Nikon D3 vs Olympus E-5

The Nikon D3 and the Olympus E-5 are two professional cameras that were announced, respectively, in August 2007 and September 2010. Both are DSLR (Digital Single Lens Reflex) cameras that are based on a full frame (D3) and a Four Thirds (E-5) sensor. The Nikon has a resolution of 12.1 megapixels, whereas the Olympus provides 12.2 MP.

Below is an overview of the main specs of the two cameras as a starting point for the comparison.

Headline Specifications

Nikon D3		Olympus E-5
Digital single lens reflex		Digital single lens reflex
Nikon F mount lenses		Four Thirds lenses
12.1 MP – Full Frame sensor		12.2 MP – Four Thirds sensor
no Video		720/30p Video
ISO 200-6,400 (100 - 25,600)		ISO 100-6,400
Optical viewfinder		Optical viewfinder
3.0" LCD – 922k dots		3.0" LCD – 920k dots
Fixed screen (not touch-sensitive)		Swivel screen (not touch-sensitive)
11 shutter flaps per second		5 shutter flaps per second
Lens stabilization only		In-body stabilization
Weathersealed body		Weathersealed body
4300 shots per battery charge		750 shots per battery charge
160 x 157 x 88 mm, 1300 g		142 x 117 x 75 mm, 873 g

Check D3 offers at
ebay.com
Check E-5 offers at
ebay.com

Going beyond this snapshot of core features and characteristics, what are the differences between the Nikon D3 and the Olympus E-5? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.

Body comparison

The side-by-side display below illustrates the physical size and weight of the Nikon D3 and the Olympus E-5. The two cameras are presented according to their relative size. Three consecutive perspectives from the front, the top, and the back are available. All width, height and depth measures are rounded to the nearest millimeter.

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Olympus E-5 is considerably smaller (34 percent) than the Nikon D3. Moreover, the E-5 is markedly lighter (33 percent) than the D3. In this context, it is worth noting that both cameras are splash and dust-proof and can, hence, be used in inclement weather conditions or harsh environments.

The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. A larger imaging sensor will tend to go along with bigger and heavier lenses, although exceptions exist. You can compare the optics available for the two cameras in the Nikon Lens Catalog (D3) and the Four Thirds Lens Catalog (E-5).

Concerning battery life, the D3 gets 4300 shots out of its Nikon EN-EL4a battery, while the E-5 can take 750 images on a single charge of its Olympus BLM-5 power pack. As can be seen in the images above, the D3 has a battery grip built in. This facilitates image-taking in portrait orientation and gives it additional battery power. In order to provide similar functionality for the E-5, Olympus provides the HLD-4 vertical grip as an optional accessory (see here on ebay).

The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. In case you want to display and compare another camera duo, you can use the CAM-parator app to select your camera combination among a large number of options.

Body Specifications

		Camera Model	Camera Width	Camera Height	Camera Depth	Camera Weight	Battery Life	Weather Sealing	Camera Launch	Launch Price	Street Price
1.		Nikon D3	160 mm	157 mm	88 mm	1300 g	4300	Y	Aug 2007	US$ 4 999	ebay.com
2.		Olympus E-5	142 mm	117 mm	75 mm	873 g	750	Y	Sep 2010	US$ 1 699	ebay.com
3.		Canon 1D Mark III	156 mm	157 mm	80 mm	1155 g	2200	Y	Feb 2007	US$ 4 499	ebay.com
4.		Nikon D2X	158 mm	150 mm	86 mm	1252 g	3800	Y	Sep 2004	US$ 4 999	ebay.com
5.		Nikon D2Xs	158 mm	150 mm	86 mm	1252 g	3800	Y	Jun 2006	US$ 4 699	ebay.com
6.		Nikon D3S	160 mm	157 mm	88 mm	1240 g	4200	Y	Oct 2009	US$ 5 199	ebay.com
7.		Nikon D3X	160 mm	157 mm	88 mm	1260 g	4400	Y	Dec 2008	US$ 7 999	ebay.com
8.		Nikon D4	160 mm	157 mm	91 mm	1340 g	2600	Y	Jan 2012	US$ 5 999	ebay.com
9.		Nikon D4S	160 mm	157 mm	91 mm	1350 g	3020	Y	Feb 2014	US$ 6 499	ebay.com
10.		Nikon D5	160 mm	159 mm	92 mm	1415 g	3780	Y	Jan 2016	US$ 6 499	ebay.com
11.		Nikon D300	147 mm	114 mm	74 mm	925 g	1000	Y	Aug 2007	US$ 1 799	ebay.com
12.		Nikon D700	147 mm	123 mm	77 mm	1074 g	1000	Y	Jul 2008	US$ 2 999	ebay.com
13.		Olympus E-1	141 mm	104 mm	81 mm	738 g	750	Y	Jun 2003	US$ 1 699	ebay.com
14.		Olympus E-3	142 mm	116 mm	75 mm	876 g	750	Y	Oct 2007	US$ 1 699	ebay.com
15.		Olympus E-30	142 mm	108 mm	75 mm	701 g	750	n	Nov 2008	US$ 1 299	ebay.com
16.		Olympus E-510	136 mm	92 mm	68 mm	538 g	750	n	Mar 2007	US$ 799	ebay.com
17.		Olympus E-520	136 mm	92 mm	68 mm	535 g	750	n	May 2008	US$ 699	ebay.com
Note: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
Convert to Imperial

