Canon 500D vs 700D
The Canon EOS 500D (called Canon T1i in some regions) and the Canon EOS 700D (labelled Canon T5i in some countries) are two digital cameras that were announced, respectively, in March 2009 and March 2013. Both are DSLR (Digital Single Lens Reflex) cameras that are equipped with an APS-C sensor. The 500D has a resolution of 15.1 megapixels, whereas the 700D provides 17.9 MP.
Below is an overview of the main specs of the two cameras as a starting point for the comparison.
|Canon 500D||Canon 700D|
|Digital single lens reflex||Digital single lens reflex|
|Canon EF mount lenses||Canon EF mount lenses|
|15.1 MP, APS-C Sensor||17.9 MP, APS-C Sensor|
|1080/20p Video||1080/30p Video|
|ISO 100-6400 (100-12800)||ISO 100-12800 (100-25600)|
|Optical viewfinder||Optical viewfinder|
|3.0" LCD, 920k dots||3.0" LCD, 1040k dots|
|Fixed screen (not touch-sensitive)||Swivel touchscreen|
|3.4 shutter flaps per second||5 shutter flaps per second|
|400 shots per battery charge||440 shots per battery charge|
|129 x 98 x 62 mm, 520 g||133 x 100 x 79 mm, 580 g|
Going beyond this snapshot of core features and characteristics, what are the differences between the Canon EOS 500D and the Canon EOS 700D? Which one should you buy? Read on to find out how these two cameras compare with respect to their body size, their imaging sensors, their shooting features, their input-output connections, and their reception by expert reviewers.
An illustration of the physical size and weight of the Canon 500D and the Canon 700D is provided in the side-by-side display below. The two cameras are presented according to their relative size. Three consecutive views from the front, the top, and the rear side are shown. All width, height and depth measures are rounded to the nearest millimeter.
If the front view area (width x height) of the cameras is taken as an aggregate measure of their size, the Canon 700D is notably larger (5 percent) than the Canon 500D. Moreover, the 700D is markedly heavier (12 percent) than the 500D. In this context, it is worth noting that neither the 500D nor the 700D are weather-sealed.
The above size and weight comparisons are to some extent incomplete since they do not consider the interchangeable lenses that both of these cameras require. In this particular case, both cameras feature the same lens mount, so that they can use the same lenses. You can compare the optics available in the Canon EF Lens Catalog.
The adjacent table lists the principal physical characteristics of the two cameras alongside a wider set of alternatives. If you want to switch the focus of the display and review another camera pair, just select a new right or left comparator from among the camera models in the table. Alternatively, you can also move across to the CAM-parator tool and choose from the broad selection of possible camera comparisons there.
|Canon 500D»||5.1 in||3.9 in||2.4 in||18.3 oz||400||n||Mar 2009||799||-||Canon 500D|
|Canon 700D«||5.2 in||3.9 in||3.1 in||20.5 oz||440||n||Mar 2013||649||-||Canon 700D|
|Canon 750D« »||5.2 in||4.0 in||3.1 in||19.6 oz||440||n||Feb 2015||749||-||Canon 750D|
|Canon 760D« »||5.2 in||4.0 in||3.1 in||19.9 oz||440||n||Feb 2015||649||-||Canon 760D|
|Canon 1200D« »||5.1 in||3.9 in||3.1 in||16.9 oz||500||n||Feb 2014||449||-||Canon 1200D|
|Canon G1 X Mark II« »||4.6 in||2.9 in||2.6 in||19.5 oz||240||n||Feb 2014||799||Canon G1 X Mark II|
|Canon 100D« »||4.6 in||3.6 in||2.7 in||14.4 oz||380||n||Mar 2013||549||-||Canon 100D|
|Canon 650D« »||5.2 in||3.9 in||3.1 in||20.3 oz||440||n||Jun 2012||849||-||Canon 650D|
|Canon G1 X« »||4.6 in||3.2 in||2.6 in||18.8 oz||250||n||Jan 2012||799||-||Canon G1 X|
|Canon 600D« »||5.2 in||3.9 in||3.1 in||20.1 oz||440||n||Feb 2011||599||-||Canon 600D|
|Canon 550D« »||5.1 in||3.9 in||2.4 in||18.7 oz||440||n||Feb 2010||699||-||Canon 550D|
|Canon 450D« »||5.1 in||3.9 in||2.4 in||18.5 oz||500||n||Jan 2008||799||-||Canon 450D|
|Note: Measurements and pricing do not include easily detachable parts, such as interchangeable lenses or optional viewfinders.|
Any camera decision will obviously take relative prices into account. The retail prices at the time of the camera’s release place the model in the market relative to other models in the producer’s line-up and the competition. The 700D was launched at a somewhat lower price (by 19 percent) than the 500D, which makes it more attractive for photographers on a tight budget. Usually, retail prices stay at first close to the launch price, but after several months, discounts become available. Later in the product cycle and, in particular, when the replacement model is about to appear, further discounting and stock clearance sales often push the camera price considerably down.
