Fujifilm X-T20 vs Olympus E-M10 III

The Fujifilm X-T20 and the Olympus OM-D E-M10 Mark III are two digital cameras that were officially introduced, respectively, in January 2017 and August 2017. Both the X-T20 and the E-M10 III are mirrorless interchangeable lens cameras that are based on an APS-C (X-T20) and a Four Thirds (E-M10 III) sensor. The Fujifilm has a resolution of 24 megapixels, whereas the Olympus provides 15.9 MP.

Below is an overview of the main specs of the two cameras as a starting point for the comparison.

Headline Specifications

Fujifilm X-T20		Olympus E-M10 III
Mirrorless system camera		Mirrorless system camera
Fujifilm X mount lenses		Micro Four Thirds lenses
24 MP – APS-C sensor		15.9 MP – Four Thirds sensor
4K/30p Video		4K/30p Video
ISO 200-12,800 (100 - 51,200)		ISO 200-25,600
Electronic viewfinder (2360k dots)		Electronic viewfinder (2360k dots)
3.0" LCD – 1040k dots		3.0" LCD – 1040k dots
Tilting touchscreen		Tilting touchscreen
8 shutter flaps per second		8.6 shutter flaps per second
Lens stabilization only		In-body stabilization
350 shots per battery charge		330 shots per battery charge
118 x 83 x 41 mm, 383 g		122 x 84 x 50 mm, 410 g

Check X-T20 offers at
ebay.com
Check E-M10 III offers at
ebay.com

Going beyond this snapshot of core features and characteristics, what are the differences between the Fujifilm X-T20 and the Olympus OM-D E-M10 Mark III? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.

Body comparison

An illustration of the physical size and weight of the Fujifilm X-T20 and the Olympus E-M10 III is provided in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive views from the front, the top, and the rear side are shown. All width, height and depth dimensions are rounded to the nearest millimeter.

Both cameras are available in two different colors (black, silver).

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Olympus E-M10 III is somewhat larger (5 percent) than the Fujifilm X-T20. Moreover, the E-M10 III is markedly heavier (7 percent) than the X-T20. In this context, it is worth noting that neither the X-T20 nor the E-M10 III are weather-sealed.

The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. A larger imaging sensor will tend to go along with bigger and heavier lenses, although exceptions exist. You can compare the optics available for the two cameras in the Fujinon X Lens Catalog (X-T20) and the Micro Four Thirds Lens Catalog (E-M10 III). Mirrorless cameras, such as the two under consideration, have the additional advantage of having a short flange to focal plane distance, which makes it possible to mount many lenses from other systems onto the camera via adapters.

Concerning battery life, the X-T20 gets 350 shots out of its Fujifilm NP-W126S battery, while the E-M10 III can take 330 images on a single charge of its Olympus BLS-50 power pack. The power pack in the X-T20 can be charged via the USB port, so that it is not always necessary to take the battery charger along when travelling.

The table below summarizes the key physical specs of the two cameras alongside a broader set of comparators. In case you want to display and compare another camera duo, you can use the CAM-parator app to select your camera combination among a large number of options.

Body Specifications

#		Camera Model	Camera Width	Camera Height	Camera Depth	Camera Weight	Battery Life	Weather Sealing	Camera Launch	Launch Price (USD)	Street Price
1.		Fujifilm X-T20	118 mm	83 mm	41 mm	383 g	350	n	Jan 2017	899	ebay.com
2.		Olympus E-M10 III	122 mm	84 mm	50 mm	410 g	330	n	Aug 2017	649	ebay.com
3.		Fujifilm X-E4	121 mm	73 mm	33 mm	364 g	380	n	Jan 2021	849	amazon.com
4.		Fujifilm X-T30 II	118 mm	83 mm	47 mm	383 g	380	n	Sep 2021	899	amazon.com
5.		Fujifilm X-T30	118 mm	83 mm	47 mm	383 g	380	n	Feb 2019	899	ebay.com
6.		Fujifilm X-A5	117 mm	68 mm	40 mm	361 g	450	n	Jan 2018	399	ebay.com
7.		Fujifilm X-T100	121 mm	83 mm	47 mm	448 g	430	n	May 2018	599	ebay.com
8.		Fujifilm X-E3	121 mm	74 mm	43 mm	337 g	350	n	Sep 2017	899	ebay.com
9.		Fujifilm X70	113 mm	64 mm	44 mm	340 g	330	n	Jan 2016	799	ebay.com
10.		Fujifilm X-A3	117 mm	67 mm	40 mm	339 g	410	n	Aug 2016	399	ebay.com
11.		Fujifilm X-T10	118 mm	83 mm	41 mm	381 g	350	n	May 2015	799	ebay.com
12.		Fujifilm X-E2	129 mm	75 mm	37 mm	350 g	350	n	Oct 2013	999	ebay.com
13.		Olympus E-M10 IV	122 mm	84 mm	49 mm	383 g	360	n	Aug 2020	699	amazon.com
14.		Olympus E-PL10	117 mm	68 mm	39 mm	380 g	350	n	Oct 2019	599	ebay.com
15.		Olympus E-PL9	117 mm	68 mm	39 mm	380 g	350	n	Feb 2018	599	ebay.com
16.		Olympus E-PL8	115 mm	67 mm	38 mm	357 g	350	n	Sep 2016	549	ebay.com
17.		Olympus E-M10 II	120 mm	83 mm	47 mm	390 g	320	n	Aug 2015	649	ebay.com
Note: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
Convert to Imperial

