 21.0 | 10.3 | 499 | 52 | |
5. | Olympus TG-4 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/30p | 20.2 | 11.6 | 737 | 47 | |
6. | Olympus TG-5 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 20.5 | 11.9 | 934 | 50 | |
7. | Olympus XZ-1 | 1/1.7 | 10.1 | 3664 | 2752 | 720/30p | 18.8 | 10.4 | 117 | 34 | |
8. | OM System TG-7 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 20.9 | 12.7 | 1553 | 54 | |
9. | Panasonic TS7 | 1/2.3 | 20.2 | 5184 | 3888 | 4K/30p | 20.6 | 12.1 | 1028 | 51 | |
10. | Ricoh WG-6 | 1/2.3 | 20.2 | 5184 | 3888 | 4K/30p | 20.7 | 12.2 | 1104 | 52 | |
11. | Sony HX99 | 1/2.3 | 18.0 | 4896 | 3672 | 4K/30p | 20.6 | 12.1 | 1058 | 51 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
In the United States, the TG-6 was initially launched in May 2019 at a price of $449.
Camera to camera comparisons
In case you are interested in seeing how this camera compares to another one, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon SX620 vs Olympus TG-6
- Canon T3i vs Olympus TG-6
- Fujifilm X-E4 vs Olympus TG-6
- Fujifilm X-T5 vs Olympus TG-6
- Leica X Typ 113 vs Nikon Z6
- Nikon D850 vs Nikon Z6
- Nikon Z6 vs Olympus E-M10 II
- Nikon Z6 vs Olympus E-M10 IV
- Nikon Z6 vs Panasonic FZ150
- Nikon Z6 vs Pentax K-3 III
- Olympus E-PL3 vs Olympus TG-6
- Olympus TG-6 vs Zeiss ZX1
Camera Model | Olympus TG-6 | |
---|---|---|
Camera Type | Fixed lens compact camera | |
Camera Lens | 25-100mm f/2.0-4.9 | |
Launch Date | May 2019 | |
Launch Price | USD 449 | |
Sensor Specs | ||
Sensor Technology | BSI-CMOS | |
Sensor Format | 1/2.3" Sensor | |
Sensor Size | 6.17 x 4.55 mm | |
Sensor Area | 28 mm2 | |
Sensor Diagonal | 7.7 mm | |
Crop Factor | 5.6x | |
Sensor Resolution | 12 Megapixels | |
Image Resolution | 4 000 x 3 000 pixels | |
Pixel Pitch | 1.53 μm | |
Pixel Density | 42.74 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 4K/30p Video | |
ISO Setting | 100 - 12 800 ISO | |
Image Processor | TruePic VIII | |
Screen Specs | ||
Viewfinder Type | No viewfinder | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1040k dots | |
LCD Attachment | Fixed screen | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/2000s | |
Continuous Shooting | 20 shutter flaps/s | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | no Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Geotagging | GPS built-in | |
Body Specs | ||
Environmental Sealing | Waterproof body (15m) | |
Battery Type | Olympus LI-92B power pack | |
Battery Life (CIPA) | 340 shots per charge | |
In-Camera Charging | USB charging | |
Body Dimensions |
113 x 66 x 32 mm (4.4 x 2.6 x 1.3 in) |
|
Camera Weight | 253 g (8.9 oz) |
