How many Megapixels does the Canon 50D have?
The Canon EOS 50D is equipped with a an APS-C sensor that offers an image resolution of 15.1 megapixels (MP), or 15.1 million pixels. With its native aspect ratio of 3:2, the sensor has 4 752 horizontal pixels and 3 168 vertical pixels.
A 35mm film slide or negative contains 5-15 MP of useful detail, so that the Canon 50D can be considered to be a high-resolution camera that outresolves any 35mm film camera.
A high megapixel count makes it possible to crop any captured image substantially or to make very large prints from the image file. On the downside, large megapixel files are slower to transfer and take up more storage space on the computer harddisk. Also, high-resolution imaging requires sharper, more expensive lenses than low-res picture taking.
How large can I print with 15.1 MP?
The maximum print size of the Canon 50D for good quality output (200 dots per inch) amounts to 23.8 x 15.8 inches or 60.4 x 40.2 cm, for very good quality (250 dpi) 19 x 12.7 inches or 48.3 x 32.2 cm, and for excellent quality (300 dpi) 15.8 x 10.6 inches or 40.2 x 26.8 cm. Few people actually print their images that large on a regular basis, but it is nice to have the option to make very large prints of exceptional shots. Also, as mentioned earlier, a key advantage of high-MP cameras is that it is possible to crop an image ex-post and thereby, for example, change the composition of the capture or zoom in on some detail.
Sensor specs and performance
The table below compares the sensor specs of the Canon 50D to those of several similar cameras. In addition to sensor class and megapixel count, DXO values are reported as indicators of the sensor's imaging quality (higher is better). Three aspects are covered: color depth (DXO Portrait), dynamic range (DXO Landscape), and high-ISO noise (DXO Sports). Larger sensor cameras tend to outperform cameras of the same generation that are equipped with a smaller imager. On the other hand, larger sensors are more expensive and require bigger and heavier lenses than smaller light receptors.
# | Camera Model |
Sensor Class |
Resolution (MP) |
Horiz. Pixels |
Vert. Pixels |
Video Format |
DXO Portrait |
DXO Landscape |
DXO Sports |
DXO Overall |
|
---|---|---|---|---|---|---|---|---|---|---|---|
1. | Canon 50D | APS-C | 15.1 | 4752 | 3168 | none | 21.8 | 11.4 | 696 | 63 | |
2. | Canon 90D | APS-C | 32.3 | 6960 | 4640 | 4K/30p | 24.0 | 13.5 | 1848 | 83 | |
3. | Canon 80D | APS-C | 24.0 | 6000 | 4000 | 1080/60p | 23.6 | 13.2 | 1135 | 79 | |
4. | Canon 7D II | APS-C | 20.0 | 5472 | 3648 | 1080/60p | 22.4 | 11.8 | 1082 | 70 | |
5. | Canon 70D | APS-C | 20.0 | 5472 | 3648 | 1080/30p | 22.5 | 11.6 | 926 | 68 | |
6. | Canon 60D | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 22.2 | 11.5 | 813 | 66 | |
7. | Canon 7D | APS-C | 17.9 | 5184 | 3456 | 1080/30p | 22.0 | 11.7 | 854 | 66 | |
8. | Canon T1i | APS-C | 15.1 | 4752 | 3168 | 1080/20p | 21.7 | 11.5 | 663 | 63 | |
9. | Canon 40D | APS-C | 10.1 | 3888 | 2592 | none | 22.1 | 11.3 | 703 | 64 | |
10. | Canon 30D | APS-C | 8.2 | 3504 | 2336 | none | 21.5 | 10.8 | 736 | 59 | |
11. | Canon 20D | APS-C | 8.2 | 3504 | 2336 | none | 21.9 | 11.0 | 721 | 62 | |
Note: DXO values in italics represent estimates based on sensor size and age. |
In the United States, the 50D was initially launched in August 2008 at a price of $1,299.
Camera to camera comparisons
If you would like to see a side-by-side review with another camera, just use the search menu below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
Camera Model | Canon 50D | |
---|---|---|
Camera Type | Digital single lens reflex | |
Camera Lens | Canon EF mount lenses | |
Launch Date | August 2008 | |
Launch Price | USD 1 299 | |
Sensor Specs | ||
Sensor Technology | CMOS | |
Sensor Format | APS-C Sensor | |
Sensor Size | 22.3 x 14.9 mm | |
Sensor Area | 332 mm2 | |
Sensor Diagonal | 26.8 mm | |
Crop Factor | 1.6x | |
Sensor Resolution | 15.1 Megapixels | |
Image Resolution | 4 752 x 3 168 pixels | |
Pixel Pitch | 4.69 μm | |
Pixel Density | 4.53 MP/cm2 | |
Moiré control | Anti-Alias filter | |
Movie Capability | no Video | |
ISO Setting | 100 - 3 200 ISO | |
ISO Boost | 100 - 12 800 ISO | |
Image Processor | DIGIC 4 | |
DXO Sensor Quality (score) | 63 | |
DXO Color Depth (bits) | 21.8 | |
DXO Dynamic Range (EV) | 11.4 | |
DXO Low Light (ISO) | 696 | |
Screen Specs | ||
Viewfinder Type | Optical viewfinder | |
Viewfinder Field of View | 95% | |
Viewfinder Magnification | 0.59x | |
Top-Level Screen | Control Panel | |
LCD Framing | Live View | |
LCD Size | 3.0 inch | |
LCD Resolution | 920k dots | |
LCD Attachment | Fixed screen | |
Touch Input | No touchscreen | |
Shooting Specs | ||
Focus System | Phase-detect AF | |
Manual Focusing Aid | no Peaking Feature | |
Maximum Shutter Speed | 1/8000s | |
Continuous Shooting | 6.3 shutter flaps/s | |
Shutter Life Expectancy | 100 000 actuations | |
Silent Shooting | no E-Shutter | |
Time Lapse Photography | no Intervalometer | |
Fill Flash | Built-in Flash | |
Storage Medium | CF cards | |
Single or Dual Card Slots | Single card slot | |
Connectivity Specs | ||
External Flash | Hotshoe | |
Studio Flash | PC Sync socket | |
USB Connector | USB 2.0 | |
HDMI Port | mini HDMI | |
Wifi Support | no Wifi | |
Body Specs | ||
Environmental Sealing | Weathersealed body | |
Battery Type | Canon BP-511A power pack | |
Battery Life (CIPA) | 800 shots per charge | |
Body Dimensions |
146 x 108 x 74 mm (5.7 x 4.3 x 2.9 in) |
|
Camera Weight | 822 g (29.0 oz) |
