Leica V-LUX 5 PDF User Manual
Did you lose or misplace the instruction manual that came with your Leica V-LUX 5? It happens all too easily, but fortunately Leica makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the V-LUX 5 offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.
That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.
Also, you might want to check out the video tutorial on the Leica V-LUX 5 below.
In any case, the V-LUX 5 is an advanced imaging tool, whose many features merit serious attention. This fixed lens compact camera was officially introduced on July 10th, 2019, which means that, as of today, the camera is 1723 days old (young?). Given that the V-LUX 5 is a relatively recent model, it forms part of the current Leica product line-up.
Leica's instruction manual for the V-LUX 5
The camera's instruction manual is 227 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the V-LUX 5 is included towards the bottom of this webpage.
Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!
Click on the button below to download the pdf version of the Leica V-LUX 5 manual to your computer. The file will open in a new browser window.
If you prefer to read the user guide in another language, please check the respective availability on Leica's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.
Printed, hardcopy versions of the Leica V-LUX 5 manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.
Video tutorial for the Leica V-LUX 5
Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your V-LUX 5 by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.
Once again, the Leica V-LUX 5 is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.
Leica V-LUX 5 FAQ
Below are some additional questions and answers concerning some particular features of the V-LUX 5.
What technology is the imaging sensor in the Leica V-LUX 5 based on?
The camera features a BSI-CMOS (Backside Illuminated Complementary Metal–Oxide–Semiconductor) sensor.
What is the ISO sensitivity range of the Leica V-LUX 5?
The camera has a native sensitivity range from ISO 125 to ISO 12800, which can be extended to ISO 80-25600.
Does the Leica V-LUX 5 have a selfie-friendly screen?
Yes, the LCD-screen of the V-LUX 5 is flexible and can be turned to be front-facing for capturing selfies.
Is completely silent shooting possible with the Leica V-LUX 5?
The camera has an electronic shutter option, so that it is indeed feasible to capture images without any shutter noise.
Do I need to purchase an external camera trigger to shoot time-lapse sequences with the Leica V-LUX 5?
No, the Leica V-LUX 5 has an intervalometer built-in, so that low frequency shooting (for example, flower blooming, sunset, moon rise) can be undertaken without the need to purchase a separate external intervalometer and related software.
Is it difficult to use manual focus lenses with the Leica V-LUX 5?
The V-LUX 5 offers focus peaking as a manual focus aid. This feature works by placing a colored highlight on in-focus zones within the image.
Does the Leica V-LUX 5 feature an autofocus assist light?
Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.
Does the Leica V-LUX 5 support the Ultra High Speed (UHS) bus interface for SD cards?
Yes, the camera can indeed use UHS-I cards (data transfer speed of up to 104 MB/s).
Which battery does the Leica V-LUX 5 use?
The camera gets its power from the Leica BP-DC12 (here at amazon), which is a rechargeable Lithium-Ion power pack.
Where can I find the best deals for the Leica V-LUX 5?
Grey imports from Asia, as found on ebay, are often very attractively priced. However, these cameras come without a warranty from Leica.
Further reading
How does the V-LUX 5 stack up against available alternatives? If you would like to see a side-by-side review with another camera, just use the search menu below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 1300D vs Sony A9 II
- Canon 850D vs Sony A9 II
- Canon R5 C vs Sony A9 II
- Fujifilm X-Pro2 vs Leica V-LUX 5
- Leica V-LUX 5 vs Olympus E-P1
- Leica V-LUX 5 vs Panasonic GF7
- Leica V-LUX 5 vs Panasonic GH5 II
- Leica V-LUX 5 vs Panasonic LX100
- Leica V-LUX 5 vs Sony RX1R II
- Panasonic ZS100 vs Sony A9 II
- Pentax K-3 III vs Sony A9 II
- Sony A9 II vs Sony RX100 VII
Core camera specifications
Here is a list of the main features and technical characteristics of the Leica V-LUX 5.
Camera Model | Leica V-LUX 5 | |
---|---|---|
Camera Type | Fixed lens compact camera | |
Camera Lens | 25-400mm f/2.8-4.0 | |
Launch Date | July 2019 | |
Launch Price | USD 1 249 | |
Sensor Specs | ||
Sensor Technology | BSI-CMOS | |
Sensor Format | 1" Sensor | |
Sensor Size | 13.2 x 8.8 mm | |
Sensor Area | 116 mm2 | |
Sensor Diagonal | 15.9 mm | |
Crop Factor | 2.7x | |
Sensor Resolution | 20 Megapixels | |
Image Resolution | 5 472 x 3 648 pixels | |
Pixel Pitch | 2.41 μm | |
Pixel Density | 17.18 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 4K/30p Video | |
ISO Setting | 125 - 12 800 ISO | |
ISO Boost | 80 - 25 600 ISO | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 2360k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1240k dots | |
LCD Attachment | Swivel screen | |
V-logging Friendliness | Front-flip possible | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 12 shutter flaps/s | |
Silent Shooting | Electronic Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Bluetooth Support | Bluetooth built-in | |
Body Specs | ||
Battery Type | Leica BP-DC12 power pack | |
Battery Life (CIPA) | 350 shots per charge | |
In-Camera Charging | USB charging | |
Body Dimensions |
136 x 97 x 131 mm (5.4 x 3.8 x 5.2 in) |
|
Camera Weight | 812 g (28.6 oz) |
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
