Canon T3 PDF User Manual
Did you lose or misplace the instruction manual that came with your Canon EOS Rebel T3? It happens all too easily, but fortunately Canon makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the T3 offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.
That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.
Also, you might want to check out the video tutorial on the Canon EOS Rebel T3 below.
In any case, the T3 (called Canon 1100D in some regions) is an advanced imaging tool, whose many features merit serious attention. This DSLR (Digital Single Lens Reflex) camera was revealed to the public on February 7th, 2011, which means that, as of today, the camera is 4256 days old (young?). The camera has meanwhile been discontinued and was succeeded by the Canon T5 as a replacement in the same line of cameras.
Canon's instruction manual for the T3
The camera's instruction manual is 292 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the T3 is included towards the bottom of this webpage.
Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!
Click on the button below to download the pdf version of the Canon EOS Rebel T3 manual to your computer. The file will open in a new browser window.
If you prefer to read the user guide in another language, please check the respective availability on Canon's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.
Printed, hardcopy versions of the Canon T3 manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.
Video tutorial for the Canon EOS Rebel T3
Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your T3 by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.
Once again, the Canon T3 is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.
Canon T3 FAQ
Below are some additional questions and answers concerning some particular features of the T3.
What is the technology behind the imaging sensor in the T3?
The camera is build around a CMOS (Complementary Metal–Oxide–Semiconductor) sensor.
Which image processing chip is used to convert the raw signal into an image file and perform noise reduction and image sharpening?
Canon equipped the T3 with the DIGIC 4 image processor.
What is the ISO sensitivity range of the T3?
The camera has a native sensitivity range from ISO 100 to ISO 6400.
What is the life expectancy of the shutter in the Canon EOS Rebel T3?
Canon mentions a shutter rating of 100 000 actuations for the T3. This number represents a Mean Time before Failure, that is an average value. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust the expected shutter life of the T3 over, say, three years, one would have to take about 100 pictures each and every day.
Does the Canon T3 feature an autofocus assist light?
Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.
What is the fastest shutter speed that can be used with flash?
The T3's flash sync speed is 1/200 sec.
Which battery does the T3 use?
Is there a vertical grip available for the T3?
Canon does not offer an optional battery grip, but third party suppliers do (see here on ebay).
How does the T3 stack up against available alternatives? In case you are interested in seeing how this camera compares to another one, just make your choice using the following search menu. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
Core camera specifications
Here is a list of the main features and technical characteristics of the Canon EOS Rebel T3.
|Camera Model||Canon T3|
|Camera Type||Digital single lens reflex|
|Camera Lens||Canon EF mount lenses|
|Launch Date||February 2011|
|Launch Price||USD 449|
|Sensor Format||APS-C Sensor|
|Sensor Size||22.0 x 14.7 mm|
|Sensor Area||323 mm2|
|Sensor Diagonal||26.5 mm|
|Sensor Resolution||12.2 Megapixels|
|Image Resolution||4 272 x 2 848 pixels|
|Pixel Pitch||5.15 μm|
|Pixel Density||3.76 MP/cm2|
|Moiré control||Anti-Alias filter|
|Movie Capability||720/30p Video|
|ISO Setting||100 - 6 400 ISO|
|Image Processor||DIGIC 4|
|DXO Sensor Quality (score)||62|
|DXO Color Depth (bits)||21.9|
|DXO Dynamic Range (EV)||11.0|
|DXO Low Light (ISO)||755|
|Viewfinder Type||Optical viewfinder|
|Viewfinder Field of View||95%|
|Top-Level Screen||no Top Display|
|LCD Framing||Live View|
|LCD Size||2.7 inch|
|LCD Resolution||230k dots|
|LCD Attachment||Fixed screen|
|Touch Input||No touchscreen|
|Focus System||Phase-detect AF|
|Manual Focusing Aid||no Peaking Feature|
|Maximum Shutter Speed||1/4000s|
|Continuous Shooting||3 shutter flaps/s|
|Shutter Life Expectancy||100 000 actuations|
|Silent Shooting||no E-Shutter|
|Time Lapse Photography||no Intervalometer|
|Fill Flash||Built-in Flash|
|Storage Medium||SDXC cards|
|Single or Dual Card Slots||Single card slot|
|UHS card support||no|
|USB Connector||USB 2.0|
|HDMI Port||mini HDMI|
|Wifi Support||no Wifi|
|Battery Type||LP-E10 power pack|
|Battery Life (CIPA)||700 shots per charge|
130 x 100 x 78 mm
(5.1 x 3.9 x 3.1 in)
|Camera Weight||495 g (17.5 oz)|
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
