How much dynamic range does the Olympus E-M10 offer?
According to measurements carried out by DXO Mark, the sensor in the Olympus OM-D E-M10 provides a maximum of 12.3 EV of dynamic range (DR). DR is defined as the ratio between the highest and lowest brightness a camera can capture. A value of 12 EV or above is considered excellent.
High dynamic range of a camera sensor is particularly desirable for scenes with a mix of very bright and very dark parts, such as in some landscape photography settings. It helps to avoid that highlights get washed out or that detail in shadows is lost.
Sensor specs and performance
The table below compares the sensor specs of the Olympus E-M10 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better). In addition to dynamic range (DXO Landscape), the listing also covers color depth (DXO Portrait) and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Olympus E-M10 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.8 | 12.3 | 884 | 72 | |
2. | Olympus E-M10 II | Four Thirds | 15.9 | 4608 | 3456 | 1080/60p | 23.1 | 12.5 | 842 | 73 | |
3. | Olympus E-P5 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.8 | 12.4 | 895 | 72 | |
4. | Olympus E-PL5 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.8 | 12.3 | 889 | 72 | |
5. | Olympus E-PL6 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.5 | 12.0 | 717 | 68 | |
6. | Olympus E-PL7 | Four Thirds | 15.9 | 4608 | 3456 | 1080/30p | 22.7 | 12.4 | 873 | 72 | |
7. | Olympus E-PL9 | Four Thirds | 15.9 | 4608 | 3456 | 4K/30p | 23.1 | 12.8 | 1162 | 74 | |
8. | Olympus E-PL10 | Four Thirds | 15.9 | 4608 | 3456 | 4K/30p | 23.3 | 13.1 | 1324 | 76 | |
9. | Panasonic G6 | Four Thirds | 15.9 | 4608 | 3456 | 1080/60p | 21.3 | 11.5 | 639 | 61 | |
10. | Panasonic GX7 | Four Thirds | 15.8 | 4592 | 3448 | 1080/60p | 22.6 | 12.2 | 718 | 70 | |
11. | Panasonic GX85 | Four Thirds | 15.8 | 4592 | 3448 | 4K/30p | 22.9 | 12.6 | 662 | 71 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
In the United States, the E-M10 was initially launched in January 2014 at a price of $699.
Camera to camera comparisons
If you would like to see a side-by-side review with another camera, just make a corresponding selection in the search boxes below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.
Camera Model | Olympus E-M10 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | January 2014 | |
Launch Price | USD 699 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 15.9 Megapixels | |
Image Resolution | 4 608 x 3 456 pixels | |
Pixel Pitch | 3.76 μm | |
Pixel Density | 7.08 MP/cm2 | |
Moiré control | no AA filter | |
Movie Capability | 1080/30p Video | |
ISO Setting | 200 - 25 600 ISO | |
ISO Boost | 100 - 25 600 ISO | |
Image Processor | TruePic VII | |
DXO Sensor Quality (score) | 72 | |
DXO Color Depth (bits) | 22.8 | |
DXO Dynamic Range (EV) | 12.3 | |
DXO Low Light (ISO) | 884 | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.58x | |
Viewfinder Resolution | 1440k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1037k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | No front-flip | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 8 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Body Specs | ||
Battery Type | Olympus BLS-5 power pack | |
Battery Life (CIPA) | 320 shots per charge | |
Body Dimensions |
119 x 82 x 46 mm (4.7 x 3.2 x 1.8 in) |
|
Camera Weight | 396 g (14.0 oz) |
Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
