Sony A6400 PDF User Manual
Did you lose or misplace the instruction manual that came with your Sony Alpha A6400? It happens all too easily, but fortunately Sony makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the A6400 offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.
That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.
Also, you might want to check out the video tutorial on the Sony Alpha A6400 below.
In any case, the A6400 is an advanced imaging tool, whose many features merit serious attention. This mirrorless interchangeable lens camera was officially introduced on January 15th, 2019, which means that, as of today, the camera is 1462 days old (young?). Given that the A6400 is a relatively recent model, it forms part of the current Sony product line-up.
Sony's help guide for the A6400
The camera's help guide is 659 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the A6400 is included towards the bottom of this webpage.
Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!
Click on the button below to download the pdf version of the Sony Alpha A6400 manual to your computer. The file will open in a new browser window.
If you prefer to read the user guide in another language, please check the respective availability on Sony's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.
Printed, hardcopy versions of the Sony A6400 manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.
Video tutorial for the Sony Alpha A6400
Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your A6400 by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.
Once again, the Sony A6400 is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.
Sony A6400 FAQ
Below are some additional questions and answers concerning some particular features of the A6400.
What type of imaging sensor is used in the A6400?
The camera is build around a CMOS (Complementary Metal–Oxide–Semiconductor) sensor.
Which image processing chip is used to convert the raw signal into an image file and perform noise reduction and image sharpening?
Sony equipped the A6400 with the BIONZ X image processor.
What is the ISO sensitivity range of the A6400?
The camera has a native sensitivity range from ISO 100 to ISO 32000.
Does the camera have a selfie-friendly screen?
Yes, the LCD-screen of the A6400 is flexible and can be turned to be front-facing for capturing selfies.
What is the life expectancy of the shutter in the Sony Alpha A6400?
Sony mentions a shutter rating of 200 000 actuations for the A6400. This number represents a Mean Time before Failure, that is an average value. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust the expected shutter life of the A6400 over, say, three years, one would have to take about 200 pictures each and every day.
How do I find the shutter count on my A6400?
Sony embeds the number of shutter actuations in image metadata. You can check the number of shots that your A6400 has taken up to now by uploading a recent image to the free online shutter count finder app.
Is completely silent shooting possible with the Sony A6400?
The camera has an electronic shutter option, so that it is indeed feasible to capture images without any shutter noise.
Is it difficult to use manual focus lenses with the Sony A6400?
The A6400 offers focus peaking as a manual focus aid. This feature works by placing a colored highlight on in-focus zones within the image.
Does the Sony A6400 feature an autofocus assist light?
Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.
What is the fastest shutter speed that can be used with flash?
The A6400's flash sync speed is 1/160 sec.
Does the Sony A6400 support the Ultra High Speed (UHS) bus interface for SD cards?
Yes, the camera can indeed use UHS-I cards (data transfer speed of up to 104 MB/s).
Which battery does the A6400 use?
Where can I find the best deals for the A6400?
How does the A6400 stack up against available alternatives? In case you would like to check on the differences and similarities with other camera models, just make a corresponding selection in the search boxes below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.
Core camera specifications
Here is a list of the main features and technical characteristics of the Sony Alpha A6400.
|Camera Model||Sony A6400|
|Camera Type||Mirrorless system camera|
|Camera Lens||Sony E mount lenses|
|Launch Date||January 2019|
|Launch Price||USD 899|
|Sensor Format||APS-C Sensor|
|Sensor Size||23.5 x 15.6 mm|
|Sensor Area||367 mm2|
|Sensor Diagonal||28.2 mm|
|Sensor Resolution||24 Megapixels|
|Image Resolution||6 000 x 4 000 pixels|
|Pixel Pitch||3.91 μm|
|Pixel Density||6.55 MP/cm2|
|Moiré control||Anti-Alias filter|
|Movie Capability||4K/30p Video|
|ISO Setting||100 - 32 000 ISO|
|ISO Boost||100 - 102 400 ISO|
|Image Processor||BIONZ X|
|DXO Sensor Quality (score)||83|
|DXO Color Depth (bits)||24|
|DXO Dynamic Range (EV)||13.6|
|DXO Low Light (ISO)||1431|
|Viewfinder Type||Electronic viewfinder|
|Viewfinder Field of View||100%|
|Viewfinder Resolution||2359k dots|
|Top-Level Screen||no Top Display|
|LCD Framing||Live View|
|LCD Size||3.0 inch|
|LCD Resolution||922k dots|
|LCD Attachment||Tilting screen|
|V-logging Friendliness||Front-flip possible|
|Focus System||On-Sensor Phase-detect|
|Manual Focusing Aid||Focus Peaking|
|Maximum Shutter Speed||1/4000s|
|Continuous Shooting||11 shutter flaps/s|
|Shutter Life Expectancy||200 000 actuations|
|Silent Shooting||Electronic Shutter|
|Time Lapse Photography||no Intervalometer|
|Fill Flash||Built-in Flash|
|Storage Medium||MS or SDXC cards|
|Single or Dual Card Slots||Single card slot|
|UHS card support||UHS-I|
|USB Connector||USB 2.0|
|HDMI Port||micro HDMI|
|Microphone Port||External MIC port|
|Wifi Support||Wifi built-in|
|Near-Field Communication||NFC built-in|
|Bluetooth Support||Bluetooth built-in|
|Environmental Sealing||Weathersealed body|
|Battery Type||NP-FW50 power pack|
|Battery Life (CIPA)||410 shots per charge|
|In-Camera Charging||USB charging|
120 x 67 x 50 mm
(4.7 x 2.6 x 2.0 in)
|Camera Weight||403 g (14.2 oz)|