The imaging sensor is at the core of digital cameras and its size is one of the main determining factors of image quality. All other things equal, a large sensor will have larger individual pixel-units that offer better low-light sensitivity, wider dynamic range, and richer color-depth than smaller pixels in a sensor of the same technological generation. Further, a large sensor camera will give the photographer additional creative options when using shallow depth-of-field to isolate a subject from its background. On the downside, larger sensors tend to be more expensive and lead to bigger and heavier cameras and lenses.
Both cameras under consideration feature an APS-C sensor and have a format factor (sometimes also referred to as "crop factor") of 1.6. Within the spectrum of camera sensors, this places the review cameras among the medium-sized sensor cameras that aim to strike a balance between image quality and portability. Both cameras have a native aspect ratio (sensor width to sensor height) of 3:2.
Technology-wise, the 700D uses a more advanced image processing engine (DIGIC 5) than the 500D (DIGIC 4), with benefits for noise reduction, color accuracy, and processing speed.
While the two cameras under review share the same sensor size, the 700D offers a higher resolution of 17.9 megapixels, compared with 15.1 MP of the 500D. This megapixels advantage translates into a 9 percent gain in linear resolution. On the other hand, these sensor specs imply that the 700D has a higher pixel density and a smaller size of the individual pixel (with a pixel pitch of 4.31μm versus 4.69μm for the 500D). However, it should be noted that the 700D is much more recent (by 3 years and 11 months) than the 500D, and its sensor will have benefitted from technological advances during this time that compensate for the smaller pixel size.
The resolution advantage of the Canon 700D implies greater flexibility for cropping images or the possibility to print larger pictures. The maximum print size of the 700D for good quality output (200 dots per inch) amounts to 25.9 x 17.3 inch or 65.8 x 43.9 cm, for very good quality (250 dpi) 20.7 x 13.8 inch or 52.7 x 35.1 cm, and for excellent quality (300 dpi) 17.3 x 11.5 inch or 43.9 x 29.3 cm. The corresponding values for the Canon 500D are 23.8 x 15.8 inch or 60.4 x 40.2 cm for good quality, 19 x 12.7 inch or 48.3 x 32.2 cm for very good quality, and 15.8 x 10.6 inch or 40.2 x 26.8 cm for excellent quality prints.
The 700D has on-sensor phase detect pixels, which results in fast and reliable autofocus acquisition even during live view operation.
The Canon EOS 500D has a native sensitivity range from ISO 100 to ISO 6400, which can be extended to ISO 100-12800. The corresponding ISO settings for the Canon EOS 700D are ISO 100 to ISO 12800, with the possibility to increase the ISO range to 100-25600.
