Canon 77D vs Pentax 645Z

The Canon EOS 77D and the Pentax 645Z are two digital cameras that were officially introduced, respectively, in February 2017 and April 2014. Both are DSLR (Digital Single Lens Reflex) cameras that are based on an APS-C (77D) and a medium format (645Z) sensor. The Canon has a resolution of 24 megapixel, whereas the Pentax provides 51.1 MP. Read on to find out how these two cameras compare with respect to their body size, their sensors, their features, their input-output connections, and their reception by expert reviewers.

Body comparison: Canon 77D vs Pentax 645Z

The side-by-side display below illustrates the physical size and weight of the Canon 77D and the Pentax 645Z. The two cameras are presented according to their relative size. Three consecutive perspectives from the front, the top, and the back are available. All size dimensions are rounded to the nearest millimeter. You can also use the toggle button to switch to a percentage comparison if you prefer that the measures are being expressed in relative terms (in this case, the camera on the left – the 77D – represents the basis or 100 percent across all the size and weight measures).

Compare Canon 77D and Pentax 645Z
Compare 77D versus 645Z top
Compare 77D or 645Z rear

If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Pentax 645Z is notably larger (39 percent) than the Canon 77D. Moreover, the 645Z is substantially heavier (187 percent) than the 77D. It is noteworthy in this context that the 645Z is splash and dust-proof, while the 77D does not feature any corresponding weather-sealing.

The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. Hence, you might want to study and compare the specifications of available lenses in order to get the full picture of the size and weight of the two camera systems.

Concerning battery life, the 77D gets 600 shots out of its LP-E17 battery, while the 645Z can take 650 images on a single charge of its D-LI90 power pack.

The following table provides a synthesis of the main physical specifications of the two cameras and other similar ones. If you want to switch the focus of the display and review another camera pair, just select a new right or left comparator from among the camera models in the table. Alternatively, you can also move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.

Camera Body Specifications
  Camera
Model
Camera
Width
Camera
Height
Camera
Depth
Camera
Weight
Battery
Life
(CIPA)
Weather
Sealing
(yes/no)
Camera
Launch
(announced)
Launch
Price
(USD)
Street
Price
(USD)
Used
Price
(USD)
Camera
Model
Canon 77D» 5.2 in 3.9 in 3.0 in 19.0 oz 600 n Feb 2017 899 i i Canon 77D
Pentax 645Z« 6.1 in 4.6 in 4.8 in 54.7 oz 650 Y Apr 2014 8,499 i i Pentax 645Z
Canon M50« » 4.6 in 3.5 in 2.3 in 13.8 oz 235 n Feb 2018 779 i i Canon M50
Canon T7« » 5.1 in 4.0 in 3.1 in 16.8 oz 500 n Feb 2018 449 i i Canon T7
Canon SL2« » 4.8 in 3.7 in 2.8 in 16.0 oz 650 n Jun 2017 549 i i Canon SL2
Canon T7i« » 5.2 in 3.9 in 3.0 in 18.8 oz 600 n Feb 2017 749 i i Canon T7i
Canon M5« » 4.6 in 3.5 in 2.4 in 15.1 oz 295 n Sep 2016 979 i i Canon M5
Canon T6« » 5.1 in 4.0 in 3.1 in 17.1 oz 500 n Mar 2016 449- i Canon T6
Canon 5DS« » 6.0 in 4.6 in 3.0 in 32.8 oz 700 Y Feb 2015 3,699 i i Canon 5DS
Canon 5DS R« » 6.0 in 4.6 in 3.0 in 32.8 oz 700 Y Feb 2015 3,699 i i Canon 5DS R
Canon T6i« » 5.2 in 4.0 in 3.1 in 19.6 oz 440 n Feb 2015 749- i Canon T6i
Canon T6s« » 5.2 in 4.0 in 3.1 in 19.9 oz 440 n Feb 2015 849- i Canon T6s
Canon T4i« » 5.2 in 3.9 in 3.1 in 20.3 oz 440 n Jun 2012 849- i Canon T4i
Canon T3i« » 5.2 in 3.9 in 3.1 in 20.1 oz 440 n Feb 2011 599- i Canon T3i
Hasselblad X1D« » 5.9 in 3.9 in 2.8 in 25.6 oz .. Y Jun 2016 8,995 i i Hasselblad X1D
Leica SL« » 5.8 in 4.1 in 1.5 in 29.9 oz 400 Y Oct 2015 7,450 i i Leica SL
Pentax 645D« » 6.1 in 4.6 in 4.7 in 52.2 oz 800 Y Mar 2010 9,995- i Pentax 645D

