Canon T6i vs XSi

The Canon EOS Rebel T6i (called Canon 750D in some regions) and the Canon EOS Rebel XSi (labelled Canon 450D in some countries) are two digital cameras that were revealed to the public, respectively, in February 2015 and January 2008. Both are DSLR (Digital Single Lens Reflex) cameras that are equipped with an APS-C sensor. The T6i has a resolution of 24 megapixels, whereas the XSi provides 12.2 MP.

As their names suggest, both the Canon EOS Rebel T6i and the Canon EOS Rebel XSi belong to Canon's Rebel line of DSLR cameras. This range of APS-C cameras, which started out with the Canon EOS Digital Rebel in 2003, has been a big commercial success and the backbone of Canon's dominance in the digital camera market. The popularity of the Rebel cameras is the result of them inheriting much of the sensor and shooting technology from earlier released professional DSLRs, while being sold at a much more budget-friendly price point. The strong brand reputation of Canon and the comprehensive EOS system of compatible lenses and accessories further contributes to the appeal of the Rebel cams, including the Canon T6i and Canon XSi. Below is an overview of the main specs of the two cameras as a starting point for the comparison.

Headline Specifications

Canon T6i		Canon XSi
Digital single lens reflex		Digital single lens reflex
Canon EF mount lenses		Canon EF mount lenses
24 MP – APS-C sensor		12.2 MP – APS-C sensor
1080/30p Video		no Video
ISO 100-12,800 (100 - 25,600)		ISO 100-1,600
Optical viewfinder		Optical viewfinder
3.0" LCD – 1040k dots		3.0" LCD – 230k dots
Swivel touchscreen		Fixed screen (not touch-sensitive)
5 shutter flaps per second		3.5 shutter flaps per second
440 shots per battery charge		500 shots per battery charge
132 x 101 x 78 mm, 555 g		129 x 98 x 62 mm, 524 g

Check T6i offers at
ebay.com
Check XSi offers at
ebay.com

Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS Rebel T6i and the Canon EOS Rebel XSi? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.

Body comparison

An illustration of the physical size and weight of the Canon T6i and the Canon XSi is provided in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive views from the front, the top, and the rear side are shown. All width, height and depth measures are rounded to the nearest millimeter.

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Canon XSi is notably smaller (5 percent) than the Canon T6i. Moreover, the XSi is markedly lighter (6 percent) than the T6i. In this context, it is worth noting that neither the T6i nor the XSi are weather-sealed.

The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. In this particular case, both cameras feature the same lens mount, so that they can use the same lenses. You can compare the optics available in the Canon EF Lens Catalog.

Concerning battery life, the T6i gets 440 shots out of its Canon LP-E17 battery, while the XSi can take 500 images on a single charge of its Canon LP-E5 power pack.

The following table provides a synthesis of the main physical specifications of the two cameras and other similar ones. In case you want to display and compare another camera duo, you can use the CAM-parator app to select your camera combination among a large number of options.

Body Specifications

#		Camera Model	Camera Width	Camera Height	Camera Depth	Camera Weight	Battery Life	Weather Sealing	Camera Launch	Launch Price (USD)	Street Price
1.		Canon T6i	132 mm	101 mm	78 mm	555 g	440	n	Feb 2015	749	ebay.com
2.		Canon XSi	129 mm	98 mm	62 mm	524 g	500	n	Jan 2008	799	ebay.com
3.		Canon 77D	131 mm	100 mm	76 mm	540 g	600	n	Feb 2017	899	ebay.com
4.		Canon T7i	131 mm	100 mm	76 mm	532 g	600	n	Feb 2017	749	ebay.com
5.		Canon T6s	132 mm	101 mm	78 mm	565 g	440	n	Feb 2015	649	ebay.com
6.		Canon T5	130 mm	100 mm	78 mm	480 g	500	n	Feb 2014	449	ebay.com
7.		Canon T5i	133 mm	100 mm	79 mm	580 g	440	n	Mar 2013	649	ebay.com
8.		Canon T4i	133 mm	100 mm	79 mm	575 g	440	n	Jun 2012	849	ebay.com
9.		Canon T3	130 mm	100 mm	78 mm	495 g	700	n	Feb 2011	449	ebay.com
10.		Canon T1i	129 mm	98 mm	62 mm	520 g	400	n	Mar 2009	799	ebay.com
11.		Canon 40D	146 mm	108 mm	74 mm	822 g	750	n	Aug 2007	1,299	ebay.com
12.		Canon XTi	127 mm	84 mm	65 mm	556 g	370	n	Aug 2006	799	ebay.com
13.		Canon XT	127 mm	94 mm	64 mm	540 g	400	n	Feb 2005	899	ebay.com
Note: Measurements and pricing do not include easily detachable parts, such as add-on or interchangeable lenses or optional viewfinders.
Convert to Imperial

