What is the pixel pitch of the Sony A6300?

The Sony Alpha A6300 provides 24 megapixels from an APS-C sensor. This pixel density gives rise to a size of the individual pixel of 3.91µm.

The pixel size or pixel pitch can be calculated by dividing the sensor area by the pixel count and then taking the square root. In particular, the sensor in the Sony A6300 measures 23.5mm in width and 15.6mm in height, so that the total imaging area of the sensor amounts to 367 mm2. Moreover, the A6300 has 6 000 horizontal pixels and 4 000 vertical pixels, for a total of 24 megapixels. Then, the size (height or width) of each individual pixel can be calculated as the square root of the ratio of the sensor area (367 mm2) to the MP count (24 000 000).

camera

Larger pixels provide advantages with respect to gathering light, particularly in low-light situations. Large pixels notably have a better signal to noise ratio, meaning that they can better differentiate between incoming photons and the noisy signals that the internal processes of the camera create. As a result, big pixels are particularly helpful to the photographer when shooting with high ISO settings.

ad

Sensor specs and performance

The table below compares the sensor specs of the Sony A6300 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.

scroll hint
Sensor Characteristics
#   Camera
Model
Sensor
Class
Resolution
(MP)
Horiz.
Pixels
Vert.
Pixels
Video
Format
DXO
Portrait
DXO
Landscape
DXO
Sports
DXO
Overall
1.

Sony A6300 APS-C 24.0 6000 40004K/30p24.413.7143785
2.

Canon 80D APS-C 24.0 6000 40001080/60p23.613.2113579
3.

Nikon D5500 APS-C 24.0 6000 40001080/60p24.114.0143884
4.

Nikon D7200 APS-C 24.0 6000 40001080/60p24.514.6133387
5.

Sony A6400 APS-C 24.0 6000 40004K/30p24.013.6143183
6.

Sony A6500 APS-C 24.0 6000 40004K/30p24.513.7140585
7.

Sony RX100 IV 1-inch 20.0 5472 36484K/30p22.812.659170
8.

Sony A6000 APS-C 24.0 6000 40001080/60p24.113.1134782
9.

Sony A3000 APS-C 19.8 5456 36321080/60i23.712.8106878
10.

Sony NEX-6 APS-C 16.0 4912 32641080/60i23.713.1101878
11.

Sony NEX-7 APS-C 24.0 6000 40001080/60i24.113.4101681
padding

Further information on the sensor in the Sony A6300 and the camera's operation can be found in the camera manual.

In the United States, the A6300 was initially launched in February 2016 at a price of $999.

logo
Check A6300 offers at
ebay.com

Camera to camera comparisons

If you would like to see a side-by-side review with another camera, just use the search menu below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.

~
    loader
    ad

    Specifications Summary
    Camera Model Sony A6300
    Camera Type Mirrorless system camera
    Camera Lens Sony E mount lenses
    Launch Date February 2016
    Launch Price USD 999
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format APS-C Sensor
    Sensor Size 23.5 x 15.6 mm
    Sensor Area 367 mm2
    Sensor Diagonal 28.2 mm
    Crop Factor 1.5x
    Sensor Resolution 24 Megapixels
    Image Resolution 6 000 x 4 000 pixels
    Pixel Pitch 3.91 μm
    Pixel Density 6.55 MP/cm2
    Moiré control Anti-Alias filter
    Movie Capability 4K/30p Video
    ISO Setting 100 - 25 600 ISO
    ISO Boost 100 - 51 200 ISO
    Image Processor BIONZ X
    DXO Sensor Quality (score) 85
    DXO Color Depth (bits) 24.4
    DXO Dynamic Range (EV) 13.7
    DXO Low Light (ISO) 1437
    Screen Specs
    Viewfinder Type Electronic viewfinder
    Viewfinder Field of View 100%
    Viewfinder Magnification 0.70x
    Viewfinder Resolution 2359k dots
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 922k dots
    LCD Attachment Tilting screen
    V-logging Friendliness No front-flip
    Touch Input No touchscreen
    Shooting Specs
    Focus System On-Sensor Phase-detect
    Manual Focusing AidFocus Peaking
    Maximum Shutter Speed 1/4000s
    Continuous Shooting 11 shutter flaps/s
    Shutter Life Expectancy100 000 actuations
    Silent ShootingElectronic Shutter
    Time Lapse Photographyno Intervalometer
    Fill Flash Built-in Flash
    Storage Medium MS or SDXC cards
    Single or Dual Card Slots Single card slot
    UHS card support UHS-I
    Connectivity Specs
    External Flash Hotshoe
    USB Connector USB 2.0
    HDMI Port micro HDMI
    Microphone Port External MIC port
    Wifi Support Wifi built-in
    Near-Field Communication NFC built-in
    Body Specs
    Environmental SealingWeathersealed body
    Battery Type Sony NP-FW50 power pack
    Battery Life (CIPA)400 shots per charge
    In-Camera Charging USB charging
    Body Dimensions 120 x 67 x 49 mm
    (4.7 x 2.6 x 1.9 in)
    Camera Weight 404 g (14.3 oz)