The price is, of course, an important factor in any camera decision. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The 77D was launched at a markedly lower price (by 89 percent) than the 645Z, which puts it into a different market segment. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down. Then, after the new model is out, very good deals can frequently be found on the pre-owned market.



Sensor comparison: Canon 77D vs Pentax 645Z

The imaging sensor is at the core of digital cameras and its size is one of the main determining factors of image quality. A large sensor will tend to have larger individual pixels that provide better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixel-units in a sensor of the same technological generation. Further, a large sensor camera will give the photographer additional creative options when using shallow depth-of-field to isolate a subject from its background. On the downside, larger sensors are more costly to manufacture and tend to lead to bigger and heavier cameras and lenses.

Of the two cameras under consideration, the Canon 77D features an APS-C sensor and the Pentax 645Z a medium format sensor. The sensor area in the 645Z is 333 percent bigger. As a result of these sensor size differences, the cameras have a format factor of, respectively, 1.6 and 0.79. The sensor in the 77D has a native 3:2 aspect ratio, while the one in the 645Z offers a 4:3 aspect.

Canon 77D and Pentax 645Z sensor measures

With 51.1MP, the 645Z offers a higher resolution than the 77D (24MP), but the 645Z nevertheless has larger individual pixels (pixel pitch of 5.30μm versus 3.72μm for the 77D) due to its larger sensor. However, the 77D is a much more recent model (by 2 years and 10 months) than the 645Z, and its sensor will have benefitted from technological advances during this time that enhance the light gathering capacity of its pixel-units. Coming back to sensor resolution, it should be mentioned that the 645Z has no anti-alias filter installed, so that it can capture all the detail its sensor resolves.

The 77D has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition during video recording.

77D versus 645Z MP

Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service assesses and scores the color depth ("DXO Portrait"), dynamic range ("DXO Landscape"), and low-light sensitivity ("DXO Sports") of camera sensors, and also publishes an overall camera score. Of the two cameras under consideration, the 645Z offers substantially better image quality than the 77D (overall score 23 points higher). The advantage is based on 2.4 bits higher color depth, 1.4 EV in additional dynamic range, and 2.2 stops in additional low light sensitivity. The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.

Sensor Characteristics
  Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
Camera
Model
Canon 77D» APS-C 24.0 6000 40001080/60p23.613.397178Canon 77D
Pentax 645Z« Medium Format 51.1 8256 61921080/60i26.014.74505101Pentax 645Z
Canon M50« » APS-C 24.0 6000 40004K/24p----Canon M50
Canon T7« » APS-C 24.0 6000 40001080/30p----Canon T7
Canon SL2« » APS-C 24.0 6000 40001080/60p23.613.4104179Canon SL2
Canon T7i« » APS-C 24.0 6000 40001080/60p----Canon T7i
Canon M5« » APS-C 24.0 6000 40001080/60p23.412.4126277Canon M5
Canon T6« » APS-C 17.9 5184 34561080/30p----Canon T6
Canon 5DS« » Full Frame 50.3 8688 57921080/60p24.712.4238187Canon 5DS
Canon 5DS R« » Full Frame 50.3 8688 57921080/60p24.612.4230886Canon 5DS R
Canon T6i« » APS-C 24.0 6000 40001080/60p22.712.091971Canon T6i
Canon T6s« » APS-C 24.0 6000 40001080/30p22.612.091570Canon T6s
Canon T4i« » APS-C 17.9 5184 34561080/30p21.711.272262Canon T4i
Canon T3i« » APS-C 17.9 5184 34561080/30p22.111.579365Canon T3i
Hasselblad X1D« » Medium Format 51.3 8272 62001080/25p26.214.84489102Hasselblad X1D
Leica SL« » Full Frame 24.0 6000 40004K/30p25.013.4182188Leica SL
Pentax 645D« » Medium Format 39.5 7264 5440-24.612.6126282Pentax 645D