The price is, of course, an important factor in any camera decision. The listed launch prices provide an indication of the market segment that the manufacturer of the cameras have been targeting. The T6i was somewhat cheaper (by 6 percent) than the XSi at launch, but both cameras fall into the same price category. Normally, street prices remain initially close to the MSRP, but after a couple of months, the first discounts appear. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.

Sensor comparison

The size of the imaging sensor is a crucial determinant of image quality. A large sensor will generally have larger individual pixels that offer better low-light sensitivity, provide wider dynamic range, and have richer color-depth than smaller pixels in a sensor of the same technological generation. Moreover, a large sensor camera will give the photographer more control over depth-of-field in the image and, thus, the ability to better isolate a subject from the background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.

Both cameras under consideration feature an APS-C sensor, but their sensors differ slightly in size. The sensor area in the XSi is 1 percent smaller. They nevertheless have the same format factor of 1.6. Both cameras have a native aspect ratio (sensor width to sensor height) of 3:2.

In terms of chip-set technology, the T6i uses a more advanced image processing engine (DIGIC 6) than the XSi (DIGIC 3), with benefits for noise reduction, color accuracy, and processing speed.

With 24MP, the T6i offers a higher resolution than the XSi (12.2MP), but the T6i has smaller individual pixels (pixel pitch of 3.72μm versus 5.19μm for the XSi). However, the T6i is a much more recent model (by 7 years) than the XSi, and its sensor will have benefitted from technological advances during this time that enhance the light gathering capacity of its pixels.

The resolution advantage of the Canon T6i implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the T6i for good quality output (200 dots per inch) amounts to 30 x 20 inches or 76.2 x 50.8 cm, for very good quality (250 dpi) 24 x 16 inches or 61 x 40.6 cm, and for excellent quality (300 dpi) 20 x 13.3 inches or 50.8 x 33.9 cm. The corresponding values for the Canon XSi are 21.4 x 14.2 inches or 54.3 x 36.2 cm for good quality, 17.1 x 11.4 inches or 43.4 x 28.9 cm for very good quality, and 14.2 x 9.5 inches or 36.2 x 24.1 cm for excellent quality prints.

The T6i has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.

The Canon EOS Rebel T6i has a native sensitivity range from ISO 100 to ISO 12800, which can be extended to ISO 100-25600. The corresponding ISO settings for the Canon EOS Rebel XSi are ISO 100 to ISO 1600 (no boost).

Technology-wise, both cameras are equipped with CMOS (Complementary Metal–Oxide–Semiconductor) sensors. Both cameras use a Bayer filter for capturing RGB colors on a square grid of photosensors. This arrangement is found in most digital cameras.

Since 2007, DXO Mark has published sensor performance measurements that have been derived using a consistent methodology. This service is based on lab testing and assigns an overall score to each camera sensor, as well as ratings for dynamic range ("DXO Landscape"), color depth ("DXO Portrait"), and low-light sensitivity ("DXO Sports"). Of the two cameras under review, the T6i has a notably higher overall DXO score than the XSi (overall score 10 points higher), which gives it an advantage in terms of imaging quality. This advantage is based on 0.8 bits higher color depth, 1.2 EV in additional dynamic range, and 0.4 stops in additional low light sensitivity. The table below summarizes the physical sensor characteristics and sensor quality findings and compares them across a set of similar cameras.