The price is, of course, an important factor in any camera decision. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The E-M10 III was launched at a markedly lower price (by 28 percent) than the X-T20, which puts it into a different market segment. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.

Sensor comparison

The size of the sensor inside a digital camera is one of the key determinants of image quality. A large sensor will tend to have larger individual pixels that provide better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixel-units in a sensor of the same technological generation. Furthermore, a large sensor camera will give the photographer more possibilities to use shallow depth-of-field in order to isolate a subject from the background. On the downside, larger sensors tend to be associated with larger, more expensive camera bodies and lenses.

Of the two cameras under consideration, the Fujifilm X-T20 features an APS-C sensor and the Olympus E-M10 III a Four Thirds sensor. The sensor area in the E-M10 III is 39 percent smaller. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.5 and 2.0. The sensor in the X-T20 has a native 3:2 aspect ratio, while the one in the E-M10 III offers a 4:3 aspect.

With 24MP, the X-T20 offers a higher resolution than the E-M10 III (15.9MP), but the X-T20 nevertheless has larger individual pixels (pixel pitch of 3.92μm versus 3.76μm for the E-M10 III) due to its larger sensor. However, the E-M10 III is a somewhat more recent model (by 7 months) than the X-T20, and its sensor might have benefitted from technological advances during this time that enhance the light gathering capacity of its pixels. Coming back to sensor resolution, it should be mentioned that neither of the two cameras has an anti-alias filter installed, so they are able to capture all the detail the sensor resolves.

The resolution advantage of the Fujifilm X-T20 implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the X-T20 for good quality output (200 dots per inch) amounts to 30 x 20 inches or 76.2 x 50.8 cm, for very good quality (250 dpi) 24 x 16 inches or 61 x 40.6 cm, and for excellent quality (300 dpi) 20 x 13.3 inches or 50.8 x 33.9 cm. The corresponding values for the Olympus E-M10 III are 23 x 17.3 inches or 58.5 x 43.9 cm for good quality, 18.4 x 13.8 inches or 46.8 x 35.1 cm for very good quality, and 15.4 x 11.5 inches or 39 x 29.3 cm for excellent quality prints.

The X-T20 has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.

The Fujifilm X-T20 has a native sensitivity range from ISO 200 to ISO 12800, which can be extended to ISO 100-51200. The corresponding ISO settings for the Olympus OM-D E-M10 Mark III are ISO 200 to ISO 25600, with the possibility to increase the ISO range to 100-25600.

Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors. The X-T20 uses Fujifilm's X-Trans layout of photosites, while the E-M10 III employs the more common Bayer array.

Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). The table below summarizes the physical sensor characteristics and sensor quality findings and compares them across a set of similar cameras.