Many modern cameras are not only capable of taking still images, but also of capturing video footage. Both cameras under consideration have a sensor with sufficiently fast read-out times for moving pictures, but the 77D provides a higher frame rate than the 645Z. It can shoot video footage at 1080/60p, while the Pentax is limited to 1080/60i.



Feature comparison: Canon 77D vs Pentax 645Z

Apart from body and sensor, cameras can and do differ across a range of features. The 77D and the 645Z are similar in the sense that both have an optical viewfinder. The latter is useful for getting a clear image for framing even in brightly lit environments. The adjacent table lists some of the other core features of the Canon 77D and Pentax 645Z along with similar information for a selection of comparators. If you need more detail on the specs, you can find comprehensive listings, for example, in the dpreview camera hub.

Core Features
  Camera
Model
Viewfinder
(Type or
'000 dots)
Control
Panel
(yes/no)
LCD
Size
(inch)
LCD
Resolution
('000 dots)
LCD
Attach-
ment
Touch
Screen
(yes/no)
Shutter
speed
(1/sec)
Shutter
flaps
(1/sec)
built-in
Flash
(yes/no)
built-in
Stab
Camera
Model
Canon 77D»optical Y 3.0 1040 swivel Y 4000 6.0 Y n Canon 77D
Pentax 645Z«optical Y 3.2 1037 tilting n 4000 3.0 n n Pentax 645Z
Canon M50« »2360 n 3.0 1040 swivel Y 4000 10.0 Y n Canon M50
Canon T7« »optical n 3.0 920 fixed n 4000 3.0 Y n Canon T7
Canon SL2« »optical n 3.0 1040 swivel Y 4000 5.0 Y n Canon SL2
Canon T7i« »optical n 3.0 1040 swivel Y 4000 6.0 Y n Canon T7i
Canon M5« »2360 n 3.2 1620 tilting Y 4000 9.0 Y n Canon M5
Canon T6« »optical n 3.0 920 fixed n 4000 3.0 Y n Canon T6
Canon 5DS« »optical Y 3.2 1040 fixed n 8000 5.0 n n Canon 5DS
Canon 5DS R« »optical Y 3.2 1040 fixed n 8000 5.0 n n Canon 5DS R
Canon T6i« »optical n 3.0 1040 swivel Y 4000 5.0 Y n Canon T6i
Canon T6s« »optical Y 3.0 1040 swivel Y 4000 5.0 Y n Canon T6s
Canon T4i« »optical n 3.0 1040 swivel Y 4000 5.0 Y n Canon T4i
Canon T3i« »optical n 3.0 1040 swivel n 4000 3.7 Y n Canon T3i
Hasselblad X1D« »2360 n 3.0 920 fixed Y 2000 2.3 n n Hasselblad X1D
Leica SL« »4400 Y 3.0 1040 fixed Y 8000 11.0 n n Leica SL
Pentax 645D« »optical Y 3.0 921 fixed n 4000 1.1 n n Pentax 645D

One difference between the cameras concerns the presence of an on-board flash. The 77D has one, while the 645Z does not. While the built-in flash of the 77D is not very powerful, it can at times be useful as a fill-in light.

The 77D has an articulated LCD that can be turned to be front-facing. This characteristic will be appreciated by vloggers and photographers who are interested in snapping selfies. In contrast, the 645Z does not have a selfie-screen.

Concerning the storage of imaging data, both the 77D and the 645Z write their files to SDXC cards. The 645Z features dual card slots, which can be very useful in case a memory card fails. In contrast, the 77D only has one slot.