Any camera decision will naturally be influenced heavily by the price. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The E-5 was launched at a markedly lower price (by 66 percent) than the D3, which puts it into a different market segment. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.

Sensor comparison

The imaging sensor is at the core of digital cameras and its size is one of the main determining factors of image quality. A large sensor will generally have larger individual pixels that offer better low-light sensitivity, provide wider dynamic range, and have richer color-depth than smaller pixels in a sensor of the same technological generation. Moreover, a large sensor camera will give the photographer more control over depth-of-field in the image and, thus, the ability to better isolate a subject from the background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.

Of the two cameras under consideration, the Nikon D3 features a full frame sensor and the Olympus E-5 a Four Thirds sensor. The sensor area in the E-5 is 74 percent smaller. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.0 and 2.0. The sensor in the D3 has a native 3:2 aspect ratio, while the one in the E-5 offers a 4:3 aspect.

Despite having a smaller sensor, the E-5 offers a slightly higher resolution of 12.2 megapixels, compared with 12.1 MP of the D3. This megapixels advantage comes at the cost of a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 4.29μm versus 8.43μm for the D3). However, it should be noted that the E-5 is much more recent (by 3 years) than the D3, and its sensor will have benefitted from technological advances during this time that make it possible to gather light more efficiently.

The Nikon D3 has a native sensitivity range from ISO 200 to ISO 6400, which can be extended to ISO 100-25600. The corresponding ISO settings for the Olympus E-5 are ISO 100 to ISO 6400 (no boost).

Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors. Both cameras use a Bayer filter for capturing RGB colors on a square grid of photosensors. This arrangement is found in most digital cameras.

For many cameras, data on sensor performance has been reported by DXO Mark. This service assesses and scores the color depth ("DXO Portrait"), dynamic range ("DXO Landscape"), and low-light sensitivity ("DXO Sports") of camera sensors, and also publishes an overall camera score. Of the two cameras under review, the D3 provides substantially higher image quality than the E-5, with an overall score that is 25 points higher. This advantage is based on 1.9 bits higher color depth, 1.7 EV in additional dynamic range, and 2.1 stops in additional low light sensitivity. The table below summarizes the physical sensor characteristics and sensor quality findings and compares them across a set of similar cameras.

