What is the sensor size of the Sony HX400V?
The Sony Cyber-shot DSC-HX400V is a digital camera that has a 1/2.3-inch sensor at its core. This imager measures 6.17mm in width and 4.55mm in height, so that the total imaging area of the sensor amounts to 28 mm2.
The HX400V provides an image resolution of 20.2 megapixels, based on 5 184 horizontal pixels and 3 888 vertical pixels.
Sensor size comparison with a film slide
The sensor diagonal measures 7.7mm, which gives rise to a format factor (or crop factor) of 5.6. Hence, the Sony HX400V is a crop-sensor camera, as its sensor is smaller than a traditional 35mm film slide or negative.
Sensor specs and performance
The table below compares the sensor specs of the Sony HX400V to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Sony HX400V | 1/2.3 | 20.2 | 5184 | 3888 | 1080/60p | 20.1 | 11.4 | 629 | 45 | |
2. | Canon SX60 | 1/2.3 | 14.2 | 4608 | 3072 | 1080/60p | 19.2 | 10.8 | 127 | 39 | |
3. | Canon SX70 | 1/2.3 | 20.2 | 5184 | 3888 | 4K/30p | 20.6 | 12.1 | 1063 | 51 | |
4. | Kodak AZ901 | 1/2.3 | 20.2 | 5184 | 3888 | 1080/30p | 20.3 | 11.7 | 806 | 48 | |
5. | Nikon B700 | 1/2.3 | 20.2 | 5184 | 3888 | 4K/30p | 20.4 | 11.8 | 818 | 48 | |
6. | Sony H300 | 1/2.3 | 19.9 | 5152 | 3864 | 720/30p | 20.1 | 11.4 | 630 | 45 | |
7. | Sony H400 | 1/2.3 | 19.9 | 5152 | 3864 | 720/30p | 20.1 | 11.4 | 630 | 45 | |
8. | Sony HX90V | 1/2.3 | 18.0 | 4896 | 3672 | 1080/60p | 20.2 | 11.6 | 738 | 47 | |
9. | Sony HX95 | 1/2.3 | 18.0 | 4896 | 3672 | 4K/30p | 20.6 | 12.1 | 1057 | 51 | |
10. | Sony HX99 | 1/2.3 | 18.0 | 4896 | 3672 | 4K/30p | 20.6 | 12.1 | 1058 | 51 | |
11. | Sony HX350 | 1/2.3 | 19.9 | 5152 | 3864 | 1080/60p | 20.5 | 11.9 | 896 | 49 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
In the United States, the HX400V was initially launched in February 2014 at a price of $499.
Camera to camera comparisons
In case you would like to check on the differences and similarities with other camera models, just make a corresponding selection in the search boxes below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 1D Mark II N vs Sony HX400V
- Canon 250D vs Sony HX400V
- Canon G1 X Mark III vs Nikon Z6
- Fujifilm X-M1 vs Sony HX400V
- Leica D-LUX 7 vs Nikon Z6
- Leica T vs Sony HX400V
- Nikon D100 vs Nikon Z6
- Nikon Z6 vs Panasonic G10
- Nikon Z6 vs Panasonic S5
- Nikon Z6 vs Zeiss ZX1
- Olympus TG-5 vs Sony HX400V
- Sony A7R III vs Sony HX400V
Camera Model | Sony HX400V | |
---|---|---|
Camera Type | Fixed lens compact camera | |
Camera Lens | 24-1200mm f/2.8-6.3 | |
Launch Date | February 2014 | |
Launch Price | USD 499 | |
Sensor Specs | ||
Sensor Technology | BSI-CMOS | |
Sensor Format | 1/2.3" Sensor | |
Sensor Size | 6.17 x 4.55 mm | |
Sensor Area | 28 mm2 | |
Sensor Diagonal | 7.7 mm | |
Crop Factor | 5.6x | |
Sensor Resolution | 20.2 Megapixels | |
Image Resolution | 5 184 x 3 888 pixels | |
Pixel Pitch | 1.18 μm | |
Pixel Density | 71.80 MP/cm2 | |
Moiré control | no AA filter | |
Movie Capability | 1080/60p Video | |
ISO Setting | 80 - 3 200 ISO | |
ISO Boost | 80 - 12 800 ISO | |
Image Processor | BIONZ X | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Resolution | 210k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 921k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | No front-flip | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 10 shutter flaps/s | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | MS or SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | no | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Near-Field Communication | NFC built-in | |
Geotagging | GPS built-in | |
Body Specs | ||
Battery Type | Sony NP-BX1 power pack | |
Battery Life (CIPA) | 300 shots per charge | |
Body Dimensions |
130 x 93 x 103 mm (5.1 x 3.7 x 4.1 in) |
|
Camera Weight | 660 g (23.3 oz) |