Consistent information on actual sensor performance is available from DXO Mark for many cameras. This service determines an overall sensor rating, as well as sub-scores for low-light sensitivity ("DXO Sports"), dynamic range ("DXO Landscape"), and color depth ("DXO Portrait"). The Overall DXO ratings for the two cameras under consideration are close, suggesting that they provide similar imaging performance. The adjacent table reports on the physical sensor characteristics and the outcomes of the DXO sensor quality tests for a sample of comparator-cameras.
|Canon 500D»||APS-C||15.1||4752||3168||1080/20p||21.7||11.5||663||63||Canon 500D|
|Canon 700D«||APS-C||17.9||5184||3456||1080/30p||21.7||11.2||681||61||Canon 700D|
|Canon 750D« »||APS-C||24.0||6000||4000||1080/60p||22.7||12.0||919||71||Canon 750D|
|Canon 760D« »||APS-C||24.0||6000||4000||1080/30p||22.6||12.0||915||70||Canon 760D|
|Canon 1200D« »||APS-C||17.9||5184||3456||1080/30p||21.9||11.3||724||63||Canon 1200D|
|Canon G1 X Mark II« »||1.5-inch||13.0||4160||3120||1080/30p||21.5||10.8||581||58||Canon G1 X Mark II|
|Canon 100D« »||APS-C||17.9||5184||3456||1080/30p||21.8||11.3||843||63||Canon 100D|
|Canon 650D« »||APS-C||17.9||5184||3456||1080/30p||21.7||11.2||722||62||Canon 650D|
|Canon G1 X« »||1.5-inch||14.2||4352||3264||1080/24p||21.7||10.8||644||60||Canon G1 X|
|Canon 600D« »||APS-C||17.9||5184||3456||1080/30p||22.1||11.5||793||65||Canon 600D|
|Canon 550D« »||APS-C||17.9||5184||3456||1080/30p||22.1||11.5||784||66||Canon 550D|
|Canon 450D« »||APS-C||12.2||4272||2848||-||21.9||10.8||692||61||Canon 450D|
Many modern cameras are not only capable of taking still images, but can also record movies. Both cameras under consideration have a sensor with sufficiently fast read-out times for moving pictures, but the 700D provides a faster frame rate than the 500D. It can shoot movie footage at 1080/30p, while the 500D is limited to 1080/20p.
Beyond body and sensor, cameras can and do differ across a range of features. The 500D and the 700D are similar in the sense that both have an optical viewfinder. The latter is useful for getting a clear image for framing even in brightly lit environments. The viewfinders of both cameras offer the same field of view (95%), but the viewfinder of the 500D has a higher magnification than the one of the 700D (0.54x vs 0.53x), so that the size of the image transmitted appears closer to the size seen with the naked human eye. The following table reports on some other key feature differences and similarities of the Canon 500D, the Canon 700D, and comparable cameras.
|Canon 500D»||optical||n||3.0||920||fixed||n||1/4000s||3.4||Y||n||Canon 500D|
|Canon 700D«||optical||n||3.0||1040||swivel||Y||1/4000s||5.0||Y||n||Canon 700D|
|Canon 750D« »||optical||n||3.0||1040||swivel||Y||1/4000s||5.0||Y||n||Canon 750D|
|Canon 760D« »||optical||Y||3.0||1040||swivel||Y||1/4000s||5.0||Y||n||Canon 760D|
|Canon 1200D« »||optical||n||3.0||460||fixed||n||1/4000s||3.0||Y||n||Canon 1200D|
|Canon G1 X Mark II« »||-||n||3.0||1040||tilting||Y||1/4000s||5.2||Y||Y||Canon G1 X Mark II|
|Canon 100D« »||optical||n||3.0||1040||fixed||Y||1/4000s||4.9||Y||n||Canon 100D|
|Canon 650D« »||optical||n||3.0||1040||swivel||Y||1/4000s||5.0||Y||n||Canon 650D|
|Canon G1 X« »||optical||n||3.0||922||Swivel||n||1/4000s||1.9||Y||Y||Canon G1 X|
|Canon 600D« »||optical||n||3.0||1040||swivel||n||1/4000s||3.7||Y||n||Canon 600D|
|Canon 550D« »||optical||n||3.0||1040||fixed||n||1/4000s||3.7||Y||n||Canon 550D|
|Canon 450D« »||optical||n||3.0||230||fixed||n||1/4000s||3.5||Y||n||Canon 450D|
One differentiating feature between the two cameras concerns the touch sensitivity of the rear screen. The 700D has a touchscreen, while the 500D has a conventional panel. Touch control can be particularly helpful, for example, for setting the focus point.The 700D has an articulated screen that can be turned to be front-facing. This characteristic will be appreciated by vloggers and photographers who are interested in taking selfies. In contrast, the 500D does not have a selfie-screen.
