What is the crop factor of the Canon XT?
The Canon EOS Rebel XT is equipped with an APS-C sensor, whose diagonal measures 26.7mm. The sensor has a crop factor (or format factor, or focal length multiplier) of 1.6.
The crop factor is defined as the ratio of the 35mm full-frame film diagonal to the diagonal of a digital sensor. This number indicates how a lens behaves in relation to the size of the image sensor.
Sensor size comparison with a film slide
With a crop factor of 1.6, the sensor in the Canon XT is smaller than the receptor area of a 35mm film slide or negative. As a result, a lens that is attached to the Canon XT will offer a narrower angle of view and provide deeper depth of field than a lens of similar focal length and aperture on a film camera. The equivalent focal length is obtained by multiplying the actual focal length of the lens with the crop factor. For example, a 31mm lens on the Canon XT will provide the same angle of view and depth of field as a 50mm normal lens on a film camera (31mm * 1.6 = 50mm).
Sensor specs and performance
The table below compares the sensor specs of the Canon XT to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Canon XT | APS-C | 8.0 | 3456 | 2304 | none | 21.8 | 10.8 | 637 | 60 | |
2. | Canon 20D | APS-C | 8.2 | 3504 | 2336 | none | 21.9 | 11.0 | 721 | 62 | |
3. | Canon 30D | APS-C | 8.2 | 3504 | 2336 | none | 21.5 | 10.8 | 736 | 59 | |
4. | Canon 77D | APS-C | 24.0 | 6000 | 4000 | 1080/60p | 23.6 | 13.3 | 971 | 78 | |
5. | Canon Rebel | APS-C | 6.3 | 3072 | 2048 | none | 21.0 | 10.8 | 544 | 55 | |
6. | Canon T1i | APS-C | 15.1 | 4752 | 3168 | 1080/20p | 21.7 | 11.5 | 663 | 63 | |
7. | Canon T4i | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 21.7 | 11.2 | 722 | 62 | |
8. | Canon T6i | APS-C | 24.0 | 6000 | 4000 | 1080/30p | 22.7 | 12.0 | 919 | 71 | |
9. | Canon T6s | APS-C | 24.0 | 6000 | 4000 | 1080/30p | 22.6 | 12.0 | 915 | 70 | |
10. | Canon XSi | APS-C | 12.2 | 4272 | 2848 | none | 21.9 | 10.8 | 692 | 61 | |
11. | Canon XTi | APS-C | 10.1 | 3888 | 2592 | none | 22.1 | 11.0 | 664 | 62 |
In the United States, the XT was initially launched in February 2005 at a price of $899.
Camera to camera comparisons
In case you would like to check on the differences and similarities with other camera models, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 1D Mark II vs Canon XT
- Canon 1D Mark III vs Canon XT
- Canon 1D X Mark III vs Nikon Z6
- Canon R3 vs Nikon Z6
- Canon XT vs Leica V-LUX 3
- Canon XT vs Nikon D3000
- Canon XT vs Panasonic GX85
- Canon XT vs Sony A6500
- Nikon Z6 vs Olympus E-300
- Nikon Z6 vs Olympus E-M10
- Nikon Z6 vs Olympus E-P3
- Nikon Z6 vs Panasonic L10
Camera Model | Canon XT | |
---|---|---|
Camera Type | Digital single lens reflex | |
Camera Lens | Canon EF mount lenses | |
Launch Date | February 2005 | |
Launch Price | USD 899 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | APS-C Sensor | |
Sensor Size | 22.2 x 14.8 mm | |
Sensor Area | 329 mm2 | |
Sensor Diagonal | 26.7 mm | |
Crop Factor | 1.6x | |
Sensor Resolution | 8 Megapixels | |
Image Resolution | 3 456 x 2 304 pixels | |
Pixel Pitch | 6.41 μm | |
Pixel Density | 2.42 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | no Video | |
ISO Setting | 100 - 1 600 ISO | |
Image Processor | DIGIC II | |
DXO Sensor Quality (score) | 60 | |
DXO Color Depth (bits) | 21.8 | |
DXO Dynamic Range (EV) | 10.8 | |
DXO Low Light (ISO) | 637 | |
Screen Specs | ||
Viewfinder Type | Optical viewfinder | |
Viewfinder Field of View | 95% | |
Viewfinder Magnification | 0.49x | |
Top-Level Screen | no Top Display | |
LCD Size | 1.8 inch | |
LCD Resolution | 115k dots | |
LCD Attachment | Fixed screen | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Phase-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 3 shutter flaps/s | |
Shutter Life Expectancy | 50 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | CF cards | |
Single or Dual Card Slots | Single card slot | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | no HDMI | |
Wifi Support | no Wifi | |
Body Specs | ||
Battery Type | Canon NB-2LH power pack | |
Battery Life (CIPA) | 400 shots per charge | |
Body Dimensions |
127 x 94 x 64 mm (5.0 x 3.7 x 2.5 in) |
|
Camera Weight | 540 g (19.0 oz) |
