Did you lose or misplace the instruction manual that came with your Panasonic Lumix DC-GH5 II? It happens all too easily, but fortunately Panasonic makes a soft copy available that you can browse through online, print out, or download (see the pdf file below). It is certainly good practice to carefully familiarize oneself with the many different functionalities and options that the GH5 II offers, and the official user manual is without doubt an authoritative and comprehensive source of respective information.

That said, the instruction booklet can be a dry read, so that a dedicated camera guide book from a professional photographer that illustrates the camera's core functions in a real life photography context can be a very helpful complement. Yes, getting one of these camera guides (see here at amazon) would involve an additional expense, but if that book helps to exploit the camera's potential to the full, the (small) additional investment may well be worth it.

Also, you might want to check out the video tutorial on the Panasonic Lumix DC-GH5 II below.

camera

In any case, the GH5 II is an advanced imaging tool, whose many features merit serious attention. This mirrorless interchangeable lens camera was revealed to the public on May 25th, 2021, which means that, as of today, the camera is 1039 days old (young?). Given that the GH5 II is a relatively recent model, it forms part of the current Panasonic product line-up.

ad

Panasonic's owner manual for the GH5 II

The camera's owner manual is 811 pages long. The pdf version is embedded below. As you browse through, you will hopefully find the information you are looking for. You can also print out a hard copy by right clicking on the manual and then choosing the respective menu option. For convenience, a summary of the key specs of the GH5 II is included towards the bottom of this webpage.

Don't forget to bookmark this page for future reference (Ctrl-Shift-D on a Windows PC; Cmd-Shift-D on a Mac). Happy browsing!

Click on the button below to download the pdf version of the Panasonic Lumix DC-GH5 II manual to your computer. The file will open in a new browser window.

Download the Manual

If you prefer to read the user guide in another language, please check the respective availability on Panasonic's support site. That site also provides complementary online resources, such as information on the compatibility of various camera accessories or the availability of firmware updates that are not necessarily comprehensively covered in the instruction manual.

Printed, hardcopy versions of the Panasonic GH5 II manual can sometimes be found online. You can check the availability on amazon and ebay via the buttons below.

amazon.com ebay.com

ad

Video tutorial for the Panasonic Lumix DC-GH5 II

Perhaps instead of reading through a manual or operations guide, you might prefer to better familiarize yourself with your GH5 II by watching a video tutorial. It can notably help to quickly get to know the key functions and to set up your camera according to your particular preferences and needs.

Once again, the Panasonic GH5 II is a sophisticated imaging tool and not exploiting its capabilities to the full would be a pity. Hence, taking the time to study online information material or to read through a well-written camera guide book is highly recommended to make the most of your purchase.

Find GH5 II guide book at
amazon.com

Panasonic GH5 II FAQ

Below are some additional questions and answers concerning some particular features of the GH5 II.

What type of imaging sensor is used in the Panasonic GH5 II?

The camera is build around a CMOS (Complementary Metal–Oxide–Semiconductor) sensor.

Which image processing chip is used in the Panasonic GH5 II to convert the raw signal into an image file and perform noise reduction and image sharpening?

Panasonic equipped the GH5 II with the Venus 10 image processor.

What is the ISO sensitivity range of the Panasonic GH5 II?

The camera has a native sensitivity range from ISO 200 to ISO 25600, which can be extended to ISO 100-25600.

Does the Panasonic GH5 II have a selfie-friendly screen?

Yes, the LCD-screen of the GH5 II is flexible and can be turned to be front-facing for capturing selfies.

What is the life expectancy of the shutter in the Panasonic Lumix DC-GH5 II?

Panasonic mentions a shutter rating of 200 000 actuations for the GH5 II. This number represents a Mean Time before Failure, that is an average value. The shutter might fail earlier, or it might last longer. Anyway, in order to exhaust the expected shutter life of the GH5 II over, say, three years, one would have to take about 200 pictures each and every day.

How do I find the shutter count on my Panasonic GH5 II?

Panasonic embeds the number of shutter actuations in hidden menus. You can check the number of shots that your GH5 II has taken up to now by carefully following the steps described on the Panasonic GH5 II shutter count page.

Is completely silent shooting possible with the Panasonic GH5 II?

The camera has an electronic shutter option, so that it is indeed feasible to capture images without any shutter noise.

Do I need to purchase an external camera trigger to shoot time-lapse sequences with the Panasonic GH5 II?

No, the Panasonic Lumix DC-GH5 II has an intervalometer built-in, so that low frequency shooting (for example, flower blooming, sunset, moon rise) can be undertaken without the need to purchase a separate external intervalometer and related software.