The 500D writes its imaging data to SDHC cards, while the 700D uses SDXC cards. The 700D supports UHS-I cards (Ultra High Speed data transfer of up to 104 MB/s), while the 500D cannot take advantage of Ultra High Speed SD cards.
For some imaging applications, the extent to which a camera can communicate with its environment can be an important aspect in the camera decision process. The table below provides an overview of the connectivity of the Canon EOS 500D and Canon EOS 700D and, in particular, the interfaces the cameras (and selected comparators) provide for accessory control and data transfer.
|Canon 500D»||Y||mono||mono||-||-||mini||2.0||-||-||-||Canon 500D|
|Canon 700D«||Y||stereo||mono||Y||-||mini||2.0||-||-||-||Canon 700D|
|Canon 750D« »||Y||stereo||mono||Y||-||mini||2.0||Y||Y||-||Canon 750D|
|Canon 760D« »||Y||stereo||mono||Y||-||mini||2.0||Y||Y||-||Canon 760D|
|Canon 1200D« »||Y||mono||mono||-||-||mini||2.0||-||-||-||Canon 1200D|
|Canon G1 X Mark II« »||Y||stereo||mono||-||-||mini||2.0||Y||Y||-||Canon G1 X Mark II|
|Canon 100D« »||Y||mono||mono||Y||-||mini||2.0||-||-||-||Canon 100D|
|Canon 650D« »||Y||stereo||mono||Y||-||mini||2.0||-||-||-||Canon 650D|
|Canon G1 X« »||Y||stereo||mono||-||-||mini||2.0||-||-||-||Canon G1 X|
|Canon 600D« »||Y||mono||mono||Y||-||mini||2.0||-||-||-||Canon 600D|
|Canon 550D« »||Y||stereo||-||Y||-||mini||2.0||-||-||-||Canon 550D|
|Canon 450D« »||Y||-||-||-||-||mini||2.0||-||-||-||Canon 450D|
It is notable that the 700D has a microphone port, which can help to improve the quality of audio recordings by attaching an external microphone. The 500D does not feature such a mic input.
Both the 500D and the 700D have been discontinued, but can regularly be found used on eBay. The 500D was replaced by the Canon 550D, while the 700D was followed by the Canon 750D. Further information on the two cameras (e.g. user guides, manuals), as well as related accessories, can be found on the official Canon website.
So how do things add up? Which of the two cameras – the Canon 500D or the Canon 700D – has the upper hand? Is one clearly better than the other? A synthesis of the relative strong points of each of the models is listed below.
Arguments in favor of the Canon EOS 500D:
- Larger viewfinder image: Features a viewfinder with a higher magnification (0.54x vs 0.53x).
- Less heavy: Is lighter (by 60g or 10 percent) and hence easier to carry around.
- More heavily discounted: Has been available for much longer (launched in March 2009).
Advantages of the Canon EOS 700D:
- More detail: Has more megapixels (17.9 vs 15.1MP), which boosts linear resolution by 9%.
- Better jpgs: Has a more modern image processing engine (DIGIC 5 vs DIGIC 4).
