Nikon D80 PDF User Manual
Did you lose or misplace the instruction manual that came with your Nikon D80? It happens all too easily, but fortunately Nikon makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the D80 offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.
That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.
Also, you might want to check out the video tutorial on the Nikon D80 below.
In any case, the D80 is an advanced imaging tool, whose many features merit serious attention. This DSLR (Digital Single Lens Reflex) camera was announced on August 9th, 2006, which means that, as of today, the camera is 6441 days old (young?). The camera has meanwhile been discontinued and was succeeded by the Nikon D90 as a replacement in the same line of cameras.
Nikon's user manual for the D80
The camera's user manual is 162 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the D80 is included towards the bottom of this webpage.
Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!
Click on the button below to download the pdf version of the Nikon D80 manual to your computer. The file will open in a new browser window.
If you prefer to read the user guide in another language, please check the respective availability on Nikon's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.
Printed, hardcopy versions of the Nikon D80 manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.
Video tutorial for the Nikon D80
Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your D80 by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.
Once again, the Nikon D80 is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.
Nikon D80 FAQ
Below are some additional questions and answers concerning some particular features of the D80.
What technology is the imaging sensor in the Nikon D80 based on?
The camera is build around a CCD (Charged Coupled Device) sensor.
What is the ISO sensitivity range of the Nikon D80?
The camera has a native sensitivity range from ISO 100 to ISO 1600.
What is the life expectancy of the shutter in the Nikon D80?
Nikon mentions a shutter rating of 100 000 actuations for the D80. This number represents a Mean Time before Failure, that is an average value. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust the expected shutter life of the D80 over, say, three years, one would have to take about 100 pictures each and every day.
How do I find the shutter count on my Nikon D80?
Nikon embeds the number of shutter actuations in image metadata. You can check the number of shots that your D80 has taken up to now by uploading a recent image to the free online shutter count finder app.
Does the Nikon D80 feature an autofocus assist light?
Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.
What is the fastest shutter speed that can be used with the Nikon D80 for flash photography?
The D80's flash sync speed is 1/200 sec.
Which battery does the Nikon D80 use?
The camera gets its power from the Nikon EN-EL3e (here at amazon), which is a rechargeable Lithium-Ion power pack.
Is there a vertical grip available for the Nikon D80?
Yes, Nikon offers the MB-D80 as an optional accessory to facilitate shooting in portrait orientation and to provide additional battery power.
Further reading
How does the D80 stack up against available alternatives? If you would like to see a side-by-side review with another camera, just make a corresponding selection in the search boxes below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 5DS vs Nikon D80
- Canon 6D Mark II vs Sony A9 II
- Canon SL3 vs Sony A9 II
- Canon SX620 vs Sony A9 II
- Hasselblad X2D 100C vs Sony A9 II
- Nikon 1 V2 vs Nikon D80
- Nikon D7100 vs Nikon D80
- Nikon D80 vs Panasonic S1
- Nikon D80 vs Sony A850
- Nikon D80 vs Sony NEX-6
- Panasonic LX15 vs Sony A9 II
- Panasonic TZ100 vs Sony A9 II
Core camera specifications
Here is a list of the main features and technical characteristics of the Nikon D80.
Camera Model | Nikon D80 | |
---|---|---|
Camera Type | Digital single lens reflex | |
Camera Lens | Nikon F mount lenses | |
Launch Date | August 2006 | |
Launch Price | USD 999 | |
Sensor Specs | ||
Sensor Technology | CCD | |
Sensor Format | APS-C Sensor | |
Sensor Size | 23.6 x 15.8 mm | |
Sensor Area | 373 mm2 | |
Sensor Diagonal | 28.4 mm | |
Crop Factor | 1.5x | |
Sensor Resolution | 10 Megapixels | |
Image Resolution | 3 872 x 2 592 pixels | |
Pixel Pitch | 6.11 μm | |
Pixel Density | 2.69 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | no Video | |
ISO Setting | 100 - 1 600 ISO | |
ISO Boost | 100 - 3 200 ISO | |
DXO Sensor Quality (score) | 61 | |
DXO Color Depth (bits) | 22.1 | |
DXO Dynamic Range (EV) | 11.2 | |
DXO Low Light (ISO) | 524 | |
Screen Specs | ||
Viewfinder Type | Optical viewfinder | |
Viewfinder Field of View | 95% | |
Viewfinder Magnification | 0.62x | |
Top-Level Screen | no Top Display | |
LCD Size | 2.5 inch | |
LCD Resolution | 230k dots | |
LCD Attachment | Fixed screen | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Phase-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 3 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | SDHC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | no | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | no HDMI | |
Wifi Support | no Wifi | |
Body Specs | ||
Battery Type | Nikon EN-EL3e power pack | |
Battery Life (CIPA) | 600 shots per charge | |
Body Dimensions |
132 x 103 x 77 mm (5.2 x 4.1 x 3.0 in) |
|
Camera Weight | 668 g (23.6 oz) |
