Olympus E-M10 II vs Zeiss ZX1
The Olympus OM-D E-M10 Mark II and the Zeiss ZX1 are two digital cameras that were officially introduced, respectively, in August 2015 and September 2018. The E-M10 II is a mirrorless interchangeable lens camera, while the ZX1 is a fixed lens compact. The cameras are based on a Four Thirds (E-M10 II) and a full frame (ZX1) sensor. The Olympus has a resolution of 15.9 megapixels, whereas the Zeiss provides 37.4 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
Going beyond this snapshot of core features and characteristics, what are the differences between the Olympus OM-D E-M10 Mark II and the Zeiss ZX1? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
The physical size and weight of the Olympus E-M10 II and the Zeiss ZX1 are illustrated in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive views from the front, the top, and the rear side are shown. All width, height and depth dimensions are rounded to the nearest millimeter.
The E-M10 II can be obtained in three different colors (black, silver, brown), while the ZX1 is only available in black.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Zeiss ZX1 is notably larger (33 percent) than the Olympus E-M10 II. In this context, it is worth noting that neither the E-M10 II nor the ZX1 are weather-sealed.
The above size and weight comparisons are to some extent incomplete and possibly misleading, as the ZX1 has a lens built in, whereas the E-M10 II is an interchangeable lens camera that requires a separate lens. Attaching the latter will add extra weight and bulk to the setup. You can compare the optics available for the E-M10 II and their specifications in the Micro Four Thirds Lens Catalog.
The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you would like to visualize and compare a different camera combination, just use the right or left arrows in the table to switch to the respective camera. Alternatively, you can also navigate to the CAM-parator app and make your selection from the full list of cameras there.
|Olympus E-M10 II||4.7 in||3.3 in||1.9 in||13.8 oz||320||n||Aug 2015||649|
|Zeiss ZX1||5.6 in||3.7 in||1.8 in||28.2 oz||250||n||Sep 2018||5,999|
|Leica Q2||5.1 in||3.1 in||3.6 in||25.3 oz||370||Y||Mar 2019||4,995|
|Leica M10||5.5 in||3.1 in||1.5 in||23.3 oz||210||Y||Jan 2017||6,595|
|Leica Q Typ 116||5.1 in||3.1 in||3.7 in||22.6 oz||300||n||Jun 2015||4,249|
|Olympus E-PL9||4.6 in||2.7 in||1.5 in||13.4 oz||350||n||Feb 2018||599|
|Olympus E-M10 III||4.8 in||3.3 in||2.0 in||14.5 oz||330||n||Aug 2017||649|
|Olympus E-PL8||4.5 in||2.6 in||1.5 in||12.6 oz||350||n||Sep 2016||549|
|Olympus PEN-F||4.9 in||2.8 in||1.5 in||15.1 oz||330||n||Jan 2016||1,199|
|Olympus E-M10||4.7 in||3.2 in||1.8 in||14.0 oz||320||n||Jan 2014||699|
|Olympus E-PL7||4.5 in||2.6 in||1.5 in||12.6 oz||350||n||Aug 2014||599|
|Olympus E-P5||4.8 in||2.7 in||1.5 in||14.8 oz||330||n||May 2013||999|
|Olympus E-PL6||4.4 in||2.5 in||1.5 in||11.5 oz||360||n||May 2013||599|
|Olympus E-PL5||4.4 in||2.5 in||1.5 in||11.5 oz||360||n||Sep 2012||599|
|Panasonic GX85||4.8 in||2.8 in||1.7 in||15.0 oz||290||n||Apr 2016||799|
|Panasonic FZ1000||5.4 in||3.9 in||5.2 in||29.3 oz||360||n||Jun 2014||899|
|Sony RX1R II||4.4 in||2.6 in||2.8 in||17.9 oz||220||n||Oct 2015||3,299|
Notes: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
(1) Number of images that can be taken on a full battery charge according to the CIPA-standard; (2) Official announcement.
Any camera decision will obviously take relative prices into account. The listed launch prices provide an indication of the market segment that the manufacturer of the cameras have been targeting. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.