Sensor Characteristics

#		Camera Model	Sensor Class	Resolution (MP)	Horiz. Pixels	Vert. Pixels	Video Format	DXO Portrait	DXO Landscape	DXO Sports	DXO Overall
1.		Fujifilm X-T20	APS-C	24.0	6000	4000	4K/30p	23.9	13.2	1704	81
2.		Olympus E-M10 III	Four Thirds	15.9	4608	3456	4K/30p	23.1	12.8	1120	74
3.		Fujifilm X-E4	APS-C	26.0	6240	4160	4K/30p	24.2	13.7	2085	85
4.		Fujifilm X-T30 II	APS-C	26.0	6240	4160	4K/30p	24.2	13.8	2144	85
5.		Fujifilm X-T30	APS-C	26.0	6240	4160	4K/30p	24.1	13.5	1895	83
6.		Fujifilm X-A5	APS-C	24.0	6000	4000	4K/15p	24.0	13.3	1800	82
7.		Fujifilm X-T100	APS-C	24.0	6000	4000	4K/15p	24.0	13.4	1829	83
8.		Fujifilm X-E3	APS-C	24.0	6000	4000	4K/30p	23.9	13.3	1764	82
9.		Fujifilm X70	APS-C	16.0	4896	3264	1080/60p	23.7	13.0	1608	80
10.		Fujifilm X-A3	APS-C	24.0	6000	4000	1080/60p	23.8	13.1	1664	81
11.		Fujifilm X-T10	APS-C	16.0	4896	3264	1080/60p	23.7	12.9	1546	79
12.		Fujifilm X-E2	APS-C	16.0	4896	3264	1080/60p	23.4	12.6	1400	77
13.		Olympus E-M10 IV	Four Thirds	20.2	5184	3888	4K/30p	23.3	13.2	1402	76
14.		Olympus E-PL10	Four Thirds	15.9	4608	3456	4K/30p	23.3	13.1	1324	76
15.		Olympus E-PL9	Four Thirds	15.9	4608	3456	4K/30p	23.1	12.8	1162	74
16.		Olympus E-PL8	Four Thirds	15.9	4608	3456	1080/30p	23.0	12.6	1030	73
17.		Olympus E-M10 II	Four Thirds	15.9	4608	3456	1080/60p	23.1	12.5	842	73
Note: DXO values in italics represent estimates based on sensor size and age.

Many modern cameras cannot only take still pictures, but also record videos. The two cameras under consideration both have sensors whose read-out speed is fast enough to capture moving pictures, and both provide the same movie specifications (4K/30p).

Feature comparison

Apart from body and sensor, cameras can and do differ across a range of features. The X-T20 and the E-M10 III are similar in the sense that both feature an electronic viewfinder, which is helpful when framing images in bright sunlight. Moreover, their viewfinders offer an identical resolution of 2360k dots. The adjacent table lists some of the other core features of the Fujifilm X-T20 and Olympus E-M10 III along with similar information for a selection of comparators.

Core Features

#		Camera Model	Viewfinder (Type or 000 dots)	Control Panel (yes/no)	LCD Specifications (inch/000 dots)	LCD Attach- ment	Touch Screen (yes/no)	Max Shutter Speed *	Max Shutter Flaps *	Built-in Flash (yes/no)	Built-in Image Stab
1.		Fujifilm X-T20	2360	n	3.0 / 1040	tilting	Y	1/4000s	8.0/s	Y	n
2.		Olympus E-M10 III	2360	n	3.0 / 1040	tilting	Y	1/4000s	8.6/s	Y	Y
3.		Fujifilm X-E4	2360	n	3.0 / 1620	tilting	Y	1/4000s	8.0/s	n	n
4.		Fujifilm X-T30 II	2360	n	3.0 / 1620	tilting	Y	1/4000s	8.0/s	Y	n
5.		Fujifilm X-T30	2360	n	3.0 / 1040	tilting	Y	1/4000s	8.0/s	Y	n
6.		Fujifilm X-A5	none	n	3.0 / 1040	tilting	Y	1/4000s	6.0/s	Y	n
7.		Fujifilm X-T100	2360	n	3.0 / 1040	swivel	Y	1/4000s	6.0/s	Y	n
8.		Fujifilm X-E3	2360	n	3.0 / 1040	fixed	Y	1/4000s	8.0/s	n	n
9.		Fujifilm X70	optional	n	3.0 / 1040	tilting	Y	1/4000s	8.0/s	Y	n
10.		Fujifilm X-A3	none	n	3.0 / 1040	tilting	Y	1/4000s	6.0/s	Y	n
11.		Fujifilm X-T10	2360	n	3.0 / 920	tilting	n	1/4000s	8.0/s	Y	n
12.		Fujifilm X-E2	2360	n	3.0 / 1040	fixed	n	1/4000s	7.0/s	Y	n
13.		Olympus E-M10 IV	2360	n	3.0 / 1040	tilting	Y	1/4000s	15.0/s	Y	Y
14.		Olympus E-PL10	none	n	3.0 / 1040	tilting	Y	1/4000s	8.6/s	Y	Y
15.		Olympus E-PL9	none	n	3.0 / 1040	tilting	Y	1/4000s	8.6/s	Y	Y
16.		Olympus E-PL8	optional	n	3.0 / 1037	tilting	Y	1/4000s	8.0/s	n	Y
17.		Olympus E-M10 II	2360	n	3.0 / 1040	tilting	Y	1/4000s	8.0/s	Y	Y
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one.

