Fujifilm X-T30 II PDF User Manual

Did you lose or misplace the instruction manual that came with your Fujifilm X-T30 II? It happens all too easily, but fortunately Fujifilm makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the X-T30 II offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.

That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.

camera

In any case, the X-T30 II is an advanced imaging tool, whose many features merit serious attention. This mirrorless interchangeable lens camera was revealed to the public on September 2nd, 2021, which means that, as of today, the camera is 447 days old (young?). Given that the X-T30 II is a relatively recent model, it forms part of the current Fujifilm product line-up.

Fujifilm's owner manual for the X-T30 II

The camera's owner manual is 360 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the X-T30 II is included towards the bottom of this webpage.

Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!

Click on the button below to download the pdf version of the Fujifilm X-T30 II manual to your computer. The file will open in a new browser window.

Download the Manual

If you prefer to read the user guide in another language, please check the respective availability on Fujifilm's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.

Printed, hardcopy versions of the Fujifilm X-T30 II manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.

amazon.com ebay.com

Fujifilm X-T30 II FAQ

Below are some additional questions and answers concerning some particular features of the X-T30 II.

What technology is the imaging sensor in the X-T30 II based on?

The camera features a BSI-CMOS (Backside Illuminated Complementary Metal–Oxide–Semiconductor) sensor.

Which image processing chip is used to convert the raw signal into an image file and perform noise reduction and image sharpening?

Fujifilm equipped the X-T30 II with the X-Processor 4 image processor.

What is the ISO sensitivity range of the X-T30 II?

The camera has a native sensitivity range from ISO 160 to ISO 12800, which can be extended to ISO 80-51200.

What is the life expectancy of the shutter in the Fujifilm X-T30 II?

Fujifilm does not publish a shutter rating for the X-T30 II. Yet, shutters in comparable cameras from other manufacturers are said to be good for at least 100 000 actuations. It should be noted, though, that this number represents a Mean Time before Failure. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust an expected shutter life of 100 000 shots over, say, three years, one would have to take about 100 pictures each and every day.

How do I find the shutter count on my X-T30 II?

Fujifilm embeds the number of shutter actuations in image metadata. You can check the number of shots that your X-T30 II has taken up to now by uploading a recent image to the free online shutter count finder app.

Is completely silent shooting possible with the Fujifilm X-T30 II?

The camera has an electronic shutter option, so that it is indeed feasible to capture images without any shutter noise.

Do I need to purchase an external camera trigger to shoot time-lapse sequences?

No, the Fujifilm X-T30 II has an intervalometer built-in, so that low frequency shooting (for example, flower blooming, sunset, moon rise) can be undertaken without the need to purchase a separate external intervalometer and related software.

Is it difficult to use manual focus lenses with the Fujifilm X-T30 II?

The X-T30 II offers focus peaking as a manual focus aid. This feature works by placing a colored highlight on in-focus zones within the image.

Does the Fujifilm X-T30 II feature an autofocus assist light?

Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.

What is the fastest shutter speed that can be used with flash?

The X-T30 II's flash sync speed is 1/180 sec.

Does the Fujifilm X-T30 II support the Ultra High Speed (UHS) bus interface for SD cards?

Yes, the camera can indeed use UHS-I cards (data transfer speed of up to 104 MB/s).

Which battery does the X-T30 II use?

The camera gets its power from the NP-W126S (here at amazon), which is a rechargeable Lithium-Ion power pack.

Where can I find the best deals for the X-T30 II?

Grey imports from Asia, as found on ebay, are often very attractively priced. However, these cameras come without a warranty from Fujifilm.

Further reading

How does the X-T30 II stack up against available alternatives? In case you are interested in seeing how this camera compares to another one, just make your choice using the following search menu. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.

~
    loader

    Core camera specifications

    Here is a list of the main features and technical characteristics of the Fujifilm X-T30 II.

    Specifications Summary
    Camera Model Fujifilm X-T30 II
    Camera Type Mirrorless system camera
    Camera Lens Fujifilm X mount lenses
    Launch Date September 2021
    Launch Price USD 899
    Sensor Specs
    Sensor Technology BSI-CMOS
    Sensor Format APS-C Sensor
    Sensor Size 23.5 x 15.6 mm
    Sensor Area 367 mm2
    Sensor Diagonal 28.2 mm
    Crop Factor 1.5x
    Sensor Resolution 26 Megapixels
    Image Resolution 6 240 x 4 160 pixels
    Pixel Pitch 3.76 μm
    Pixel Density 7.08 MP/cm2
    Moiré control no AA filter
    Movie Capability 4K/30p Video
    ISO Setting 160 - 12 800 ISO
    ISO Boost 80 - 51 200 ISO
    Image Processor X-Processor 4
    Screen Specs
    Viewfinder Type Electronic viewfinder
    Viewfinder Field of View 100%
    Viewfinder Magnification 0.62x
    Viewfinder Resolution 2360k dots
    Top-Level Screen no Top Display
    LCD Size 3.0 inch
    LCD Resolution 1620k dots
    LCD Attachment Tilting screen
    V-logging Friendliness No front-flip
    Touch Input Touchscreen
    Shooting Specs
    Focus System On-Sensor Phase-detect
    Manual Focusing AidFocus Peaking
    Maximum Shutter Speed 1/4000s
    Continuous Shooting 8 shutter flaps/s
    Shutter Life Expectancy100 000 actuations
    Silent ShootingElectronic Shutter
    Time Lapse PhotographyIntervalometer Built-in
    Fill Flash Built-in Flash
    Storage Medium SDXC cards
    Single or Dual Card Slots Single card slot
    UHS card support UHS-I
    Connectivity Specs
    External Flash Hotshoe
    USB Connector USB 3.2
    HDMI Port micro HDMI
    Microphone Port External MIC port
    Wifi Support Wifi built-in
    Bluetooth Support Bluetooth built-in
    Body Specs
    Battery Type NP-W126S power pack
    Battery Life (CIPA)380 shots per charge
    In-Camera Charging USB charging
    Body Dimensions 118 x 83 x 47 mm
    (4.6 x 3.3 x 1.9 in)
    Camera Weight 383 g (13.5 oz)