The imaging sensor is at the core of digital cameras and its size is one of the main determining factors of image quality. A large sensor will tend to have larger individual pixels that provide better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixel-units in a sensor of the same technological generation. Further, a large sensor camera will give the photographer additional creative options when using shallow depth-of-field to isolate a subject from its background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.
Of the two cameras under consideration, the Olympus E-M10 II features a Four Thirds sensor and the Zeiss ZX1 a full frame sensor. The sensor area in the ZX1 is 284 percent bigger. As a result of these sensor size differences, the cameras have a format factor of, respectively, 2.0 and 1.0. The sensor in the E-M10 II has a native 4:3 aspect ratio, while the one in the ZX1 offers a 3:2 aspect.
With 37.4MP, the ZX1 offers a higher resolution than the E-M10 II (15.9MP), but the ZX1 nevertheless has larger individual pixels (pixel pitch of 4.81μm versus 3.76μm for the E-M10 II) due to its larger sensor. Moreover, the ZX1 is a much more recent model (by 3 years and 1 month) than the E-M10 II, and its sensor will have benefitted from technological advances during this time that further enhance the light gathering capacity of its pixel-units. Coming back to sensor resolution, it should be mentioned that the E-M10 II has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.
The resolution advantage of the Zeiss ZX1 implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the ZX1 for good quality output (200 dots per inch) amounts to 37.4 x 25 inches or 95.1 x 63.4 cm, for very good quality (250 dpi) 30 x 20 inches or 76.1 x 50.7 cm, and for excellent quality (300 dpi) 25 x 16.6 inches or 63.4 x 42.3 cm. The corresponding values for the Olympus E-M10 II are 23 x 17.3 inches or 58.5 x 43.9 cm for good quality, 18.4 x 13.8 inches or 46.8 x 35.1 cm for very good quality, and 15.4 x 11.5 inches or 39 x 29.3 cm for excellent quality prints.
The Olympus OM-D E-M10 Mark II has a native sensitivity range from ISO 200 to ISO 25600, which can be extended to ISO 100-25600. The corresponding ISO settings for the Zeiss ZX1 are ISO 80 to ISO 51200 (no boost).
Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service assesses and scores the color depth ("DXO Portrait"), dynamic range ("DXO Landscape"), and low-light sensitivity ("DXO Sports") of camera sensors, and also publishes an overall camera score. The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.
|Olympus E-M10 II||Four Thirds||15.9||4608||3456||1080/60p||23.1||12.5||842||73|
|Zeiss ZX1||Full Frame||37.4||7488||4992||4K/30p||..||..||..||..|
|Leica Q2||Full Frame||46.7||8368||5584||4K/30p||26.4||13.5||2491||96|
|Leica M10||Full Frame||23.8||5952||3992||none||24.4||13.2||2133||86|
|Leica Q Typ 116||Full Frame||24.0||6000||4000||1080/60p||24.3||12.7||2221||85|
|Olympus E-PL9||Four Thirds||15.9||4608||3456||4K/30p||..||..||..||..|
|Olympus E-M10 III||Four Thirds||15.9||4608||3456||4K/30p||..||..||..||..|
|Olympus E-PL8||Four Thirds||15.9||4608||3456||1080/30p||..||..||..||..|
|Olympus PEN-F||Four Thirds||20.2||5184||3888||1080/60p||23.1||12.4||894||74|
|Olympus E-M10||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.3||884||72|
|Olympus E-PL7||Four Thirds||15.9||4608||3456||1080/30p||22.7||12.4||873||72|
|Olympus E-P5||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.4||895||72|
|Olympus E-PL6||Four Thirds||15.9||4608||3456||1080/30p||..||..||..||..|
|Olympus E-PL5||Four Thirds||15.9||4608||3456||1080/30p||22.8||12.3||889||72|
|Panasonic GX85||Four Thirds||15.8||4592||3448||4K/30p||22.9||12.6||662||71|
|Sony RX1R II||Full Frame||42.2||7952||5304||1080/60p||25.8||13.9||3204||97|
Many modern cameras cannot only take still pictures, but also record videos. Both cameras under consideration are equipped with sensors that have a sufficiently high read-out speed for moving images, but the ZX1 provides a better video resolution than the E-M10 II. It can shoot movie footage at 4K/30p, while the Olympus is limited to 1080/60p.