Is it difficult to use manual focus lenses with the Panasonic GH5 II?

The GH5 II offers focus peaking as a manual focus aid. This feature works by placing a colored highlight on in-focus zones within the image.

Does the Panasonic GH5 II feature an autofocus assist light?

Yes, the camera has a lamp built-in that can illuminate the subject and improve autofocus in low-light settings.

What is the fastest shutter speed that can be used with the Panasonic GH5 II for flash photography?

The GH5 II's flash sync speed is 1/250 sec.

Does the Panasonic GH5 II support the Ultra High Speed (UHS) bus interface for SD cards?

Yes, the camera can indeed use UHS-II cards, which provide for data transfer speed of up to 312 MB/s, in both of its card slots.

Which battery does the Panasonic GH5 II use?

The camera gets its power from the Panasonic DMW-BLK22 (here at amazon), which is a rechargeable Lithium-Ion power pack.

Is there a vertical grip available for the Panasonic GH5 II?

Yes, Panasonic offers the DMW-BGGH5 as an optional accessory to facilitate shooting in portrait orientation and to provide additional battery power.

Where can I find the best deals for the Panasonic GH5 II?

Grey imports from Asia, as found on ebay, are often very attractively priced. However, these cameras come without a warranty from Panasonic.

ad

Further reading

How does the GH5 II stack up against available alternatives? In case you are interested in seeing how this camera compares to another one, just use the search menu below. There is also a set of direct links to comparison reviews that other users of the CAM-parator app explored.

~
    loader
    ad

    Core camera specifications

    Here is a list of the main features and technical characteristics of the Panasonic Lumix DC-GH5 II.

    Specifications Summary
    Camera Model Panasonic GH5 II
    Camera Type Mirrorless system camera
    Camera Lens Micro Four Thirds lenses
    Launch Date May 2021
    Launch Price USD 1 699
    Sensor Specs
    Sensor Technology CMOS
    Sensor Format Four Thirds Sensor
    Sensor Size 17.3 x 13.0 mm
    Sensor Area 225 mm2
    Sensor Diagonal 21.6 mm
    Crop Factor 2.0x
    Sensor Resolution 20.2 Megapixels
    Image Resolution 5 184 x 3 888 pixels
    Pixel Pitch 3.34 μm
    Pixel Density 8.96 MP/cm2
    Moiré control no AA filter
    Movie Capability 4K/60p Video
    ISO Setting 200 - 25 600 ISO
    ISO Boost 100 - 25 600 ISO
    Image Processor Venus 10
    DXO Sensor Quality (score) 79
    DXO Color Depth (bits) 23.7
    DXO Dynamic Range (EV) 13.1
    DXO Low Light (ISO) 1136
    Screen Specs
    Viewfinder Type Electronic viewfinder
    Viewfinder Field of View 100%
    Viewfinder Magnification 0.76x
    Viewfinder Resolution 3680k dots
    Top-Level Screen no Top Display
    LCD Framing Live View
    LCD Size 3.0 inch
    LCD Resolution 1840k dots
    LCD Attachment Swivel screen
    V-logging Friendliness Front-flip possible
    Touch Input Touchscreen
    Shooting Specs
    Focus System Contrast-detect AF
    Manual Focusing AidFocus Peaking
    Maximum Shutter Speed 1/8000s
    Continuous Shooting 12 shutter flaps/s
    Shutter Life Expectancy200 000 actuations
    Silent ShootingElectronic Shutter
    Time Lapse PhotographyIntervalometer Built-in
    Image StabilizationIn-body stabilization
    Fill Flash no On-Board Flash
    Storage Medium SDXC cards
    Single or Dual Card Slots Dual card slots
    UHS card support Dual UHS-II
    Connectivity Specs
    External Flash Hotshoe
    Studio Flash PC Sync socket
    USB Connector USB 3.2
    HDMI Port full HDMI
    Microphone Port External MIC port
    Headphone Socket Headphone port
    Wifi Support Wifi built-in
    Bluetooth Support Bluetooth built-in
    Body Specs
    Environmental SealingWeathersealed body
    Battery Type Panasonic DMW-BLK22 power pack
    Battery Life (CIPA)400 shots per charge
    Body Dimensions 139 x 98 x 87 mm
    (5.5 x 3.9 x 3.4 in)
    Camera Weight 727 g (25.6 oz)

    Did you notice an error on this page? If so, please get in touch, so that we can correct the information.