Sensor Characteristics

		Camera Model	Sensor Class	Resolution (MP)	Horiz. Pixels	Vert. Pixels	Video Format	DXO Portrait	DXO Landscape	DXO Sports	DXO Overall
1.		Nikon D3	Full Frame	12.1	4256	2832	none	23.5	12.2	2290	81
2.		Olympus E-5	Four Thirds	12.2	4032	3024	720/30p	21.6	10.5	519	56
3.		Canon 1D Mark III	APS-H	10.1	3888	2592	none	22.7	11.7	1078	71
4.		Nikon D2X	APS-C	12.2	4288	2848	none	22.1	10.9	476	59
5.		Nikon D2Xs	APS-C	12.2	4288	2848	none	22.2	10.9	489	59
6.		Nikon D3S	Full Frame	12.1	4256	2832	720/24p	23.5	12.0	3253	82
7.		Nikon D3X	Full Frame	24.4	6048	4032	none	24.7	13.7	1992	88
8.		Nikon D4	Full Frame	16.2	4928	3280	1080/30p	24.7	13.1	2965	89
9.		Nikon D4S	Full Frame	16.2	4928	3280	1080/60p	24.4	13.3	3074	89
10.		Nikon D5	Full Frame	20.7	5588	3712	4K/30p	25.1	12.3	2343	88
11.		Nikon D300	APS-C	12.2	4288	2848	none	22.1	12.0	679	67
12.		Nikon D700	Full Frame	12.1	4256	2832	none	23.5	12.2	2303	80
13.		Olympus E-1	Four Thirds	4.9	2560	1920	none	20.0	9.7	-145	44
14.		Olympus E-3	Four Thirds	10.0	3648	2736	none	21.6	10.5	571	56
15.		Olympus E-30	Four Thirds	12.2	4032	3024	none	21.3	10.4	530	55
16.		Olympus E-510	Four Thirds	10.0	3648	2736	none	21.2	10.0	442	52
17.		Olympus E-520	Four Thirds	10.0	3648	2736	none	21.4	10.4	548	55
Note: DXO values in italics represent estimates based on sensor size and age.

Many modern cameras are not only capable of taking still images, but also of capturing video footage. The E-5 indeed provides for movie recording, while the D3 does not. The highest resolution format that the E-5 can use is 720/30p.

Feature comparison

Apart from body and sensor, cameras can and do differ across a range of features. The D3 and the E-5 are similar in the sense that both have an optical viewfinder. The latter is useful for getting a clear image for framing even in brightly lit environments. The viewfinders of both cameras offer the same field of view (100%), but the viewfinder of the D3 has a higher magnification than the one of the E-5 (0.70x vs 0.58x), so that the size of the image transmitted appears closer to the size seen with the naked human eye. The following table reports on some other key feature differences and similarities of the Nikon D3, the Olympus E-5, and comparable cameras.

Core Features

		Camera Model	Viewfinder (Type or 000 dots)	Control Panel (yes/no)	LCD Specifications (inch/000 dots)	LCD Attach- ment	Touch Screen (yes/no)	Max Shutter Speed *	Max Shutter Flaps *	Built-in Flash (yes/no)	Built-in Image Stab
1.		Nikon D3	optical	Y	3.0 / 922	fixed	n	1/8000s	11.0/s	n	n
2.		Olympus E-5	optical	Y	3.0 / 920	swivel	n	1/8000s	5.0/s	Y	Y
3.		Canon 1D Mark III	optical	Y	3.0 / 230	fixed	n	1/8000s	10.0/s	n	n
4.		Nikon D2X	optical	Y	2.5 / 235	fixed	n	1/8000s	5.0/s	n	n
5.		Nikon D2Xs	optical	Y	2.5 / 230	fixed	n	1/8000s	5.0/s	n	n
6.		Nikon D3S	optical	Y	3.0 / 921	fixed	n	1/8000s	11.0/s	n	n
7.		Nikon D3X	optical	Y	3.0 / 922	fixed	n	1/8000s	5.0/s	n	n
8.		Nikon D4	optical	Y	3.2 / 921	fixed	n	1/8000s	11.0/s	n	n
9.		Nikon D4S	optical	Y	3.2 / 921	fixed	n	1/8000s	11.0/s	n	n
10.		Nikon D5	optical	Y	3.2 / 2359	fixed	Y	1/8000s	14.0/s	n	n
11.		Nikon D300	optical	Y	3.0 / 922	fixed	n	1/8000s	6.0/s	Y	n
12.		Nikon D700	optical	Y	3.0 / 922	fixed	n	1/8000s	8.0/s	Y	n
13.		Olympus E-1	optical	Y	1.8 / 134	fixed	n	1/4000s	3.0/s	n	n
14.		Olympus E-3	optical	Y	2.5 / 230	swivel	n	1/8000s	5.0/s	Y	Y
15.		Olympus E-30	optical	Y	2.7 / 230	swivel	n	1/8000s	5.0/s	Y	Y
16.		Olympus E-510	optical	n	2.5 / 215	fixed	n	1/4000s	3.0/s	Y	Y
17.		Olympus E-520	optical	n	2.7 / 215	fixed	n	1/4000s	3.5/s	Y	Y
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one.