Beyond body and sensor, cameras can and do differ across a range of features. The two cameras under review are similar with respect to both having an electronic viewfinder. However, the one in the ZX1 offers a substantially higher resolution than the one in the E-M10 II (6221k vs 2360k dots). The adjacent table lists some of the other core features of the Olympus E-M10 II and Zeiss ZX1 along with similar information for a selection of comparators.
|Olympus E-M10 II||2360||n||3.0||1040||tilting||Y||1/4000s||8.0||Y||Y|
|Leica Q Typ 116||3680||n||3.0||1040||fixed||Y||1/2000s||10.0||n||Y|
|Olympus E-M10 III||2360||n||3.0||1040||tilting||Y||1/4000s||8.6||Y||Y|
|Sony RX1R II||2360||n||3.0||1229||tilting||n||1/4000s||5.0||n||n|
One difference between the cameras concerns the presence of an on-board flash. The E-M10 II has one, while the ZX1 does not. While the built-in flash of the E-M10 II is not very powerful, it can at times be useful as a fill-in light.
The reported shutter speed information refers to the use of the mechanical shutter. Yet, some cameras only have an electronic shutter, while others have an electronic shutter in addition to a mechanical one. In fact, both cameras under consideration feature an electronic shutter, which makes completely silent shooting possible. However, this mode is less suitable for photographing moving objects (risk of rolling shutter) or shooting under artificial light sources (risk of flickering).
The Olympus E-M10 II has an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.
The E-M10 II writes its imaging data to SDXC cards, while the ZX1 uses an internal SSD.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Olympus OM-D E-M10 Mark II and Zeiss ZX1 and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
| WiFi |
|Olympus E-M10 II||Y||stereo||mono||-||-||micro||2.0||Y||-||-|
|Leica Q Typ 116||Y||stereo||mono||-||-||micro||2.0||Y||Y||-|
|Olympus E-M10 III||Y||stereo||mono||-||-||micro||2.0||Y||-||-|
|Sony RX1R II||Y||stereo||mono||Y||-||micro||2.0||Y||Y||-|
The ZX1 is a recent model that features in the current product line-up of Zeiss. In contrast, the E-M10 II has been discontinued (but can be found pre-owned on eBay). As a replacement in the same line of cameras, the E-M10 II was succeeded by the Olympus E-M10 III. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Olympus and Zeiss websites.
So how do things add up? Which of the two cameras – the Olympus E-M10 II or the Zeiss ZX1 – has the upper hand? Is one clearly better than the other? The listing below highlights the relative strengths of the two models.
Arguments in favor of the Olympus OM-D E-M10 Mark II:
- Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
- More flexible LCD: Has a tilting screen for odd-angle shots in landscape orientation.
- Faster shutter: Has higher mechanical shutter speed (1/4000s vs 1/1000s) to freeze action.
- Faster burst: Shoots at higher frequency (8 vs 3 flaps/sec) to capture the decisive moment.
- Easier time-lapse photography: Has an intervalometer built-in for low frequency shooting.
- More flexible: Accepts interchangeable lenses, so that lens characteristics can be altered.
- More compact: Is smaller (120x83mm vs 142x93mm) and thus needs less room in the bag.
- Longer lasting: Can take more shots (320 versus 250) on a single battery charge.
- Sharper images: Has hand-shake reducing image stabilization built-in.
- Easier fill-in: Is equipped with a small onboard flash to brighten deep shadow areas.
Advantages of the Zeiss ZX1:
- More detail: Has more megapixels (37.4 vs 15.9MP), which boosts linear resolution by 56%.
- Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
- Better image quality: Is equipped with a larger and more technologically advanced sensor.
- Richer colors: The sensor size advantage translates into images with better, more accurate colors.
- More dynamic range: Larger sensor captures a wider spectrum of light and dark details.
- Better low-light sensitivity: Larger sensor produces good images even in poorly lit environments.