I-O connection comparison: Canon 77D vs Pentax 645Z

For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS 77D and Pentax 645Z and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.

Input-Output Connections
  Camera
Model
Hotshoe
Port
Internal
Microphone
Internal
Speaker
Microphone
Port
Headphone
Port
HDMI
Port
USB
Type
WiFi
Support
NFC
Support
Bluetooth
Support
Camera
Model
Canon 77D»YstereomonoY-mini2.0YYYCanon 77D
Pentax 645Z«YstereomonoY-mini3.0---Pentax 645Z
Canon M50« »YstereomonoY-micro2.0YYYCanon M50
Canon T7« »Ymonomono--mini2.0YY-Canon T7
Canon SL2« »YstereomonoY-mini2.0YYYCanon SL2
Canon T7i« »YstereomonoY-mini2.0YYYCanon T7i
Canon M5« »YstereomonoY-mini2.0YYYCanon M5
Canon T6« »Ymonomono--mini2.0YY-Canon T6
Canon 5DS« »YmonomonoY-mini3.0---Canon 5DS
Canon 5DS R« »YmonomonoY-mini3.0---Canon 5DS R
Canon T6i« »YstereomonoY-mini2.0YY-Canon T6i
Canon T6s« »YstereomonoY-mini2.0YY-Canon T6s
Canon T4i« »YstereomonoY-mini2.0---Canon T4i
Canon T3i« »YmonomonoY-mini2.0---Canon T3i
Hasselblad X1D« »YstereomonoYYmini3.0Y--Hasselblad X1D
Leica SL« »YstereomonoYYfull3.0Y--Leica SL
Pentax 645D« »Ystereo----2.0---Pentax 645D

Both the 77D and the 645Z are recent models that feature in their makers' current product line-up. The 645Z replaced the earlier Pentax 645D, while the 77D followed on from the Canon T6s.


Review summary: Canon 77D vs Pentax 645Z

So what conclusions can be drawn? Is there a clear favorite between the Canon 77D and the Pentax 645Z? A synthesis of the relative strong points of each of the models is listed below.

ilogo

Advantages of the Canon EOS 77D:

  • Better moiré control: Has an anti-alias filter to avoid artificial patterns to appear in images.
  • Better video: Provides higher movie framerates (1080/60p versus 1080/60i).
  • Better video autofocus: Features on-sensor phase-detection for more confident movie autofocus.
  • More flexible LCD: Has swivel screen for odd-angle shots in portrait or landscape orientation.
  • Fewer buttons to press: Is equipped with a touch-sensitive rear screen to facilitate handling.
  • More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
  • Faster burst: Shoots at higher frequency (6 vs 3 flaps/sec) to capture the decisive moment.
  • More compact: Is smaller (131x100mm vs 156x117mm) and thus needs less room in the bag.
  • Less heavy: Is lighter (by 1010g or 65 percent) and hence easier to carry around.
  • Easier fill-in: Is equipped with a small onboard flash to brighten deep shadow areas.
  • Easier file upload: Has wifi build in for automatic backup or image transfer to the web.
  • Easier device pairing: Supports NFC for fast wireless image transfer over short distances.
  • Easier wireless transfer: Supports Bluetooth for image sharing without cables.
  • More affordable: Was introduced into a lower priced category (89 percent cheaper at launch).
  • More modern: Reflects 2 years and 10 months of technical progress since the 645Z launch.

ilogo

Arguments in favor of the Pentax 645Z:

  • More detail: Has more megapixels (51.1 vs 24MP), which boosts linear resolution by 43%.
  • Maximized detail: Lacks an anti-alias filter to exploit the sensor's full resolution potential.
  • Better image quality: Scores substantially higher (23 points) in the DXO overall evaluation.
  • Richer colors: Generates noticeably more natural colors (2.4 bits more color depth).
  • More dynamic range: Captures a broader range of light and dark details (1.4 EV of extra DR).
  • Better low-light sensitivity: Can shoot in dim conditions (2.2 stops ISO advantage).
  • Larger screen: Has a bigger rear LCD (3.2" vs 3.0") for image review and settings control.
  • Better sealing: Is splash and dust sealed for shooting in inclement weather conditions.
  • Faster data transfer: Supports a more advanced USB protocol (3.0 vs 2.0).
  • Greater peace of mind: Features a second card slot as a backup in case of memory card failure.
  • More heavily discounted: Has been around for much longer (launched in April 2014).

