How many Megapixels does the Canon M have?
The Canon EOS M is equipped with a an APS-C sensor that offers an image resolution of 17.9 megapixels (MP), or 17.9 million pixels. With its native aspect ratio of 3:2, the sensor has 5 184 horizontal pixels and 3 456 vertical pixels.
A 35mm film slide or negative contains 5-15 MP of useful detail, so that the Canon M can be considered to be a high-resolution camera that outresolves any 35mm film camera.
A high megapixel count makes it possible to crop any captured image substantially or to make very large prints from the image file. On the downside, large megapixel files are slower to transfer and take up more storage space on the computer harddisk. Also, high-resolution imaging requires sharper, more expensive lenses than low-res picture taking.
How large can I print with 17.9 MP?
The maximum print size of the Canon M for good quality output (200 dots per inch) amounts to 25.9 x 17.3 inches or 65.8 x 43.9 cm, for very good quality (250 dpi) 20.7 x 13.8 inches or 52.7 x 35.1 cm, and for excellent quality (300 dpi) 17.3 x 11.5 inches or 43.9 x 29.3 cm. Few people actually print their images that large on a regular basis, but it is nice to have the option to make very large prints of exceptional shots. Also, as mentioned earlier, a key advantage of high-MP cameras is that it is possible to crop an image ex-post and thereby, for example, change the composition of the capture or zoom in on some detail.
Sensor specs and performance
The table below compares the sensor specs of the Canon M to those of several similar cameras. In addition to sensor class and megapixel count, DXO values are reported as indicators of the sensor's imaging quality (higher is better). Three aspects are covered: color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
|4.||Canon G7 X||1-inch||20.0||5472||3648||1080/60p||23.0||12.7||556||71|
|9.||Panasonic GF6||Four Thirds||15.8||4592||3448||1080/60i||20.7||10.6||622||54|
|10.||Panasonic G3||Four Thirds||15.8||4592||3448||1080/60i||21.0||10.6||667||56|
In the United States, the Canon M was initially launched in July 2012 at a price of $599.
Camera to camera comparisons
In case you are interested in seeing how this camera compares to another one, just use the search menu below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
|Camera Model||Canon M|
|Camera Type||Mirrorless system camera|
|Camera Lens||Canon EF-M mount lenses|
|Launch Date||July 2012|
|Launch Price||USD 599|
|Sensor Format||APS-C Sensor|
|Sensor Size||22.3 x 14.9 mm|
|Sensor Area||332 mm2|
|Sensor Diagonal||26.8 mm|
|Sensor Resolution||17.9 Megapixels|
|Image Resolution||5 184 x 3 456 pixels|
|Pixel Pitch||4.31 μm|
|Pixel Density||5.39 MP/cm2|
|Moiré control||Anti-Alias filter|
|Movie Capability||1080/30p Video|
|ISO Setting||100 - 12 800 ISO|
|ISO Boost||100 - 25 600 ISO|
|Image Processor||DIGIC V|
|DXO Sensor Quality (score)||65|
|DXO Color Depth (bits)||22.1|
|DXO Dynamic Range (EV)||11.2|
|DXO Low Light (ISO)||827|
|Viewfinder Type||No viewfinder|
|Top-Level Screen||no Top Display|
|LCD Framing||Live View|
|LCD Size||3.0 inch|
|LCD Resolution||1040k dots|
|LCD Attachment||Fixed screen|
|Focus System||On-Sensor Phase-detect|
|Manual Focusing Aid||no Peaking Feature|
|Maximum Shutter Speed||1/4000s|
|Continuous Shooting||4.3 shutter flaps/s|
|Shutter Life Expectancy||100 000 actuations|
|Silent Shooting||no E-Shutter|
|Time Lapse Photography||no Intervalometer|
|Fill Flash||no On-Board Flash|
|Storage Medium||SDXC cards|
|Single or Dual Card Slots||Single card slot|
|UHS card support||UHS-I|
|USB Connector||USB 2.0|
|HDMI Port||mini HDMI|
|Microphone Port||External MIC port|
|Wifi Support||no Wifi|
|Battery Type||LP-E12 power pack|
|Battery Life (CIPA)||230 shots per charge|
109 x 66 x 32 mm
(4.3 x 2.6 x 1.3 in)
|Camera Weight||298 g (10.5 oz)|