- Better video: Provides higher definition movie capture (4K/30p vs 1080/60p).
- More detailed viewfinder: Has higher resolution electronic viewfinder (6221k vs 2360k dots).
- Larger viewfinder image: Features a viewfinder with a higher magnification (0.74x vs 0.62x).
- Larger screen: Has a bigger rear LCD (4.3" vs 3.0") for image review and settings control.
- More detailed LCD: Has a higher resolution rear screen (2765k vs 1040k dots).
- Ready to shoot: Has an integrated lens, whereas the E-M10 II necessitates an extra lens.
- Faster data transfer: Supports a more advanced USB protocol (3.1 vs 2.0).
- Easier device pairing: Supports NFC for fast wireless image transfer over short distances.
- Easier wireless transfer: Supports Bluetooth for image sharing without cables.
- More prestigious: Has the Zeiss luxury appeal, which ensures a high resale value.
If the number of relative strengths (bullet points above) is taken as a guide, the ZX1 is the clear winner of the contest (16 : 10 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional wedding photographer will view the differences between cameras in a way that diverges from the perspective of a travel photog, and a person interested in cityscapes has distinct needs from a macro shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Olympus E-M10 II and the Zeiss ZX1 place the cameras among the top in their class? Find out in the latest Best Mirrorless Interchangeable Lens Camera and Best Prime Lens Compact Camera listings whether the two cameras rank among the cream of the crop.
In any case, while the comparison of technical specifications can provide a useful overview of the capabilities of different cameras, it remains partial and cannot reveal, for example, the shooting experience and imaging performance when actually working with the E-M10 II or the ZX1. At times, user reviews, such as those published at amazon, address these issues in a useful manner, but such feedback is on many occasions incomplete, inconsistent, and unreliable.
This is why expert reviews are important. The adjacent summary-table relays the overall verdicts of several of the most popular camera review sites (cameralabs, dpreview, ephotozine, imaging-resource, and photographyblog). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|Olympus E-M10 II||+ +||80/100||5/5||5/5||5/5||Aug 2015||649|
|Zeiss ZX1||..||..||..||..||..||Sep 2018||5,999|
|Leica Q2||..||84/100||4.5/5||..||4/5||Mar 2019||4,995|
|Leica M10||..||..||4/5||..||4.5/5||Jan 2017||6,595|
|Leica Q Typ 116||..||80/100||4.5/5||..||4.5/5||Jun 2015||4,249|
|Olympus E-PL9||+||..||4.5/5||4.5/5||4/5||Feb 2018||599|
|Olympus E-M10 III||+||80/100||4.5/5||4/5||4.5/5||Aug 2017||649|
|Olympus E-PL8||..||..||4.5/5||..||4/5||Sep 2016||549|
|Olympus PEN-F||..||82/100||4.5/5||4.5/5||5/5||Jan 2016||1,199|
|Olympus E-M10||..||80/100||5/5||4.5/5||5/5||Jan 2014||699|
|Olympus E-PL7||+||..||5/5||4.5/5||4/5||Aug 2014||599|
|Olympus E-P5||+ +||78/100||4.5/5||4.5/5||5/5||May 2013||999|
|Olympus E-PL6||..||..||..||..||..||May 2013||599|
|Olympus E-PL5||+ +||..||4.5/5||4.5/5||4.5/5||Sep 2012||599|
|Panasonic GX85||+ +||82/100||5/5||4.5/5||5/5||Apr 2016||799|
|Panasonic FZ1000||+ +||82/100||4.5/5||4.5/5||4.5/5||Jun 2014||899|
|Sony RX1R II||..||82/100||..||o||4.5/5||Oct 2015||3,299|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.|
The review scores listed above should be treated with care, though. The ratings are only valid when referring to cameras in the same category and of the same age. Thus, a score needs to be put into the context of the launch date and the launch price of the camera, and comparisons of ratings among very different cameras or across long time periods have little meaning. Also, please note that some of the review sites have changed their methodology and reporting over time.
Other camera comparisons
Did this review help to inform your camera decision process? In case you would like to check on the differences and similarities of other camera models, just use the search menu below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.
