How many Megapixels does the Canon SX520 have?

The Canon PowerShot SX520 HS is equipped with a a 1/2.3-inch sensor that offers an image resolution of 15.9 megapixels (MP), or 15.9 million pixels. With its native aspect ratio of 4:3, the sensor has 4 608 horizontal pixels and 3 456 vertical pixels.

A 35mm film slide or negative contains 5-15 MP of useful detail, so that the Canon SX520 can be considered to be a high-resolution camera that outresolves any 35mm film camera.

camera

A high megapixel count makes it possible to crop any captured image substantially or to make very large prints from the image file. On the downside, large megapixel files are slower to transfer and take up more storage space on the computer harddisk. Also, high-resolution imaging requires sharper, more expensive lenses than low-res picture taking.

How large can I print with 15.9 MP?

The maximum print size of the Canon SX520 for good quality output (200 dots per inch) amounts to 23 x 17.3 inches or 58.5 x 43.9 cm, for very good quality (250 dpi) 18.4 x 13.8 inches or 46.8 x 35.1 cm, and for excellent quality (300 dpi) 15.4 x 11.5 inches or 39 x 29.3 cm. Few people actually print their images that large on a regular basis, but it is nice to have the option to make very large prints of exceptional shots. Also, as mentioned earlier, a key advantage of high-MP cameras is that it is possible to crop an image ex-post and thereby, for example, change the composition of the capture or zoom in on some detail.

ad

Sensor specs and performance

The table below compares the sensor specs of the Canon SX520 to those of several similar cameras. In addition to sensor class and megapixel count, DXO values are reported as indicators of the sensor's imaging quality (higher is better). Three aspects are covered: color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.

scroll hint
Sensor Characteristics
#   Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Canon SX520 1/2.3 15.9 4608 34561080/30p20.111.567246
2.

Canon SX540 1/2.3 20.2 5184 38881080/60p20.311.780648
3.

Canon SX530 1/2.3 15.9 4608 34561080/30p20.211.671247
4.

Canon SX710 1/2.3 20.2 5184 38881080/60p20.211.671247
5.

Canon SX700 1/2.3 15.9 4608 34561080/60p20.111.462945
6.

Canon SX60 1/2.3 14.2 4608 30721080/60p19.210.812739
7.

Canon T5 APS-C 17.9 5184 34561080/30p21.911.372463
8.

Canon SX510 1/2.3 15.9 4608 34561080/24p20.011.358645
9.

Nikon B600 1/2.3 15.9 4608 34561080/30p20.712.2109552
10.

Sony HX90V 1/2.3 18.0 4896 36721080/60p20.211.673847
11.

Sony H200 1/2.3 15.2 5184 2930720/30p19.911.252944
Note: DXO values in italics represent estimates based on sensor size and age.
padding
Further information on the sensor in the Canon SX520 and the camera's operation can be found in the camera manual.

In the United States, the SX520 was initially launched in July 2014 at a price of $399.

logo
Check SX520 offers at
ebay.com

Camera to camera comparisons

If you would like to see a side-by-side review with another camera, just make your choice using the following search menu. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.

~
    loader
    ad

    Specifications Summary
    Camera Model Canon SX520
    Camera Type Fixed lens compact camera
    Camera Lens 24-1008mm f/3.4-6
    Launch Date July 2014
    Launch Price USD 399
    Sensor Specs
    Sensor Technology BSI-CMOS
    Sensor Format 1/2.3" Sensor
    Sensor Size 6.17 x 4.55 mm
    Sensor Area 28 mm2
    Sensor Diagonal 7.7 mm
    Crop Factor 5.6x
    Sensor Resolution 15.9 Megapixels
    Image Resolution 4 608 x 3 456 pixels
    Pixel Pitch 1.33 μm
    Pixel Density 56.73 MP/cm2
    Moiré control no AA filter
    Movie Capability 1080/30p Video
    ISO Setting 100 - 3 200 ISO
    Image Processor DIGIC 4+
    Screen Specs
    Viewfinder Type No viewfinder
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 461k dots
    LCD Attachment Fixed screen
    Touch Input No touchscreen
    Shooting Specs
    Focus System Contrast-detect AF
    Manual Focusing Aidno Peaking Feature
    Maximum Shutter Speed 1/2000s
    Continuous Shooting 1.6 shutter flaps/s
    Silent Shootingno E-Shutter
    Time Lapse Photographyno Intervalometer
    Fill Flash Built-in Flash
    Storage Medium SDXC cards
    Single or Dual Card Slots Single card slot
    UHS card support no
    Connectivity Specs
    External Flash no Hotshoe
    USB Connector USB 2.0
    HDMI Port mini HDMI
    Wifi Support no Wifi
    Body Specs
    Battery Type Canon NB-6LH power pack
    Battery Life (CIPA)210 shots per charge
    Body Dimensions 120 x 82 x 92 mm
    (4.7 x 3.2 x 3.6 in)
    Camera Weight 441 g (15.6 oz)

    Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