One feature that differentiates the E-M10 III and the X-T20 is in-body image stabilization (IBIS). The E-M10 III reduces the risk of handshake-induced blur with all attached lenses, while the X-T20 offers no blur reduction with lenses that themselves do not provide optical image stabilization.

The reported shutter speed information refers to the use of the mechanical shutter. Yet, some cameras only have an electronic shutter, while others have an electronic shutter in addition to a mechanical one. In fact, both cameras under consideration feature an electronic shutter, which makes completely silent shooting possible. However, this mode is less suitable for photographing moving objects (risk of rolling shutter) or shooting under artificial light sources (risk of flickering).

The Fujifilm X-T20 and the Olympus E-M10 III both have an intervalometer built-in. This enables the photographer to capture time lapse sequences, such as flower blooming, a sunset or moon rise, without purchasing an external camera trigger and related software.

Concerning the storage of imaging data, both the X-T20 and the E-M10 III write their files to SDXC cards. The E-M10 III supports UHS-II cards (Ultra High Speed data transfer of up to 312 MB/s), while the X-T20 can use UHS-I cards (up to 104 MB/s).

Connectivity comparison

For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Fujifilm X-T20 and Olympus OM-D E-M10 Mark III and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.

Input-Output Connections

#		Camera Model	Hotshoe Port	Internal Mic / Speaker	Microphone Port	Headphone Port	HDMI Port	USB Port	WiFi Support	NFC Support	Bluetooth Support
1.		Fujifilm X-T20	Y	stereo / mono	Y	-	micro	2.0	Y	-	-
2.		Olympus E-M10 III	Y	stereo / mono	-	-	micro	2.0	Y	-	-
3.		Fujifilm X-E4	Y	stereo / mono	Y	-	micro	3.2	Y	-	Y
4.		Fujifilm X-T30 II	Y	stereo / mono	Y	-	micro	3.2	Y	-	Y
5.		Fujifilm X-T30	Y	stereo / mono	Y	-	micro	3.1	Y	-	Y
6.		Fujifilm X-A5	Y	stereo / mono	Y	-	micro	2.0	Y	-	Y
7.		Fujifilm X-T100	Y	stereo / mono	Y	-	micro	2.0	Y	-	Y
8.		Fujifilm X-E3	Y	stereo / mono	Y	-	micro	2.0	Y	-	Y
9.		Fujifilm X70	Y	stereo / mono	Y	-	micro	2.0	Y	-	-
10.		Fujifilm X-A3	Y	stereo / mono	-	-	micro	2.0	Y	-	-
11.		Fujifilm X-T10	Y	stereo / mono	Y	-	micro	2.0	Y	-	-
12.		Fujifilm X-E2	Y	stereo / mono	Y	-	micro	2.0	Y	-	-
13.		Olympus E-M10 IV	Y	stereo / mono	-	-	micro	2.0	Y	-	Y
14.		Olympus E-PL10	Y	stereo / mono	-	-	micro	2.0	Y	-	Y
15.		Olympus E-PL9	Y	stereo / mono	-	-	micro	2.0	Y	-	Y
16.		Olympus E-PL8	Y	stereo / mono	-	-	micro	2.0	Y	-	-
17.		Olympus E-M10 II	Y	stereo / mono	-	-	micro	2.0	Y	-	-

It is notable that the X-T20 has a microphone port, which is missing on the E-M10 III. Such an external microphone input can help to substantially improve the quality of audio recordings when a good external microphone is used.

Both the X-T20 and the E-M10 III have been discontinued, but can regularly be found used on ebay. The X-T20 was replaced by the Fujifilm X-T100, while the E-M10 III was followed by the Olympus E-M10 IV. Further information on the features and operation of the X-T20 and E-M10 III can be found, respectively, in the Fujifilm X-T20 Manual (free pdf) or the online Olympus E-M10 III Manual.

Review summary

So what is the bottom line? Which of the two cameras – the Fujifilm X-T20 or the Olympus E-M10 III – has the upper hand? Is one clearly better than the other? The listing below highlights the relative strengths of the two models.

