What is the pixel pitch of the Fujifilm XP130?
The Fujifilm FinePix XP130 provides 15.9 megapixels from a 1/2.3-inch sensor. This pixel density gives rise to a size of the individual pixel of 1.33µm.
The pixel size or pixel pitch can be calculated by dividing the sensor area by the pixel count and then taking the square root. In particular, the sensor in the Fujifilm XP130 measures 6.17mm in width and 4.55mm in height, so that the total imaging area of the sensor amounts to 28 mm2. Moreover, the XP130 has 4 608 horizontal pixels and 3 456 vertical pixels, for a total of 15.9 megapixels. Then, the size (height or width) of each individual pixel can be calculated as the square root of the ratio of the sensor area (28 mm2) to the MP count (15 925 248).
Larger pixels provide advantages with respect to gathering light, particularly in low-light situations. Large pixels notably have a better signal to noise ratio, meaning that they can better differentiate between incoming photons and the noisy signals that the internal processes of the camera create. As a result, big pixels are particularly helpful to the photographer when shooting with high ISO settings.
Sensor specs and performance
The table below compares the sensor specs of the Fujifilm XP130 to those of several similar cameras. The reported DXO values are indicators of the sensor's imaging quality (higher is better), covering color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
||
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Fujifilm XP130 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/60p | 20.6 | 12.1 | 1000 | 51 | |
2. | Fujifilm XP120 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/60p | 20.5 | 11.9 | 900 | 49 | |
3. | Fujifilm XP140 | 1/2.3 | 15.9 | 4608 | 3456 | 4K/15p | 20.7 | 12.2 | 1102 | 52 | |
4. | Nikon W300 | 1/2.3 | 15.9 | 4608 | 3456 | 4K/30p | 20.5 | 12.0 | 938 | 50 | |
5. | Olympus TG-4 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/30p | 20.2 | 11.6 | 737 | 47 | |
6. | Olympus TG-5 | 1/2.3 | 12.0 | 4000 | 3000 | 4K/30p | 20.5 | 11.9 | 934 | 50 | |
7. | Pentax WG-90 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/60p | 20.9 | 12.8 | 1570 | 54 | |
8. | Ricoh WG-60 | 1/2.3 | 15.9 | 4608 | 3456 | 1080/60p | 20.6 | 12.2 | 1072 | 51 | |
9. | Sony HX95 | 1/2.3 | 18.0 | 4896 | 3672 | 4K/30p | 20.6 | 12.1 | 1057 | 51 | |
10. | Sony HX99 | 1/2.3 | 18.0 | 4896 | 3672 | 4K/30p | 20.6 | 12.1 | 1058 | 51 | |
11. | Sony WX800 | 1/2.3 | 18.0 | 4896 | 3672 | 4K/30p | 20.6 | 12.2 | 1070 | 51 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
Further information on the sensor in the Fujifilm XP130 and the camera's operation can be found in the camera manual.
In the United States, the XP130 was initially launched in January 2018 at a price of $229.
Camera to camera comparisons
In case you are interested in seeing how this camera compares to another one, just make a corresponding selection in the search boxes below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
- Canon 1100D vs Fujifilm XP130
- Canon 1Ds Mark III vs Nikon Z6
- Canon M5 vs Fujifilm XP130
- Canon R6 Mark II vs Nikon Z6
- Fujifilm XP130 vs Leica M Typ 262
- Fujifilm XP130 vs Leica SL2
- Fujifilm XP130 vs Leica V-LUX 2
- Fujifilm XP130 vs Olympus E-M10 III
- Nikon Coolpix A vs Nikon Z6
- Nikon Z6 vs Panasonic FZ150
- Nikon Z6 vs Panasonic G80
- Nikon Z6 vs Sony NEX-5
Camera Model | Fujifilm XP130 | |
---|---|---|
Camera Type | Fixed lens compact camera | |
Camera Lens | 28-140mm f/3.9-4.9 | |
Launch Date | January 2018 | |
Launch Price | USD 229 | |
Sensor Specs | ||
Sensor Technology | BSI-CMOS | |
Sensor Format | 1/2.3" Sensor | |
Sensor Size | 6.17 x 4.55 mm | |
Sensor Area | 28 mm2 | |
Sensor Diagonal | 7.7 mm | |
Crop Factor | 5.6x | |
Sensor Resolution | 15.9 Megapixels | |
Image Resolution | 4 608 x 3 456 pixels | |
Pixel Pitch | 1.33 μm | |
Pixel Density | 56.73 MP/cm2 | |
Moiré control | no AA filter | |
Movie Capability | 1080/60p Video | |
ISO Setting | 100 - 3 200 ISO | |
Screen Specs | ||
Viewfinder Type | No viewfinder | |
Top-Level Screen | no Top Display | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 920k dots | |
LCD Attachment | Fixed screen | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Contrast-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/2000s | |
Continuous Shooting | 10 shutter flaps/s | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | Intervalometer Built-in | |
Image Stabilization | In-body stabilization | |
Fill Flash | Built-in Flash | |
Storage Medium | SDXC cards | |
Single or Dual Card Slots | Single card slot | |
UHS card support | no | |
Connectivity Specs | ||
External Flash | no Hotshoe | |
USB Connector | USB 2.0 | |
HDMI Port | micro HDMI | |
Wifi Support | Wifi built-in | |
Bluetooth Support | Bluetooth built-in | |
Body Specs | ||
Environmental Sealing | Waterproof body (20m) | |
Battery Type | Fujifilm NP-45S power pack | |
Battery Life (CIPA) | 240 shots per charge | |
In-Camera Charging | USB charging | |
Body Dimensions |
110 x 71 x 28 mm (4.3 x 2.8 x 1.1 in) |
|
Camera Weight | 207 g (7.3 oz) |