- Better video: Provides higher movie framerates (1080/30p versus 1080/20p).
- Better live-view autofocus: Features on-sensor phase-detection for more confident autofocus.
- Better sound: Can connect to an external microphone for higher quality sound recording.
- More detailed LCD: Has a higher resolution rear screen (1040k vs 920k dots).
- More flexible LCD: Has a swivel screen for odd-angle shots in portrait or landscape orientation.
- Fewer buttons to press: Has a touchscreen to facilitate handling and shooting adjustments.
- More selfie-friendly: Has an articulated screen that can be turned to be front-facing.
- Faster burst: Shoots at higher frequency (5 vs 3.4 flaps/sec) to capture the decisive moment.
- Faster buffer clearing: Has an SD card interface that supports the UHS-I standard.
- More affordable: Was released into a lower priced segment (19 percent cheaper at launch).
- More modern: Reflects 3 years and 11 months of technical progress since the 500D launch.
If the count of individual advantages (bullet points above) is taken as a guide, the 700D is the clear winner of the contest (13 : 3 points). However, the relevance of individual strengths will vary across photographers, so that you might want to apply your own weighing scheme to the summary points when reflecting and deciding on a new camera. A professional wedding photographer will view the differences between cameras in a way that diverges from the perspective of a travel photog, and a person interested in cityscapes has distinct needs from a macro shooter. Hence, the decision which camera is best and worth buying is often a very personal one.
How about other alternatives? Do the specifications of the Canon 500D and the Canon 700D place the cameras among the top in their class? Find out in the latest Best DSLR Camera listing whether the two cameras rank among the cream of the crop.
In any case, while the specs-based evaluation of cameras can be instructive in revealing their potential as photographic tools, it remains partial and cannot reveal, for example, the shooting experience and imaging performance when actually working with the 500D or the 700D. User reviews that are available, for instance, at amazon can sometimes shed light on these issues, but such feedback is all too often partial, inconsistent, and inaccurate.
This is where reviews by experts come in. The adjacent summary-table relays the overall verdicts of several of the most popular camera review sites (cameralabs, dpreview, ephotozine, imaging-resource, and photographyblog). As can be seen, the professional reviewers agree in many cases on the quality of different cameras, but sometimes their assessments diverge, reinforcing the earlier point that a camera decision is often a very personal choice.
|Canon 500D»||+ +||74/100||4.5/5||5/5||4.5/5||Mar 2009||799||-||Canon 500D|
|Canon 700D«||-||76/100||4.5/5||4.5/5||4.5/5||Mar 2013||649||-||Canon 700D|
|Canon 750D« »||-||75/100||4.5/5||4.5/5||4.5/5||Feb 2015||749||-||Canon 750D|
|Canon 760D« »||+||77/100||4.5/5||4.5/5||4.5/5||Feb 2015||649||-||Canon 760D|
|Canon 1200D« »||+||-||4/5||4/5||4.5/5||Feb 2014||449||-||Canon 1200D|
|Canon G1 X Mark II« »||+||77/100||4/5||4/5||4.5/5||Feb 2014||799||Canon G1 X Mark II|
|Canon 100D« »||+||78/100||4/5||4/5||4/5||Mar 2013||549||-||Canon 100D|
|Canon 650D« »||+ +||77/100||4.5/5||4.5/5||4.5/5||Jun 2012||849||-||Canon 650D|
|Canon G1 X« »||+||76/100||4/5||4/5||4.5/5||Jan 2012||799||-||Canon G1 X|
|Canon 600D« »||o||77/100||4.5/5||5/5||4.5/5||Feb 2011||599||-||Canon 600D|
|Canon 550D« »||+ +||77/100||4/5||5/5||4.5/5||Feb 2010||699||-||Canon 550D|
|Canon 450D« »||+ +||+ +||4/5||5/5||4.5/5||Jan 2008||799||-||Canon 450D|
|Notes: (+ +) highly recommended; (+) recommended; (o) reviewed; (-) not available.|
The review scores listed above should be treated with care, though. The assessments were made in relation to similar cameras of the same technological generation. Hence, a score should always be seen in the context of the camera's market launch date and its price, and comparing ratings of very distinct cameras or ones that are far apart in terms of their release date have little meaning. Also, kindly note that some of the listed sites have over time developped their review approaches and their reporting style.