Sensor Characteristics

#		Camera Model	Sensor Class	Resolution (MP)	Horiz. Pixels	Vert. Pixels	Video Format	DXO Portrait	DXO Landscape	DXO Sports	DXO Overall
1.		Canon T6i	APS-C	24.0	6000	4000	1080/30p	22.7	12.0	919	71
2.		Canon XSi	APS-C	12.2	4272	2848	none	21.9	10.8	692	61
3.		Canon 77D	APS-C	24.0	6000	4000	1080/60p	23.6	13.3	971	78
4.		Canon T7i	APS-C	24.0	6000	4000	1080/60p	23.7	13.1	1586	80
5.		Canon T6s	APS-C	24.0	6000	4000	1080/30p	22.6	12.0	915	70
6.		Canon T5	APS-C	17.9	5184	3456	1080/30p	21.9	11.3	724	63
7.		Canon T5i	APS-C	17.9	5184	3456	1080/30p	21.7	11.2	681	61
8.		Canon T4i	APS-C	17.9	5184	3456	1080/30p	21.7	11.2	722	62
9.		Canon T3	APS-C	12.2	4272	2848	720/30p	21.9	11.0	755	62
10.		Canon T1i	APS-C	15.1	4752	3168	1080/20p	21.7	11.5	663	63
11.		Canon 40D	APS-C	10.1	3888	2592	none	22.1	11.3	703	64
12.		Canon XTi	APS-C	10.1	3888	2592	none	22.1	11.0	664	62
13.		Canon XT	APS-C	8.0	3456	2304	none	21.8	10.8	637	60
Note: DXO values in italics represent estimates based on sensor size and age.

Many modern cameras are not only capable of taking still images, but also of capturing video footage. The T6i indeed provides movie recording capabilities, while the XSi does not. The highest resolution format that the T6i can use is 1080/30p.

Feature comparison

Apart from body and sensor, cameras can and do differ across a range of features. The T6i and the XSi are similar in the sense that both have an optical viewfinder. The latter is useful for getting a clear image for framing even in brightly lit environments. The viewfinders of both cameras offer the same field of view (95%), but the viewfinder of the XSi has a higher magnification than the one of the T6i (0.54x vs 0.51x), so that the size of the image transmitted appears closer to the size seen with the naked human eye. The table below summarizes some of the other core capabilities of the Canon T6i and Canon XSi in connection with corresponding information for a sample of similar cameras.

Core Features

#		Camera Model	Viewfinder (Type or 000 dots)	Control Panel (yes/no)	LCD Specifications (inch/000 dots)	LCD Attach- ment	Touch Screen (yes/no)	Max Shutter Speed *	Max Shutter Flaps *	Built-in Flash (yes/no)	Built-in Image Stab
1.		Canon T6i	optical	n	3.0 / 1040	swivel	Y	1/4000s	5.0/s	Y	n
2.		Canon XSi	optical	n	3.0 / 230	fixed	n	1/4000s	3.5/s	Y	n
3.		Canon 77D	optical	Y	3.0 / 1040	swivel	Y	1/4000s	6.0/s	Y	n
4.		Canon T7i	optical	n	3.0 / 1040	swivel	Y	1/4000s	6.0/s	Y	n
5.		Canon T6s	optical	Y	3.0 / 1040	swivel	Y	1/4000s	5.0/s	Y	n
6.		Canon T5	optical	n	3.0 / 460	fixed	n	1/4000s	3.0/s	Y	n
7.		Canon T5i	optical	n	3.0 / 1040	swivel	Y	1/4000s	5.0/s	Y	n
8.		Canon T4i	optical	n	3.0 / 1040	swivel	Y	1/4000s	5.0/s	Y	n
9.		Canon T3	optical	n	2.7 / 230	fixed	n	1/4000s	3.0/s	Y	n
10.		Canon T1i	optical	n	3.0 / 920	fixed	n	1/4000s	3.4/s	Y	n
11.		Canon 40D	optical	Y	3.0 / 230	fixed	n	1/8000s	6.5/s	Y	n
12.		Canon XTi	optical	n	2.5 / 230	fixed	n	1/4000s	3.0/s	Y	n
13.		Canon XT	optical	n	1.8 / 115	fixed	n	1/4000s	3.0/s	Y	n
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one.