One feature that differentiates the E-5 and the D3 is in-body image stabilization (IBIS). The E-5 reduces the risk of handshake-induced blur with all attached lenses, while the D3 offers no blur reduction with lenses that themselves do not provide optical image stabilization.

The Nikon D3 has an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.

The D3 writes its imaging data to Compact Flash cards, while the E-5 uses Compact Flash or xD Picture cards. Both cameras feature dual card slots, which can be very useful in case a memory card fails.

Connectivity comparison

For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Nikon D3 and Olympus E-5 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.

Input-Output Connections

		Camera Model	Hotshoe Port	Internal Mic / Speaker	Microphone Port	Headphone Port	HDMI Port	USB Port	WiFi Support	NFC Support	Bluetooth Support
1.		Nikon D3	Y	- / -	-	-	mini	2.0	-	-	-
2.		Olympus E-5	Y	stereo / -	-	-	mini	2.0	-	-	-
3.		Canon 1D Mark III	Y	- / -	-	-	-	2.0	-	-	-
4.		Nikon D2X	Y	- / -	-	-	-	2.0	-	-	-
5.		Nikon D2Xs	Y	- / -	-	-	-	2.0	-	-	-
6.		Nikon D3S	Y	stereo / -	-	-	mini	2.0	-	-	-
7.		Nikon D3X	Y	- / -	-	-	mini	2.0	-	-	-
8.		Nikon D4	Y	mono / mono	Y	Y	micro	2.0	-	-	-
9.		Nikon D4S	Y	mono / mono	Y	Y	mini	2.0	-	-	-
10.		Nikon D5	Y	stereo / mono	Y	Y	mini	3.0	-	-	-
11.		Nikon D300	Y	- / -	-	-	mini	2.0	-	-	-
12.		Nikon D700	Y	- / -	-	-	mini	2.0	-	-	-
13.		Olympus E-1	Y	- / -	-	-	-	2.0	-	-	-
14.		Olympus E-3	Y	- / -	-	-	-	2.0	-	-	-
15.		Olympus E-30	Y	- / -	-	-	-	2.0	-	-	-
16.		Olympus E-510	Y	- / -	-	-	-	2.0	-	-	-
17.		Olympus E-520	Y	- / -	-	-	-	2.0	-	-	-

Both cameras feature a PC Sync terminal to control professional strobe lights, which will be appreciated by studio photographers.

Both the D3 and the E-5 have been discontinued, but can regularly be found used on ebay. The D3 was replaced by the Nikon D4, while the E-5 does not have a direct successor. Further information on the features and operation of the D3 and E-5 can be found, respectively, in the Nikon D3 Manual (free pdf) or the online Olympus E-5 Manual.

Review summary

So what is the bottom line? Is there a clear favorite between the Nikon D3 and the Olympus E-5? Which camera is better? The listing below highlights the relative strengths of the two models.

Arguments in favor of the Nikon D3:

• Better image quality: Scores substantially higher (25 points) in the DXO overall assessment.
• Richer colors: Generates images with noticeably better colors (1.9 bits more color depth).
• More dynamic range: Captures a larger spectrum of light and dark details (1.7 EV of extra DR).
• Better low-light sensitivity: Requires less light for good images (2.1 stops ISO advantage).
• Larger viewfinder image: Features a viewfinder with a higher magnification (0.70x vs 0.58x).
• Faster burst: Shoots at higher frequency (11 vs 5 flaps/sec) to capture the decisive moment.
• Easier time-lapse photography: Has an intervalometer built-in for low frequency shooting.
• More portrait friendly: Features an integrated vertical grip for easier portrait shooting.
• Longer lasting: Can take more shots (4300 versus 750) on a single battery charge.
• More heavily discounted: Has been available for much longer (launched in August 2007).

