LCD resolution of the Olympus E-M1
The rear LCD screen of the Olympus OM-D E-M1 has a resolution of 1,037,000 dots and measures 3.0 inches across its diagonal. A high-resolution display offers a clearer and crisper user experience than a lower pixel screen, notably during live view framing and image review. While the physical size of the LCD is naturally limited by the space that is available on the back of the camera, the resolution of the rear screen has continued to increase over time, with new camera models often featuring nicer rear panels as one of the key arguments for a camera upgrade.
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.74x | |
Viewfinder Resolution | 2360k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1037k dots | |
LCD Attachment | Tilting screen | |
Touch Input | Touchscreen |
In terms of screen handling characteristics, the LCD of the Olympus E-M1 is touch sensitive and is flexibly attached to the body to allow for odd-angle shots.
Back side of the Olympus E-M1 with LCD
As can be seen from the rear-side image, the 3.0-inch LCD occupies a large part of the backside of the camera. For comparison, the diagonal on a standard credit card measures 4 inches.
Camera to camera comparisons
The Olympus OM-D E-M1 is a mirrorless interchangeable lens camera that was revealed to the public in September 2013 and is equipped with a Four Thirds sensor. It offers a resolution of 15.9 megapixel. In the United States, the Olympus E-M1 was initially launched at a price of $1,399.
The table below compares the rear screen specs of the Olympus E-M1 to those of several similar cameras. Additionally, the table includes some information on other core features, such as the viewfinder, shutter, flash, and image stabilization system.
# | Camera Model |
Viewfinder (Type or 000 dots) |
Control Panel (yes/no) |
LCD Specifications (inch/000 dots) |
LCD Attach- ment |
Touch Screen (yes/no) |
Mech Shutter Speed |
Shutter Flaps (1/sec) |
Built-in Flash (yes/no) |
Built-in Image Stab |
|
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Olympus E-M1 | 2360 | n | 3.0 / 1037 | tilting | Y | 1/8000s | 10.0/s | n | Y | |
2. | Olympus E-M1 II | 2360 | n | 3.0 / 1037 | swivel | Y | 1/8000s | 18.0/s | n | Y | |
3. | Olympus PEN-F | 2360 | n | 3.0 / 1037 | swivel | Y | 1/8000s | 10.0/s | n | Y | |
4. | Olympus E-M5 II | 2360 | n | 3.0 / 1037 | swivel | Y | 1/8000s | 10.0/s | n | Y | |
5. | Olympus E-PL7 | optional | n | 3.0 / 1037 | tilting | Y | 1/4000s | 8.0/s | n | Y | |
6. | Olympus E-P5 | optional | n | 3.0 / 1037 | tilting | Y | 1/8000s | 9.0/s | Y | Y | |
7. | Olympus E-M5 | 1440 | n | 3.0 / 610 | tilting | Y | 1/4000s | 9.0/s | n | Y | |
8. | Olympus E-PL5 | optional | n | 3.0 / 460 | tilting | Y | 1/4000s | 8.0/s | n | Y | |
9. | Olympus E-PM2 | optional | n | 3.0 / 460 | fixed | Y | 1/4000s | 8.0/s | n | Y | |
10. | Panasonic GH4 | 2359 | n | 3.0 / 1036 | swivel | Y | 1/8000s | 12.0/s | Y | n | |
11. | Panasonic GH3 | 1746 | n | 3.0 / 614 | swivel | Y | 1/4000s | 6.0/s | Y | n | |
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one. |
One feature that differentiates the E-M1 from many older cameras is in-body image stabilization (IBIS). The E-M1 reduces the risk of handshake-induced blur with all attached lenses, while cameras without IBIS have to rely on optical image stabilization in OIS-equipped lenses to achieve the same effect.
In case you would like to check on the differences and similarities with other camera models, just use the search menu below. An an alternative, you can also directly jump to any one of the listed comparisons that were previously generated by the CAM-parator tool.
- Canon 300D vs Olympus E-M1
- Fujifilm GFX 100S vs Olympus E-M1
- Fujifilm X-H1 vs Olympus E-M1
- Nikon D3000 vs Olympus E-M1
- Nikon D3100 vs Olympus E-M1
- Nikon D5200 vs Olympus E-M1
- Olympus E-M1 vs Olympus E-M1X
- Olympus E-M1 vs Olympus E-PL8
- Olympus E-M1 vs Panasonic G1
- Olympus E-M1 vs Panasonic S1H
- Olympus E-M1 vs Sony A7C
- Olympus E-M1 vs Sony A7R V
Camera Model | Olympus E-M1 | |
---|---|---|
Camera Type | Mirrorless system camera | |
Camera Lens | Micro Four Thirds lenses | |
Launch Date | September 2013 | |
Launch Price | USD 1 399 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | Four Thirds Sensor | |
Sensor Size | 17.3 x 13.0 mm | |
Sensor Area | 225 mm2 | |
Sensor Diagonal | 21.6 mm | |
Crop Factor | 2.0x | |
Sensor Resolution | 15.9 Megapixels | |
Image Resolution | 4 608 x 3 456 pixels | |
Pixel Pitch | 3.76 μm | |
Pixel Density | 7.08 MP/cm2 | |
Moiré control | no AA filter | |
Movie Capability | 1080/30p Video | |
ISO Setting | 200 - 25 600 ISO | |
ISO Boost | 100 - 25 600 ISO | |
Image Processor | TruePIC VII | |
DXO Sensor Quality (score) | 73 | |
DXO Color Depth (bits) | 23.0 | |
DXO Dynamic Range (EV) | 12.7 | |
DXO Low Light (ISO) | 757 | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.74x | |
Viewfinder Resolution | 2360k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 1037k dots | |
LCD Attachment | Tilting screen | |
V-logging Friendliness | No front-flip | |
Touch Input | Touchscreen | |
Shooting Specs | ||
Focus System | On-Sensor Phase-detect | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/8000s | |
Continuous Shooting | 10 shutter flaps/s | |
Shutter Life Expectancy | 150 000 actuations | |
Silent Shooting | Electronic Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | no On-Board Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
Studio Flash | PC Sync socket | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Microphone Port | External MIC port | |
Wifi Support | Wifi built-in | |
Body Specs | ||
Environmental Sealing | Weathersealed body | |
Battery Type | Olympus BLN-1 power pack | |
Battery Life (CIPA) | 350 shots per charge | |
Body Dimensions |
130 x 94 x 63 mm (5.1 x 3.7 x 2.5 in) |
|
Camera Weight | 497 g (17.5 oz) |