One differentiating feature between the two cameras concerns the touch sensitivity of the rear screen. The T6i has a touchscreen, while the XSi has a conventional panel. Touch control can be particularly helpful, for example, for setting the focus point.

The T6i writes its imaging data to SDXC cards, while the XSi uses SDHC cards. The T6i supports UHS-I cards (Ultra High Speed data transfer of up to 104 MB/s), while the XSi cannot take advantage of Ultra High Speed SD cards.

Connectivity comparison

For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS Rebel T6i and Canon EOS Rebel XSi and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.

Input-Output Connections

#		Camera Model	Hotshoe Port	Internal Mic / Speaker	Microphone Port	Headphone Port	HDMI Port	USB Port	WiFi Support	NFC Support	Bluetooth Support
1.		Canon T6i	Y	stereo / mono	Y	-	mini	2.0	Y	Y	-
2.		Canon XSi	Y	- / -	-	-	mini	2.0	-	-	-
3.		Canon 77D	Y	stereo / mono	Y	-	mini	2.0	Y	Y	Y
4.		Canon T7i	Y	stereo / mono	Y	-	mini	2.0	Y	Y	Y
5.		Canon T6s	Y	stereo / mono	Y	-	mini	2.0	Y	Y	-
6.		Canon T5	Y	mono / mono	-	-	mini	2.0	-	-	-
7.		Canon T5i	Y	stereo / mono	Y	-	mini	2.0	-	-	-
8.		Canon T4i	Y	stereo / mono	Y	-	mini	2.0	-	-	-
9.		Canon T3	Y	stereo / mono	-	-	mini	2.0	-	-	-
10.		Canon T1i	Y	mono / mono	-	-	mini	2.0	-	-	-
11.		Canon 40D	Y	- / -	-	-	-	2.0	-	-	-
12.		Canon XTi	Y	- / -	-	-	-	2.0	-	-	-
13.		Canon XT	Y	- / -	-	-	-	2.0	-	-	-

It is notable that the T6i offers wifi support, while the XSi does not. Wifi can be a very convenient means to transfer image data to an off-camera location.

Both the T6i and the XSi have been discontinued, but can regularly be found used on ebay. The XSi was replaced by the Canon T1i, while the T6i was followed by the Canon T7i. Further information on the features and operation of the T6i and XSi can be found, respectively, in the Canon T6i Manual (free pdf) or the online Canon XSi Manual.

Review summary

So how do things add up? Is the Canon T6i better than the Canon XSi or vice versa? The listing below highlights the relative strengths of the two models.

Advantages of the Canon EOS Rebel T6i:

• More detail: Offers more megapixels (24 vs 12.2MP) with a 40% higher linear resolution.
• Better image quality: Scores markedly higher (10 points) in the DXO overall assessment.
• More dynamic range: Captures a larger spectrum of light and dark details (1.2 EV of extra DR).
• Better low-light sensitivity: Requires less light for good images (0.4 stops ISO advantage).
• Better jpgs: Has a more modern image processing engine (DIGIC 6 vs DIGIC 3).
• Broader imaging potential: Can record not only still images but also 1080/30p movies.
• Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
• More detailed LCD: Has a higher resolution rear screen (1040k vs 230k dots).
• More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
• Fewer buttons to press: Is equipped with a touch-sensitive rear screen to facilitate handling.
• More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
• Faster burst: Shoots at higher frequency (5 vs 3.5 flaps/sec) to capture the decisive moment.
• Easier file upload: Has wifi built in for automatic backup or image transfer to the web.
• Easier device pairing: Supports NFC for fast wireless image transfer over short distances.
• Faster buffer clearing: Has an SD card interface that supports the UHS-I standard.
• More modern: Reflects 7 years of technical progress since the XSi launch.