- Canon 1D Mark IV vs Zeiss ZX1
- Canon G1 X Mark II vs Zeiss ZX1
- Fujifilm XP130 vs Zeiss ZX1
- Hasselblad X1D vs Olympus E-M10 II
- Leica D-LUX 7 vs Olympus E-M10 II
- Nikon D500 vs Olympus E-M10 II
- Nikon D7500 vs Olympus E-M10 II
- Olympus E-M10 II vs Panasonic GH1
- Olympus E-M10 II vs Panasonic GH2
- Panasonic G10 vs Zeiss ZX1
- Panasonic GX8 vs Zeiss ZX1
Specifications: Olympus E-M10 II vs Zeiss ZX1
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Olympus E-M10 II||Zeiss ZX1|
|Camera Type||Mirrorless system camera||Fixed lens compact camera|
|Camera Lens||Micro Four Thirds lenses||35mm f/2.8|
|Launch Date||August 2015||September 2018|
|Launch Price||USD 649||USD 5,999|
|Sensor Specs||Olympus E-M10 II||Zeiss ZX1|
|Sensor Format||Four Thirds Sensor||Full Frame Sensor|
|Sensor Size||17.3 x 13.0 mm||36.0 x 24.0 mm|
|Sensor Area||224.9 mm2||864 mm2|
|Sensor Diagonal||21.6 mm||43.3 mm|
|Sensor Resolution||15.9 Megapixels||37.4 Megapixels|
|Image Resolution||4608 x 3456 pixels||7488 x 4992 pixels|
|Pixel Pitch||3.76 μm||4.81 μm|
|Pixel Density||7.08 MP/cm2||4.33 MP/cm2|
|Moiré control||no AA filter||Anti-Alias filter|
|Movie Capability||1080/60p Video||4K/30p Video|
|ISO Setting||200 - 25,600 ISO||80 - 51,200 ISO|
|ISO Boost||100 - 25,600 ISO||no Enhancement|
|DXO Sensor Quality (score)||73||..|
|DXO Color Depth (bits)||23.1||..|
|DXO Dynamic Range (EV)||12.5||..|
|DXO Low Light (ISO)||842||..|
|Screen Specs||Olympus E-M10 II||Zeiss ZX1|
|Viewfinder Type||Electronic viewfinder||Electronic viewfinder|
|Viewfinder Field of View||100%||100%|
|Viewfinder Resolution||2360k dots||6221k dots|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0inch||4.3inch|
|LCD Resolution||1040k dots||2765k dots|
|LCD Attachment||Tilting screen||Fixed screen|
|Shooting Specs||Olympus E-M10 II||Zeiss ZX1|
|Focus System||Contrast-detect AF||Contrast-detect AF|
|Manual Focusing Aid||Focus Peaking||no Peaking Feature|
|Continuous Shooting||8 shutter flaps/s||3 shutter flaps/s|
|Electronic Shutter||up to 1/16000s||up to 1/8000s|
|Time-Lapse Photography||Intervalometer built-in||no Intervalometer|
|Image Stabilization||In-body stabilization||no handshake reduction|
|Fill Flash||Build-in Flash||no On-Board Flash|
|Storage Medium||SDXC cards||Internal SSD|
|Second Storage Option||Single card slot||Single SSD|
|Connectivity Specs||Olympus E-M10 II||Zeiss ZX1|
|USB Connector||USB 2.0||USB 3.1|
|HDMI Port||micro HDMI||no HDMI|
|Wifi Support||Wifi built-in||Wifi built-in|
|Near-Field Communication||no NFC||NFC built-in|
|Bluetooth Support||no Bluetooth||Bluetooth built-in|
|Body Specs||Olympus E-M10 II||Zeiss ZX1|
|Battery Life (CIPA)||320 shots per charge||250 shots per charge|
120 x 83 x 47 mm
(4.7 x 3.3 x 1.9 in)
142 x 93 x 46 mm
(5.6 x 3.7 x 1.8 in)
|Camera Weight||390 g (13.8 oz)||800 g (28.2 oz)|