Advantages of the Fujifilm X-T20:

• More detail: Offers more megapixels (24 vs 15.9MP) with a 25% higher linear resolution.
• Better image quality: Features bigger pixels on a larger sensor for higher quality imaging.
• Richer colors: The pixel size advantage translates into images with better, more accurate colors.
• More dynamic range: Larger pixels capture a wider spectrum of light and dark details.
• Better low-light sensitivity: Larger pixels means good image quality even under poor lighting.
• Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
• Better sound: Can connect to an external microphone for higher quality sound recording.
• Easier travel charging: Can be conveniently charged via its USB port.
• More heavily discounted: Has been on the market for longer (launched in January 2017).

Arguments in favor of the Olympus OM-D E-M10 Mark III:

• Sharper images: Has stabilization technology built-in to reduce the impact of hand-shake.
• Faster buffer clearing: Supports a more advanced SD data transfer standard (UHS-II vs UHS-I).
• More affordable: Was introduced into a lower priced category (28 percent cheaper at launch).
• More modern: Was introduced somewhat (7 months) more recently.

If the number of relative strengths (bullet points above) is taken as a guide, the X-T20 is the clear winner of the match-up (9 : 4 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional wedding photographer will view the differences between cameras in a way that diverges from the perspective of a travel photog, and a person interested in cityscapes has distinct needs from a macro shooter. Hence, the decision which camera is best and worth buying is often a very personal one.

How about other alternatives? Do the specifications of the Fujifilm X-T20 and the Olympus E-M10 III place the cameras among the top in their class? Find out in the latest Best Mirrorless Interchangeable Lens Camera listing whether the two cameras rank among the cream of the crop.

In any case, while the comparison of the spec-sheets of cameras can offer a general idea of their imaging potential, it remains partial and cannot reveal, for example, the shooting experience and imaging performance when actually working with the X-T20 or the E-M10 III. At times, user reviews, such as those published at amazon, address these issues in a useful manner, but such feedback is on many occasions incomplete, inconsistent, and unreliable.

Expert reviews

This is where reviews by experts come in. The adjacent summary-table relays the overall verdicts of several of the most popular camera review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.

Expert Camera Reviews

#		Camera   Model	AP   score	CL   score	DCW   score	DPR   score	EPZ   score	PB   score	Camera Launch	Launch Price (USD)	Street Price
1.		Fujifilm X-T20	5/5	+ +	5/5	82/100	5/5	4.5/5	Jan 2017	899	ebay.com
2.		Olympus E-M10 III	..	+	5/5	80/100	4.5/5	4.5/5	Aug 2017	649	ebay.com
3.		Fujifilm X-E4	4/5	..	4/5	..	4.5/5	4/5	Jan 2021	849	amazon.com
4.		Fujifilm X-T30 II	5/5	..	4/5	..	4.5/5	4.5/5	Sep 2021	899	amazon.com
5.		Fujifilm X-T30	5/5	+ +	5/5	84/100	4.5/5	4.5/5	Feb 2019	899	ebay.com
6.		Fujifilm X-A5	..	+	4.1/5	..	4/5	3.5/5	Jan 2018	399	ebay.com
7.		Fujifilm X-T100	4/5	+	4.5/5	79/100	4/5	4.5/5	May 2018	599	ebay.com
8.		Fujifilm X-E3	4.5/5	+	4.5/5	84/100	4.5/5	4.5/5	Sep 2017	899	ebay.com
9.		Fujifilm X70	4.5/5	..	..	76/100	4.5/5	4.5/5	Jan 2016	799	ebay.com
10.		Fujifilm X-A3	..	..	..	74/100	4.5/5	4/5	Aug 2016	399	ebay.com
11.		Fujifilm X-T10	4.5/5	+ +	..	80/100	5/5	5/5	May 2015	799	ebay.com
12.		Fujifilm X-E2	4/5	..	..	80/100	4.5/5	5/5	Oct 2013	999	ebay.com
13.		Olympus E-M10 IV	4.5/5	..	5/5	81/100	4.5/5	4.5/5	Aug 2020	699	amazon.com
14.		Olympus E-PL10	..	..	4/5	77/100	..	4/5	Oct 2019	599	ebay.com
15.		Olympus E-PL9	..	+	..	..	4.5/5	4/5	Feb 2018	599	ebay.com
16.		Olympus E-PL8	..	..	..	..	4.5/5	4/5	Sep 2016	549	ebay.com
17.		Olympus E-M10 II	4.5/5	+ +	..	80/100	5/5	5/5	Aug 2015	649	ebay.com
Note: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.

The above review scores should be interpreted with care, though. The ratings are only valid when referring to cameras in the same category and of the same age. Hence, a score should always be seen in the context of the camera's market launch date and its price, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, please note that some of the review sites have changed their methodology and reporting over time.