Reasons to prefer the Canon EOS Rebel XSi:

• Larger viewfinder image: Features a viewfinder with a higher magnification (0.54x vs 0.51x).
• Longer lasting: Gets more shots (500 versus 440) out of a single battery charge.
• More heavily discounted: Has been around for much longer (launched in January 2008).

If the number of relative strengths (bullet points above) is taken as a guide, the T6i is the clear winner of the match-up (16 : 3 points). However, the pertinence of the various camera strengths will differ across photographers, so that you might want to weigh individual camera traits according to their importance for your own imaging needs before making a camera decision. A professional wildlife photographer will view the differences between cameras in a way that diverges from the perspective of a family photog, and a person interested in architecture has distinct needs from a sports shooter. Hence, the decision which camera is best and worth buying is often a very personal one.

How about other alternatives? Do the specifications of the Canon T6i and the Canon XSi place the cameras among the top in their class? Find out in the latest Best DSLR Camera listing whether the two cameras rank among the cream of the crop.

In any case, while the specs-based evaluation of cameras can be instructive in revealing their potential as photographic tools, it remains partial and cannot reveal, for example, the shooting experience and imaging performance when actually working with the T6i or the XSi. At times, user reviews, such as those published at amazon, address these issues in a useful manner, but such feedback is on many occasions incomplete, inconsistent, and unreliable.

Expert reviews

This is why expert reviews are important. The table below provides a synthesis of the camera assessments of some of the best known photo-gear review sites (amateurphotographer [AP], cameralabs [CL], digitalcameraworld [DCW], dpreview [DPR], ephotozine [EPZ], photographyblog [PB]). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.

Expert Camera Reviews

#		Camera   Model	AP   score	CL   score	DCW   score	DPR   score	EPZ   score	PB   score	Camera Launch	Launch Price (USD)	Street Price
1.		Canon T6i	5/5	..	..	75/100	4.5/5	4.5/5	Feb 2015	749	ebay.com
2.		Canon XSi	..	+ +	..	+ +	4/5	4.5/5	Jan 2008	799	ebay.com
3.		Canon 77D	4.5/5	..	4/5	82/100	4.5/5	4/5	Feb 2017	899	ebay.com
4.		Canon T7i	4.5/5	..	3.5/5	80/100	4.5/5	4/5	Feb 2017	749	ebay.com
5.		Canon T6s	5/5	+	..	77/100	4.5/5	4.5/5	Feb 2015	649	ebay.com
6.		Canon T5	3/5	+	..	..	4/5	4.5/5	Feb 2014	449	ebay.com
7.		Canon T5i	..	..	..	76/100	4.5/5	4.5/5	Mar 2013	649	ebay.com
8.		Canon T4i	4/5	+ +	..	77/100	4.5/5	4.5/5	Jun 2012	849	ebay.com
9.		Canon T3	..	80/100	..	69/100	4/5	4.5/5	Feb 2011	449	ebay.com
10.		Canon T1i	..	+ +	..	74/100	4.5/5	4.5/5	Mar 2009	799	ebay.com
11.		Canon 40D	..	+ +	..	+ +	4.5/5	4.5/5	Aug 2007	1,299	ebay.com
12.		Canon XTi	..	+ +	..	+ +	o	4/5	Aug 2006	799	ebay.com
13.		Canon XT	..	80/100	..	+ +	o	..	Feb 2005	899	ebay.com
Note: (+ +) highly recommended; (+) recommended; (o) reviewed; (..) not available.

The review scores listed above should be treated with care, though. The assessments were made in relation to similar cameras of the same technological generation. Hence, a score should always be seen in the context of the camera's market launch date and its price, and comparisons of ratings among very different cameras or across long time periods have little meaning. It should also be noted that some of the review sites have over time altered the way they render their verdicts.
