How many Megapixels does the Canon 700D have?

The Canon EOS 700D is equipped with a an APS-C sensor that offers an image resolution of 17.9 megapixels (MP), or 17.9 million pixels. With its native aspect ratio of 3:2, the sensor has 5 184 horizontal pixels and 3 456 vertical pixels.

A 35mm film slide or negative contains 5-15 MP of useful detail, so that the Canon 700D can be considered to be a high-resolution camera that outresolves any 35mm film camera.

camera

A high megapixel count makes it possible to crop any captured image substantially or to make very large prints from the image file. On the downside, large megapixel files are slower to transfer and take up more storage space on the computer harddisk. Also, high-resolution imaging requires sharper, more expensive lenses than low-res picture taking.

How large can I print with 17.9 MP?

The maximum print size of the Canon 700D for good quality output (200 dots per inch) amounts to 25.9 x 17.3 inches or 65.8 x 43.9 cm, for very good quality (250 dpi) 20.7 x 13.8 inches or 52.7 x 35.1 cm, and for excellent quality (300 dpi) 17.3 x 11.5 inches or 43.9 x 29.3 cm. Few people actually print their images that large on a regular basis, but it is nice to have the option to make very large prints of exceptional shots. Also, as mentioned earlier, a key advantage of high-MP cameras is that it is possible to crop an image ex-post and thereby, for example, change the composition of the capture or zoom in on some detail.

Sensor specs and performance

The table below compares the sensor specs of the Canon 700D to those of several similar cameras. In addition to sensor class and megapixel count, DXO values are reported as indicators of the sensor's imaging quality (higher is better). Three aspects are covered: color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.

scroll hint
Sensor Characteristics
    Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Canon 700D APS-C 17.9 5184 34561080/30p21.711.268161
2.

Canon 750D APS-C 24.0 6000 40001080/30p22.712.091971
3.

Canon 760D APS-C 24.0 6000 40001080/30p22.612.091570
4.

Canon 1200D APS-C 17.9 5184 34561080/30p21.911.372463
5.

Canon G7 X 1-inch 20.0 5472 36481080/60p23.012.755671
6.

Canon 100D APS-C 17.9 5184 34561080/30p21.811.384363
7.

Canon 650D APS-C 17.9 5184 34561080/30p21.711.272262
8.

Canon M APS-C 17.9 5184 34561080/30p22.111.282765
9.

Canon 600D APS-C 17.9 5184 34561080/30p22.111.579365
10.

Canon 550D APS-C 17.9 5184 34561080/30p22.111.578466
11.

Canon 500D APS-C 15.1 4752 31681080/20p21.711.566363
Further information on the sensor in the Canon 700D and the camera's operation can be found in the camera manual.

In the United States, the 700D was initially launched in March 2013 at a price of $649.

logo
Check 700D offers at
ebay.com

Camera to camera comparisons

In case you are interested in seeing how this camera compares to another one, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.

~
    loader

    Specifications Summary
    Camera Model Canon 700D
    Camera Type Digital single lens reflex
    Camera Lens Canon EF mount lenses
    Launch Date March 2013
    Launch Price USD 649
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format APS-C Sensor
    Sensor Size 22.3 x 14.9 mm
    Sensor Area 332 mm2
    Sensor Diagonal 26.8 mm
    Crop Factor 1.6x
    Sensor Resolution 17.9 Megapixels
    Image Resolution 5 184 x 3 456 pixels
    Pixel Pitch 4.31 μm
    Pixel Density 5.39 MP/cm2
    Moiré control Anti-Alias filter
    Movie Capability 1080/30p Video
    ISO Setting 100 - 12 800 ISO
    ISO Boost 100 - 25 600 ISO
    Image Processor DIGIC 5
    DXO Sensor Quality (score) 61
    DXO Color Depth (bits) 21.7
    DXO Dynamic Range (EV) 11.2
    DXO Low Light (ISO) 681
    Screen Specs
    Viewfinder Type Optical viewfinder
    Viewfinder Field of View 95%
    Viewfinder Magnification 0.53x
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 1040k dots
    LCD Attachment Swivel screen
    V-logging Friendliness Front-flip possible
    Touch Input Touchscreen
    Shooting Specs
    Focus System Phase-detect AF
    Manual Focusing Aidno Peaking Feature
    Maximum Shutter Speed 1/4000s
    Continuous Shooting 5 shutter flaps/s
    Shutter Life Expectancy100 000 actuations
    Silent Shootingno E-Shutter
    Time Lapse Photographyno Intervalometer
    Fill Flash Built-in Flash
    Storage Medium SDXC cards
    Single or Dual Card Slots Single card slot
    UHS card support UHS-I
    Connectivity Specs
    External Flash Hotshoe
    USB Connector USB 2.0
    HDMI Port mini HDMI
    Microphone Port External MIC port
    Wifi Support no Wifi
    Body Specs
    Battery Type LP-E8 power pack
    Battery Life (CIPA)440 shots per charge
    Body Dimensions 133 x 100 x 79 mm
    (5.2 x 3.9 x 3.1 in)
    Camera Weight 580 g (20.5 oz)