Other camera comparisons
Did this review help to inform your camera decision process? In case you are interested in seeing how other cameras pair up, just make your choice using the following search menu. As an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
Specifications: Canon 500D vs Canon 700D
Below is a side-by-side comparison of the specs of the two cameras to facilitate a quick review of their differences and common features.
|Camera Model||Canon 500D||Canon 700D|
|Camera Type||Digital single lens reflex||Digital single lens reflex|
|Camera Lens||Canon EF mount lenses||Canon EF mount lenses|
|Launch Date||March 2009||March 2013|
|Launch Price||USD 799||USD 649|
|Sensor Specs||Canon 500D||Canon 700D|
|Sensor Format||APS-C Sensor||APS-C Sensor|
|Sensor Size||22.3 x 14.9 mm||22.3 x 14.9 mm|
|Sensor Area||332.27 mm2||332.27 mm2|
|Sensor Diagonal||26.8 mm||26.8 mm|
|Sensor Resolution||15.1 Megapixels||17.9 Megapixels|
|Image Resolution||4752 x 3168 pixels||5184 x 3456 pixels|
|Pixel Pitch||4.69 μm||4.31 μm|
|Pixel Density||4.53 MP/cm2||5.39 MP/cm2|
|Moiré control||Anti-Alias filter||Anti-Alias filter|
|Movie Capability||1080/20p Video||1080/30p Video|
|ISO Setting||100-6400 ISO||100-12800 ISO|
|ISO Boost||100-12800 ISO||100-25600 ISO|
|Image Processor||DIGIC 4||DIGIC 5|
|DXO Sensor Quality (score)||63||61|
|DXO Color Depth (bits)||21.7||21.7|
|DXO Dynamic Range (EV)||11.5||11.2|
|DXO Low Light (ISO)||663||681|
|Screen Specs||Canon 500D||Canon 700D|
|Viewfinder Type||Optical viewfinder||Optical viewfinder|
|Viewfinder Field of View||95%||95%|
|LCD Framing||Live View||Live View|
|Rear LCD Size||3.0 inch||3.0 inch|
|LCD Resolution||920k dots||1040k dots|
|LCD Attachment||Fixed screen||Swivel screen|
|Touch Input||no Touchscreen||Touchscreen|
|Shooting Specs||Canon 500D||Canon 700D|
|Autofocus System||Phase-detect AF||Phase-detect AF|
|Continuous Shooting||3.4 shutter flaps/s||5 shutter flaps/s|
|Shutter Life Expectancy||100 000 actuations||100 000 actuations|
|Fill Flash||Build-in Flash||Build-in Flash|
|Storage Medium||SDHC cards||SDXC cards|
|Second Storage Option||Single card slot||Single card slot|
|UHS card support||no||UHS-I|
|Connectivity Specs||Canon 500D||Canon 700D|
|USB Connector||USB 2.0||USB 2.0|
|HDMI Port||mini HDMI||mini HDMI|
|Microphone Port||no MIC socket||External MIC port|
|Wifi Support||no Wifi||no Wifi|
|Body Specs||Canon 500D||Canon 700D|
|Battery Life (CIPA)||400 shots per charge||440 shots per charge|
129 x 98 x 62 mm
(5.1 x 3.9 x 2.4 in)
133 x 100 x 79 mm
(5.2 x 3.9 x 3.1 in)
|Camera Weight||520 g (18.3 oz)||580 g (20.5 oz)|
