LCD resolution of the Leica V-LUX Typ 114
The rear LCD screen of the Leica V-LUX (Typ 114) has a resolution of 921,000 dots and measures 3.0 inches across its diagonal. A high-resolution display offers a clearer and crisper user experience than a lower pixel screen, notably during live view framing and image review. While the physical size of the LCD is naturally limited by the space that is available on the back of the camera, the resolution of the rear screen has continued to increase over time, with new camera models often featuring nicer rear panels as one of the key arguments for a camera upgrade.
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 2359k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 921k dots | |
LCD Attachment | Swivel screen | |
Touch Input | No touchscreen |
In terms of screen handling characteristics, the LCD of the Leica V-LUX Typ 114 is not touch sensitive and is flexibly attached to the body to allow for odd-angle shots. Also, the screen can be turned to be front-facing, such that it enables selfies and facilitates v-logging.
Back side of the Leica V-LUX Typ 114 with LCD
As can be seen from the rear-side image, the 3.0-inch LCD occupies a large part of the backside of the camera. For comparison, the diagonal on a standard credit card measures 4 inches.
Camera to camera comparisons
The Leica V-LUX (Typ 114) is a fixed lens compact camera that was announced in September 2014 and is equipped with an one-inch sensor. It offers a resolution of 20 megapixel. In the United States, the Leica V-LUX Typ 114 was initially launched at a price of $1,349.
The table below compares the rear screen specs of the Leica V-LUX Typ 114 to those of several similar cameras. Additionally, the table includes some information on other core features, such as the viewfinder, shutter, flash, and image stabilization system.
# | Camera Model |
Viewfinder (Type or 000 dots) |
Control Panel (yes/no) |
LCD Specifications (inch/000 dots) |
LCD Attach- ment |
Touch Screen (yes/no) |
Mech Shutter Speed |
Shutter Flaps (1/sec) |
Built-in Flash (yes/no) |
Built-in Image Stab |
|
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Leica V-LUX Typ 114 | 2359 | n | 3.0 / 921 | swivel | n | 1/4000s | 12.0/s | Y | Y | |
2. | Leica V-LUX 5 | 2360 | n | 3.0 / 1240 | swivel | Y | 1/4000s | 12.0/s | Y | Y | |
3. | Leica Q Typ 116 | 3680 | n | 3.0 / 1040 | fixed | Y | 1/2000s | 10.0/s | n | Y | |
4. | Leica D-LUX Typ 109 | 2764 | n | 3.0 / 921 | fixed | n | 1/4000s | 11.0/s | n | Y | |
5. | Leica X Vario | optional | n | 3.0 / 920 | fixed | n | 1/2000s | 5.0/s | Y | n | |
6. | Leica V-LUX 4 | 1312 | n | 3.0 / 460 | swivel | n | 1/4000s | 12.0/s | Y | Y | |
7. | Panasonic FZ2500 | 2360 | n | 3.0 / 1040 | swivel | Y | 1/4000s | 12.0/s | Y | Y | |
8. | Panasonic FZ1000 | 2359 | n | 3.0 / 921 | swivel | n | 1/4000s | 12.0/s | Y | Y | |
9. | Sony RX100 VI | 2359 | n | 3.0 / 1229 | tilting | Y | 1/2000s | 24.0/s | Y | Y | |
10. | Sony RX10 II | 2359 | Y | 3.0 / 1229 | tilting | n | 1/3200s | 14.0/s | Y | Y | |
11. | Sony RX10 | 1440 | Y | 3.0 / 1229 | tilting | n | 1/3200s | 10.0/s | Y | Y | |
Note: *) Information refers to the mechanical shutter, unless the camera only has an electronic one. |
One convenient feature of the V-LUX Typ 114 is the presence of an on-board flash. While this built-in flash is not very powerful, it can at times be useful as a fill-in light to brighten deep shadow areas.
If you would like to see a side-by-side review with another camera, just use the search menu below. Alternatively, you can follow any of the listed hyperlinks for comparisons that others found interesting.
- Canon 2000D vs Leica V-LUX Typ 114
- Canon 80D vs Leica V-LUX Typ 114
- Canon RP vs Leica V-LUX Typ 114
- Leica M9 vs Leica V-LUX Typ 114
- Leica V-LUX 4 vs Leica V-LUX Typ 114
- Leica V-LUX Typ 114 vs Olympus E-420
- Leica V-LUX Typ 114 vs Olympus E-510
- Leica V-LUX Typ 114 vs Olympus E-520
- Leica V-LUX Typ 114 vs Panasonic GH5
- Leica V-LUX Typ 114 vs Panasonic LX100 II
- Leica V-LUX Typ 114 vs Panasonic TS7
- Leica V-LUX Typ 114 vs Sony A6400
Camera Model | Leica V-LUX Typ 114 | |
---|---|---|
Camera Type | Fixed lens compact camera | |
Camera Lens | 25-400mm f/2.8-4.0 | |
Launch Date | September 2014 | |
Launch Price | USD 1 349 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | 1" Sensor | |
Sensor Size | 13.2 x 8.8 mm | |
Sensor Area | 116 mm2 | |
Sensor Diagonal | 15.9 mm | |
Crop Factor | 2.7x | |
Sensor Resolution | 20 Megapixels | |
Image Resolution | 5 472 x 3 648 pixels | |
Pixel Pitch | 2.41 μm | |
Pixel Density | 17.18 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | 4K/30p Video | |
ISO Setting | 125 - 12 800 ISO | |
ISO Boost | 80 - 25 600 ISO | |
Screen Specs | ||
Viewfinder Type | Electronic viewfinder | |
Viewfinder Field of View | 100% | |
Viewfinder Magnification | 0.70x | |
Viewfinder Resolution | 2359k dots | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 921k dots | |
LCD Attachment | Swivel screen | |
V-logging Friendliness | Front-flip possible | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | Focus Peaking | |
Maximum Shutter Speed | 1/4000s | |
Continuous Shooting | 12 shutter flaps/s | |
Silent Shooting | Electronic Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | UHS-I | |
Connectivity Specs | ||
External Flash | Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Microphone Port | External MIC port | |
Wifi Support | Wifi built-in | |
Near-Field Communication | NFC built-in | |
Body Specs | ||
Battery Type | Leica BP-DC12 power pack | |
Battery Life (CIPA) | 360 shots per charge | |
Body Dimensions |
137 x 99 x 131 mm (5.4 x 3.9 x 5.2 in) |
|
Camera Weight | 830 g (29.3 oz) |