If the count of individual advantages (bullet points above) is taken as a guide, the 77D is the clear winner of the match-up (15 : 11 points). However, the pertinence of the various camera strengths will differ across photographers, so that you might want to weigh individual camera traits according to their importance for your own imaging needs before making a camera decision.

77D 15:11 645Z

In any case, while the specs-based evaluation of cameras is instructive in revealing their potential as photographic tools, it remains incomplete and does no justice, for example, to the way the 77D or the 645Z handle or perform in practice. User reviews that are available, for instance, at amazon can sometimes shed light on these issues, but such feedback is all too often partial, inconsistent, and inaccurate.

Expert reviews: Canon 77D vs Pentax 645Z

This is where reviews by experts come in. The following table reports the overall rankings of the cameras as published by some of the major camera review sites (cameralabs, dpreview, ephotozine, imaging-resource, photographyblog). You can find the full text of the reviews by clicking on the site logo in the table header.

Review Scores
  Camera
Model
cameralabs dpreview ephotozine imaging-resource photographyblog Camera
Launch
(announced)
Launch
Price
(USD)
Street
Price
(USD)
Used
Price
(USD)
Camera
Model
Canon 77D»-82/1004.5/54.5/54/5 Feb 2017 899 i i Canon 77D
Pentax 645Z«--4.5/55/55/5 Apr 2014 8,499 i i Pentax 645Z
Canon M50« »Rec79/100--3.5/5 Feb 2018 779 i i Canon M50
Canon T7« »rev-3.5/5-3.5/5 Feb 2018 449 i i Canon T7
Canon SL2« »HiRec78/1004.5/54.5/54.5/5 Jun 2017 549 i i Canon SL2
Canon T7i« »-80/1004.5/54/54/5 Feb 2017 749 i i Canon T7i
Canon M5« »Rec82/1004/54.5/54/5 Sep 2016 979 i i Canon M5
Canon T6« »rev73/1004/53.5/54/5 Mar 2016 449- i Canon T6
Canon 5DS« »Rec83/1004.5/55/54.5/5 Feb 2015 3,699 i i Canon 5DS
Canon 5DS R« »Rec83/1005/55/54.5/5 Feb 2015 3,699 i i Canon 5DS R
Canon T6i« »-75/1004.5/54.5/54.5/5 Feb 2015 749- i Canon T6i
Canon T6s« »Rec77/1004.5/54.5/54.5/5 Feb 2015 849- i Canon T6s
Canon T4i« »HiRec77/1004.5/54.5/54.5/5 Jun 2012 849- i Canon T4i
Canon T3i« »rev77/1004.5/55/54.5/5 Feb 2011 599- i Canon T3i
Hasselblad X1D« »rev81/100--4/5 Jun 2016 8,995 i i Hasselblad X1D
Leica SL« »-84/1004.5/54/54/5 Oct 2015 7,450 i i Leica SL
Pentax 645D« »---4.5/5- Mar 2010 9,995- i Pentax 645D

The review scores listed above should be treated with care, though. The ratings are only valid when referring to cameras in the same category and of the same age. Hence, a score should always be seen in the context of the camera's market launch date and its price, and rating-comparisons among cameras that span long time periods or concern very differently equipped models make little sense. Also, kindly note that some of the listed sites have over time developped their review approaches and their reporting style.



Other camera comparisons

Did this review help to inform your camera decision process? In case you would like to check on the differences and similarities of other camera models, just make your choice using the following search menu. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.

~

    Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