Reasons to prefer the Olympus E-5:

• Broader imaging potential: Can capture not only stills but also 720/30p video.
• More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
• More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
• More compact: Is smaller (142x117mm vs 160x157mm) and will fit more readily into a bag.
• Less heavy: Has a lower weight (by 427g or 33 percent) and is thus easier to take along.
• Sharper images: Has stabilization technology built-in to reduce the impact of hand-shake.
• Easier fill-in: Has a small integrated flash to brighten shadows of backlit subjects.
• More affordable: Was introduced into a lower priced category (66 percent cheaper at launch).
• More modern: Reflects 3 years of technical progress since the D3 launch.

If the count of relative strengths (bullet points above) is taken as a measure, the D3 comes out slightly ahead of the E-5 (10 : 9 points). However, the relative importance of the various individual camera aspects will vary according to personal preferences and needs, so that you might like to apply corresponding weights to the particular features before making a decision on a new camera. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.

How about other alternatives? Do the specifications of the Nikon D3 and the Olympus E-5 place the cameras among the top in their class? Find out in the latest Best DSLR Camera listing whether the two cameras rank among the cream of the crop.

In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it remains partial and cannot reveal, for example, the shooting experience and imaging performance when actually working with the D3 or the E-5. At times, user reviews, such as those published at amazon, address these issues in a useful manner, but such feedback is on many occasions incomplete, inconsistent, and unreliable.

Expert reviews

This is where reviews by experts come in. The table below provides a synthesis of the camera assessments of some of the best known photo-gear review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.

Expert Camera Reviews

		Camera   Model	AP   score	CL   score	DCW   score	DPR   score	EPZ   score	PB   score	Camera Launch	Launch Price	Street Price
1.		Nikon D3	..	..	..	+ +	5/5	4.5/5	Aug 2007	US$ 4 999	ebay.com
2.		Olympus E-5	4/5	..	..	75/100	4/5	4.5/5	Sep 2010	US$ 1 699	ebay.com
3.		Canon 1D Mark III	..	..	..	..	..	..	Feb 2007	US$ 4 499	ebay.com
4.		Nikon D2X	..	..	..	+ +	..	..	Sep 2004	US$ 4 999	ebay.com
5.		Nikon D2Xs	..	..	..	..	..	..	Jun 2006	US$ 4 699	ebay.com
6.		Nikon D3S	5/5	..	..	89/100	4.5/5	5/5	Oct 2009	US$ 5 199	ebay.com
7.		Nikon D3X	..	..	..	86/100	4/5	5/5	Dec 2008	US$ 7 999	ebay.com
8.		Nikon D4	..	..	..	..	4.5/5	4.5/5	Jan 2012	US$ 5 999	ebay.com
9.		Nikon D4S	5/5	..	..	..	4.5/5	4.5/5	Feb 2014	US$ 6 499	ebay.com
10.		Nikon D5	..	..	4/5	89/100	4.5/5	5/5	Jan 2016	US$ 6 499	ebay.com
11.		Nikon D300	..	+ +	..	+ +	5/5	4.5/5	Aug 2007	US$ 1 799	ebay.com
12.		Nikon D700	..	89/100	..	+ +	4.5/5	4.5/5	Jul 2008	US$ 2 999	ebay.com
13.		Olympus E-1	..	..	..	+	o	..	Jun 2003	US$ 1 699	ebay.com
14.		Olympus E-3	..	88/100	..	+ +	o	4/5	Oct 2007	US$ 1 699	ebay.com
15.		Olympus E-30	..	..	..	71/100	4.5/5	4/5	Nov 2008	US$ 1 299	ebay.com
16.		Olympus E-510	..	89/100	..	+ +	3.5/5	4.5/5	Mar 2007	US$ 799	ebay.com
17.		Olympus E-520	..	87/100	..	+ +	4.5/5	4.5/5	May 2008	US$ 699	ebay.com
Note: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.

The review scores listed above should be treated with care, though. The ratings are only valid when referring to cameras in the same category and of the same age. Thus, a score needs to be put into the context of the launch date and the launch price of the camera, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, kindly note that some of the listed sites have over time developped their review approaches and their reporting style.
