What is the sensor size of the Fujifilm X-A1?

The Fujifilm X-A1 is a digital camera that has an APS-C sensor at its core. This imager measures 23.5mm in width and 15.7mm in height, so that the total imaging area of the sensor amounts to 369 mm2.

The X-A1 provides an image resolution of 16 megapixels, based on 4 896 horizontal pixels and 3 264 vertical pixels.

camera

Sensor size comparison with a film slide

The sensor diagonal measures 28.3mm, which gives rise to a format factor (or crop factor) of 1.5. Hence, the Fujifilm X-A1 is a crop-sensor camera, as its sensor is smaller than a traditional 35mm film slide or negative.

Fujifilm X-A1 and Credit Card sensor measures
ad

Sensor specs and performance

The table below compares the sensor specs of the Fujifilm X-A1 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.

scroll hint
Sensor Characteristics
    Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Fujifilm X-A1 APS-C 16.0 4896 32641080/30p23.412.6139076
2.

Fujifilm X-A2 APS-C 16.0 4896 32641080/30p23.612.8151579
3.

Fujifilm X-A3 APS-C 24.0 6000 40001080/60p23.813.1166481
4.

Fujifilm X-A5 APS-C 24.0 6000 40004K/15p24.013.3180082
5.

Fujifilm X-A10 APS-C 16.0 4896 32641080/30p23.913.2169181
6.

Fujifilm X-E1 APS-C 16.0 4896 32641080/24p23.212.4129875
7.

Fujifilm X-E2 APS-C 16.0 4896 32641080/60p23.412.6140077
8.

Fujifilm X-E2S APS-C 16.0 4896 32641080/60p23.713.0160880
9.

Fujifilm X-M1 APS-C 16.0 4896 32641080/30p23.412.6137176
10.

Fujifilm X-Pro1 APS-C 16.0 4896 32641080/24p23.112.3123874
11.

Fujifilm X-T10 APS-C 16.0 4896 32641080/60p23.712.9154679
Note: DXO values in italics represent estimates based on sensor size and age.
Further information on the sensor in the Fujifilm X-A1 and the camera's operation can be found in the camera manual.

In the United States, the X-A1 was initially launched in September 2013 at a price of $399.

logo
Check X-A1 offers at
ebay.com

Camera to camera comparisons

In case you are interested in seeing how this camera compares to another one, just make your choice using the following search menu. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.

~
    loader
    ad

    Specifications Summary
    Camera Model Fujifilm X-A1
    Camera Type Mirrorless system camera
    Camera Lens Fujifilm X mount lenses
    Launch Date September 2013
    Launch Price USD 399
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format APS-C Sensor
    Sensor Size 23.5 x 15.7 mm
    Sensor Area 369 mm2
    Sensor Diagonal 28.3 mm
    Crop Factor 1.5x
    Sensor Resolution 16 Megapixels
    Image Resolution 4 896 x 3 264 pixels
    Pixel Pitch 4.80 μm
    Pixel Density 4.33 MP/cm2
    Moiré control Anti-Alias filter
    Movie Capability 1080/30p Video
    ISO Setting 200 - 6 400 ISO
    ISO Boost 100 - 25 600 ISO
    Image Processor EXR Processor II
    Screen Specs
    Viewfinder Type No viewfinder
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 920k dots
    LCD Attachment Tilting screen
    V-logging Friendliness Front-flip possible
    Touch Input No touchscreen
    Shooting Specs
    Focus System Contrast-detect AF
    Manual Focusing AidFocus Peaking
    Maximum Shutter Speed 1/4000s
    Continuous Shooting 5.6 shutter flaps/s
    Shutter Life Expectancy100 000 actuations
    Silent Shootingno E-Shutter
    Time Lapse Photographyno Intervalometer
    Fill Flash Built-in Flash
    Storage Medium SDHC cards
    Single or Dual Card Slots Single card slot
    UHS card support UHS-I
    Connectivity Specs
    External Flash Hotshoe
    USB Connector USB 2.0
    HDMI Port mini HDMI
    Wifi Support Wifi built-in
    Body Specs
    Battery Type Fujifilm NP-W126 power pack
    Battery Life (CIPA)350 shots per charge
    Body Dimensions 117 x 67 x 39 mm
    (4.6 x 2.6 x 1.5 in)
    Camera Weight 330 g (11.6 oz)
