Canon 600D PDF User Manual
Did you lose or misplace the instruction manual that came with your Canon EOS 600D? It happens all too easily, but fortunately Canon makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the 600D offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.
That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.
Also, you might want to check out the video tutorial on the Canon EOS 600D below.
In any case, the 600D (called Canon T3i in some regions) is an advanced imaging tool, whose many features merit serious attention. This DSLR (Digital Single Lens Reflex) camera was officially introduced on February 7th, 2011, which means that, as of today, the camera is 4826 days old (young?). The camera has meanwhile been discontinued and was succeeded by the Canon 650D as a replacement in the same line of cameras.
Canon's instruction manual for the 600D
The camera's instruction manual is 324 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the 600D is included towards the bottom of this webpage.
Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!
Click on the button below to download the pdf version of the Canon EOS 600D manual to your computer. The file will open in a new browser window.
If you prefer to read the user guide in another language, please check the respective availability on Canon's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.
Printed, hardcopy versions of the Canon 600D manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.
Video tutorial for the Canon EOS 600D
Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your 600D by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.
Once again, the Canon 600D is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.
Canon 600D FAQ
Below are some additional questions and answers concerning some particular features of the 600D.
What technology is the imaging sensor in the Canon 600D based on?
The camera features a CMOS (Complementary Metal–Oxide–Semiconductor) sensor.
Which image processing chip is used in the Canon 600D to convert the raw signal into an image file and perform noise reduction and image sharpening?
Canon equipped the 600D with the DIGIC 4 image processor.
What is the ISO sensitivity range of the Canon 600D?
The camera has a native sensitivity range from ISO 100 to ISO 6400.
Does the Canon 600D have a selfie-friendly screen?
Yes, the LCD-screen of the 600D is flexible and can be turned to be front-facing for capturing selfies.
What is the life expectancy of the shutter in the Canon EOS 600D?
Canon mentions a shutter rating of 100 000 actuations for the 600D. This number represents a Mean Time before Failure, that is an average value. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust the expected shutter life of the 600D over, say, three years, one would have to take about 100 pictures each and every day.
How do I find the shutter count on my Canon 600D?
Canon embeds the number of shutter actuations in the camera firmware. You can check the number of shots that your 600D has taken up to now by using a third-party app, as described on the Canon 600D shutter count page.
Does the Canon 600D feature an autofocus assist light?
Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.
What is the fastest shutter speed that can be used with the Canon 600D for flash photography?
The 600D's flash sync speed is 1/200 sec.
Which battery does the Canon 600D use?
The camera gets its power from the Canon LP-E8 (here at amazon), which is a rechargeable Lithium-Ion power pack.
Is there a vertical grip available for the Canon 600D?
Yes, Canon offers the BG-E8 as an optional accessory to facilitate shooting in portrait orientation and to provide additional battery power.
Further reading
How does the 600D stack up against available alternatives? If you would like to see a side-by-side review with another camera, just make your choice using the following search menu. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 1D X Mark III vs Sony A9 II
- Canon 600D vs Canon G5 X
- Canon 600D vs Canon S120
- Canon 600D vs Canon SX540
- Canon 600D vs Fujifilm X100F
- Canon 600D vs Fujifilm X100T
- Canon 600D vs Leica D-LUX 7
- Canon R3 vs Sony A9 II
- Canon R6 vs Sony A9 II
- Nikon D200 vs Sony A9 II
- Panasonic FZ82 vs Sony A9 II
- Panasonic ZS200 vs Sony A9 II
Core camera specifications
Here is a list of the main features and technical characteristics of the Canon EOS 600D.
Camera Model | Canon 600D | |
---|---|---|
Camera Type | Digital single lens reflex | |
Camera Lens | Canon EF mount lenses | |
Launch Date | February 2011 | |
Launch Price | USD 599 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | APS-C Sensor | |
Sensor Size | 22.3 x 14.9 mm | |
Sensor Area | 332 mm2 | |
Sensor Diagonal | 26.8 mm | |
Crop Factor | 1.6x | |
Sensor Resolution | 17.9 Megapixels | |
Image Resolution | 5 184 x 3 456 pixels | |
Pixel Pitch | 4.31 μm | |
Pixel Density | 5.39 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 1080/30p Video | |
ISO Setting | 100 - 6 400 ISO | |
ISO Boost | 100 - 12 800 ISO | |
Image Processor | DIGIC 4 | |
DXO Sensor Quality (score) | 65 | |
DXO Color Depth (bits) | 22.1 | |
DXO Dynamic Range (EV) | 11.5 | |
DXO Low Light (ISO) | 793 | |
Screen Specs | ||
Viewfinder Type | Optical viewfinder | |
Viewfinder Field of View | 95% | |
Viewfinder Magnification | 0.53x | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1040k dots | |
LCD Attachment | Swivel screen | |
V-logging Friendliness | Front-flip possible | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Phase-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 3.7 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | no | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | mini HDMI | |
Microphone Port | External MIC port | |
Wifi Support | no Wifi | |
Body Specs | ||
Battery Type | Canon LP-E8 power pack | |
Battery Life (CIPA) | 440 shots per charge | |
Body Dimensions |
133 x 100 x 80 mm (5.2 x 3.9 x 3.1 in) |
|
Camera Weight | 570 g (20.1 oz) |
