What is the pixel pitch of the Fujifilm X10?

The Fujifilm X10 provides 12 megapixels from a 2/3 sensor. This pixel density gives rise to a size of the individual pixel of 2.20µm.

The pixel size or pixel pitch can be calculated by dividing the sensor area by the pixel count and then taking the square root. In particular, the sensor in the Fujifilm X10 measures 8.8mm in width and 6.6mm in height, so that the total imaging area of the sensor amounts to 58 mm2. Moreover, the X10 has 4 000 horizontal pixels and 3 000 vertical pixels, for a total of 12 megapixels. Then, the size (height or width) of each individual pixel can be calculated as the square root of the ratio of the sensor area (58 mm2) to the MP count (12 000 000).

camera

Larger pixels provide advantages with respect to gathering light, particularly in low-light situations. Large pixels notably have a better signal to noise ratio, meaning that they can better differentiate between incoming photons and the noisy signals that the internal processes of the camera create. As a result, big pixels are particularly helpful to the photographer when shooting with high ISO settings.

ad

Sensor specs and performance

The table below compares the sensor specs of the Fujifilm X10 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.

scroll hint
Sensor Characteristics
#   Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Fujifilm X10 2/3 12.0 4000 30001080/30p20.511.324550
2.

Canon G16 1/1.7 12.0 4000 30001080/60p21.011.723054
3.

Canon G15 1/1.7 12.0 4000 30001080/24p19.911.516546
4.

Canon G12 1/1.7 10.0 3648 2736720/24p20.411.216147
5.

Fujifilm X30 2/3 12.0 4000 30001080/60p20.411.2-31249
6.

Fujifilm X20 2/3 12.0 4000 30001080/60p20.110.9-46246
7.

Leica D-LUX 6 1/1.7 10.0 3648 27361080/60p19.810.8-30343
8.

Panasonic LX7 1/1.7 10.0 3648 27361080/60p20.711.714750
9.

Panasonic G10 Four Thirds 12.0 4000 3000720/30p21.210.141152
10.

Panasonic GF2 Four Thirds 12.0 4000 30001080/60i21.210.350654
11.

Panasonic LX5 1/1.7 10.0 3648 2736720/60p19.610.813241
Note: DXO values in italics represent estimates based on sensor size and age.
padding

Further information on the sensor in the Fujifilm X10 and the camera's operation can be found in the camera manual.

In the United States, the X10 was initially launched in September 2011 at a price of $599.

logo
Check X10 offers at
ebay.com

Camera to camera comparisons

In case you would like to check on the differences and similarities with other camera models, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.

~
    loader
    ad

    Specifications Summary
    Camera Model Fujifilm X10
    Camera Type Fixed lens compact camera
    Camera Lens 28-112mm f/2.0-2.8
    Launch Date September 2011
    Launch Price USD 599
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format Two Thirds Sensor
    Sensor Size 8.8 x 6.6 mm
    Sensor Area 58 mm2
    Sensor Diagonal 11 mm
    Crop Factor 3.9x
    Sensor Resolution 12 Megapixels
    Image Resolution 4 000 x 3 000 pixels
    Pixel Pitch 2.20 μm
    Pixel Density 20.66 MP/cm2
    Moiré control no AA filter
    Movie Capability 1080/30p Video
    ISO Setting 100 - 3 200 ISO
    ISO Boost 100 - 12 800 ISO
    Image Processor EXR Processor II
    DXO Sensor Quality (score) 50
    DXO Color Depth (bits) 20.5
    DXO Dynamic Range (EV) 11.3
    DXO Low Light (ISO) 245
    Screen Specs
    Viewfinder Type Optical viewfinder
    Viewfinder Field of View 85%
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 2.8 inch
    LCD Resolution 460k dots
    LCD Attachment Fixed screen
    Touch Input No touchscreen
    Shooting Specs
    Focus System Contrast-detect AF
    Manual Focusing Aidno Peaking Feature
    Maximum Shutter Speed 1/4000s
    Continuous Shooting 10 shutter flaps/s
    Silent Shootingno E-Shutter
    Time Lapse Photographyno Intervalometer
    Fill Flash Built-in Flash
    Storage Medium SDXC cards
    Single or Dual Card Slots Single card slot
    UHS card support no
    Connectivity Specs
    External Flash Hotshoe
    USB Connector USB 2.0
    HDMI Port mini HDMI
    Wifi Support no Wifi
    Body Specs
    Battery Type Fujifilm NP-50 power pack
    Battery Life (CIPA)270 shots per charge
    Body Dimensions 117 x 70 x 57 mm
    (4.6 x 2.8 x 2.2 in)
    Camera Weight 350 g (12.3 oz)
